Siemens SIMATIC IPC277E User manual

xyz
50 50 50
1.1 Vor Einbau und Inbetriebnahme – Before mounting and commissioning
1.2
1.3 Gerät einsetzen – Installing the HMI device
1.4 Gerät befestigen – Mounting the device
2.2 Stromversorgung anschließen – Connecting the power supply
2.3 Leitungen sichern – Securing the cables
Gerät einbauen
Mounting the device
1
Gerät anschließen
Connecting the device
2
2.1 Schutzleiter anschließen – Connecting the protective earth
5
IP65
wh
1
2-6
0.5
Enclosure
Type 4X/12
50 °C (7“, 9“, 12“, 15“)
0 °C
0°–45° 0°–45°
+1
0
+1
0
IPC277E 7“
w
197
h
141
IPC277E 9“ 251 166
221
IPC277E 12“ 310
290
IPC277E 15“ 395
318
IPC277E 19“ 464
IPC277E 7“ 10 x
IPC277E 9“ 12 x
IPC277E 12“ 12 x
12 x
12 x
IPC277E 15“
IPC277E 19“
mm
45 °C (19“)
50 °C (7“, 9“ *, 12“)
0 °C
45 °C (15“, 19“)
45 °C (7“, 9“, 12“)
0 °C
40 °C (15“, 19“)
Zulässige Einbaulagen – Valid Mounting positions
4
4
7“, 9“
12“, 15“, 19“
Sichern Sie die angeschlossenen Leitungen zur Zugentlastung mit Kabelbindern an den markierten
Befestigungselementen. Achten Sie darauf, dass die Leitungen durch die Kabelbinder nicht gequetscht
werden. Beispiele:
Use cable ties to secure the connected cables to the selected fixing elements for strain relief.
Make sure that the cables are not crushed by the cable tie. Examples:
SIMATIC IPC277E 9“
SIMATIC IPC277E 12“
16 mm²
2
y
x
x
y
z
y
y
z
x
x
0,5 x 3
1
2
0.5 x 3
≤0.5 Nm
1
2
0.5 x 3
≤0.5 Nm
0,5 x 3
1
M4
2.5 mm²
3
2
M
L+
3
0/OFF
1
DC 24 V
Power
Supply
Das Gerät darf nur an eine DC-24-V-Stromversorgung angeschlos-
sen werden, die den Anforderungen einer sicheren Kleinspannung
(SELV) gemäß der IEC/EN/DIN EN/UL 60950-1 entspricht.
Die Stromversorgung muss die Anforderung NEC Class 2 bzw. LPS
gemäß der IEC/EN/DIN EN/UL 60950-1 erfüllen.
The device must only be connected to a 24 VDC power supply
which satisfies the requirements of safety extra low voltage (SELV)
according to IEC/EN/DIN EN/UL 60950-1.
The power supply must meet the NEC Class 2 or LPS requirement in
accordance with IEC/EN/DIN EN/UL 60950-1.
WICHTIG: Beachten Sie alle dem Gerät beiliegenden Dokumente und die Betriebsanleitung, bevor
Sie das Gerät einbauen und anschließen. Die vollständige Dokumentation des Geräts finden Sie auf
der beiliegenden DVD "Documentation and Drivers" und im Internet
(http://www.siemens.de/simatic-ipc-doku-portal).
IMPORTANT: observe all documents enclosed with the device and the operating instructions manual
before mounting and connecting the device. You find the complete documentation of the device on
the enclosed „Documentation and Drivers" DVD and on the internet
(http://www.siemens.com/simatic-ipc-doku-portal).
12“, 15“, 19“
7“, 9“
2
T20
Das Handbuchsymbol weist auf detaillierte Informationen in der Betriebsanleitung hin.
The manual symbol refers to detailed information in the operating instructions.
0.75 ... 2.5 mm2
Gehäuse erforderlich
* 9“-Gerät bei >45 °C
Enclosure required
* 9“ device at >45 °C
3.1 Maus und Tastatur anschließen – Connecting mouse and keyboard
Gerät in Betrieb nehmen
Commissioning the device
3
3.2 Gerät einschalten – Switching on the device
Self-Test
06/2015
A5E35783421-AA
Press <ESC> for Boot Options
Schalten Sie den Ein-/Aus-Schalter in Position "I" (EIN).
Set the on/off switch to position "I" (ON).
1
2
Warten Sie bis die Meldung erlischt.
Wait for the message to disappear.
3
Folgen Sie den Anweisungen auf dem Bildschirm.
Follow the instructions on the screen.
Haftungsausschluss
Wir haben den Inhalt der Druckschrift auf Übereinstimmung mit der beschriebenen Hard- und
Software geprüft. Dennoch können Abweichungen nicht ausgeschlossen werden, so dass wir für
die vollständige Übereinstimmung keine Gewähr übernehmen. Die Angaben in dieser Druckschrift
werden regelmäßig überprüft, notwendige Korrekturen sind in den nachfolgenden Auflagen
enthalten.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and
software described. Since variance cannot be precluded entirely, we cannot guarantee full
consistency. However, the information in this publication is reviewed regularly and any necessary
corrections are included in subsequent editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
Abbildungen
Das vorliegende Dokument enthält Abbildungen zu den beschriebenen Geräten und Zubehör.
Die Abbildungen können bezogen auf das gelieferte Gerät und Zubehör in Einzelheiten abweichen.
Illustrations
This document contains illustrations of the described devices and accessories.
The illustrations may deviate from the particularities of the delivered device and accessories.
SIMATIC
Industrial PC
SIMATIC IPC277E
Quick Install Guide
Technische Support-Zentrale
Central Technical Support
www.siemens.com/
automation/support
Reparatur und Ersatzteile
Service and spare parts
www.automation.
siemens.com/service
Gerät einbauen
Mounting the device
Gerät anschließen
Connecting the device
Gerät in Betrieb nehmen
Commissioning the device
1
2
3
