Siemens SINAMICS PERFECT HARMONY GH180 User manual

www.siemens.com/drives
tT}GkGGzpuhtpjzGwlymlj{GohytvuGnoX_W
mG{aG]zy\aGhTjGk
h\lZ`Z`WXXY
hrlWZVYWYXOperating Instructions

Type 6SR5 Air-Cooled
Operating Instructions
AK
A5E39390112
Introduction 1
Security information 2
Safety notes 3
Description 4
Preparing for Use 5
Assembly 6
Electrical Connections 7
Commissioning 8
Operation 9
Maintenance 10
Spare Parts 11
Disposal and Recycling 12
Service and Support A
Technical Data B
Quality C
List of symbols and
abbreviations D

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage
to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices shown below are graded according to
the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Global Services Information Technology
80200 MÜNCHEN
GERMANY
A5E39390112
Ⓟ 06/2021 Subject to change
Copyright © Siemens AG 2017 - 2021.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 9
1.1 Introduction......................................................................................................................... 9
2 Security information............................................................................................................................ 11
3 Safety notes ......................................................................................................................................... 13
3.1 General Safety Information ................................................................................................ 13
3.2 Observing the Five Safety Rules.......................................................................................... 14
3.3 Safety Information and Warnings ....................................................................................... 15
3.4 ESD-sensitive Components................................................................................................. 17
4 Description........................................................................................................................................... 19
4.1 Cabinet Details................................................................................................................... 19
4.1.1 Supply Scope .................................................................................................................... 19
4.1.2 Input / Output Section........................................................................................................ 19
4.1.3 Transformer Section........................................................................................................... 19
4.1.4 Cell Section........................................................................................................................ 20
4.1.5 Control Section.................................................................................................................. 21
4.1.5.1 Control Door Cabinet Components ..................................................................................... 24
4.1.6 Cooling System Section...................................................................................................... 27
4.1.6.1 Application of Voltage........................................................................................................ 27
4.1.6.2 Blowers and Speed Settings ............................................................................................... 27
4.1.6.3 Air-to-Air Heat Exchanged (W41) Drive Preparation............................................................. 28
5 Preparing for Use ................................................................................................................................. 31
5.1 Transportation, Handling, and Storage ............................................................................... 31
6 Assembly.............................................................................................................................................. 33
6.1 General Mounting ............................................................................................................. 33
6.2 Proper Cabinet Anchoring Methods .................................................................................... 34
6.3 Combining Several Shipping Splits...................................................................................... 35
7 Electrical Connections ......................................................................................................................... 37
7.1 General Electrical .............................................................................................................. 37
7.2 Installation External Wiring ............................................................................................... 38
7.3 Grounding the Drive .......................................................................................................... 41
7.4 EMC Installation Guidelines................................................................................................ 42
7.5 Cable Gland Plates Removal and Installation Guidelines ...................................................... 46
7.6 Terminal Blocks.................................................................................................................. 47
7.7 E-Stops .............................................................................................................................. 48
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 3

7.8 Associated Protection provided by the Customer................................................................. 49
8 Commissioning .................................................................................................................................... 51
8.1 Residual Current Device (RCD) Compatibility....................................................................... 51
8.2 Cell Reforming................................................................................................................... 52
8.3 Pre-Commissioning Process................................................................................................ 53
9 Operation............................................................................................................................................. 55
9.1 Operating the Drive ........................................................................................................... 55
9.2 Resetting the Protection Scheme ........................................................................................ 56
10 Maintenance........................................................................................................................................ 57
10.1 Introduction....................................................................................................................... 57
10.2 Drive (BDM) Maintenance and Protective Earthing (PE) Procedure....................................... 58
10.3 VFD Power Down and Door Access ..................................................................................... 59
10.3.1 Mechanical Interlock System (if provided)........................................................................... 59
10.3.2 Unlocking the Doors .......................................................................................................... 59
10.3.3 Closing the make-proof grounding switch .......................................................................... 65
10.4 Preventive Maintenance..................................................................................................... 67
10.4.1 Introduction....................................................................................................................... 67
10.4.2 Inspection.......................................................................................................................... 67
10.4.3 Preventive Maintenance Checklist ...................................................................................... 68
10.5 Touch-Up Paint .................................................................................................................. 69
10.6 Cleaning............................................................................................................................ 70
10.6.1 Contact for Cleaning Measures........................................................................................... 70
10.6.2 Removing Dust Deposits .................................................................................................... 70
10.7 Remove and Replace.......................................................................................................... 71
10.7.1 Maintenance and Earthing Procedure................................................................................. 71
10.7.2 Part Replacement .............................................................................................................. 72
10.7.3 Replacing the Filter Media.................................................................................................. 72
10.7.4 Air-to-Air Heat Exchanger Cleaning..................................................................................... 79
10.7.5 Replacing the Control Fuse (6SR5 40-260A, 9-cell).............................................................. 80
10.7.6 Replacing the Door-Mounted Keypad.................................................................................. 80
10.7.7 Removing the Power Cell Procedure ................................................................................... 81
10.7.8 Replacing the Compact Flash Card...................................................................................... 85
10.7.9 Installing Perfect Harmony Power Cells............................................................................... 86
10.7.10 Fuse Location .................................................................................................................... 95
10.7.11 Replacing Cell Input Power Fuses........................................................................................ 96
10.7.12 Printed Circuit Board Replacement Procedure (NXGpro or NXGpro+) ................................... 97
11 Spare Parts........................................................................................................................................... 99
11.1 Replaceable Spare Parts ..................................................................................................... 99
12 Disposal and Recycling ...................................................................................................................... 101
12.1 Disposing of Device Components ..................................................................................... 101
Table of contents
Type 6SR5 Air-Cooled
4Operating Instructions, AK, A5E39390112

A Service and Support .......................................................................................................................... 103
A.1 Field Service Operation .................................................................................................... 103
B Technical Data.................................................................................................................................... 105
B.1 Storage, Transport and Operation Ambient Conditions...................................................... 105
B.2 Power Cell Speci󹪝cations Table ........................................................................................ 107
B.3 9-Cell System Speci󹪝cations ............................................................................................. 108
B.4 12-Cell System Speci󹪝cations ........................................................................................... 110
B.5 15-Cell System Speci󹪝cations ........................................................................................... 111
B.6 18-Cell System Speci󹪝cations ........................................................................................... 112
B.7 24-Cell System Speci󹪝cations ........................................................................................... 113
B.8 Synchronous Transfer....................................................................................................... 114
B.9 Output Filter.................................................................................................................... 115
B.10 Drive Input Energization................................................................................................... 116
C Quality ............................................................................................................................................... 117
C.1 CE Marking and Directives................................................................................................ 117
C.2 CE Marking ...................................................................................................................... 118
C.3 CE Marking on Power Drive Systems (PDS)........................................................................ 119
C.4 EMC Factory Certi󹪝cate .................................................................................................... 120
D List of symbols and abbreviations ..................................................................................................... 121
D.1 Symbols and Abbreviations .............................................................................................. 121
Glossary ............................................................................................................................................. 127
Index .................................................................................................................................................. 139
Tables
Table 7-1 Drive Torque Speci󹪝cations (Zinc-Plated Hardware and Electrical Connections Only)................. 39
Table 7-2 Drive Torque Speci󹪝cations (Stainless Steel Hardware, Mechanical Connections) ...................... 40
Table B-1 General Ambient Conditions ................................................................................................. 105
Table B-2 Power Cell ........................................................................................................................... 107
Table B-3 Power Cell ........................................................................................................................... 107
Table B-4 9-Cell System Parameters...................................................................................................... 108
Table B-5 12-Cell System Parameters.................................................................................................... 110
Table B-6 15-Cell System Parameters.................................................................................................... 111
Table B-7 21/24-Cell System Speci󹪝cations ........................................................................................... 112
Table B-8 24-Cell System Speci󹪝cations ................................................................................................ 113
Table D-1 Commonly Used Abbreviations.............................................................................................. 121
Table of contents
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 5

Figures
Figure 3-1 ESD Protective Measures ......................................................................................................... 18
Figure 4-1 Input Protection Interface for Trip Contacts.............................................................................. 22
Figure 4-2 K41 Input Protection Interface for Trip Contacts....................................................................... 22
Figure 4-3 Standard Contacts K3 / CIMV (Close Input MV) and K4 / TIMV (Trip Input MV) .......................... 24
Figure 4-4 SIMATICS Touchpad ................................................................................................................ 25
Figure 6-1 Proper Anchoring in Concrete Technique ................................................................................. 34
Figure 6-2 Combining Several Shipping Splits (Transport Units)................................................................ 36
Figure 7-1 SINAMICS Perfect Harmony GH180™ Drive System .................................................................. 42
Figure 7-2 Earthing (Grounding) cable screens (shields) when multiple sections are used......................... 44
Figure 7-3 Recommended Cable Segregation........................................................................................... 45
Figure 10-1 DC Bus Voltage Indicator......................................................................................................... 60
Figure 10-2 DC Bus Voltage Indicator (340-430A) ...................................................................................... 61
Figure 10-3 DC Bus Voltage Indicator (550-780A) ...................................................................................... 61
Figure 10-4 VFD Cabinet (front view)......................................................................................................... 62
Figure 10-5 VFD Cabinet - (Front View) from left to right: (100-140A, 600-1000Hp) and (200-260A,
1100-2000Hp)........................................................................................................................ 63
Figure 10-6 VFD Cabinet - (Front View): (340-430A, 1250-3500Hp) ........................................................... 64
Figure 10-7 Make-proof grounding switch ................................................................................................. 66
Figure 10-8 Type 6SR5 40A, 70A ONLY (Blower Cage Louver Installation) ................................................... 73
Figure 10-9 Installed Filter ........................................................................................................................ 74
Figure 10-10 Screwdriver Insertion Points.................................................................................................... 75
Figure 10-11 Filter Cover Removal ............................................................................................................... 76
Figure 10-12 Filter with Cover Removed ...................................................................................................... 77
Figure 10-13 Filter Media Removal .............................................................................................................. 78
Figure 10-14 HEX Cleaning Using Water....................................................................................................... 79
Figure 10-15 Fiber Optic to Remove............................................................................................................. 82
Figure 10-16 Fiber Optic Removed............................................................................................................... 83
Figure 10-17 NXGpro Digital Control Rack - Compact Flash .......................................................................... 85
Figure 10-18 40 A - 140 A - proper alignment of power cell mounting with receiving holes .......................... 87
Figure 10-19 200 A - 260 A, 4Q 120 A-160 A - proper alignment of power cell mounting with receiving
holes ...................................................................................................................................... 87
Figure 10-20 340 - 430 A, 4Q 325 A - proper alignment of power cell mounting with receiving holes ........... 88
Figure 10-21 Fiber Optic Location................................................................................................................ 89
Figure 10-22 Fiber Optic Location................................................................................................................ 90
Figure 10-23 40-140 Fiber Optic and DC Bus Indicator ................................................................................. 92
Figure 10-24 Torque Connections for 40 A, 70 A, 100 A, 140 A Power Cells.................................................. 92
Figure 10-25 200 - 260 A, 4Q 120 A-160 A Fiber Optic and DC Bus Indicator ................................................ 93
Table of contents
Type 6SR5 Air-Cooled
6Operating Instructions, AK, A5E39390112

Figure 10-26 Torque Connections for 200-260A, 4Q 120 A-160 A Power Cells .............................................. 93
Figure 10-27 Torque Connections for 340-430A, 4Q 325 A Power Cells ........................................................ 93
Figure 10-28 Torque Connections for 340-430A 4Q Power Cells ................................................................... 94
Figure 10-29 Fuse Location (40 - 260 A) ...................................................................................................... 95
Figure 10-30 Fuse Location (340 - 430 A), 4Q 325 A.................................................................................... 95
Figure C-1 CE Marking ........................................................................................................................... 118
Table of contents
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 7

Table of contents
Type 6SR5 Air-Cooled
8Operating Instructions, AK, A5E39390112

Introduction 1
1.1 Introduction
About This Manual
This manual provides customer documentation for the SINAMICS Perfect Harmony™ GH180
Variable Frequency Drive (VFD).
The content of this manual provides standard information as well as descriptions of all available
options for this product line. The contents also provides safety warning and notes, preparation
for use, assembly/installation, electrical, commissioning, operation, maintenance, spare parts,
and disposal information. The latter pages of this manual contain appendices for speci󹪝c
technical documents, support services information, technical drawings, and other relevant data.
This manual is intended for use by trained personnel having unique job functions and
quali󹪝cations since there are areas on the VFD that are hazardous and therefore may cause death
or serious bodily harm to personnel and also cause serious damage to the drive.
The manual is also intended for use by planners, project engineers, installation personnel,
programmers, commissioning personnel, operators, service and maintenance personnel.
This documentation contains the most important safety-related information for the SINAMICS
Perfect Harmony™ GH180 VFD. It is important supplementary information, but is not a
replacement for the operating instructions nor the other product documentation on your CD.
WARNING
Familiarity with the Product Documentation
Only the complete product documentation will allow you to assemble and install the
equipment, to put it into operation and to maintain it correctly and safely.
Incorrect work on the equipment can result in death, severe injury or material damage.
Always refer to the operating instructions when working on the equipment. You will 󹪝nd the
operating instructions and other equipment information about your product that you will need
on the CD supplied with the Drive.
Variable Frequency Drive Introduction
A variable frequency drive (VFD) system controls the rotational speed and torque of an
alternating current (AC) electric motor by adjusting the frequency and voltage of the electrical
power supplied to the motor. In an AC motor, frequency determines the motor speed.
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 9

Introduction
1.1 Introduction
Type 6SR5 Air-Cooled
10 Operating Instructions, AK, A5E39390112

Security information 2
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is necessary
to implement – and continuously maintain – a holistic, state-of-the-art industrial security
concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected to
an enterprise network or the internet if and to the extent such a connection is necessary and only
when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available
and that the latest product versions are used. Use of product versions that are no longer
supported, and failure to apply the latest updates may increase customer’s exposure to cyber
threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed
under
https://www.siemens.com/industrialsecurity.
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 11

Security information
Type 6SR5 Air-Cooled
12 Operating Instructions, AK, A5E39390112

Safety notes 3
3.1 General Safety Information
Proper Use
SINAMICS Perfect Harmony™ GH180 medium voltage drives must always be installed in closed
electrical operating areas. The drive is connected to the industrial network via a circuit-breaker
or contactor that is electrically connected to the VFD control to enable the drive protection
features.
The speci󹪝c transport conditions must be observed when the equipment is transported. The
equipment shall be assembled/installed and the separate cabinet units connected properly by
cable and/or busbar in accordance with the assembly/installation instructions. The relevant
instructions regarding correct storage, EMC-compliant installation, cabling, shielding and
grounding and an adequate auxiliary power supply must be strictly observed. Fault-free
operation is also dependent on careful operation and maintenance.
The power sections are designed for variable-speed drives use with synchronous and
asynchronous motors. Operating modes, overload conditions, load cycles, and ambient
conditions di󹪜erent to those described in this document are allowed only by special
arrangement with the manufacturer.
Commissioning should only be carried out by trained service personnel in accordance with the
commissioning instructions.
System components such as circuit-breaker, transformer, cables, cooling unit, motor, speed
sensors, etc., must be matched to VFD operation. System con󹪝guration may only be carried out
by an experienced system integrator.
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 13

3.2 Observing the Five Safety Rules
There are 󹪝ve safety rules that must always be observed to assure not only personal safety, but
to prevent material damage as well. Always obey safety-related labels located on the product
itself and always read and understand each safety precaution prior to operating or working on
the drive.
The 󹪝ve safety rules:
1. Disconnect the power applied to the system.
2. Protect against reapplication of power.
3. Make sure that the equipment is de-energized.
4. Apply grounding (earthing) means.
5. Cover or enclose adjacent components to secure all forms of hazardous energy.
DANGER
Danger Due to High Voltages
High voltages cause death or serious injury if the safety instructions are not observed or if the
equipment is handled incorrectly.
Potentially fatal voltages occur when this equipment is in operation which can remain present
even after the VFD is switched o󹪜.
Ensure that only quali󹪝ed and trained personnel carry out work on the equipment.
Follow the 󹪝ve safety rules during each stage of the work.
Safety notes
3.2 Observing the Five Safety Rules
Type 6SR5 Air-Cooled
14 Operating Instructions, AK, A5E39390112

3.3 Safety Information and Warnings
DANGER
Hazardous Voltage!
•Always follow the proper lock-out/tag-out procedures before beginning any maintenance
or troubleshooting work on the VFD.
•Always follow standard safety precautions and local codes during installation of external
wiring. The installation must follow wiring practices and insulation systems as speci󹪝ed in
IEC 61800-5-1.
•Hazardous voltages may still exist within the VFD cabinets even when the disconnect
switch is open (o󹪜) and the supply power is shut o󹪜.
•Only quali󹪝ed individuals should install, operate, troubleshoot, and maintain this VFD. A
quali󹪝ed individual is "a person, who is familiar with the construction and operation of the
equipment and the hazards involved."
•Always work with one hand, wear electrical safety gloves, wear insulated electrical hazard
rated safety shoes, and safety goggles. Also, always work with another person present.
•Always use extreme caution when handling or measuring components that are inside the
enclosure. Be careful to prevent meter leads from shorting together or from touching other
terminals.
•Use only instrumentation (e.g., meters, oscilloscopes, etc.) intended for high voltage
measurements (that is, isolation is provided inside the instrument, not provided by isolating
the chassis ground of the instrument).
•Never assume that switching o󹪜 the input disconnector will remove all voltage from
internal components. Voltage is still present on the terminals of the input disconnector.
Also, there may be voltages present that are applied from other external sources.
•Never touch anything within the VFD cabinets until verifying that it is neither thermally hot
nor electrically alive.
•Never remove safety shields (marked with a HIGH VOLTAGE sign) or attempt to measure
points beneath the shields.
•Never operate the VFD with cabinet doors open. The only exception is the control cabinet.
•Never connect any grounded (i.e., non-isolated) meters or oscilloscopes to the system.
•Never connect or disconnect any meters, wiring, or printed circuit boards while the VFD is
energized.
•Never defeat the instrument’s grounding.
• When a system is con󹪝gured with VFD bypass switchgear (e.g. contactors between line and
motor, and VFD and motor), these switches should be interlocked so that the line voltage
is never applied to the VFD output if the medium voltage input is removed from the VFD.
• When a system is con󹪝gured with VFD pre-charge, medium voltage is present on the
primary side of the input transformer and upstream device even though the MV contactor
is not closed.
Safety notes
3.3 Safety Information and Warnings
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 15

WARNING
Potential Arc Hazard
• Arcing can result in damage to property, serious injury and even death.
• The equipment has not been tested and rated for arc 󹪞ash protection.
• Avoiding arc hazard risks is dependent upon proper installation and maintenance.
• Incorrectly applied equipment, incorrectly selected, connected or unconnected cables, or
the presence of foreign materials can cause arcing in the equipment.
• Follow all applicable precautionary rules and guidelines as used in working with medium
voltage equipment.
• The equipment may be used only:
– for the applications de󹪝ned as suitable in the technical description.
– in combination with equipment and components supplied by other manufacturers
which have been approved and recommended by Siemens.
• Always follow the facility / installation site rules / guidelines for Personal Protectiive
Equipment (PPE) based on the Arc Flash study of that facility.
Additional safety precautions and warnings appear throughout this manual. These important
messages should be followed to reduce the risk of personal injury or equipment damage.
WARNING
Obey Rules to Avoid Risk of Death
•Always comply with local codes and requirements if disposal of failed components is
necessary.
•Always ensure the use of an even and 󹪞at truck bed to transport the VFD system. Before
unloading, be sure that the concrete pad is level for storage and permanent positioning.
•Always con󹪝rm proper tonnage ratings of cranes, cables, and hooks when lifting the VFD
system. Dropping the cabinet or lowering it too quickly could damage the unit.
•Never disconnect control power while medium voltage is energized. This could cause
severe system overheating and/or damage.
•Never store 󹪞ammable material in, on, or near the drive enclosure. This includes equipment
drawings and manuals.
•Never use fork trucks to lift cabinets that are not equipped with lifting tubes. Be sure that
the fork truck tines 󹪝t the lifting tubes properly and are the appropriate length.
Safety notes
3.3 Safety Information and Warnings
Type 6SR5 Air-Cooled
16 Operating Instructions, AK, A5E39390112

3.4 ESD-sensitive Components
Guidelines for Handling Electrostatic Sensitive Devices (ESD)
NOTICE
ESD Sensitive Equipment
• Always be aware of electrostatic discharge (ESD) when working near or touching
components inside the VFD cabinet. The printed circuit boards contain components that are
sensitive to electrostatic discharge. Handling and servicing of components that are
sensitive to ESD should be done only by quali󹪝ed personnel and only after reading and
understanding proper ESD techniques. The following ESD guidelines should be observed.
Following these rules can greatly reduce the possibility of ESD damage to printed circuit
board (PCB) components.
• Always transport static sensitive equipment in antistatic bags.
• Always use a soldering iron that has a grounded tip. Also, use either a metallic vacuum-style
plunger or copper braid when desoldering.
• Ensure that anyone handling the printed circuit boards is wearing a properly grounded static
strap. The wrist strap should be connected to ground through a 1 Megohm resistor.
Grounding kits are available commercially through most electronic wholesalers.
• Static charge build-up can be removed from a conductive object by touching the object with
a properly grounded piece of metal.
• When handling a PC board, always hold the card by its edges.
• Do not slide printed circuit boards (PCBs) across any surface (e.g., a table or work bench).
If possible, perform PCB maintenance at a workstation that has a conductive covering that
is grounded through a 1 Megohm resistor. If a conductive tabletop cover is unavailable, a
clean steel or aluminum tabletop is an excellent substitute.
• Avoid plastic Styrofoam™, vinyl and other non-conductive materials. They are excellent
static generators and do not give up their charge easily.
• When returning components to Siemens Industry, Inc. always use static-safe packing. This
limits any further component damage due to ESD.
Components that can be destroyed by electrostatic discharge (ESD)
NOTICE
Electrostatic discharge
Electronic components can be destroyed in the event of improper handling, transporting,
storage, and shipping.
Pack the electronic components in appropriate ESD packaging; e.g. ESD foam, ESD packaging
bags and ESD transport containers.
To protect your equipment against damage, follow the instructions given below.
Safety notes
3.4 ESD-sensitive Components
Type 6SR5 Air-Cooled
Operating Instructions, AK, A5E39390112 17

• Avoid physical contact with electronic components. If you need to perform absolutely
essential work on these components, then you must wear one of the following protective
gear:
– Grounded ESD wrist strap
– ESD shoes or ESD shoe grounding strips if there is also an ESD 󹪞oor.
• Do not place electronic components close to data terminals, monitors or televisions.
Maintain a minimum clearance to the screen (> 10 cm).
• Electronic components should not be brought into contact with electrically insulating
materials such as plastic foil, plastic parts, insulating table supports or clothing made of
synthetic 󹪝bers.
• Place components in contact with ESD-suited materials e.g. ESD tables, ESD surfaces, ESD
packaging.
• Measure on the components only if one of the following conditions is met:
– The measuring device is grounded with a protective conductor.
– The measuring head of a 󹪞oating measuring device has been discharged directly before
the measurement.
The necessary ESD protective measures for the entire working range for electrostatically
sensitive devices are illustrated once again in the following drawings. Precise instructions for
ESD protective measures are speci󹪝ed in the standard IEC 61340-5-1.
6HDWLQJSRVLWLRQ6WDQGLQJSRVLWLRQ6WDQGLQJVHDWLQJSRVLWLRQEEDFDIIIIIDFFHGGHG
1 Sitting
2 Standing
3 Standing/sitting
a Conductive 󹪞oor surface, only e󹪜ective in conjunction with ESD shoes or ESD shoe grounding
strips
b ESD furniture
c ESD shoes or ESD shoe grounding strips are only e󹪜ective in conjunction with conductive 󹪞ooring
d ESD clothing
e ESD wristband
f Cabinet ground connection
Figure 3-1 ESD Protective Measures
Safety notes
3.4 ESD-sensitive Components
Type 6SR5 Air-Cooled
18 Operating Instructions, AK, A5E39390112
