Siemens Sitrans F Series User manual

Operating Instructions
Answers for industry.
08/2017
Edition
Ultrasonic Flowmeters
FST030 (Modbus)
SITRANS F

SITRANS F
Ultrasonic flowmeters
SITRANS F Ultrasonic flowmeters
FST030 (Modbus)
Operating Instructions
These Operating Instructions a33pply to Siemens
SITRANS FST030 transmitters for use in flowmeter
systems with order codes commencing 7ME372
08/2017
A5E37367739
-AC
Introduction
1
Safety notes
2
Description
3
Installing/Mounting
4
Connecting
5
Commissioning
6
Operating
7
Service and maintenance
8
Diagnosing and
troubleshooting
9
Technical data
10
Dimension drawings
11
Modbus communication
A
Certificates and support
B
SIMATIC PDM
C

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E37367739
Ⓟ
08/2017 Subject to change
Copyright © Siemens AG 2017.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury
may
result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 3
Table of contents
1 Introduction............................................................................................................................................. 9
1.1 Purpose of this documentation .................................................................................................9
1.2 Product compatibility.................................................................................................................9
1.3 Document history ....................................................................................................................10
1.4 Device documentation package..............................................................................................11
1.5 Items supplied.........................................................................................................................11
1.6 Checking the consignment .....................................................................................................12
1.7 Security information ................................................................................................................12
1.8 Transportation and storage.....................................................................................................13
1.9 Notes on warranty...................................................................................................................14
2 Safety notes.......................................................................................................................................... 15
2.1 Preconditions for safe use ......................................................................................................15
2.1.1 Warning symbols on the device..............................................................................................15
2.1.2 Improper device modifications ................................................................................................15
2.2 Laws and directives ................................................................................................................16
2.2.1 FCC Conformity ......................................................................................................................16
2.2.2 Conformity with European directives ......................................................................................16
2.3 Requirements for special applications ....................................................................................17
2.4 Use in hazardous areas..........................................................................................................17
2.4.1 Use in hazardous areas..........................................................................................................18
2.4.2 Loss of safety of device with type of protection "Intrinsic safety Ex i" ....................................18
2.4.3 Dust layers above 5 mm .........................................................................................................19
2.5 Installation in hazardous areas ...............................................................................................20
3 Description............................................................................................................................................ 23
3.1 Design.....................................................................................................................................23
3.1.1 Transmitter..............................................................................................................................23
3.2 Features..................................................................................................................................23
3.3 Applications.............................................................................................................................26
3.4 Approvals ................................................................................................................................26
3.5 Modbus communication..........................................................................................................26
4 Installing/Mounting ................................................................................................................................ 27
4.1 Installation location requirements ...........................................................................................27
4.2 Installation instructions............................................................................................................28
4.2.1 Wall mount housing transmitter ..............................................................................................28

Table of contents
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
4Operating Instructions, 08/2017, A5E37367739-AC
5 Connecting ........................................................................................................................................... 31
5.1 Basic safety notes.................................................................................................................. 31
5.1.1 Missing PE/ground connection .............................................................................................. 31
5.1.2 Unsuitable cables, cable glands and/or plugs ....................................................................... 32
5.1.3 Lack of equipotential bonding ................................................................................................ 32
5.1.4 Unprotected cable ends ......................................................................................................... 32
5.1.5 Improper laying of shielded cables ........................................................................................ 33
5.1.6 Insufficient isolation of intrinsically safe and non-intrinsically safe circuits ............................ 33
5.1.7 Incorrect conduit system ........................................................................................................ 33
5.1.8 Energized devices.................................................................................................................. 34
5.2 Disconnecting device ............................................................................................................. 34
5.3 Device nameplates ................................................................................................................ 34
5.4 Integrating the FST030 with Modbus system ........................................................................ 36
5.4.1 System configuration ............................................................................................................. 37
5.4.2 System wiring......................................................................................................................... 39
5.5 Transmitter power supply, communications and I/Os connection ......................................... 41
5.5.1 Preparing for the connections ................................................................................................ 42
5.5.2 Connecting Modbus ............................................................................................................... 43
5.5.3 Connecting channels 2 to 4 ................................................................................................... 44
5.5.3.1 Input/output configuration ...................................................................................................... 46
5.5.4 Connecting channels 5 and 6 ................................................................................................ 47
5.5.5 Connecting the power supply................................................................................................. 48
5.6 Finishing the transmitter connection ...................................................................................... 49
6 Commissioning ..................................................................................................................................... 51
6.1 Basic safety notes.................................................................................................................. 51
6.1.1 Opening device in energized state......................................................................................... 51
6.2 General requirements ............................................................................................................ 52
6.3 Power-up................................................................................................................................ 52
6.4 Local display .......................................................................................................................... 52
6.5 Initial startup........................................................................................................................... 53
6.6 Commissioning via local display ............................................................................................ 54
6.6.1 Wizards .................................................................................................................................. 54
6.6.1.1 Quick commissioning wizard.................................................................................................. 55
6.6.1.2 Quick Commissioning wizard (wizard) ................................................................................... 56
6.6.1.3 Sensor settings wizard........................................................................................................... 56
6.6.1.4 Process values wizard ........................................................................................................... 61
6.6.1.5 Inputs and outputs wizard ...................................................................................................... 63
6.6.1.6 Communication wizard........................................................................................................... 68
6.6.1.7 Communication wizard (wizard)............................................................................................. 69
6.6.2 Navigating the menu structure ............................................................................................... 69
6.6.2.1 Navigation view...................................................................................................................... 69
7 Operating.............................................................................................................................................. 71
7.1 Operating via the local display ............................................................................................... 71
7.1.1 Display views ......................................................................................................................... 71
7.1.2 Access control........................................................................................................................ 71

Table of contents
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 5
7.2 Operating the FST030 ............................................................................................................72
7.2.1 Fixed display texts ..................................................................................................................72
7.2.2 Reading the process values ...................................................................................................74
7.2.3 Operating the totalizers...........................................................................................................76
7.2.4 Handling alarms ......................................................................................................................77
7.2.5 Reading the diagnostic values................................................................................................79
7.3 Reading / changing parameters..............................................................................................79
7.3.1 Alphanumeric parameters.......................................................................................................79
7.3.1.1 Changing the resolution ..........................................................................................................80
7.3.2 Parameter lists ........................................................................................................................81
8 Service and maintenance...................................................................................................................... 83
8.1 Basic safety notes...................................................................................................................83
8.1.1 Impermissible repair of explosion protected devices..............................................................83
8.2 Recalibration ...........................................................................................................................83
8.3 Cleaning..................................................................................................................................84
8.4 Electrostatic charge ................................................................................................................84
8.5 Maintenance and repair work .................................................................................................84
8.5.1 Service and maintenance information ....................................................................................84
8.6 Return procedure ....................................................................................................................85
8.7 Disposal ..................................................................................................................................86
9 Diagnosing and troubleshooting ............................................................................................................ 87
9.1 Unexpected behavior..............................................................................................................87
9.2 Application questionnaire........................................................................................................89
9.3 Device status icons .................................................................................................................90
9.4 Fault codes and corrective actions .........................................................................................92
10 Technical data .................................................................................................................................... 115
10.1 Power....................................................................................................................................115
10.2 Modbus interface ..................................................................................................................115
10.3 Inputs ....................................................................................................................................116
10.4 Outputs .................................................................................................................................117
10.5 Construction..........................................................................................................................119
10.6 Operating conditions.............................................................................................................120
10.7 Approvals ..............................................................................................................................121
10.8 Approvals ..............................................................................................................................121
10.9 SensorFlash..........................................................................................................................122
11 Dimension drawings............................................................................................................................ 123
11.1 Transmitter............................................................................................................................123
A Modbus communication ...................................................................................................................... 125

Table of contents
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
6Operating Instructions, 08/2017, A5E37367739-AC
A.1 Modbus addressing model................................................................................................... 125
A.2 Modbus communication ....................................................................................................... 125
A.3 Coil configuration ................................................................................................................. 127
A.4 Modbus register mapping .................................................................................................... 128
A.5 Integer byte order................................................................................................................. 130
A.6 Float byte order .................................................................................................................... 130
A.7 Modbus function codes ........................................................................................................ 131
A.8 Access control...................................................................................................................... 132
A.9 Modbus holding registers tables .......................................................................................... 133
A.9.1 Process values..................................................................................................................... 133
A.9.2 Totalizers.............................................................................................................................. 137
A.9.3 Units ..................................................................................................................................... 140
A.9.4 Setup.................................................................................................................................... 155
A.9.4.1 Sensor.................................................................................................................................. 155
A.9.4.2 Process values..................................................................................................................... 180
A.9.4.3 Totalizers.............................................................................................................................. 191
A.9.4.4 Inputs and outputs ............................................................................................................... 197
A.9.4.5 Date and time....................................................................................................................... 270
A.9.4.6 Local display ........................................................................................................................ 271
A.9.4.7 Selectable values dependent on the view type.................................................................... 282
A.9.4.8 Process value filter masks ................................................................................................... 285
A.9.5 Maintenance and diagnostics .............................................................................................. 286
A.9.5.1 Maintenance & diagnostics .................................................................................................. 286
A.9.5.2 Identification ......................................................................................................................... 286
A.9.6 Diagnostic events................................................................................................................. 290
A.9.6.1 Active events........................................................................................................................ 290
A.9.6.2 Diagnostic log....................................................................................................................... 294
A.9.6.3 Alarm items .......................................................................................................................... 295
A.9.7 Diagnostics........................................................................................................................... 302
A.9.7.1 Sensor.................................................................................................................................. 302
A.9.7.2 DSL ...................................................................................................................................... 308
A.9.7.3 Temperature monitoring....................................................................................................... 308
A.9.7.4 Inputs and outputs ............................................................................................................... 310
A.9.7.5 Peak values.......................................................................................................................... 315
A.9.8 Characteristics ..................................................................................................................... 319
A.9.8.1 Product................................................................................................................................. 319
A.9.8.2 Transmitter ........................................................................................................................... 319
A.9.8.3 Sensor frontend.................................................................................................................... 320
A.9.9 SensorFlash ......................................................................................................................... 320
A.9.9.1 SensorFlash ......................................................................................................................... 320
A.9.9.2 Data logging ......................................................................................................................... 321
A.9.10 Simulation ............................................................................................................................ 322
A.9.10.1 Inputs and outputs ............................................................................................................... 322
A.9.10.2 Process values..................................................................................................................... 328
A.9.10.3 Alarms .................................................................................................................................. 330
A.9.11 Audit trail .............................................................................................................................. 332
A.9.11.1 Operating time...................................................................................................................... 332
A.9.11.2 Parameter change log.......................................................................................................... 333

Table of contents
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 7
A.9.11.3 FW update change log..........................................................................................................335
A.9.12 Device reset ..........................................................................................................................335
A.9.13 Oil table settings ...................................................................................................................336
A.9.14 Communication .....................................................................................................................338
A.9.14.1 Service channel ....................................................................................................................338
A.9.15 Security .................................................................................................................................338
A.9.15.1 Access management ............................................................................................................338
B Certificates and support ...................................................................................................................... 341
B.1 Certificates ............................................................................................................................341
B.2 Technical support..................................................................................................................341
B.3 QR code label .......................................................................................................................342
C SIMATIC PDM .................................................................................................................................... 343
C.1 Commissioning with PDM.....................................................................................................343
C.1.1 Functions in SIMATIC PDM..................................................................................................343
C.1.2 Supported SIMATIC PDM versions ......................................................................................343
C.1.3 Initial setup............................................................................................................................343
C.1.4 Integrating the EDD ..............................................................................................................344
C.1.5 Adding device to communication network ............................................................................345
C.1.6 Configuring a new device .....................................................................................................346
C.1.7 Wizard - Quick Start via PDM ...............................................................................................347
C.1.8 Wizard - Clamp-On Configuration.........................................................................................348
C.1.9 Wizard - Zero point adjustment.............................................................................................348
C.1.10 Changing parameter settings using SIMATIC PDM .............................................................349
C.1.11 Parameters accessed via drop-down menus .......................................................................349
C.1.12 Process variables..................................................................................................................351
Index................................................................................................................................................... 353

Table of contents
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
8Operating Instructions, 08/2017, A5E37367739-AC

SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 9
Introduction
1
Note
This manual applies to the SITRANS FST030 transmitter Modbus version only. Modbus
®
is a
registered trademark of MODICON, Inc.
Use the device to measure process medium in accordance with the information in the
Operating Instructions.
Note
Use in a domestic environment
This Class A Group 1 equipment is intended for use in industrial areas.
In a domestic environment this device may cause radio interference.
In order to operate an ultrasonic flow meter, you need both the transmitter Operating
Instructions and the sensor Installation Manual, see Flow documentation
(https://support.industry.siemens.com/cs/products?pnid=17317&lc=en-WW).
1.1
Purpose of this documentation
These instructions contain all information required to commission and use the device. Read
the instructions carefully prior to installation and commissioning. In order to use the device
correctly, first review its principle of operation.
The instructions are aimed at persons mechanically installing the device, connecting it
electronically, configuring the parameters and commissioning it, as well as service and
maintenance engineers.
1.2
Product compatibility
Manual
edition
Remarks
Device revision
Compatible version of device integration package
08/2017 New features Modbus
FW: 1.00.00 or later
HW: 02 or later
SIMATIC PDM V8.2
1.00.00 or later
AMS Device Manager 12.0
1.00.00 or later
SITRANS DTM V4.1
1.00.00 or later
Field communicator V3.8
1.00.00 or later
02/2017 First edition Modbus
FW: 1.00.00
SIMATIC PDM V8.2
1.00.00 or later
AMS Device Manager 12.0
1.00.00 or later

Introduction
1.3 Document history
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
10 Operating Instructions, 08/2017, A5E37367739-AC
Manual
edition
Remarks
Device revision
Compatible version of device integration package
HW: 01
SITRANS DTM V4.1
1.00.00 or later
Field communicator V3.8 1.00.00 or later
1.3
Document history
The following table shows major changes in the documentation compared to the previous
edition.
The most important changes in the documentation when compared with the respective
previous edition are given in the following table.
Edition
Note
08/2017 •
Chapter: Safety notes. Use in hazardous areas. Special conditions for safe use. Added: Must be installed
in accordance with Siemens control drawing A5E32778336A.
02/2017 •First edition

Introduction
1.4 Device documentation package
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 11
1.4
Device documentation package
The user documentation package for this product includes the following documents
Document
Purpose
Intended users
Availability
Operating Instruc-
tions
Contains all information needed to
•check and identify the delivered pack-
age
•install and electrically connect the
product
•commission the product, (setting pa-
rameters via HMI menu)
•operate and maintain the device on a
daily basis
•troubleshoot and remedy minor opera-
tion interruptions
Instrument techni-
cians, plant opera-
tors
•Available for download from
homepage
•Hardcopy can be purchased
via PIA Life Cycle Portal
(only English and German
versions)
Compact Operating
Instructions - Ex
Contains all information needed to
•satisfy the Special conditions for instal-
lation of Ex-certified products
Instrument techni-
cians, plant opera-
tors with special
training in systems
for hazardous are-
as.
•On documentation disk
•Available for download from
homepage
•Hardcopy can be ordered
via PIA Life Cycle Portal
Functions Manual Contains
•descriptions of all functions that can be
accessed via the local display (HMI)
•guide to setting parameters to obtain
optimum operation of the device
Instrument techni-
cians, plant opera-
tors
•Available for download from
homepage
1.5
Items supplied
The device is delivered as:
Wall mount enclosure
With internal DSL (Digital Sensor Link)
•
SITRANS FST030 wall mount enclosure
transmitter with internal DSL
•
Siemens Process Instrumentation
documentation disk containing certificates,
and manuals for ATEX approved devices

Introduction
1.6 Checking the consignment
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
12 Operating Instructions, 08/2017, A5E37367739-AC
Note
Supplementary information
Supplementary product and production specific certificate
s are included on the SensorFlash
®
SD card in the transmitter socket.
Note
Scope of delivery may vary, depending on version and add
-ons. Make sure the scope of
delivery and the information on the nameplate correspond to your order and the delivery
not
e.
Note
The SD
-Card Mass Storage functionality has been disabled by SIEMENS on all products
sold or imported in the United States. Products having enabled SD
-Card Mass storage
functionality are intended to be used solely outside the United States and s
hould not be
imported into the United States by the user. SIEMENS expressly prohibits customers from
using, importing, or buying products with the SD
-Card Mass Storage functionality in the
United States or performing any acts to enable the SD
-Card Mass Storage functionality on
products sold by SIEMENS with this feature disabled.
1.6
Checking the consignment
1. Check the packaging and the delivered items for visible damage.
2. Report any claims for damages immediately to the shipping company.
3. Retain damaged parts for clarification.
4. Check the scope of delivery by comparing your order to the shipping documents for
correctness and completeness.
WARNING
Using a damaged or incomplete device
Risk of explosion in hazardous areas. May cause death or serious injury.
•Do not use damaged or incomplete devices.
1.7
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines, and networks.

Introduction
1.8 Transportation and storage
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 13
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines
and networks. Systems, machines and components should only be connected to the
enterprise network or the internet if and to the extent necessary and with appropriate security
measures (e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit:
http://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends to apply product updates as soon as available and to
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
http://www.siemens.com/industrialsecurity.
1.8
Transportation and storage
To guarantee sufficient protection during transport and storage, observe the following:
●Keep the original packaging for subsequent transportation.
●Devices/replacement parts should be returned in their original packaging.
●If the original packaging is no longer available, ensure that all shipments are properly
packaged to provide sufficient protection during transport. Siemens cannot assume
liability for any costs associated with transportation damages.
NOTICE
Insufficient protection during storage
The packaging only provides limited protection against moisture and infiltration.
•Provide additional packaging as necessary.
Special conditions for storage and transportation of the device are listed in Technical data
(Page 115).
CAUTION
Protection of transmitter parts
The styrofoam parts in the transmitter are NOT packaging material.
•Do not remove styrofoam parts.

Introduction
1.9 Notes on warranty
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
14 Operating Instructions, 08/2017, A5E37367739-AC
1.9
Notes on warranty
The contents of this manual shall not become part of or modify any prior or existing
agreement, commitment or legal relationship. The sales contract contains all obligations on
the part of Siemens as well as the complete and solely applicable warranty conditions. Any
statements regarding device versions described in the manual do not create new warranties
or modify the existing warranty.
The content reflects the technical status at the time of publishing. Siemens reserves the right
to make technical changes in the course of further development.

SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 15
Safety notes
2
2.1
Preconditions for safe use
This device left the factory in good working condition. In order to maintain this status and to
ensure safe operation of the device, observe these instructions and all the specifications
relevant to safety.
Observe the information and symbols on the device. Do not remove any information or
symbols from the device. Always keep the information and symbols in a completely legible
state.
2.1.1
Warning symbols on the device
Symbol
Explanation
Consult operating instructions
2.1.2
Improper device modifications
WARNING
Improper device modifications
Risk of explosion in hazardous areas. May cause death or serious injury.
Risk to personnel, system and environment can result from modifications to the device,
particularly in hazardous areas.
•Only carry out modifications that are described in the instructions for the device. Failure
to observe this requirement cancels the manufacturer's warranty and the product
approvals.

Safety notes
2.2 Laws and directives
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
16 Operating Instructions, 08/2017, A5E37367739-AC
2.2
Laws and directives
Observe the safety rules, provisions and laws applicable in your country during connection,
assembly and operation. These include, for example:
●National Electrical Code (NEC - NFPA 70) (USA)
●Canadian Electrical Code (CEC) (Canada)
Further provisions for hazardous area applications are for example:
●IEC 60079-14 (international)
●EN 60079-14 (EC)
2.2.1
FCC Conformity
US Installations only: Federal Communications Commission (FCC) rules
Note
•
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
•
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the operating instructions, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference to radio communications, in which case the user will
be required to correct the interference at his own expense.
2.2.2
Conformity with European directives
The CE marking on the device symbolizes the conformity with the following European
directives:
Electromagnetic
compatibility EMC
2014/30/EU
Directive of the European Parliament and of the Council on the harm
o-
nisation of the laws of the Member States relating to electr
omagnetic
compatibility
Low voltage d
i-
rective LVD
2014/35/EU
Directive of the European Parliament and of the Council on the harm
o-
nisation of the laws of the Member States relating to the making avail
a-
ble on the market of electrical equipment designed for use within certain
voltage limits
Atmosphère expl
o-
sible ATEX
2014/34/EU
Directive of the European Parliament and the Council on the harmonisa-
tion of the laws of the Member States relating to equipment and prote
c-
tive systems intended for use in potentially explosive atmospheres

Safety notes
2.3 Requirements for special applications
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
Operating Instructions, 08/2017, A5E37367739-AC 17
The applicable directives can be found in the EC conformity declaration of the specific d
e-
vice.
RoHS directive
2011/65/EU
Directive of the European Parliament and the Council on the r
estriction
of the use of certain hazardous substances in electrical
and electronic
equipment.
Note
CE declaration
The CE declaration certificate is available on the SensorFlash SD card delivered with the
device.
2.3
Requirements for special applications
Due to the large number of possible applications, each detail of the described device
versions for each possible scenario during commissioning, operation, maintenance or
operation in systems cannot be considered in the instructions. If you need additional
information not covered by these instructions, contact your local Siemens office or company
representative.
Note
Operation under special ambient conditions
We highly recommend that you contact your Siemens representative or our application
department before you operate the device under special ambient conditions as c
an be
encountered in nuclear power plants or when the device is used for research and
development purposes.
2.4
Use in hazardous areas
Qualified personnel for hazardous area applications
Persons who install, connect, commission, operate, and service the device in a hazardous
area must have the following specific qualifications:
●They are authorized, trained or instructed in operating and maintaining devices and
systems according to the safety regulations for electrical circuits, high pressures,
aggressive, and hazardous media.
●They are authorized, trained, or instructed in carrying out work on electrical circuits for
hazardous systems.
●They are trained or instructed in maintenance and use of appropriate safety equipment
according to the pertinent safety regulations.

Safety notes
2.4 Use in hazardous areas
SITRANS F Ultrasonic flowmeters FST030 (Modbus)
18 Operating Instructions, 08/2017, A5E37367739-AC
2.4.1
Use in hazardous areas
WARNING
Use in hazardous areas
Risk of explosion. May cause death or serious injury.
•Only use equipment that is approved for use in the intended hazardous area and
labelled accordingly.
2.4.2
Loss of safety of device with type of protection "Intrinsic safety Ex i"
WARNING
Loss of safety of device with type of protection "Intrinsic safety Ex i"
Risk of explosion May cause death or serious injury.
If the device has already been operated in non-intrinsically safe circuits or the electrical
specifications have not been observed, the safety of the device is no longer ensur
ed for use
in hazardous areas. There is a risk of explosion.
•Connect the device with type of protection "Intrinsic safety" solely to an intrinsically safe
circuit.
•Observe the specifications for the electrical data on the certificate and/or in Technical
data (Page 115).
Special conditions for safe use
In general, it is required that:
●The terminal space may be opened when an explosive gas or dust atmosphere may be
present at any time. Access power terminals by lifting the cover only when de-energized.
●Appropriate cable connectors are used.
●Substitution of components may impair Intrinsic Safety.
●Sensor and transmitter are connected to the potential equalization throughout the
hazardous area.
●EN/IEC 60079-14 is considered for installation in hazardous areas.
Must be installed in accordance with Siemens control drawing A5E32778336A
