Siemens RDE100.1RFS User manual

1/4 Operating Instructions CB1B1425en_01 / 2014-11-26 Siemens Building Technologies
s
Operating Instructions
RDE10
0.1
RF
S
The RDE100.1RFS consists of a wireless room thermostat RDE100.1RF and an RCR100RF receiver.
The units allow you to set the ideal room temperature at the time you want.
There are several switching patterns available that can be set to meet your individual needs.
RDE100.1RF 1 Display
Indicates that batteries
need to be replaced Time of day
Frost protection (heating)
active Morning: 12-hour format
Afternoon: 12-hour format
Auto Timer mode Confirmation
View and set Auto Timer
F
Room temperature in
degrees Fahrenheit
Comfort mode
C
Room temperature in
degrees Celsius
Economy mode Button lock activated
Escape Room temperature,
setpoint, etc.
External input enabled Display of zone
(default = 1)
Permanent setpoint setting Heating On
Weekday and time of day
setting Weekday 1 = Monday
Weekday 7 = Sunday
Holiday mode setting Timer bar
Current room temperature
2 Change operating mode
3 Set
4 Ok
5 Decrease value
6 Increase value
7 Battery holder
RCR100RF
8 Indication of data transmission and operating state (LED)
9 Initialization of wireless communication with transmitter
(LEARN button)
Do you want to set the time of day and the weekday?
Set
Ok
+
–
Mode
Proceed as follows:
·Press Set and select
·Press Ok and the time of day flashes for setting
·Press +or –to adjust the time of day
·Press Ok to confirm
·The weekday flashes; press +or –to select the desired day
·Press Ok to save the setting
·Press Mode to exit or wait for the program to exit automatically

2/4 Operating Instructions CB1B1425en_01 / 2014-11-26 Siemens Building Technologies
Are your rooms too warm/too cold?
+
–
Ok
Set
Mode
Press +or –to increase or decrease the
room temperature setpoint in increments of
0.5 °C/1 °F. Proceed as follows:
·Press +or –to change the setpoint
temporarily.
This readjustment is reset as soon as
the operating mode changes
·Press Ok,Set or Mode to save the
setting or wait for the program to exit
automatically
·To lock the setpoints, use parameters
P06 and P08
Do you want to change the operating
mode?
mode
!
The thermostat provides Comfort, Economy
and automatic mode. Changeover between
the operating modes can be made manually
by pressing Mode.
Comfort mode is the permanent (24 h)
selection of Comfort. Select this operating
mode to maintain Comfort temperature
permanently without any timeswitch. It is
used during occupancy periods, for example.
Economy mode is the permanent (24 h)
selection of Economy. Select this operating
mode to maintain the Economy temperature
permanently without any time switch.
It is used during non-occupancy periods
(e.g. at night).
AUTO
In Auto Timer mode, the operating
modes (Comfort, Economy) are changed
automatically according to the time switch
settings.
Note:
Frost protection is a function always active
in the background. As soon the room
temperature falls below 5 ºC, the unit
automatically activates heating .
Do you want to set permanent temperature
setpoints?
Set
Ok
+
–
Mode
!
·Press Set and select
·Press Ok to confirm
·Press Mode to select the operating
mode (Comfort or Economy)
·Press +or –to adjust the setpoint
permanently
·Press Ok to confirm
·Press Mode to exit or wait for a timeout
to exit automatically
Note:
This permanent setpoint is used during Auto Timer
mode.
Energy saving tips without loss of
comfort
·Select Auto Timer mode for the heating period, and
set the time switch according to your normal habits at
home
·Select Economy or Holiday mode for longer periods
of non-occupancy and the summer period
Do you want to set your Holiday mode?
Set
Ok
+
–
Mode
!
Use the Holiday mode to set the thermostat
to a constant room temperature while
absent.
·Press Set and select
·Press Ok to confirm
·Press +or –to adjust the temperature
setpoint
·Press Ok to confirm
·Press +or –to set the number of days
for holidays (0 = Holiday mode Off)
·Press Ok to save the setting
·When Holiday mode is activated, the
remaining days are displayed
Note:
If you press Mode while Holidaymode is active,
the function is turned off and symbol
disappears.
If the Comfort and Economysetpoints are both
locked, the lowest locked setpoint is the Holiday
mode setpoint. You can adjust the setpoint from
5 ºC up to the lowest locked setpoint.
Do you want to enter your own time switch?
Option 1: Time switch with individual day settings
(P11=0)
Set
Ok
+
–
Mode
You can select Comfort or Economy mode in
steps of 15 minutes throughout the day. The
0:00 to 24:00 hour time bar allows you to set
the operating mode for the selected day(s).
Example:
0
6
12
24
18
1 2

Visible bars: Control to Comfort temperature
Invisible bars: Control to Economy
temperature
When Auto Timer mode is enabled,
changeover between the operating modes is
automatic after the settings are saved.
Proceed as follows:
1) Press Set and select
AUTO
.
2) Press Ok to confirm.
3) Time switch for Mon (1) is displayed.
4) Press +or –to select the weekday,
from Mon (1) to Sun (7).
5) Press Ok to confirm the selection and
initiate time programming.
During programming:
6) Press Mode to select the operating mode
(Comfort or Economy) or
7) Press +or –to set the time in steps of 15
minutes for the selected mode.
8) Press Ok to save the time switch.
9) Repeat steps 4-8 for all remaining days (if
required) or
10) Press Mode or wait for the program to exit
automatically.

3/4 Operating Instructions CB1B1425en_01 / 2014-11-26 Siemens Building Technologies
Option 2: Time switch with the same 7-day settings
(P11=1)
Set
Ok
+
–
Mode
You can set the time switch so that all settings
apply to the 7 weekdays.
Example:
0
6
12
24
18
1 2

Visible bars: Control to Comfort temperature
Invisible bars: Control to Economy
temperature
Proceed as follows:
1) Set the parameter (P11=1). Please refer to
section "Do you want to change
parameters".
2) Press Set and select
AUTO
.
3) Press Ok to confirm.
4) Time switch for Mon (1) - Sun (7) is
displayed.
5) Press Ok to initiate time programming.
During programming:
6) Press Mode to select the operating mode
(Comfort or Economy) or
7) Press +or –to set the time in steps of 15
minutes for the selected operating mode.
8) Press Ok to save the time switch.
9) Press Mode or wait for the program to exit
automatically.
Option 3: Time switch with 5-2-day settings (P11=2)
Factory default of 7-day time switch
Default
value Day/s Comfort mode Economy mode
Mo (1) –
Fr (5) 6:00 – 8:00 hr 17:00 – 22:00 hr 22:00 – 6:00 hr 8:00 – 17:00 hr
Sa (6) –
Su (7) 7:00 – 22:00 hr 22:00 – 7:00 hr
Do you want to pair transmitter and
receiver?
+
–
Learn
Mode
The RDE100.1RF communicates with the
RCR100RF at a frequency of 433 MHz.
To pair transmitter and receiver, proceed as
follows:
RCR100RF receiver setting:
1) Press and hold the LEARN button on the
RCR100RF for at least 3 seconds and
then release it.
2) Red and green LEDs flash alternately to
indicate receiver is in learning mode.
RDE100.1/RF transmitter setting:
3) On the transmitter, set the parameters
(refer to section "Do you want to change
parameters?").
4) Check to ensure that parameter P19 is not
0, because this would mean that the
wireless function is disabled. By default,
parameter P19 is 1.
5) Proceed to parameter P20. Press Mode
and parameter P20=0 (OFF) flashes.
Adjust the value by pressing +to change
to P20=1 (ON), then press Mode to
confirm.
6) During the stages of wireless learning, the
LCD displays "rF" and "Lrn". Wait for time
out, and the transmitter exits the
parameter setting mode.
Successful wireless learning:
7) The green LED on the RCR100RF flashes
for 10 minutes to indicate that the receiver
has successfully completed wireless
learning.
Recommendation:
8) Additional test to ensure the wireless
signal is fine:
On the RDE100.1/RF, change the
operating mode by pressing Mode or
change the setpoint by pressing +or –.
On the RCR100RF, the green LED should
flash for 3 seconds before changing to
constantly green. At the same time,
observe your radiator, boiler or heater
indication (if it has one) to ensure that it
changed the operating mode.
9) If step 7 or 8 is working fine, this means
you have successfully paired the units.
Unsuccessful wireless learning:
10) If the RCR100RF fails to receive wireless
data, the red LED starts to flash **.
Repeat steps 1 to 8 until pairing is
successful.
!
Note:
Always start receiver learning before starting
pairing with the transmitter.
The units must be placed such that transmitter
and received signals have limited external
wireless interference.
**In normal operation, if a drop in wireless
communication occurs due to unforseeable
noise, just leave the receiver and it will recover
automatically.
The pairs are saved even if there is a power
shut down. Communication restarts
automatically after several minutes without any
user action.
set
ok
+
–
mode
You can set Monday - Friday and Saturday -
Sunday at the same time.
Example:
0
6
12
24
18
1 2
Visible bars: Control to Comfort temperature
Invisible bars: Control to Economy
temperature
Proceed as follows:
1) Set the parameter (P11=2). Please refer
to section "Do you want to change
parameters".
2) Press Set and select
AUTO
.
3) Press Ok to confirm.
4) Time switch for Mon (1) – Fri (5) is
displayed.
5) Press +or –to select Mon (1) – Fri ( 5) or
Sat (6) - Sun (7).
6) Press Ok to confirm the selected period
and initiate time programming.
During programming:
7) Press Mode to select the operating mode
(Comfort or Economy) or
8) Press +or –to set the time in steps of
15 minutes for the selected mode.
9) Press Ok to save the time switch.
10) Repeat steps 5-9 for the other period if
necessary or
11) Press Mode or wait for the program to exit
automatically.

4/4 Operating Instructions CB1B1425en_01 / 2014-11-26 Siemens Building Technologies
Does symbol appear on the display?
Symbol is displayed when the batteries are low.
Replace them with 2 new alkaline batteries type AAA.
Proceed as follows:
·Get 2 new alkaline batteries type AAA
·Remove the battery holder and then the batteries.
Insert the new batteries and, within 1.5 minutes,
replace the battery holder
·Ensure the exhausted batteries are disposed of
correctly, in compliance with environmental
requirements
Do you want to lock the keypad?
Mode Press and hold Mode for at least 7 seconds to
activate a button lock. Repeat to unlock.
The unit operates normally when the buttons
are locked, but changes cannot be made.
Receiver’s LED indication
State of receiver State of LED
Power up (or reset) The red and green LEDs flash
alternately for 5 seconds, then
change to constantly red.
Note: If the receiver was previ-
ously programmed, it shows
immediately constantly red.
Learning mode
Successful learning
mode
The red and green LEDs flash
alternatively.
If RCR100RF learning is
successful, the green LED will
flash for 10 minutes.
Signal ok and
output status
change
The green LED is constantly lit,
and if the output status
changes, the green LED flashes
for 3 seconds, then changes
back to constantly green.
Fail to receive
wireless data If the RCR100RF fails to receive wireless data, the red LED will
start to flash after 125 minutes.
If the RCR100RF signal is
recovered, it will return to the
previous LED state.
Do you want to change parameters?
+
–
Ok
Mode
If you want to change control parameters,
proceed as follows:
·Press +and –simultaneously for 5
seconds
·Release the buttons and parameter
P01 is displayed on the bottom
segment
·Press +or –to scroll to the parameter
that needs to be changed
·Press Ok to select the parameter
·Press +or –to change the value
·Press Ok to confirm the changed value
·Press Mode to exit the parameters
without saving or wait for the program
to exit automatically
Parameter list
Parameter
no. Description Setting range (default)
P01 Time format 1 = 24:00 hours
(default)
2 = 12:00 am/pm
P02 Selection of °C or
°F 1 = °C (default)
2 = °F
P03 Standard
temperature display 1 = room temperature (default)
2 = setpoint
P04 Temperature
sensor calibration -3…3 °C
Step 0.5 °C
(-6…6 °F, step 1 °F)
Default: 0 °C
P06 Comfort setpoint
lock 0 = OFF (default)
1 = ON àlocked
according to setting
in permanent
temperature setpoint
P08 Economy setpoint
lock 0 = OFF (default)
1 = ON àlocked
according to setting
in permanent
temperature setpoint
P09 Buzzer 0 = OFF
1 = ON (default)
P10 Show frost
protection icon 0 = OFF (default)
1 = ON
P11 Time switch type for
Auto Timer 0 = individual days (default)
1= all 7 days
2= 5-2 days
P12 Periodic pump run 0 = OFF (default)
1 = ON
P14 X1 external input 0 = no input (default)
1 = external sensor
2 = digital input
P15 Temperature
limitation 0 = OFF (default)
1 = ON
P16 Max. limitation
temperature for
floor heating
35…60 °C, step 1 °C
or
95…140 °F, step 1 °F
Default: 55 °C
P17 Window contact
features 0 = normally open contact (default)
1 = normally closed
contact
P19 Sequential number
of room unit 0 = no display of zone (RF off)
1 = zone number 1
(for standard RF)
(default)
6 = zone number 6
P20 RF learn 0 = OFF (default)
1 = ON
P21 Scanning rate for
the capacitive
buttons
Note: Shorter
scanning rate
means shorter
battery life
0.2 = 0.25 s
0.5 = 0.5 s
1.0 = 1.0 s (default)
1.5 = 1.5 s
P22 Reload factory
settings 0 = OFF (default)
1 = reload
P23 Software version
information No adjustment possible
