Siemens SIMATIC IPC DiagMonitor V5.1.6 User manual

SIMATIC
Industrial PC
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual
05/2021
A5E50981422
-AA
Introduction
1
SIMATIC IPC DiagMonitor
software components
2
Quick-Start Guide
3
Hardware and software
requirements
4
Installing and removing the
software
5
Displaying operating data
and alarms
6
Configuration
7
Diagnostics data via
Windows Performance
Counters
8

Siemens AG
Digital Industries
Post
fach 48 48
90026 NÜRNBERG
GERMANY
A5E50981422-AA
Ⓟ
04/2021 Subject to change
Copyright © Siemens AG 2021.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 3
Table of contents
1 Introduction........................................................................................................................................... 6
2 SIMATIC IPC DiagMonitor software components .................................................................................. 7
3 Quick-Start Guide................................................................................................................................... 8
4 Hardware and software requirements .................................................................................................. 9
4.1 Hardware requirements ....................................................................................................... 9
4.2 Software Requirements...................................................................................................... 10
4.3 Industrial Security.............................................................................................................. 11
5 Installing and removing the software ................................................................................................. 12
5.1 Installation ........................................................................................................................ 12
5.2 Removal ............................................................................................................................ 15
6 Displaying operating data and alarms................................................................................................. 16
6.1 The Management Explorer................................................................................................. 16
6.1.1 Starting Management Explorer........................................................................................... 16
6.1.2 Toolbar.............................................................................................................................. 17
6.1.3 Show properties ................................................................................................................ 17
6.1.3.1 Displaying the properties of a station ................................................................................. 17
6.1.3.2 Displaying the properties of a group................................................................................... 17
6.1.3.3 Displaying the properties of an element ............................................................................. 18
6.1.3.4 The "Properties..." Window................................................................................................. 18
6.1.4 Selecting the view ............................................................................................................. 18
6.1.5 "Temperatures" Group........................................................................................................ 19
6.1.6 "Fan" Group ....................................................................................................................... 19
6.1.7 "Voltages" Group................................................................................................................ 20
6.1.8 "Hard disk" Group............................................................................................................... 20
6.1.9 "LEDs" group...................................................................................................................... 21
6.1.10 "Monitoring" Group............................................................................................................ 21
6.1.11 "Operating Hours" Group.................................................................................................... 22
6.1.12 "BIOS" Group...................................................................................................................... 22
6.1.12.1 SMBIOS ............................................................................................................................. 22
6.1.13 Display of Alarms............................................................................................................... 22
6.1.14 Service mode..................................................................................................................... 23
6.1.15 Self-test............................................................................................................................. 23
6.2 Alarms............................................................................................................................... 25
6.2.1 Interpreting status information in the Management Explorer.............................................. 25
6.2.2 Acknowledging alarms in the Management Explorer .......................................................... 26
6.2.3 Mapping an alarm to a display ........................................................................................... 26

Table of contents
SIMATIC IPC DiagMonitor V5.1.6
4Operating Manual, 05/2021, A5E50981422-AA
6.3 Alarm Manager.................................................................................................................. 27
6.3.1 The Alarm Manager in the system tray ............................................................................... 27
6.3.2 Starting the Alarm Manager from the Management Explorer .............................................. 27
6.3.3 The alarm display............................................................................................................... 28
6.3.3.1 Acknowledging alarms with the Alarm Display ................................................................... 28
6.3.3.2 Changing the message text of the Alarm Display ................................................................ 28
6.3.4 Displaying events with the Event Viewer ............................................................................ 28
6.3.5 Start Alarm Manager.......................................................................................................... 29
6.3.6 Acknowledging alarms with the Alarm Manager................................................................. 29
7 Configuration ...................................................................................................................................... 30
7.1 Management Explorer ....................................................................................................... 30
7.1.1 Configuring the watchdog ................................................................................................. 30
7.1.2 Configuration of hard disk space monitoring ...................................................................... 32
7.1.3 Reading the properties of a registered application .............................................................. 32
7.1.4 Changing the settings of the Management Explorer ........................................................... 33
7.1.5 Revisions ........................................................................................................................... 33
7.1.6 Monitoring Windows tasks................................................................................................. 34
7.1.7 Station .............................................................................................................................. 35
7.1.7.1 Adding a station ................................................................................................................ 35
7.1.7.2 Removing a station ............................................................................................................ 35
7.1.7.3 Grouping stations .............................................................................................................. 35
7.1.7.4 Saving stations and groups ................................................................................................ 36
7.1.8 Notifications...................................................................................................................... 37
7.1.8.1 Email options..................................................................................................................... 37
7.1.8.2 SMS options ...................................................................................................................... 38
7.1.8.3 Using macros in e-mail and SMS notification ...................................................................... 39
7.1.8.4 SNMP options .................................................................................................................... 39
7.1.8.5 Connection error ............................................................................................................... 40
7.1.8.6 Set notifications for termination of connection................................................................... 40
7.1.9 OPC................................................................................................................................... 40
7.1.9.1 OPC server options............................................................................................................. 40
7.1.9.2 OPC tag assignment........................................................................................................... 42
7.1.9.3 OPC Tag List ...................................................................................................................... 42
7.1.9.4 OPC UA server ................................................................................................................... 42
7.1.9.5 Starting or stopping the OPC UA server .............................................................................. 42
7.1.10 MiniWeb Server ................................................................................................................. 43
7.1.10.1 MiniWeb Server ................................................................................................................. 43
7.1.10.2 Starting and stopping the MiniWeb server.......................................................................... 43
7.1.10.3 Changing the MiniWeb Network Port ................................................................................. 43
7.1.10.4 Opening the MiniWeb Site ................................................................................................. 43
7.1.10.5 Changing the Links on the MiniWeb Site ............................................................................ 44
7.1.11 Firmware of the device ...................................................................................................... 45
7.1.11.1 Firmware settings.............................................................................................................. 45
7.1.11.2 Firmware version............................................................................................................... 46

Table of contents
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 5
7.2 Alarm Manager.................................................................................................................. 48
7.2.1 The "Alarm Manager - Settings" Window............................................................................. 48
7.2.2 Adding a new application in the Alarm Manager................................................................. 48
7.2.3 Changing an application in the Alarm Manager .................................................................. 48
7.2.4 Removing an application in the Alarm Manager.................................................................. 49
7.2.5 Changing settings of the Alarm Manager............................................................................ 49
8 Diagnostics data via Windows Performance Counters ........................................................................ 50
Index.................................................................................................................................................... 51

SIMATIC IPC DiagMonitor V5.1.6
6Operating Manual, 05/2021, A5E50981422-AA
Introduction
1
Even in their basic versions, SIMATIC Industry PCs come with optional monitoring functions.
When used in combination with the appropriate software, the following functions for
displaying, monitoring and controlling are available:
•Temperature monitoring (over-temperature, under-temperature or cable break at a
temperature sensor)
•Fan monitoring (fan speed too low, fan failure, or a break in a tachometer line)
•Monitoring of the battery level
•Monitoring of hard disks with S.M.A.R.T functionality even in a RAID system
•Watchdog (hardware or software reset of the computer)
•Operating hours meter (information on the cumulative run time)
With the SIMATIC IPC DiagMonitor software, you can use these functions for local and remote
monitoring. You can use the DiagMonitor Management Explorer application for general
monitoring or DiagMonitor Alarm Manager for notification of individual alarms.
This documentation describes the functionality of SIMATIC IPC DiagMonitor software.

SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 7
SIMATIC IPC DiagMonitor software components
2
The following components are included in the scope of delivery:
Software Components
Explanations
DMDataEngine
This service returns status information of the monitored device
components to SIMATIC IPC DiagMonitor
DMMsgService
This service is responsible for advanced processing of alarms.
DMAlarmManagerService
This service is responsible for advanced processing of alarms.
IPCUniDrv
Driver for hardware access.
DMOPCService
This service is responsible for communication with OPC.
DMSNMPDataEngine
This service supplies the connection to the monitored stations.
MiniWeb
This service makes the monitoring data available in such a way that
it can be displayed via a Web browser.
Alarm Manager
Assigns the relevant alarms to executable programs.
Alarm Display
Lists the individual alarms for acknowledgment.
Management Explorer
Lists the monitored device components and status in an overview.
During installation, these components are copied to the system disk and are available for
startup in the system.

SIMATIC IPC DiagMonitor V5.1.6
8Operating Manual, 05/2021, A5E50981422-AA
Quick-Start Guide
3
The following steps are required to use SIMATIC IPC DiagMonitor monitoring:
1. Ensure that all the hardware and software requirements are met for the operation of
SIMATIC IPC DiagMonitor (see section Hardware and software requirements (Page 9) ).
2. Perform the SIMATIC IPC DiagMonitor installation on the SIMATIC IPC (see section
Installation (Page 12)).
3. Start the DiagMonitor Alarm Manager in order to be informed of malfunctioning of the
monitored device components.

SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 9
Hardware and software requirements
4
4.1 Hardware requirements
Only the following SIEMENS products are supported:
•SIMATIC IPC227D
•SIMATIC IPC277D
•SIMATIC IPC427D
•SIMATIC IPC477D
•SIMATIC IPC627D
•SIMATIC IPC647D
•SIMATIC IPC677D
•SIMATIC IPC827D
•SIMATIC IPC847D
•SIMATIC IPC127E
•SIMATIC IPC227E
•SIMATIC IPC277E
•SIMATIC IPC427E
•SIMATIC IPC477E
•SIMATIC IPC547E
•SIMATIC IPC227G
•SIMATIC IPC277G
•SIMATIC IPC547G
•SIMATIC IPC547J
•SIMATIC IPC627E
•SIMATIC IPC677E
•SIMATIC IPC647E
•SIMATIC IPC847E
•CPU 1515SP PC
•CPU 1515SP PC2

Hardware and software requirements
4.2 Software Requirements
SIMATIC IPC DiagMonitor V5.1.6
10 Operating Manual, 05/2021, A5E50981422-AA
4.2 Software Requirements
Requirement
At least one network adapter with TCP/IP.
Operating systems
The SIMATIC IPC DiagMonitor software can be used with the following operating systems:
•Microsoft® Windows® Server 2008 R2, 64-bit
•Microsoft® Windows® Embedded Standard 7, 32-bit (SIMATIC IPC configuration)
•Microsoft® Windows® Embedded Standard 7, 64-bit (SIMATIC IPC configuration)
•Microsoft® Windows® 7 Ultimate, 32-bit
•Microsoft® Windows® 7 Ultimate, 64-bit
•Microsoft® Windows® Server 2012 R2
•Microsoft® Windows® 10 Enterprise 2015 LTSB, 64-bit
•Microsoft® Windows® 10 Enterprise 2016 LTSB, 64-bit
•Microsoft® Windows® 10 Enterprise 2019 LTSC, 64-bit
•Microsoft® Windows® Server 2016
•Microsoft® Windows® Server 2019
Restriction
Remote monitoring is only possible using the TCP/IP Internet protocol with SNMP.

Hardware and software requirements
4.3 Industrial Security
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 11
4.3 Industrial Security
Industrial Security
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. firewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit (http://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply latest updates may increase customer’s exposure to
cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (https://support.industry.siemens.com/cs/ww/en/).
Disclaimer for third-party software updates
This product includes third-party software. Siemens AG only provides a warranty for
updates/patches of the third-party software, if these have been distributed as part of a
Siemens software update service contract or officially released by Siemens AG. Otherwise,
updates/patches are undertaken at your own risk. You can find more information about our
Software Update Service offer on the Internet at Software Update Service
(https://support.industry.siemens.com/cs/ww/en/view/109759444).
Notes on protecting administrator accounts
A user with administrator privileges has extensive access and manipulation options in the
system.
Therefore, ensure there are adequate safeguards for protecting the administrator accounts to
prevent unauthorized changes. To do this, use secure passwords and a standard user account
for normal operation. Other measures, such as the use of security policies, should be applied
as needed.

SIMATIC IPC DiagMonitor V5.1.6
12 Operating Manual, 05/2021, A5E50981422-AA
Installing and removing the software
5
5.1 Installation
Installing DiagMonitor
Requirement
•You have administrator rights.
•If an older version of the "SIMATIC IPC DiagMonitor" or "SIMATIC IPC DiagMonitor
DiagBase" software is installed on your PC, you need to completely uninstall it:
–Start "SIMATIC IPC DiagMonitor" or "SIMATIC IPC DiagMonitor DiagBase".
–Right-click on the "AlarmManager" icon.
–Select "Exit".
Procedure
1. Run the "Start.exe" file.
2. Select the setup language for installation of the software.
3. Follow the instructions displayed on the screen.
Silent installation
You have the option of installing SIMATIC IPC DiagMonitor without displaying a window
during the installation process. In this case, you cannot make any input during the
installation.
1. Run the "DMInstManager.exe" file with the parameter "install silent typical" or "install silent
minimal".
SNMP service for DiagMonitor
The SNMP service is required for operating the DiagMonitor. Setup checks whether this
service is installed. If it finds that the service has not been installed, an error message will
appear and setup is canceled. In this case, install the SNMP service.

Installing and removing the software
5.1 Installation
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 13
Installing SNMP service up to Windows® 10 Enterprise 2016 LTSB
1. Press the shortcut "Windows + r".
2. Enter "appwiz.cpl" in the text box and confirm your entry.
The "Programs and Features" window opens.
3. Click on "Turn Windows features on or off".
The "Windows Features" window opens.
4. Select the "Simple Network Management Protocol (SNMP)" option.
5. Confirm with "OK".
Installing SNMP service as of Windows® 10 Enterprise 2019 LTSC
Installing SNMP using the Control Panel (Internet connection required)
1. Connect the device to the Internet.
2. Press the shortcut "Windows + r".
3. Enter "ms-settings:optionalfeatures" in the text box and confirm your entry.
The "Manage optional features" window opens.
4. Click "Add a feature".
The "Add a feature" window opens.
5. Select the "Simple Network Management Protocol (SNMP)" option.
6. Click "Install".
Installing SNMP using the supplied USB stick (no Internet connection necessary)
For SIMATIC devices with pre-installed Windows® operating system, you can also install the
SNMP service as of Windows® 10 Enterprise 2019 LTSC as follows:
1. Insert the USB stick provided with the SIMATIC device into the device.
2. Wait until the USB stick is detected and connected as a drive.
3. Start the "START_DocuAndDrivers.cmd" script from the USB stick.
4. Select "Software" in the index.
5. Select "Optional Windows features".
6. Select "Simple Network Management Protocol (SNMP)".
7. Click on the "Install" icon.

Installing and removing the software
5.1 Installation
SIMATIC IPC DiagMonitor V5.1.6
14 Operating Manual, 05/2021, A5E50981422-AA
Defining the SNMP service security settings
You can use the SNMP service security settings to define whether to accept SNMP packets
from specified hosts only or from all hosts. To do so, all PCs to which you give monitoring
permission must be entered into a list.
Proceed as follows:
1. Depending on the version of your Windows operating system, open computer management
as follows:
–Windows 7:
Open the Windows start menu and right-click on "Computer".
Select "Manage" from the shortcut menu.
–Windows 10:
Right-click on the Windows Start menu.
Select "Computer Management" from the shortcut menu.
2. Double-click on the "Services and Applications" entry.
3. Double-click on the "Services" entry.
4. Open the "SNMP Service" entry.
5. Select the "Security" tab.
6. You can select the option "Accept SNMP packets from any host" if you do not wish to restrict
access.
If you want to revoke access restrictions for specific PCs, enter the PCs which you want to
give monitoring permission into an exception list.
Note
If a firewall is active, ports 161 and 162 UDP
(SNMP/SNMP trap) must be entered in the
exception list.
7. Close the dialog.
See also
SNMP options (Page 39)

Installing and removing the software
5.2 Removal
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 15
5.2 Removal
Note
Administrator rights are required to uninstall
Note that you can only uninstall with administrator rights.
As usual in Windows, you uninstall an application via the Control Panel. This SIMATIC IPC
DiagMonitor name is entered in the software installation list as follows:
SIMATIC IPC DiagMonitor
The removal routine removes all components from your system. Your configuration settings
are maintained.
Silent removal
You have the option of uninstalling SIMATIC IPC DiagMonitor without displaying a window
during the uninstallation process.
To do this, run the application DMInstManager.exe with the "remove DiagMonitor"
parameters.

SIMATIC IPC DiagMonitor V5.1.6
16 Operating Manual, 05/2021, A5E50981422-AA
Displaying operating data and alarms
6
Management Explorer
The DiagMonitor Management Explorer provides a two-pane view similar to the Windows
Explorer. In the left-hand pane, all the function groups to be monitored are listed in a tree
structure below the name of the station.
The right-hand pane of the window shows the individual devices of a function group. These
can be displayed in various views (see Selecting the view (Page 18)).
Alarm Manager
The DiagMonitor Alarm Manager is used to assign alarms to applications when they occur. If,
for example, a fault develops in a RAID hard disk array, the Intel® Rapid Storage Technology
(RST) program can be assigned to this fault (assuming it is installed). If a hard disk fault
occurs, the Intel® Rapid Storage Technology (RST) software opens.
6.1 The Management Explorer
6.1.1 Starting Management Explorer
The DiagMonitor Management Explorer can be configured in such a way that the application
is started automatically when the system starts up. You can enable this feature as follows:
1. Select the menu command "Options > Settings...".
2. Select the "Start with Windows session" field.
3. Click "OK" to confirm the selection.
DiagMonitor Management Explorer starts automatically the next time the system starts
up. The application autonomously prevents multiple starts.
Program window
The setting and size of the program window are retained during runtime.

Displaying operating data and alarms
6.1 The Management Explorer
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 17
6.1.2 Toolbar
A toolbar is displayed in the program window by default. It can be hidden using the "View"
menu command.
The toolbar contains the following icons:
•Arrow left and arrow right icons (Using the arrow left and arrow right buttons, you can
move backwards and forwards through the various function groups in much the same
way as in an Internet browser.)
•Arrow up icon (the arrow up icon can be used to switch to a higher level.)
•Add station (Page 35)
•Remove station (Page 35)
•Green check mark (alarms can be acknowledged with the green check mark.)
•Maintenance status (Page 23)
•E-mail settings (Page 37)
•SMS settings (Page 38)
•OPC settings (Page 40)
6.1.3 Show properties
6.1.3.1 Displaying the properties of a station
To display the properties of a station, follow these steps:
1. Right-click on the station in the tree view.
2. Select the menu command "Properties" from the shortcut menu.
3. The "Station properties..." window opens and displays information on the station.
6.1.3.2 Displaying the properties of a group
To display the properties of a group, follow these steps:
1. Right-click on the group in the tree view.
2. Select the menu command "Properties" from the shortcut menu.
3. The "Group properties..." window opens and displays the number of elements contained.

Displaying operating data and alarms
6.1 The Management Explorer
SIMATIC IPC DiagMonitor V5.1.6
18 Operating Manual, 05/2021, A5E50981422-AA
6.1.3.3 Displaying the properties of an element
To display the properties of an element, follow these steps:
1. Right-click on the element in the list view.
2. Select the menu command "Properties" from the shortcut menu.
3. The "Element properties..." window opens and displays the main properties of the element.
6.1.3.4 The "Properties..." Window
This window displays the main properties of a selected station, group or element.
Special features of groups:
•Sensors: For fans or temperatures, the current value and the low and high limit value are
displayed.
•Displays: For LEDs and optional 7-segment displays, you can link an alarm with an element
in the "Alarm mapping" tab. See Mapping an alarm to a display (Page 26).
•Watchdog: You can set a timeout value and options for watchdog operation. See
Configuring the watchdog (Page 30).
•Station: A station description can be stored.
•Hard disks: Limits can be defined for the free space of the partitions.
6.1.4 Selecting the view
In the right-hand pane of the program window of the DiagMonitor Management Explorer,
you can choose between three different representations. You can select these via the menu
item "View".
The following views are available:
•Tiles: The elements of the sensors, for example fans or temperatures are shown in the list
view graphically in the form of a scale. The values to the left of the scale show the
permitted high and low limits. The value below the scale is the current value. To the right
of the scale, there are two pointers. These indicate the maximum or minimum value
measured up to now. To reset the max/min pointers to the current value, right-click on the
required element in the list view. Select "Reset interval values"
•Icons: This view displays large icons and brief status information about the monitored
devices.
•Details: This view displays small icons and detailed status information about the
monitored devices.
Example of a fan: In the detailed view, apart from the type and current value, you can also
see the low and high limit of the fan speed.

Displaying operating data and alarms
6.1 The Management Explorer
SIMATIC IPC DiagMonitor V5.1.6
Operating Manual, 05/2021, A5E50981422-AA 19
6.1.5 "Temperatures" Group
The "Temperatures" group indicates the status of the existing temperature sensors (device-
dependent).
The temperature will be displayed in a thermometer symbol, depending on the view.
•The unit is °C (Celsius) for metric settings
•The unit is °F (Fahrenheit) for Anglo-American settings
Proceed as follows to change this setting:
1. Start the country setting in the Control Panel.
2. You select the measuring system in the "Numbers" tab under "Measuring system."
3. Re-start Management Explorer.
The last temperature measurement is displayed below the thermometer symbol. To the left
of the temperature scale are the minimum and maximum allowed values. Violation of these
limits will trigger an alarm. To the right of the temperature scale are the minimum and
maximum measured values.
Alarms
If the temperature exceeds or falls below the specified maximum or minimum value, this is
displayed in the status of the sensor (see Display of Alarms (Page 22) ).
6.1.6 "Fan" Group
The "fan" group indicates the status of the existing fans (device-dependent).
The fan speed is represented in a fan symbol, depending on the selected view; all speeds are
indicated in revolutions per minute. The last speed measurement is displayed below the fan
symbol. To the left of the speed scale are the minimum and maximum allowed values.
Violation of these limits will trigger an alarm. To the right of the speed scale are the minimum
and maximum measured values.
Alarms
If the speed falls below the indicated minimum value, such a reaction will be displayed in the
sensor status (see Display of Alarms (Page 22)).

Displaying operating data and alarms
6.1 The Management Explorer
SIMATIC IPC DiagMonitor V5.1.6
20 Operating Manual, 05/2021, A5E50981422-AA
6.1.7 "Voltages" Group
The "Voltages" group indicates the status of the existing voltage sensors (device-dependent).
The voltage of a backup battery (CMOS), a redundant power supply (device-dependent) or an
uninterruptible power supply (device-dependent) can be monitored.
The backup battery voltage is monitored to establish whether it is ok, critical or faulty.
Note
Backup battery (CMOS)
Replace the backup battery immediately if the sensor indicates a critical or faulty status.
Redundant power supply monitoring checks that both power inputs are enabled and the
power supply unit fan is operating.
With an uninterruptible power supply, monitoring checks whether the current input is active.
Note
Alarms
If the voltage falls below t
he indicated minimum value, the sensor status will indicate this.
See Display of Alarms (Page 22)
6.1.8 "Hard disk" Group
The "Hard Disk" group indicates the status of the existing hard disks (device-dependent). The
following hard disks are supported:
•SATA hard disks
•CompactFlash cards
•CFast cards
•SAS hard disks
•USB hard disks or USB sticks
•Hard disks for an INTEL RAID adapter or Adaptec RAID adapter
The properties for each drive indicate if the drive is S.M.A.R.T. capable and/or a RAID drive. If
this is the case, then the drive symbol is displayed actively with a symbolic LED. The type,
serial number, and firmware version of the drive is displayed in the respective text box.
Alarms
If a drive reports a SMART or RAID error, the status of the drive changes (see Display of Alarms
(Page 22)).
