Siemens SCALANCE X101-1 User manual

SCALANCE X-100 media converter
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC NET
Industrial Ethernet switches
SCALANCE X-100 media converter
Operating Instructions
04/2016
C79000
-G8976-C346-02
Introduction
1
Network topologies
2
Description of the device
3
Installation
4
Connecting up
5
Maintenance
6
Technical specifications
7
Approvals
8
Dimension drawings
9

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 3
Table of contents
1 Introduction............................................................................................................................................. 5
1.1 On the Operating Instructions...................................................................................................5
1.2 On the product ..........................................................................................................................7
2 Network topologies ............................................................................................................................... 11
2.1 Possible network topologies ...................................................................................................11
2.2 Coupling of network segments ...............................................................................................14
3 Description of the device....................................................................................................................... 15
3.1 Overview of the SCALANCE X-100 media converters ...........................................................15
3.2 Product characteristics............................................................................................................16
3.2.1 SCALANCE X101-1................................................................................................................16
3.2.2 SCALANCE X101-1LD ...........................................................................................................17
3.3 TP ports (twisted pair).............................................................................................................18
3.4 FO port (fiber optic).................................................................................................................20
3.4.1 SCALANCE X101-1................................................................................................................20
3.4.2 SCALANCE X101-1LD ...........................................................................................................21
3.5 LEDs .......................................................................................................................................22
3.6 SET button ..............................................................................................................................24
3.7 Cascading two media converters............................................................................................26
4 Installation ............................................................................................................................................ 27
4.1 Types of installation ................................................................................................................27
4.2 Installation on a DIN rail..........................................................................................................28
4.3 Installation on a standard rail..................................................................................................30
4.4 Wall mounting .........................................................................................................................31
5 Connecting up....................................................................................................................................... 33
5.1 Wiring rules .............................................................................................................................33
5.2 Power supply ..........................................................................................................................33
5.3 Signaling contact.....................................................................................................................35
5.4 Grounding ...............................................................................................................................36
5.5 IE FC RJ-45 Plug 180.............................................................................................................36
6 Maintenance ......................................................................................................................................... 39
7 Technical specifications ........................................................................................................................ 41
7.1 SCALANCE X101-1................................................................................................................41

Table of contents
SCALANCE X-100 media converter
4Operating Instructions, 04/2016, C79000-G8976-C346-02
7.2 SCALANCE X101-1LD .......................................................................................................... 43
8 Approvals ............................................................................................................................................. 47
9 Dimension drawings.............................................................................................................................. 51
Index .................................................................................................................................................... 55

SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 5
Introduction
1
1.1
On the Operating Instructions
Purpose of the Operating Instructions
These operating instructions support you when commissioning networks with the media
converters of the SCALANCE X-100.
Validity of the Operating Instructions
These operating instructions are valid for the following devices:
Device
Article number
SCALANCE X101-1 6GK5101-1BB00-2AA3
SCALANCE X101-1LD
6GK5101-1BC00-2AA3
Further documentation
The "SIMATIC NET Industrial Ethernet Twisted Pair and Fiber Optic Networks" manual
contains additional information on other SIMATIC NET products that you can operate along
with the media converters of the SCALANCE X-100 product line in an Industrial Ethernet
network.
You can order the manual "SIMATIC NET Industrial Twisted Pair and Fiber Optic Networks",
release 05/2001, using the following order numbers:
6GK1970-1BA10-0AA0 German
6GK1970-1BA10-0AA1 English
6GK1970-1BA10-0AA2 French
6GK1970-1BA10-0AA4 Italian
You will also find this network manual on the Internet pages of Service & Support under the
following entry ID: 1172207 (http://support.automation.siemens.com/WW/view/en/1172207).
You will find further information in the "System Manual Industrial Ethernet" in the Manual
Collection.
You will find further information on the SCALANCE system on the Internet at
www.siemens.com/scalance (www.siemens.com/scalance).
You can obtain the "PROFINET Installation Guide" from the PROFIBUS User Organization
(PNO).
Audience
These Operating Instructions are intended for persons commissioning networks with
SCALANCE X-100 media converters.

Introduction
1.1 On the Operating Instructions
SCALANCE X-100 media converter
6Operating Instructions, 04/2016, C79000-G8976-C346-02
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary on the Internet at the following address:
50305045 (http://support.automation.siemens.com/WW/view/en/50305045)
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, solutions, machines, equipment and/or networks. They are
important components in a holistic industrial security concept. With this in mind, Siemens’
products and solutions undergo continuous development. Siemens recommends strongly
that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable
preventive action (e.g. cell protection concept) and integrate each component into a holistic,
state-of-the-art industrial security concept. Third-party products that may be in use should
also be considered. You will find more information about Industrial Security in:
Industrial security (http://www.siemens.com/industrialsecurity)
To stay informed about product updates as they occur, sign up for a product-specific
newsletter. You will find more information about this in
Product support (https://support.industry.siemens.com/cs/ww/en/ps/15247/pm)

Introduction
1.2 On the product
SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 7
1.2
On the product
What is possible?
The media converters of the SCALANCE X-100 allow the cost-effective installation of
Industrial Ethernet linear (bus) and star structures with transitions from one media to
another.
The passive use of two identical SCALANCE X-100 media converters in series (cascaded)
within a redundant ring is possible. In this case, the media converters behave "like a section
of cable". A simple, passive coupling of two rings is also possible. See also "Coupling of
network segments (Page 14)".
Note
If devices are supplied over long 24 V power supply lines or networks, measures are
necessary to prevent interference by strong electromagnetic pulses on the supply lines.
These can result, for example, due to lightning or switching of large inductive load
s.
One of the tests used to attest the immunity of these devices to electromagnetic interference
is the "surge immunity test" according to EN 61000
-4-5. This test requires overvoltage
protection for the power supply lines. A suitable device is, for exampl
e, the Dehn Blitzductor
BVT AVD 24 V type no. 918 422 or a comparable protective element.
Manufacturer:
DEHN+SÖHNE GmbH+Co.KG Hans Dehn Str.1 Postfach 1640 D
-92306 Neumarkt,
Germany
WARNING
When used in hazardous environments corresponding to Class I, Division 2 or Class I,
Zone 2, the device must be installed in a cabinet or a suitable enclosure.
WARNING
To comply with EU Directive 94/9 (ATEX95), this enclosure must meet the requirements of
at least IP54 in compliance with EN 60529.
WARNING
EXPLOSION HAZARD
DO NOT CONNECT OR DISCONNECT EQUIPMENT WHEN A FLAMMABLE OR
COMBUSTIBLE ATMOSPHERE IS PRESENT.

Introduction
1.2 On the product
SCALANCE X-100 media converter
8Operating Instructions, 04/2016, C79000-G8976-C346-02
WARNING
Ambient temperature above 55 °C
If a device is operated in an ambient temperature of more than 55 °C, the temperature of
the device housing may be higher than 70 °C. The device must therefore be installed so
that it is only accessible to service personnel or users that are aware of the reason for
restricted access and the required safety measures at an ambient temperature higher than
55 °C.
Scope of delivery
The following components are supplied with a SCALANCE X-100 media converter:
●SCALANCE X-100 media converter
●2-pin plug-in terminal block (signaling contact)
●4-terminal plug-in block (power supply)
●Product information
Accessories
Component
Packaging unit
Article number
IE FC Stripping Tool
1
6GK1 901-1GA00
IE FC blade cassettes
1
6GK1 901-1GB00
IE FC TP standard cable GP
1
6XV1 840 2AH10
IE FC TP trailing cable
1
6XV1 840-3AH10
IE FC TP marine cable
1
6XV1 840-4AH10
IE FC TP trailing cable GP
1
6XV1 870-2D
IE FC TP flexible cable GP 1 6XV1 870-2B
IE FC RJ-45 Plug 180
1
6GK1 901-1BB10-2AA0
IE FC RJ-45 Plug 180
10
6GK1 901-1BB10-2AB0
IE FC RJ-45 Plug 180
50
6GK1 901-1BB10-2AE0

Introduction
1.2 On the product
SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 9
Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to
the specification.
If you use damaged parts, this can lead to the following problems:
•Injury to persons
•Loss of the approvals
•Violation of the EMC regulations
•Damage to the device and other components
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
•Touch electronic modules only when you absolutely need to work on them.
•If electronic modules need to be touched, the body of the person involved must first be
electrostatically discharged and grounded.
•Do not bring electronic modules in contact with electrically isolating materials such as
plastic film, isolating table top pads or clothing made of synthetic fibers.
•Place the modules only on conductive surfaces.
•Pack, store and transport electronic modules and components only in conductive
packaging such as metalized plastic or metal containers, conductive foam or household
aluminum foil.

Introduction
1.2 On the product
SCALANCE X-100 media converter
10 Operating Instructions, 04/2016, C79000-G8976-C346-02

SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 11
Network topologies
2
2.1
Possible network topologies
Switching technology allows extensive networks to be set up with numerous nodes and
simplifies network expansion.
Which topologies can be implemented?
Using the media converters of the SCALANCE X-100 product line, you can implement bus
and star topologies. It is also possible to link rings and to use two identical media converters
in a ring structure. See also "Cascading two media converters (Page 26)".
Note
Keep to the maximum permitted cable lengths of the devices you are
using. You will find the
permitted cable lengths in the section "
Technical specifications (Page 41)".
Bus topology
Figure 2-1 Example of an electrical/optical bus topology with SCALANCE X101-1

Network topologies
2.1 Possible network topologies
SCALANCE X-100 media converter
12 Operating Instructions, 04/2016, C79000-G8976-C346-02
Star topology
The following figure shows an optical star structure with the IE switches X-400 and X106-1.
A SCALANCE W access point and SIMATIC NET 200 systems are electrically connected via
the media converters SCALANCE X101-1 or SCALANCE X101-1LD.
Figure 2-2 Example of an optical star topology with SCALANCE X101-1 or SCALANCE X101-1LD

Network topologies
2.1 Possible network topologies
SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 13
Ring topology
The following figure shows an electrical ring with a SCALANCE X204IRT as redundancy
manager and SCALANCE X208 IE switches. Using the media converters SCALANCE X101-
1 or SCALANCE X101-1LD, there is a conversion to an optical section.
Figure 2-3 Example of an electrical ring with SCALANCE X101-1 or SCALANCE X101-1LD

Network topologies
2.2 Coupling of network segments
SCALANCE X-100 media converter
14 Operating Instructions, 04/2016, C79000-G8976-C346-02
2.2
Coupling of network segments
The example of a coupling between two ring networks using two SCALANCE X101-1 media
converters is only indirectly possible via nodes capable of redundancy (e.g. SCALANCE X-
400). This applies to all SCALANCE X-100 media converters.
The following figure shows the standby coupling of two redundant rings using the
master/slave concept of the SCALANCE X-400 with SCALANCE X101-1 or SCALANCE
X101-1LD media converters.
Figure 2-4 Example of a standby coupling of two redundant rings

SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 15
Description of the device
3
3.1
Overview of the SCALANCE X-100 media converters
Table 3- 1 Overview of the product characteristics
Properties
X101-1
X101-1LD
SIMATIC environment + +
Diagnostics LED
+
+
24 VDC
+
+
2 x 24 VDC
+
+
Compact housing 40 mm (securing collar, etc.)
+
+
Signaling contact + on-site operation
+
+
Diagnostics: Web, SNMP, PROFINET
-
-
C-PLUG
-
-
Ring redundancy with RM
-
-
Passive ring redundancy
+
+
Standby redundancy
-
-
IRT capability
-
-
Fast learning
-
-
Passive listening
-
-
Log table
-
-
SNTP + SICLOCK
-
-
Cut Through
+
+
Table 3- 2 Overview of the connection options
X101-1
X101-1LD
TP (RJ-45)
Fast Ethernet 10 / 100 Mbps
1 1
Fiber multimode (BFOC)
1300 nm
1 -
Fiber long distance single mode (BFOC)
1310 nm
- 1

Description of the device
3.2 Product characteristics
SCALANCE X-100 media converter
16 Operating Instructions, 04/2016, C79000-G8976-C346-02
3.2
Product characteristics
3.2.1
SCALANCE X101-1
Possible attachments
The SCALANCE X101-1 media converter has an RJ-45 jack and a BFOC socket for
connecting end devices or further network segments.
Note
The BFOC socket (Bayonet
Fiber Optic Connector) corresponds to the ST socket.
Figure 3-1 SCALANCE X101-1

Description of the device
3.2 Product characteristics
SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 17
3.2.2
SCALANCE X101-1LD
Possible attachments
The SCALANCE X101-1LD media converter has an RJ-45 jack and a BFOC socket for
connecting end devices or further network segments.
Note
The BFOC socket (Bayonet Fiber Optic Connector) corresponds to the ST socket.
Figure 3-2 SCALANCE X101-1LD

Description of the device
3.3 TP ports (twisted pair)
SCALANCE X-100 media converter
18 Operating Instructions, 04/2016, C79000-G8976-C346-02
3.3
TP ports (twisted pair)
RJ-45 connector pinout
With SCALANCE X-100 media converters, the twisted-pair port is designed as an RJ-45 jack
with the MDI-X pin assignment (Medium Dependent Interface Autocrossover) of a network
component.
Pin number
Assignment
Pin 8
n. c.
Pin 7
n. c.
Pin 6
TD-
Pin 5
n. c.
Pin 4
n. c.
Pin 3
TD+
Pin 2
RD-
Pin 1
RD+
Note
Permitted cable lengths
TP cords or TP
-XP cords with a maximum length of 10 m can be connected to the TP port
with the RJ
-45 jack.
With the IE FC cables and IE FC RJ
-45 plugs 180, an overall cable length of a maximum of
100 m is permitted between two devices depending on the cab
le type.
Autonegotiation
With the autonegotiation mechanism, repeaters and end devices can automatically
determine the transmission speed and the transmission mode of the partner port. This
makes it possible to configure different devices automatically.

Description of the device
3.3 TP ports (twisted pair)
SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02 19
Two components connected to a link segment can exchange information about the data
transfer and can adapt their settings to each other. The mode with the highest possible
speed is set.
Note
Devices not supporting autonegotiation
must be set permanently to 100 Mbps half duplex or
10
Mbps half duplex.
Auto polarity exchange
If the pair of receiving cables is connected incorrectly (RD+ and RD- interchanged), the
polarity is adapted automatically.
MDI / MDI-X autocrossover function
With the MPI/MDI-X autocrossover function, the send and receive contacts of an Ethernet
port are assigned automatically. The assignment depends on the cable with which the
communications partner is connected. This means that it does not matter whether the port is
connected using a patch cable or crossover cable. This prevents malfunctions resulting from
mismatching send and receive lines. This makes installation much easier for the user.
The SCALANCE X-100 media converters all support the MDI / MDI-X autocrossover
function.

Description of the device
3.4 FO port (fiber optic)
SCALANCE X-100 media converter
20 Operating Instructions, 04/2016, C79000-G8976-C346-02
3.4
FO port (fiber optic)
NOTICE
Failure of the data traffic due to contamination of optical plug-in connections
Optical sockets and plugs are sensitive to contamination of the end face. Contamination
can lead to the failure of the optical transmission network.
Close unused optical sockets and plugs as well as pluggable transceivers and slots with the
supplied protective caps.
Remove the protective caps only immediately before you use the plug-in connection.
3.4.1
SCALANCE X101-1
Transmission speed
The transmission speed of the optical Fast Ethernet port is 100 Mbps.
Transmission mode
The transmission mode for 100Base-FX is specified in the IEEE 802.3 standard.
Since the full duplex mode and the transmission speed cannot be modified for optical
transmission, autonegotiation cannot be used.
Transmission medium
Data transmission is via multimode fiber-optic cable (FO cable). The transceiver wavelength
is 1300 nm.
Multimode FO cable is used with a core diameter of 50 or 62.5 µm. The light source is an
LED.
The outer diameter of the FO cable is 125 µm.
Range
The maximum transmission range (segment length) is as follows:
●with 62.5/125 µm fiber multimode SIMATIC NET cable: 4 km
●with 50.0/125 µm fiber multimode SIMATIC NET cable: 5 km
Connectors
The cables are connected using BFOC sockets.
