SIMATIC NET
Network components
SCALANCE XCM-100 Media
Converter
Equipment Manual
12/2023
C79000-G8976-C659-03
Introduction 1
Safety instructions 2
Area of application 3
Device description 4
Installation and
disassembly 5
Connecting 6
Maintenance and cleaning 7
Technical speci󹪝cations 8
Dimension drawings 9
Approvals 10

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of SiemensAktiengesellschaft. The remaining trademarks in
this publication may be trademarks whose use by third parties for their own purposes could violate the rights of
the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens Aktiengesellschaft
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C659-03
Ⓟ 12/2023 Subject to change
Copyright © Siemens 2022 - 2023.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
1.1 Designations used................................................................................................................ 5
1.2 Trademarks.......................................................................................................................... 5
1.3 SIMATIC NET glossary........................................................................................................... 5
1.4 Cybersecurity information.................................................................................................... 6
1.5 Recycling and disposal ......................................................................................................... 6
1.6 Electrostatic discharge ......................................................................................................... 7
2 Safety instructions................................................................................................................................. 9
3 Area of application .............................................................................................................................. 11
3.1 Modes ............................................................................................................................... 11
3.2 Throughput times .............................................................................................................. 11
3.3 Standalone operation of a SCALANCE XCM-100.................................................................. 12
3.4 Cascade (series connection) of two SCALANCE XCM-100 .................................................... 13
3.5 Network topologies............................................................................................................ 14
3.5.1 Bus topology...................................................................................................................... 14
3.5.2 Star topology ..................................................................................................................... 15
3.5.3 Ring Topology.................................................................................................................... 16
3.5.4 Standby coupling ............................................................................................................... 17
4 Device description ............................................................................................................................... 19
4.1 Purpose ............................................................................................................................. 19
4.2 Article numbers ................................................................................................................. 19
4.3 Product properties ............................................................................................................. 19
4.4 Scope of delivery ............................................................................................................... 20
4.5 Device view ....................................................................................................................... 21
4.6 LED display ........................................................................................................................ 22
4.7 SELECT/SET button............................................................................................................. 23
4.8 Accessories........................................................................................................................ 24
5 Installation and disassembly ............................................................................................................... 29
5.1 Safety notices for installation ............................................................................................. 29
5.2 Mounting types ................................................................................................................. 32
5.3 DIN rail mounting .............................................................................................................. 33
5.4 Installing on an S7-300 mounting rail................................................................................. 35
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 3

5.5 Installing on an S7-1500 mounting rail............................................................................... 37
5.6 Wall mounting ................................................................................................................... 39
5.7 Removal ............................................................................................................................ 40
6 Connecting .......................................................................................................................................... 41
6.1 Safety instructions for operation with a power supply according to NEC Class 2................... 41
6.2 Safety instructions for operation with a power supply according to SELV ............................. 42
6.3 Safety instructions on use in hazardous areas ..................................................................... 43
6.4 Additional notes................................................................................................................. 45
6.5 Wiring rules ....................................................................................................................... 46
6.6 Power supply 24 V AC / 24 V DC and grounding .................................................................. 47
6.7 Signaling contact ............................................................................................................... 49
6.8 TP port (twisted pair port) .................................................................................................. 50
6.9 SFP port............................................................................................................................. 51
7 Maintenance and cleaning .................................................................................................................. 53
8 Technical speci󹪝cations ....................................................................................................................... 55
8.1 Technical speci󹪝cations of SCALANCE XCM102................................................................... 55
8.2 Mechanical stability (in operation) ..................................................................................... 57
8.3 RF radiation according to NAMUR NE21.............................................................................. 57
8.4 Cable lengths..................................................................................................................... 57
9 Dimension drawings............................................................................................................................ 59
10 Approvals............................................................................................................................................. 61
Index .................................................................................................................................................... 69
Table of contents
SCALANCE XCM-100 Media Converter
4Equipment Manual, 12/2023, C79000-G8976-C659-03

Introduction 1
Scope of validity
These operating instructions apply to the following devices:
• SCALANCE XCM102
Unless mentioned otherwise, the descriptions in these operating instructions refer to
all devices of the SCALANCE XCM-100 product group speci󹪝ed in the scope of validity.
1.1 Designations used
This section describes the conventions used in this document to clearly and e󹪟ciently portray
information.
Classi󹪝ca‐
tion
Description Terms used
Product
group
If information applies to all devices and versions of a product
group, the term SCALANCE XCM-100 is used.
SCALANCE XCM-100
Device If information relates to a speci󹪝c device, the device name is
used.
e.g. SCALANCE XCM102
1.2 Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
• SCALANCE
• SINEC
1.3 SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will 󹪝nd the SIMATIC NET glossary here:
• SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
• On the Internet under the following address:
50305045 (https://support.industry.siemens.com/cs/ww/en/view/50305045)
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 5

1.4 Cybersecurity information
Siemens provides products and solutions with industrial cybersecurity functions that support
the secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
cybersecurity concept. Siemens’ products and solutions constitute one element of such a
concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation)
are in place.
For additional information on industrial cybersecurity measures that may be implemented,
please visit
https://www.siemens.com/cybersecurity-industry.
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer’s exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity
RSS Feed under
https://new.siemens.com/cert.
1.5 Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return).
Note the di󹪜erent national regulations.
Introduction
1.5Recycling and disposal
SCALANCE XCM-100 Media Converter
6Equipment Manual, 12/2023, C79000-G8976-C659-03

1.6 Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
• Touch electronic modules only when you absolutely need to work on them.
• If electronic modules need to be touched, the body of the person involved must 󹪝rst be
electrostatically discharged and grounded.
• Do not bring electronic modules in contact with electrically isolating materials such as
plastic 󹪝lm, isolating table top pads or clothing made of synthetic 󹪝bers.
• Place the modules only on conductive surfaces.
• Pack, store and transport electronic modules and components only in conductive packaging
such as metalized plastic or metal containers, conductive foam or household aluminum foil.
Introduction
1.6Electrostatic discharge
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 7

Introduction
1.6Electrostatic discharge
SCALANCE XCM-100 Media Converter
8Equipment Manual, 12/2023, C79000-G8976-C659-03

Safety instructions 2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury and damage, read the manual before using the device.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Do not open the device when the supply voltage is turned on.
Safety instructions for use in hazardous locations according to UL/FM HazLoc
If you use the device under UL or FM HazLoc conditions, you must also adhere to the
following safety instructions in addition to the general safety instructions for protection
against explosion:
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-hazardous
locations only.
This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations only.
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 9

Safety instructions
SCALANCE XCM-100 Media Converter
10 Equipment Manual, 12/2023, C79000-G8976-C659-03

Area of application 3
SCALANCE XCM-100 media converters convert electrical signals into optical signals.
The media converters have two ports:
• Port1 for electrical connections (100/1000 Mbps copper)
• Port2 for optical connections (100/1000 Mbps SFP transceiver)
Individual, remote end devices or network segments can be connected via the optical port
of a SCALANCE XCM-100. With two coupled media converters, it is possible to integrate an
optical link into a redundant ring.
In addition, integration of the SCALANCE XCM-100 media converters into a standby coupling
is possible. This requires redundancy-capable stations, e.g. devices of the SCALANCE XM-400
series.
For more information, refer to "Network topologies (Page14)".
3.1 Modes
There are two operating modes with SCALANCE XCM-100:
•Fast Ethernet
•Gigabit Ethernet
Depending on which SFP transceivers are plugged into a SCALANCE XCM-100, the operating
mode is set accordingly:
• SFP991-1* → operating mode Fast Ethernet
• SFP992-2* → operating mode Gigabit Ethernet
The media converter converts the frames without bu󹪜ering them internally. Therefore, the
transmission speed for the optical and the electrical connection must be identical.
The link for the two ports of the media converter is only displayed when both sides of a
media converter have been connected correctly.
3.2 Throughput times
The SCALANCE XCM-100 media converters are characterized by a low and constant throughput
time. There are di󹪜erent runtimes for the operating modes.
Standalone operation
Direction Fast Ethernet Gigabit Ethernet
Receive optical → Send electrical 730 ns +/- 60 ns 195 ns +/- 20 ns
Receive electrical → Send optical 910 ns +/- 60 ns 345 ns +/- 20 ns
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 11

Cascade
For operation with two coupled media converters, the following values result for the overall
runtimes:
Direction Fast Ethernet Gigabit Ethernet
In both directions 1640 ns +/- 120 ns 550 ns +/- 40 ns
3.3 Standalone operation of a SCALANCE XCM-100
In standalone operation, a SCALANCE XCM-100 connects two partner devices with di󹪜erent
transmission media:
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
①SCALANCE XCM102
②Partner device (optical connection)
③Partner device (electrical connection)
The media converter does not adapt the transmission speed between the connected
partners. Make sure that the transmission speed of the two connected partners is identical.
If the connection status for one of the two ports changes (link up or link down), this change
also takes e󹪜ect for the other port without signi󹪝cant time delay.
Observe the following rules for Fast Ethernet operating mode:
• Make sure that a suitable SFP transceiver of the type SFP991-1* is installed for the partner
device of the optical connection.
• Make sure that the correct optical cable is used.
• Make sure that autonegotiation is enabled for the partner device of the optical connection.
• The media converter ensures that the Fast Ethernet link is set via autonegotiation. This
applies to partner devices with Fast Ethernet and Gigabit Ethernet.
Observe the following rules for Gigabit Ethernet operating mode:
• Make sure that a suitable SFP transceiver of the type SFP992-1* is installed for the partner
device of the optical connection.
• Make sure that the correct optical cable is used.
• Make sure that the partner device of the electrical connection is Gigabit-capable and the
con󹪝guration in the device is not restricted to Fast Ethernet.
Area of application
3.3Standalone operation of a SCALANCE XCM-100
SCALANCE XCM-100 Media Converter
12 Equipment Manual, 12/2023, C79000-G8976-C659-03

• Make sure that an 8-core copper cable is used.
• The media converter only establishes one GigabitEthernet link via autonegotiation.
3.4 Cascade (series connection) of two SCALANCE XCM-100
You can connect two media converters in series. Coupling of the two media converters is usually
performed over its optical ports. Coupling over the electrical ports is also possible (repeater for
optical links). The coupled SCALANCE XCM-100 are operated between two partner devices:
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
①SCALANCE XCM102
②Partner device (electrical connection)
The same SFP transceiver must be plugged into both media converters.
A maximum of two SCALANCE XCM-100 can be connected in series. Mixed operation of
SCALANCE XCM-100 with SCALANCE X101-1/X101-1LD is not possible.
Because the SFP ports are connected to each other, both media converters switch the
connection status (link up or link down) at almost the same time. Delays only occur due
to the length of the optical connection or the duration of link establishment on the electrical
ports of the media converters.
Observe the following rules for Fast Ethernet operating mode:
• Use an SFP transceiver of the type SFP991-1* between the two media converters.
• Make sure that the correct optical cable is used.
• Make sure that autonegotiation is enabled for the partner devices of the electrical
connections.
• The media converters ensure that the Fast Ethernet link is set via autonegotiation. This
applies to partner devices with Fast Ethernet and Gigabit Ethernet.
Observe the following rules for Gigabit Ethernet operating mode:
• Use an SFP transceiver of the type SFP992-1* between the two media converters.
• Make sure that the correct optical cable is used.
• Make sure that the partner devices of the electrical connections are Gigabit-capable and the
con󹪝guration of the devices is not restricted to Fast Ethernet.
Area of application
3.4Cascade (series connection) of two SCALANCE XCM-100
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 13

• Make sure that an 8-core copper cable is used in each case.
• The media converter only establishes one GigabitEthernet link via autonegotiation.
3.5 Network topologies
You can build the following topologies with the SCALANCE XCM-100 series media converters:
• Line
• Star
• Ring (with series connection)
• Standby coupling(with series connection)
Note
Adhere to the maximum permissible cable lengths for the respective devices. You can 󹪝nd
information about the maximum cable length in the section "Cable lengths (Page57)".
3.5.1 Bus topology
The following example shows a line topology.
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
①SCALANCE XC208
②SCALANCE XCM102
③SCALANCE XC206-2SFP
④SCALANCE XCM102
⑤SIMATIC S7-1500
Figure3-1 Line topology with electrical und optical cables and two SCALANCE XCM102
In this example, a SCALANCE XC208 ① is connected to a media converter ②. A SCALANCE
XC208 has only Fast Ethernet ports. Therefore, the media converter that is connected to
the SCALANCE XC208 can only work in Fast Ethernet mode. An SFP transceiver of the
type SFP991-1* must be inserted in each case between the media converter ② and the
SCALANCE XC206-2SFP ③.
Area of application
3.5Network topologies
SCALANCE XCM-100 Media Converter
14 Equipment Manual, 12/2023, C79000-G8976-C659-03

The media converter ④ is connected to an XC206-2SFP ③ and a SIMATIC S7-1500 ⑤.
The two devices ③ and ⑤ are Gigabit capable. The media converter can therefore work in
Gigabit Ethernet mode. Use an SFP transceiver of the type SFP992-1* between the media
converter ④ and the SCALANCE XC206-2SFP ③.
3.5.2 Star topology
The following example shows an optical star topology. SCALANCE XCM102 media converters
allow the connection of the devices with twisted pair cables.
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
①SCALANCE XCM102 (operating mode: Fast Ethernet)
②SCALANCE XCM102 (operating mode: Gigabit Ethernet)
③SCALANCE XM408-8C
④SIMATIC S7-1500
⑤SIMATIC IOT2050
Figure3-2 Optical star topology with SCALANCE XCM102
The media converters ① are each connected with a SIMATIC S7-1500. The SIMATIC S7-1500
typically uses an electrical 100Mb port. Use an SFP transceiver of the type SFP991-1* in
the media converters ①. The media converters ① are then in Fast Ethernet mode. Use SFP
transceivers of the type SFP991-1* in the connected SCALANCE XM408-8C ③ also.
The media converter ② is connected to a SIMATIC IOT2050 that has an electrical Gigabit
port. Use an SFP transceiver of the type SFP992-1* in the media converter ② . The media
converter is then in Gigabit Ethernet mode. Use an SFP transceiver of the type SFP992-1* in
the connected SCALANCE XM408-8C ③ also.
Area of application
3.5Network topologies
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 15

3.5.3 Ring Topology
The following example shows an electrical ring with a SCALANCE XM408-4C as the redundancy
manager. With two SCALANCE XCM102 media converters, part of the ring can be implemented
with a 󹪝ber-optic cable.
Note
Replacement of SCALANCE X101-1 devices with SCALANCE XCM102
If you want to replace SCALANCE X101-1 or SCALANCE X101-1LD devices with SCALANCE
XCM-100 type devices in a ring topology, you can only exchange the devices in pairs. Mixed
operation of SCALANCE X101-1 or SCALANCE X101-1LD with SCALANCE XCM-100 type devices
is not possible. SCALANCE X101-1 and SCALANCE X101-1LD devices use a proprietary protocol
to exchange link status information, which is not supported by SCALANCE XCM-100.
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
①SCALANCE XCM102
②SCALANCE XC206-2SFP
③SCALANCE XC208
④SCALANCE XM408-8C
⑤SIMATIC S7-1500
Figure3-3 Ring topology with a 󹪝ber-optic cable in one segment
In this example, two SCALANCE XCM102 ① are linked to each other via an optical
connection. The two media converters are connected to a SCALANCE XC206-2SFP ② and
a SCALANCE XC208 ③ via copper. The electrical ports of the two IE switches only support
Fast Ethernet. Therefore, the media converters can only work in Fast Ethernet mode. Use
SFP transceivers of the type SFP991-1* between the two media converters. The link is only
displayed when all connections are connected correctly to the two media converters.
Area of application
3.5Network topologies
SCALANCE XCM-100 Media Converter
16 Equipment Manual, 12/2023, C79000-G8976-C659-03

3.5.4 Standby coupling
The following example shows the redundant coupling ("stand-by coupling") of rings with two
SCALANCE XCM102 media converters. This setup is only possible with redundancy-capable
stations, in the example, SCALANCE XM408-4C.
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD4UBOECZNBTUFS4UBOECZTMBWF
①SCALANCE XCM102 ⑥SCALANCE XM408-8C
②SCALANCE XM408-8C ⑦Operator station
③SCALANCE XC206-2G SFP ⑧SIMATIC S7-1500
④SCALANCE XC206-2G SFP ⑨SIMATIC IOT2050
⑤SCALANCE XC208 ⑩SCALANCE LPE9403
Figure3-4 Coupling network segments with SCALANCE XCM102 media converters
In this example, the media converters ① are connected with Gigabit-capable devices (②
and ③). Use an SFP transceiver of the type SFP992-1* in the two media converters. Use a
suitable SFP992-1* in the connected SCALANCE XM408-8C ②.
Area of application
3.5Network topologies
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 17

Area of application
3.5Network topologies
SCALANCE XCM-100 Media Converter
18 Equipment Manual, 12/2023, C79000-G8976-C659-03

Device description 4
4.1 Purpose
The devices of the SCALANCE XCM-100 product group enable cost-e󹪜ective setup of Industrial
Ethernet networks with media transitions. The use of a SCALANCE XCM-100 Media Converter is
especially recommended for the following tasks:
• In a network with twisted pair cables, a connection is to be made with 󹪝ber-optic cables, but
the device in question does not have an FO port.
• In a redundant ring with twisted pair lines, a section is to be implemented with 󹪝ber-optic
cables. This requires the two media converters to be connected in series, which is possible
with devices of the SCALANCE XCM-100 product group.
• A device without FO port should be integrated into a network segment with 󹪝ber-optic cables.
4.2 Article numbers
Device version Description Article number
SCALANCE XCM102 1x 100/1000 Mbps RJ45 port
with retaining collar for a Fast
Connect plug, 1x 100/1000 Mbps
SFP port
6GK5102-1GS00-2AC2
4.3 Product properties
Properties SCALANCE XCM102
SIMATIC environment +
Diagnostics LED +
Redundant power supply 2x24VDC/AC +
Compact enclosure 35 mm +
Signaling contact + on-site operation +
Diagnostics: Web, SNMP, PROFINET -
C-PLUG / CLP -
Ring redundancy with RM -
Passive ring redundancy +
Standby redundancy -
IRT capability -
Fast learning -
Passive Listening transparent for (R)STP +
LLDP frames transparent +
SCALANCE XCM-100 Media Converter
Equipment Manual, 12/2023, C79000-G8976-C659-03 19

Properties SCALANCE XCM102
Log table -
SNTP + SICLOCK -
Cut Through -
4.4 Scope of delivery
The following parts are included in the scope of delivery of the SCALANCE XCM-100 Media
Converter:
• One SCALANCE XCM-100 Media Converter
• One 2-pin plug-in terminal block (signaling contact)
• Two 3-pin plug-in terminal blocks (power supply and ground connection)
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
speci󹪝cation.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of the approvals
• Violation of the EMC regulations
• Damage to the device and other components
Check all the parts for transport damage and use only undamaged parts.
Device description
4.4Scope of delivery
