Siemens RUGGEDCOM RP110 User manual

RUGGEDCOM RP110
Installation Guide
6/2014
Preface
Introduction 1
Installing the Device 2
Communication Ports 3
Technical Specifications 4
Dimension Drawings 5
Certification 6
RC1012-EN-02

RUGGEDCOM RP110
Installation Guide
ii
Copyright © 2014 Siemens Canada Ltd.
All rights reserved. Dissemination or reproduction of this document, or evaluation and communication of its contents, is not authorized
except where expressly permitted. Violations are liable for damages. All rights reserved, particularly for the purposes of patent application or
trademark registration.
This document contains proprietary information, which is protected by copyright. All rights are reserved. No part of this document may be
photocopied, reproduced or translated to another language without the prior written consent of Siemens Canada Ltd..
Disclaimer Of Liability
Siemens has verified the contents of this manual against the hardware and/or software described. However, deviations between the product
and the documentation may exist.
Siemens shall not be liable for any errors or omissions contained herein or for consequential damages in connection with the furnishing,
performance, or use of this material.
The information given in this document is reviewed regularly and any necessary corrections will be included in subsequent editions. We
appreciate any suggested improvements. We reserve the right to make technical improvements without notice.
Registered Trademarks
ROX™, Rugged Operating System On Linux™, CrossBow™ and eLAN™ are trademarks of Siemens Canada Ltd.. ROS® is a registered
trademark of Siemens Canada Ltd..
Other designations in this manual might be trademarks whose use by third parties for their own purposes would infringe the rights of the
owner.
Third Party Copyrights
Siemens recognizes the following third party copyrights:
• Copyright © 2004 GoAhead Software, Inc. All Rights Reserved.
Security Information
Siemens provides products and solutions with industrial security functions that support the secure operation of plants, machines, equipment
and/or networks. They are important components in a holistic industrial security concept. With this in mind, Siemens’ products and solutions
undergo continuous development. Siemens recommends strongly that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable preventive action (e.g. cell protection concept)
and integrate each component into a holistic, state-of-the-art industrial security concept. Third-party products that may be in use should also
be considered. For more information about industrial security, visit http://www.siemens.com/industrialsecurity.
To stay informed about product updates as they occur, sign up for a product-specific newsletter. For more information, visit http://
support.automation.siemens.com.
Warranty
Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance
during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all
warranties null and void. The warranties set forth in this article are exclusive and are in lieu of all other warranties, performance guarantees
and conditions whether written or oral, statutory, express or implied (including all warranties and conditions of merchantability and fitness for
a particular purpose, and all warranties and conditions arising from course of dealing or usage or trade). Correction of nonconformities in the
manner and for the period of time provided above shall constitute the Seller’s sole liability and the Customer’s exclusive remedy for defective
or nonconforming goods or services whether claims of the Customer are based in contract (including fundamental breach), in tort (including
negligence and strict liability) or otherwise.
For warranty details, visit www.siemens.com/ruggedcom or contact a Siemens customer service representative.
Contacting Siemens
Address
Siemens Canada Ltd.
Industry Sector
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone
Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-mail
[email protected]
Web
www.siemens.com/ruggedcom

RUGGEDCOM RP110
Installation Guide Table of Contents
iii
Table of Contents
Preface ................................................................................................................ v
Alerts .................................................................................................................................................. v
Related Documents ............................................................................................................................. v
Accessing Documentation .................................................................................................................... v
Training .............................................................................................................................................. vi
Customer Support .............................................................................................................................. vi
Chapter 1
Introduction .......................................................................................................... 1
1.1 Feature Highlights ........................................................................................................................ 1
1.2 Ports, Controls and Indicator LEDs ............................................................................................... 2
Chapter 2
Installing the Device ............................................................................................ 5
2.1 Mounting the Device .................................................................................................................... 5
2.2 Connecting Power ........................................................................................................................ 6
2.2.1 Connecting High AC/DC Power .......................................................................................... 7
2.2.2 Connecting Low DC Power ................................................................................................ 7
2.3 Grounding the Device .................................................................................................................. 8
Chapter 3
Communication Ports .......................................................................................... 9
3.1 Serial Terminal ............................................................................................................................. 9
3.1.1 RS232 Data Ports ........................................................................................................... 10
3.1.2 RS485/422 Data Ports ..................................................................................................... 11
3.2 Copper Ethernet Port ................................................................................................................. 12
Chapter 4
Technical Specifications ..................................................................................... 15
4.1 Power Supply Specifications ....................................................................................................... 15
4.2 Operating Environment ............................................................................................................... 15
4.3 Mechanical Specifications ........................................................................................................... 15

Table of Contents
RUGGEDCOM RP110
Installation Guide
iv
Chapter 5
Dimension Drawings .......................................................................................... 17
Chapter 6
Certification ........................................................................................................ 19
6.1 Agency Approvals ...................................................................................................................... 19
6.2 FCC Compliance ........................................................................................................................ 19
6.3 Industry Canada Compliance ...................................................................................................... 19
6.4 EMI and Environmental Type Tests ............................................................................................. 20

RUGGEDCOM RP110
Installation Guide Preface
Alerts v
Preface
This guide describes the RUGGEDCOM RP110. It describes the major features of the device, installation,
commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible for the installation,
commissioning and maintenance of the device. It is also recommended for use by network and system planners,
system programmers, and line technicians.
Alerts
The following types of alerts are used when necessary to highlight important information.
DANGER!
DANGER alerts describe imminently hazardous situations that, if not avoided, will result in death or
serious injury.
WARNING!
WARNING alerts describe hazardous situations that, if not avoided, may result in serious injury and/or
equipment damage.
CAUTION!
CAUTION alerts describe hazardous situations that, if not avoided, may result in equipment damage.
IMPORTANT!
IMPORTANT alerts provide important information that should be known before performing a procedure
or step, or using a feature.
NOTE
NOTE alerts provide additional information, such as facts, tips and details.
Related Documents
Other documents that may be of interest include:
•ROS User Guide for the RP110
Accessing Documentation
The latest Hardware Installation Guides and Software User Guides for most RUGGEDCOM products are
available online at www.siemens.com/ruggedcom.

Preface
RUGGEDCOM RP110
Installation Guide
vi Training
For any questions about the documentation or for assistance finding a specific document, contact a Siemens
sales representative.
Training
Siemens offers a wide range of educational services ranging from in-house training of standard courses on
networking, Ethernet switches and routers, to on-site customized courses tailored to the customer's needs,
experience and application.
Siemens' Educational Services team thrives on providing our customers with the essential practical skills to make
sure users have the right knowledge and expertise to understand the various technologies associated with critical
communications network infrastructure technologies.
Siemens' unique mix of IT/Telecommunications expertise combined with domain knowledge in the utility,
transportation and industrial markets, allows Siemens to provide training specific to the customer's application.
For more information about training services and course availability, visit www.siemens.com/ruggedcom or
contact a Siemens sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or
general information, please contact Siemens Customer Support through any of the following methods:
•Online
Visit http://www.siemens.com/automation/support-request to submit a Support Request (SR) or check on the
status of an existing SR.
•Telephone
Call a local hotline center to submit a Support Request (SR). To locate a local hotline center, visit http://
www.automation.siemens.com/mcms/aspa-db/en/automation-technology/Pages/default.aspx.
•Mobile App
Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or Windows mobile device
and be able to:
▪ Access Siemens's extensive library of support documentation, including FAQs, manuals, and much more
▪ Submit SRs or check on the status of an existing SR
▪ Find and contact a local contact person
▪ Ask questions or share knowledge with fellow Siemens customers and the support community via the forum
▪ And much more...

RUGGEDCOM RP110
Installation Guide
Chapter 1
Introduction
Feature Highlights 1
Introduction
The RUGGEDCOM RP110 provides the flexibility to power remote PoE devices using standard CAT-5E cable.
Converging data and power onto a single cable saves cost, space and labor for new and existing installations.
In addition to a power injector, the RP110 has a built in serial server, designed to bridge legacy serial devices on
to an IP network. It offers a single interface capable of supporting RS422, 485 and 232 protocols, and is protocol
aware for certain common serial protocols such as DNP and Modbus.
The RP110 is equipped with the Rugged Operating System (ROS) and is fully manageable through SNMPv3.
Compatible with the latest 802.3at high power PoE standard and backwards compatible with low power 802.3af
PoE devices, the RP110 provides versatility and investment protection to handle future demands for increased
power. The RP110 is designed to provide the ultimate in network reliability while IEC 61850-3 and IEEE
1613 electric utility substation certifications guarantees the RP110 will provide uninterrupted operation in the
harshest of environments. The RP110 delivers unprecedented EMI (Electromagnetic Interference) immunity and
performance for the most mission critical networks where a single lost message can impact operation. The RP110
is ideal to implement utility networks as part of the Smart Grid solution.
The following sections provide more information about the RP110:
•Section 1.1, “Feature Highlights”
•Section 1.2, “Ports, Controls and Indicator LEDs”
Section 1.1
Feature Highlights
Unmatched Reliability
The RP110 provides stability and performance under high levels of temperature variations, EMI stress and
voltage fluctuations that occur in electrical and industrial applications.
• -40 to 85 °C (-40 to 185 °F) temperature rating
• IEEE 1613 and IEC 61850-3 compliance means continued network uptime and operation in harsh
environments
Network Design Flexibility
The RP110 is a configuration free plug and play device suitable or any power over Ethernet connection,
supporting both IEEE 802.3af and 802.3at Power over Ethernet standards in one box.
• Supports a wide range of AC and DC input voltages
• Space saving compact design with DIN rail or panel mount
• Reduces cabling, connection and power supply requirements for PoE devices
Safety and Performance
When in AT mode, the RP110 has the same certifications as protection and control devices, providing the
confidence and assurance of continued operation even in the worst conditions.
• Automatic detection of remote power devices
• Output fault protection

Chapter 1
Introduction
RUGGEDCOM RP110
Installation Guide
2 Ports, Controls and Indicator LEDs
Key Features
• Substation Rated:
▪ IEC 61850-3
▪ IEEE 1613
▪ -40 to 85 °C (-40 to 185 °F) operating (no fans)
• Industrial Design:
▪ Panel or DIN mounting
▪ Lightweight Cast Aluminum Enclosure
▪ LED indicators for link and activity aids in field troubleshooting
• Performance:
▪ Configuration free, plug and play operation
▪ 802.3at/af compliant or RM version for connection to RUGGEDCOM WiN products
▪ Rated up to 36 W at 24 V+ input (RP110-LO_RM Only)
Section 1.2
Ports, Controls and Indicator LEDs
The RP110 features various ports, controls and indicator LEDs on the front panel for configuring and
troubleshooting the device.
2
4
3
1
Figure 1: Front Panel
1. RS232/RS422/RS485 Serial Terminal 2. Power Indicator LEDs 3. Alarm Indicator LED 4. Port Status Indicator LEDs
RS232/RS422/RS485 Serial Terminal The RS232/RS422/RS485 serial terminal serves a dual purpose:
• The RS232 terminals allow for a direct interface with the device to access initial
management functions.
• The RS422/RS485 terminals allow for half or full duplex serial connections respectively.
Power Indicator LEDs The power indicator LED illuminates when power is being supplied to the device.
Alarm Indicator LED The alarm indicator LED illuminates when an alarm condition exists.

RUGGEDCOM RP110
Installation Guide
Chapter 1
Introduction
Ports, Controls and Indicator LEDs 3
Port Status Indicator LEDs These LEDs indicate when ports are active.
LED Port Type Activity Description
Link 10Base-T Green (Solid) Link established
Act 10Base-T Green (Blinking) Transmitting/
receiving data
Tx Serial Green (Blinking) Transmitting data
Rx Serial Green (Blinking) Receiving data

RUGGEDCOM RP110
Installation Guide
Chapter 1
Introduction
Ports, Controls and Indicator LEDs 4

RUGGEDCOM RP110
Installation Guide
Chapter 2
Installing the Device
Mounting the Device 5
Installing the Device
The following sections describe how to install the device, including mounting the device, installing/removing
modules, connecting power, and connecting the device to the network.
DANGER!
Electrocution hazard – risk of serious personal injury and/or damage to equipment. Before performing
any maintenance tasks, make sure all power to the device has been disconnected and wait
approximately two minutes for any remaining energy to dissipate.
IMPORTANT!
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd. could invalidate
specifications, test results, and agency approvals, and void the user's authority to operate the
equipment.
IMPORTANT!
This product should be installed in a restricted access location where access can only be gained by
authorized personnel who have been informed of the restrictions and any precautions that must be
taken. Access must only be possible through the use of a tool, lock and key, or other means of security,
and controlled by the authority responsible for the location.
•Section 2.1, “Mounting the Device”
•Section 2.2, “Connecting Power”
•Section 2.3, “Grounding the Device”
Section 2.1
Mounting the Device
The RP110 can be equipped with DIN rail adapters pre-installed on each side of the chassis. The adapters allow
the device to be slid onto a standard 35 mm (1.4 in) DIN rail.
To mount the device to a DIN rail, do the following:
1. Align the slot in the bracket with the DIN rail.

Chapter 2
Installing the Device
RUGGEDCOM RP110
Installation Guide
6 Connecting Power
1
1
2
Figure 2: DIN Rail Mounting
1. DIN Rail 2. DIN Rail Bracket
2. Pull the release on the bracket down and slide the device onto the DIN rail. Let go of the release to lock the
device in position.
Section 2.2
Connecting Power
The RP110 supports a single high AC or low DC power supply.
The RP110 is equipped with a screw-type terminal block, which provides power to the AC/DC power supply and
PoE ports. The terminal block is installed using slot screws and compression plates, allowing either bare wire
connections or crimped terminal lugs. Use #6 size ring lugs for secure, reliable connections under severe shock
or vibration.
NOTE
• For 100-240 VAC rated equipment, an appropriately rated AC circuit breaker must be installed.
• For 125-250 VDC rated equipment, an appropriately rated DC circuit breaker must be installed.
• Use only #16 gage copper wiring when connecting terminal blocks.
• A circuit breaker is not required for 12, 24 or 48 VDC rated power supplies.
• It is recommended to provide a separate circuit breaker for each power supply module.
• Equipment must be installed according to applicable local wiring codes and standards.
The following sections describe how to connect power to the device:
•Section 2.2.1, “Connecting High AC/DC Power”
•Section 2.2.2, “Connecting Low DC Power”

RUGGEDCOM RP110
Installation Guide
Chapter 2
Installing the Device
Connecting High AC/DC Power 7
Section 2.2.1
Connecting High AC/DC Power
To connect a high AC/DC power supply to the device, do the following:
CAUTION!
Electrical hazard – risk of damage to equipment. Do not connect AC power cables to a DC power
supply terminal block. Damage to the power supply may occur.
1. Remove the terminal block cover.
2. If a screw-type terminal block is installed, remove the screws from the appropriate terminals. Use these
screws along with #6 ring lugs to secure the wires to the terminal block.
3. Connect the positive wire from the power source to the positive/live (+/L) terminal on the terminal block.
1 2 3
4
Figure 3: Terminal Block Wiring
1. Positive/Live (+/L) Terminal 2. Negative/Neutral (-/N) Terminal 3. Surge Ground Terminal 4. Braided Ground Cable
4. Connect the negative wire from the power source to the negative/neutral (-/N) terminal on the terminal block.
5. Using a braided wire or other appropriate grounding wire, connect the surge ground terminal to the chassis
ground connection. The surge ground terminal is used as the ground conductor for all surge and transient
suppression circuitry internal to the unit.
6. Connect the ground terminal on the power source to the chassis ground terminal on the device. For more
information, refer to Section 2.3, “Grounding the Device”.
Section 2.2.2
Connecting Low DC Power
To connect a low DC power supply to the device, do the following:
CAUTION!
Electrical hazard – risk of damage to equipment. Before testing the dielectric strength (HIPOT) in the
field, remove the braided ground cable connected to the surge ground terminal and chassis ground.

Chapter 2
Installing the Device
RUGGEDCOM RP110
Installation Guide
8 Grounding the Device
This cable connects transient suppression circuitry to chassis ground and must be removed in order to
avoid damage to transient suppression circuitry during testing.
1. Connect the positive wire from the power source to the positive/live (+/L) terminal on the terminal block.
1 2 3
4
Figure 4: Terminal Block Wiring
1. Positive/Live (+/L) Terminal 2. Negative/Neutral (-/N) Terminal 3. Surge Ground Terminal 4. Chassis Ground Terminal
2. Connect the negative wire from the power source to the negative/neutral (-/N) terminal on the terminal block.
3. Using a braided wire or other appropriate grounding wire, connect the surge ground terminal to the chassis
ground connection. The surge ground terminal is used as the ground conductor for all surge and transient
suppression circuitry internal to the unit.
4. Connect the ground terminal on the power source to the chassis ground terminal on the device. For more
information, refer to Section 2.3, “Grounding the Device”.
Section 2.3
Grounding the Device
The RP110 chassis ground terminal uses a #6-32 screw. It is recommended to terminate the ground connection
with a #6 ring lug and torque it to 1.7 N·m (15 lbf·in).
2
3
1
Figure 5: Chassis Ground Connection
1. Chassis Ground Connection 2. #6-32 Screw 3. #6 Ring Lug

RUGGEDCOM RP110
Installation Guide
Chapter 3
Communication Ports
Serial Terminal 9
Communication Ports
The RP110 comes equipped with a standard IRIG-B port, an RS232/RS422/RS485 pluggable terminal for serial
connections, and a 10Base-T Power over Ethernet (PoE) port for connection with RUGGEDCOM WiN devices.
1 2
3
Figure 6: Port Assignment
1. IRIG-B Port 2. RS232/RS422/RS485 Serial Terminal 3. Copper Power over Ethernet (PoE) Ethernet Port
The following sections describe the available ports:
•Section 3.1, “Serial Terminal”
•Section 3.2, “Copper Ethernet Port”
Section 3.1
Serial Terminal
The RP110 is equipped with a seven-terminal Phoenix-style connector. This connector can accommodate one
RS232 connection, and one RS485/422 connection. The following is the pin-out for the serial terminal:

Chapter 3
Communication Ports
RUGGEDCOM RP110
Installation Guide
10 RS232 Data Ports
7
64
2
53
1
Figure 7: Serial Terminal Pin Configuration
1. Rx 2. Tx 3. COM 4. -Rx 5. +Rx 6. -Tx 7. +Tx
Pin Mode Description
Rx RS232 Receive data
Tx RS232 Transmit data
COM Shared common
-Rx RS422/485 Receive data-
+Rx RS422/485 Receive data+
-Tx RS485 Transmit data-
+Tx RS485 Transmit data+
The following sections describe how to use the different modes available:
•Section 3.1.1, “RS232 Data Ports”
•Section 3.1.2, “RS485/422 Data Ports”
Section 3.1.1
RS232 Data Ports
The serial terminal includes a single EIA/TIA RS232 compliant port, consisting of three terminals: Transmit (Tx),
Receive (Rx) and Common (COM).
IMPORTANT!
The RS232 port is intended for point-to-point applications only.
The EIA/TIA guidelines for RS232 communications include (but are not limited to) the following:
• To minimize the effects of ambient electrical noise, shielded cabling is recommended.
• Reliable communications within 15 m (49 ft). Greater distances are possible.
• Communications of up to 120 kbaud signal rate.
The RS232 port does not use an industry standard DB9 connector, but rather a Phoenix-style compression
connector. The following is the pin-out for the DB9 connector
.

RUGGEDCOM RP110
Installation Guide
Chapter 3
Communication Ports
RS485/422 Data Ports 11
5
9 6
1
Figure 8: Phoenix-Style DB9 Connector Pin
Configuration
Pin Name Description
1
2 RD Receive Data
3 TD Transmit Data
4
5 SGND Signal Ground
6
7
8
9
The RS232 data port has two modes of operations, but only one mode is active at any given time:
• Communications with IEDs (intelligent electronic devices such as PLC, RTU, etc.)
• Console configuration of the device.
To activate console configuration mode, press and hold Ctrl+Z for approximately 10 seconds during power up. To
deactivate console mode, reset the device.
Section 3.1.2
RS485/422 Data Ports
The serial terminal includes a single RS485/RS422 data port. In half duplex mode, the RS485 connections (Rx+,
Rx-, COM) should be connected. In full-duplex mode, the RS422 connections (Rx+, Rx-, Tx+, Tx-, COM) should
be connected. Both RS485 and RS422 can accommodate multi-drop networks, for master-slave serial network
communications. For both RS485/RS422 connections, the following general guidelines should be followed:
• To minimize the effects of ambient electrical noise, use shielded cabling.
• The correct polarity must be observed throughout a single sequence or ring.
• The number of devices wired should not exceed 32, and total distance should be less than 1219 m (4000 ft) at
100 kbps.
• The Common terminals should be connected to the common wire inside the shield.

Chapter 3
Communication Ports
RUGGEDCOM RP110
Installation Guide
12 Copper Ethernet Port
• The shield should be connected to earth ground at a single point to avoid loop currents.
• The twisted pair should be terminated at each end of the chain (typically with a 120 Ohm resistor and a 10nF
capacitor in series across the twisted pair).
NOTE
Transient protection is provided on all RP110 terminals. Lightning strikes and ground surge currents
can cause large momentary voltage differences between ends of communication links. To ensure
maximum reliability of the entire link, all equipment should have similar transient protection installed.
The following shows the recommended RS485 wiring.
< 1219 m (4000 in)
120Ω 10nF
120Ω 10nF
1
2
35
5
6
4
Figure 9: Recommended RS485 Wiring
1. RP110 Device 2. Common (Isolated Ground) 3. Negative 4. Positive 5. Shield to Earth (Connected At a Single Point) 6. RS485
Devices (32 Total)
Section 3.2
Copper Ethernet Port
The RP110 supports a single 10Base-TX PoE (Power over Ethernet) Ethernet port that allows connection to
standard Category 5 (CAT-5) unshielded twisted-pair (UTP) cables with an RJ45 male connector. The RJ45
receptacle is directly connected to the chassis ground on the device and can accept CAT-5 shielded twisted-pair
(STP) cables.
The PoE port injects power on pins 4, 5, 7 and 8 when an IEEE 802.3at-compliant powered device is attached.
WARNING!
Electric shock hazard – risk of serious personal injury and/or equipment interference. If shielded
cables are used, make sure the shielded cables do not form a ground loop via the shield wire and the

RUGGEDCOM RP110
Installation Guide
Chapter 3
Communication Ports
Copper Ethernet Port 13
RJ45 receptacles at either end. Ground loops can cause excessive noise and interference, but more
importantly, create a potential shock hazard that can result in serious injury.
The following is the pin-out for the RJ45 male connector:
18
Figure 10: RJ45 Ethernet Port Pin Configuration
Pin Name Description
1 Rx+ Receive Data+
2 Rx- Receive Data-
3 Tx+ Transmit Data+
4 V+ Voltage+
5 V+ Voltage-
6 Tx- Transmit Data-
7 V- Voltage-
8 V- Voltage-
Case Shield (Chassis Ground)

RUGGEDCOM RP110
Installation Guide
Chapter 3
Communication Ports
Copper Ethernet Port 14
