Siemens 3TK2810-0 Technical Document

SIRIUS Industrial Controls
Safety relays
3TK2810-0 standstill monitor
Equipment Manual
08/2023
A5E50307927002A/RS-AA/001
Introduction 1
Safety instructions 2
Description 3
Functions 4
Mounting 5
Connecting 6
Operator control 7
Diagnostics 8
Technical speci󹪝cations 9
CAx data 10
Circuit diagrams 11

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of SiemensAG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Smart Infrastructure
Electrical Products
Postfach 10 09 53
93009 Regensburg
GERMANY
A5E50307927002A/RS-AA/001
Ⓟ 08/2023 Subject to change
Copyright © SiemensAG 2022.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
1.1 Purpose of this manual ........................................................................................................ 5
1.2 Required basic knowledge.................................................................................................... 6
1.3 General information about enabling and signaling circuits.................................................... 7
1.4 Validity range ...................................................................................................................... 8
1.5 Siemens Industry Online Support ......................................................................................... 9
1.6 Siemens Industry Online Support app................................................................................. 11
1.7 User responsibility for system design and function.............................................................. 12
1.8 Recycling and disposal ....................................................................................................... 13
2 Safety instructions............................................................................................................................... 15
2.1 General safety notes .......................................................................................................... 15
2.2 Intended use...................................................................................................................... 17
2.3 Safety information for hazardous areas............................................................................... 18
2.4 Current information about operational safety ..................................................................... 19
2.5 Security information .......................................................................................................... 20
2.6 Declaration of conformity .................................................................................................. 21
3 Description........................................................................................................................................... 23
3.1 Overview........................................................................................................................... 23
3.2 Applications....................................................................................................................... 24
3.3 Basic versions .................................................................................................................... 25
3.4 Accessories........................................................................................................................ 29
4 Functions ............................................................................................................................................. 31
4.1 Terminals and their functions ............................................................................................. 31
4.2 Function diagram 3TK2810-0............................................................................................. 33
5 Mounting ............................................................................................................................................. 35
5.1 Warning notices................................................................................................................. 35
5.2 Mounting the device on a DIN rail ...................................................................................... 36
5.3 Mounting the device on a level surface............................................................................... 37
5.4 Disassembling the device ................................................................................................... 38
6 Connecting .......................................................................................................................................... 41
6.1 Warning notices................................................................................................................. 41
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 3

6.2 Connection data for terminal blocks ................................................................................... 42
6.3 Connecting terminal blocks................................................................................................ 43
6.4 Disconnecting.................................................................................................................... 45
6.5 Plugging in terminal blocks ................................................................................................ 47
7 Operator control .................................................................................................................................. 49
7.1 Commissioning and settings .............................................................................................. 49
7.2 Operation on motors with switchable windings .................................................................. 51
7.3 Operation with DC motors.................................................................................................. 52
7.4 Operation with frequency converter................................................................................... 53
8 Diagnostics .......................................................................................................................................... 55
8.1 Reading the setting values during operation....................................................................... 55
8.2 Display of the operating state............................................................................................. 56
8.3 Troubleshooting................................................................................................................. 57
8.4 Display of faults and remedial actions................................................................................. 58
8.4.1 Undervoltage at A1-A2....................................................................................................... 58
8.4.2 Wire break / o󹪜set at L2...................................................................................................... 58
8.4.3 Wire break / o󹪜set at L3...................................................................................................... 58
8.4.4 Fault in the feedback circuit X1-X2 ..................................................................................... 59
8.4.5 Simultaneity fault signal L2 / L3.......................................................................................... 59
8.4.6 Fault on the potentiometer for the voltage threshold .......................................................... 59
8.4.7 Fault on the potentiometer for the time setting .................................................................. 59
8.5 Procedure in the event of a fault......................................................................................... 60
8.6 Device replacement ........................................................................................................... 62
9 Technical speci󹪝cations ....................................................................................................................... 63
9.1 Technical data in Siemens Industry Online Support............................................................. 63
9.2 Derating ............................................................................................................................ 64
9.3 Frequency dependency of the response threshold .............................................................. 65
9.4 Electrical endurance........................................................................................................... 66
10 CAx data .............................................................................................................................................. 67
11 Circuit diagrams................................................................................................................................... 69
11.1 Circuit diagrams................................................................................................................. 69
Index .................................................................................................................................................... 71
Table of contents
3TK2810-0 standstill monitor
4Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

Introduction 1
1.1 Purpose of this manual
Note
Original Equipment Manual
The Equipment Manual of the safety-related 3TK2810-0 standstill monitor described below is
the original Equipment Manual.
This manual contains a detailed description of the safety-related 3TK2810-0 standstill
monitor and its components. The manual provides you with the information you require
for con󹪝guring, commissioning, and using the safety-related 3TK2810-0 standstill monitor.
Typical application examples provide you with a clear and practice-oriented introduction. The
manual also contains circuit diagrams of the switching device for con󹪝guration purposes.
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 5

1.2 Required basic knowledge
A general knowledge of the following areas is needed in order to understand this manual:
• Low-voltage switchgear
• Digital circuit logic
• Automation systems
• Safety systems
Introduction
1.2Required basic knowledge
3TK2810-0 standstill monitor
6Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

1.3 General information about enabling and signaling circuits
Relay enabling circuits:
When a safety function is requested or a fault detected, the 3TK28 safety relays enter the safe
state. This means:
Relay enabling circuits with NO function OPEN
Relay enabling circuits with NC function CLOSE
Relay signaling circuits:
Relay signaling circuits always have NC functionality with 3TK28 devices.
Relay signaling circuits thus always operate inversely with respect to the relay enabling
circuits with NO functionality.
Solid-state signaling circuits:
Solid-state signaling circuits in 3TK28 safety relays signal the state of the enabling circuits (==>
functioning synchronously with the solid-state enabling circuits).
When a safety function is requested or a fault detected, the 3TK28 safety relays enter the safe
state. This means:
Solid-state signaling circuits switch to the inactive state.
Introduction
1.3General information about enabling and signaling circuits
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 7

1.4 Validity range
This Equipment Manual is valid for the safety-related 3TK2810-0 standstill monitors. It contains
a description of the components applicable at the time of publication. SIEMENS reserves the
right of including a Product Information for each new component, and for each component of
a later version.
Introduction
1.4Validity range
3TK2810-0 standstill monitor
8Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

1.5 Siemens Industry Online Support
Information and service
At Siemens Industry Online Support you can obtain up-to-date information from our global
support database:
• Product support
• Application examples
• Forum
• mySupport
Link: Siemens Industry Online Support (https://support.industry.siemens.com/cs/de/en)
Product support
You can 󹪝nd information and comprehensive know-how covering all aspects of your product
here:
•FAQs
Answers to frequently asked questions
•Manuals/operating instructions
Read online or download, available as PDF or individually con󹪝gurable.
•Certi󹪝cates
Clearly sorted according to approving authority, type and country.
•Characteristics
For support in planning and con󹪝guring your system.
•Product announcements
The latest information and news concerning our products.
•Downloads
Here you will 󹪝nd updates, service packs, HSPs and much more for your product.
•Application examples
Function blocks, background and system descriptions, performance statements,
demonstration systems, and application examples, clearly explained and represented.
•Technical data
Technical product data for support in planning and implementing your project
Link: Product support (https://support.industry.siemens.com/cs/ww/en/ps)
mySupport
The following functions are available in your personal work area "mySupport":
•Support Request
Search for request number, product or subject
•My 󹪝lters
With 󹪝lters, you limit the content of the online support to di󹪜erent focal points.
Introduction
1.5Siemens Industry Online Support
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 9

•My favorites
With favorites you bookmark articles and products that you need frequently.
•My noti󹪝cations
Your personal mailbox for exchanging information and managing your contacts. You can
compile yourown individual newsletter in the "Noti󹪝cations" section.
•My products
With product lists you can virtually map your control cabinet, your system or your entire
automation project.
•My documentation
Con󹪝gure your individual documentation from di󹪜erent manuals.
•CAx data
Easy access to CAx data, e.g. 3D models, 2D dimension drawings, EPLAN macros, device
circuit diagrams
•My IBase registrations
Register your Siemens products, systems and software.
Introduction
1.5Siemens Industry Online Support
3TK2810-0 standstill monitor
10 Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

1.6 Siemens Industry Online Support app
Siemens Industry Online Support app
The Siemens Industry Online Support app provides you access to all the device-speci󹪝c
information available on the Siemens Industry Online Support portal for a particular article
number, such as operating instructions, manuals, data sheets, FAQs etc.
The Siemens Industry Online Support app is available for Android and iOS:
Android iOS
Introduction
1.6Siemens Industry Online Support app
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 11

1.7 User responsibility for system design and function
The products described here were developed to perform safety-related functions as part of an
overall installation or machine. A complete, safety-related system is generally equipped with
sensors, evaluation units, and signaling units, and uses reliable shutdown concepts. It is the
responsibility of the manufacturer of a system or machine to ensure that the product functions
properly.
Siemens AG, its regional o󹪟ces, and associated companies (hereinafter referred to as "Siemens")
cannot guarantee all the properties of an entire plant, system or machine that has not been
designed by Siemens.
Nor can Siemens assume liability for recommendations that appear or are implied in the
following description. No new guarantee, warranty, or liability claims beyond the scope
of the Siemens general terms of supply are to be derived or inferred from the following
description.
Introduction
1.7User responsibility for system design and function
3TK2810-0 standstill monitor
12 Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

1.8 Recycling and disposal
For environmentally-friendly recycling and disposal of your old device, contact a company
certi󹪝ed for the disposal of used electrical and electronic equipment, and dispose of the device
as speci󹪝ed in the regulations for your particular country.
Introduction
1.8Recycling and disposal
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 13

Introduction
1.8Recycling and disposal
3TK2810-0 standstill monitor
14 Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

Safety instructions 2
2.1 General safety notes
Note
SIL 3 according to IEC 62061
PL e / Cat. 4 according to ISO 13849-1
The 3TK2810-0 safety relays are designed so that applications up to SIL3 according to
IEC62061/PL e according toISO13849‑1 can be implemented.
WARNING
Hazardous voltage.
Can cause death, serious injury, or property damage.
Hazardous electrical voltage can cause electric shock, burns and damage.
• Turn o󹪜 and lock out all power supplying the system and device before working on the
device.
WARNING
Loss of the safety functions due to missing function test.
Can cause death, serious injury, or property damage.
In accordance with RFU CNB/M/11.050, when using actuators such as 3SK1 output expansions,
contactors or relays in continuous operation in factory automation applications, a function test
interval (shutdown test) ≤ 1 year for SIL 2 according to IEC 62061 or PL d with Cat. 3 according
to ISO 13849 is required. A period ≤ 1 month for SIL 3 according to IEC 62061 or PL e with Cat. 3
or Cat.4 according to ISO13849 applies. Only then do the safety characteristic values apply.
Exception: A function test interval≤ 1 year is also permissible for SIL3applications in the
process industry (in accordance with IEC61511), exclusively for low-demand use, due to a
signi󹪝cantly lower failure rate probability of the electromechanical components. This does not
apply to safety-related applications in accordance with the Machinery Directive 2006/42/EC.
Function test procedure for actuators with contacts:
• Actuate the connected sensors.
• Check their e󹪜ect on the safety relay and the downstream actuators*.
• Activate the safety relay via the connected sensors.
• Check their e󹪜ect on the safety relay and the downstream actuators*.
• Defective devices must be replaced.
*Since the read-back time of the delayable output functions is retriggerable, the actuation
duration for switching on and o󹪜 for the regular function test must be longer than the time set
in the "Switching time" parameter. Only in this way can it be ensured that the expected
switching state has also been set on the connected actuator.
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 15

WARNING
Risk due to conductive contamination.
Can cause death, serious injury, or property damage.
The devices must be protected against conductive contamination, taking the ambient
conditions into account. One way to achieve this is to install the devices in a control cabinet
with the appropriate degree of protection.
You can 󹪝nd more information in the IEC 60529 standard "Degrees of protection provided by
enclosures (IP code)".
NOTICE
Material damage caused by electrostatic charging
When handling and installing the system components, ensure that the components are
protected from electrostatic charge. Changes to the system con󹪝guration and wiring are
permissible only when the supply voltage is switched o󹪜. The connection of 3TK2810-0 safety
relays is permitted only when the supply voltage is switched o󹪜.
Safety instructions
2.1General safety notes
3TK2810-0 standstill monitor
16 Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

2.2 Intended use
WARNING
Improper use of hardware products.
Can cause death, serious injury, or property damage.
This equipment is only allowed to be used for the applications described in the catalog and in
the technical description, and only in conjunction with non-Siemens equipment and
components recommended by Siemens.
Correct transport, storage, installation and assembly, as well as careful operation and
maintenance, are required to ensure that the product operates safely and without faults.
Before you run any sample programs or programs you have written yourself, make sure that
running the plant cannot cause injury to anyone else or damage to the machine itself.
EU note regarding machine safety: Commissioning is absolutely prohibited until it has been
ensured that the machine in which the component described here is to be installed complies
with the stipulations of the Directive 2006/42/EC.
WARNING
Hazardous condition of the plant.
Can cause death, serious injury, or property damage.
The basis of the safety concept is that a safe state exists for all process variables. For the
3TK2810-0 safety relay, this is the value "0". This applies to sensors and actuators.
WARNING
Loss of the safety functions through changes to the system.
Can cause death, serious injury, or property damage.
To ensure the safety of the system, any changes to it or any replacement of defective
components must be followed by a thorough and successfully completed function test of the
system.
Safety instructions
2.2Intended use
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 17

2.3 Safety information for hazardous areas
WARNING
Hazardous Voltage.
Can Cause Death, Serious Injury, or Property Damage.
Installation of the 3TK28 safety relays in hazardous areas
The components of the 3TK28 are not suitable for installation in hazardous areas.
Please contact your ATEX specialist.
Safety instructions
2.3Safety information for hazardous areas
3TK2810-0 standstill monitor
18 Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001

2.4 Current information about operational safety
Important note for maintaining operational safety of your system
WARNING
Hazardous voltage
Can cause death, serious injury, or property damage.
Please take note of our latest information
Systems with safety-related characteristics are subject to special operational safety
requirements on the part of the operator. The supplier is also obliged to comply with special
product monitoring measures. For this reason, we publish a special newsletter containing
information on product developments and features that are (or could be) relevant to operation
of safety-related systems. So that you are always up to date in this respect as well. You can 󹪝nd
more information here:
SIEMENS newsletter (http://www.siemens.com/sirius-newsletter)
Safety instructions
2.4Current information about operational safety
3TK2810-0 standstill monitor
Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001 19

2.5 Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Products and solutions from Siemens constitute one element of such a
concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the Internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that can be implemented, please
visit:
https://www.siemens.com/industrialsecurity
Safety instructions
2.5Security information
3TK2810-0 standstill monitor
20 Equipment Manual, 08/2023, A5E50307927002A/RS-AA/001
