Siemens SIMATIC NET RUGGEDCOM RSG2288 User manual

Edition 04/2021
Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM RSG2288
https://www.siemens.com

SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM RSG2288
Installation Manual
Preface
Introduction 1
Installing the Device 2
Device Management 3
Communication Ports 4
Technical Specifications 5
Certification 6
04/2021
C79000-G8976-1045-17

Legal Information
Warning Notice System
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety
alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown
below are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger
will be used. A notice warning of injury to persons with a safety alert symbol may also include a warning
relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the
specific task in accordance with the relevant documentation, in particular its warning notices and safety
instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper Use of Siemens Products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant
technical documentation. If products and components from other manufacturers are used, these must be
recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning,
operation and maintenance are required to ensure that the products operate safely and without any
problems. The permissible ambient conditions must be complied with. The information in the relevant
documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of
the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industry
Process Automation
Postfach 48 48
90026 NÜRNBERG
GERMANY
© 04/2021 Subject to Change Copyright © Siemens 2021
All rights reserved

Table of Contents
Preface ............................................................................................................................................ v
Related Documents ................................................................................................................. v
Accessing Documentation ....................................................................................................... v
Registered Trademarks ............................................................................................................ v
Warranty ................................................................................................................................. v
Training .................................................................................................................................. vi
Customer Support .................................................................................................................. vi
Contacting Siemens ............................................................................................................... vii
1 Introduction ........................................................................................................................... 1
1.1 Feature Highlights ................................................................................................. 1
1.2 Description ............................................................................................................ 2
1.3 Required Tools and Materials ................................................................................. 3
1.4 Decommissioning and Disposal ............................................................................. 4
1.5 Cabling Recommendations .................................................................................... 4
1.5.1 Protection On Twisted-Pair Data Ports .................................................................... 4
1.5.2 Gigabit Ethernet 1000Base-TX Cabling Recommendations ...................................... 5
1.5.3 Supported Fiber Optic Cables ................................................................................ 5
1.6 Precision Time Protocol (PTP) Support ................................................................... 6
1.6.1 Supported Time Synchronization Sources .............................................................. 6
1.6.2 IEEE 1588 Support ................................................................................................ 8
1.6.3 AM and TTL Outputs ............................................................................................. 9
2 Installing the Device ........................................................................................................... 11
2.1 General Procedure ............................................................................................... 12
2.2 Unpacking the Device ......................................................................................... 12
2.3 Mounting the Device ........................................................................................... 12
2.3.1 Mounting the Device to a Rack ............................................................................ 13
2.3.2 Mounting the Device on a DIN Rail ...................................................................... 14
2.3.3 Mounting the Device to a Panel .......................................................................... 15
2.4 Connecting the Failsafe Alarm Relay .................................................................... 16
2.5 Connecting a GPS Antenna .................................................................................. 17
2.6 Connecting Power ............................................................................................... 19
2.6.1 Connecting AC or DC Power ................................................................................ 20
2.6.2 Wiring Examples .................................................................................................. 22
3 Device Management ........................................................................................................... 27
3.1 Connecting to the Device .................................................................................... 27
3.2 Configuring the Device ........................................................................................ 28
4 Communication Ports .......................................................................................................... 29
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 iii

Table of Contents
4.1 Copper Ethernet Ports ......................................................................................... 30
4.2 Fiber Optic Ethernet Ports ................................................................................... 31
4.3 SFP Transceivers .................................................................................................. 31
4.4 BNC Ports ............................................................................................................ 32
4.5 GBIC Optic Ethernet Ports .................................................................................... 33
4.5.1 Installing a GBIC Optical Port ............................................................................... 33
4.5.2 Removing a GBIC Optical Port .............................................................................. 35
5 Technical Specifications ...................................................................................................... 37
5.1 Power Supply Specifications ................................................................................ 37
5.2 Failsafe Relay Specifications ................................................................................ 37
5.3 Supported Networking Standards ........................................................................ 37
5.4 Copper Ethernet Port Specifications ..................................................................... 38
5.5 Fiber Optic Ethernet Port Specifications ............................................................... 38
5.6 PTP Specifications ................................................................................................ 40
5.7 Operating Environment ....................................................................................... 41
5.8 Mechanical Specifications .................................................................................... 41
5.9 Dimension Drawings ........................................................................................... 41
6 Certification ......................................................................................................................... 45
6.1 Approvals ............................................................................................................ 45
6.1.1 CSA ..................................................................................................................... 45
6.1.2 European Union (EU) .......................................................................................... 45
6.1.3 FCC ..................................................................................................................... 46
6.1.4 FDA/CDRH ........................................................................................................... 46
6.1.5 ISED .................................................................................................................... 46
6.1.6 ISO ...................................................................................................................... 47
6.1.7 ACMA .................................................................................................................. 47
6.1.8 RoHS ................................................................................................................... 47
6.1.9 Other Approvals .................................................................................................. 48
6.2 EMC and Environmental Type Tests ..................................................................... 48
iv RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Preface
This guide describes the RUGGEDCOM RSG2288. It describes the major features of
the device, installation, commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible
for the installation, commissioning and maintenance of the device. It is also
recommended for use by network and system planners, system programmers, and
line technicians.
Related Documents
Other documents that may be of interest include:
Document Title Link
RUGGEDCOM ROS Configuration Manual https://support.industry.siemens.com/cs/ww/en/
view/109737235
Time Synchronization Capabilities of RUGGEDCOM
Devices
https://support.industry.siemens.com/cs/ww/en/
view/109780448
RUGGEDCOM SFP Transceiver Catalog https://support.industry.siemens.com/cs/ca/en/
view/109482309
Accessing Documentation
The latest user documentation for RUGGEDCOM RSG2288 is available online at
https://support.industry.siemens.com . To request or inquire about a user document,
contact Siemens Customer Support.
Registered Trademarks
RUGGEDCOM®, ROS®, RCDP®, and RUGGEDCOM Discovery Protocol® are registered
trademarks of Siemens Canada Ltd.
Other designations in this manual might be trademarks whose use by third parties
for their own purposes would infringe the rights of the owner.
Warranty
Siemens warrants this product for a period of five (5) years from the date of
purchase, conditional upon the return to factory for maintenance during the
warranty term. This product contains no user-serviceable parts. Attempted service by
unauthorized personnel shall render all warranties null and void. The warranties set
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 v

Preface
Training
forth in this article are exclusive and are in lieu of all other warranties, performance
guarantees and conditions whether written or oral, statutory, express or implied
(including all warranties and conditions of merchantability and fitness for a particular
purpose, and all warranties and conditions arising from course of dealing or usage
or trade). Correction of nonconformities in the manner and for the period of time
provided above shall constitute the Seller’s sole liability and the Customer’s exclusive
remedy for defective or nonconforming goods or services whether claims of the
Customer are based in contract (including fundamental breach), in tort (including
negligence and strict liability) or otherwise.
For warranty details, visit https://www.siemens.com or contact a Siemens customer
service representative.
Training
Siemens offers a wide range of educational services ranging from in-house training
of standard courses on networking, Ethernet switches and routers, to on-site
customized courses tailored to the customer's needs, experience and application.
Siemens' Educational Services team thrives on providing our customers with the
essential practical skills to make sure users have the right knowledge and expertise
to understand the various technologies associated with critical communications
network infrastructure technologies.
Siemens ' unique mix of IT/Telecommunications expertise combined with domain
knowledge in the utility, transportation and industrial markets, allows Siemens to
provide training specific to the customer's application.
For more information about training services and course availability, visit https://
www.siemens.com or contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers.
For technical support or general information, contact Siemens Customer Support
through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a
Support Request (SR) or check on the status of an existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a
local hotline center, visit https://w3.siemens.com/aspa_app/?lang=en.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android,
Apple iOS or Windows mobile device and be able to:
vi RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Preface
Contacting Siemens
• Access Siemens' extensive library of support documentation,
including FAQs and manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support,
Training, etc.
• Ask questions or share knowledge with fellow Siemens customers
and the support community
Contacting Siemens
Address Siemens AG
Industry Sector
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-Mail [email protected]
Web https://www.siemens.com
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 vii

Preface
Contacting Siemens
viii RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Introduction 1
The RUGGEDCOM RSG2288 is a rugged, fully managed, modular Ethernet switch
specifically designed to operate reliably in electrically harsh and climatically
demanding utility substation, railway and industrial environments. The RUGGEDCOM
RSG2288 includes the IEEE 1588 v2 protocol with hardware time stamping, allowing
high precision time synchronization over the Ethernet network with accuracies
of 1 μs or better. The RUGGEDCOM RSG2288’s superior rugged hardware design
coupled with the embedded Rugged Operating System (ROS) provides improved
system reliability and advanced cyber security and networking features, making it
ideally suited for creating Ethernet networks for mission-critical, real-time, control
applications.
The RUGGEDCOM RSG2288 ’s modular flexibility offers 100/1000BaseX fiber and
10/100/1000BaseTX copper port combinations. Support for front or rear mount
connectors coupled with support for multiple fiber connector types (SFP, GBIC, LC,
SC) without loss of port density makes the RUGGEDCOM RSG2288 highly versatile
and suitable for any application. The RUGGEDCOM RSG2288 is packaged in a rugged,
galvanized steel enclosure with industrial grade DIN, panel, or 48 cm (19 in) rack-
mount mounting options.
1.1 Feature Highlights
Ethernet Ports
• Up to 9 x Gigabit Ethernet ports (copper and fiber)
• Up to 9 x 100Base-FX Fiber Fast Ethernet ports
• 2-port modules for tremendous flexibility
• Non-blocking, store and forward switching
• Supports many types of fiber (multimode, single mode, bidirectional single
strand)
• Full compliance with IEEE: 802.3, 802.3u & 802.3z
• Full duplex operation and flow control (IEEE 802.3x)
• Long haul optics allow Gigabit at distances up to 70 km
• Industry standard fiber optic connectors: LC, SC, SFP, GBIC
Advanced Time Synchronization
• Support for IEEE 1588 v2, GPS and IRIG-B time synchronization
• Hardware time stamping on all ports including Gigabit
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 1

Introduction
1.2Description
• Transparent clock operation for high precision on switched networks (1us or
better)
• Peer-to-peer path delay measurements
• High precision TCXO (Temperature Compensated Oscillator)
• Supports master, slave and transparent clock modes
• Support for IRIG-B input and output
Rated for Reliability in Harsh Environments
• Immunity to EMI and heavy electrical surges
• Zero-Packet-Loss™ technology
• -40 to 85 °C (-40 to 185 °F) operating temperature (no fans)
• Conformal coated printed circuit boards (optional)
• 18 AWG galvanized steel enclosure
• Hazardous Location Certification: Class 1 Division 2
Universal Power Supply Options
• Fully integrated, dual-redundant (optional) power supplies
• Universal high-voltage range: 88-300 VDC or 85-264 VAC
• Popular low voltage ranges: 24 VDC (10-36 VDC), 48 VDC (36-72 VDC)
• Screw or pluggable terminal blocks for reliable, maintenance-free connections
• CSA/UL 62368-1 safety approved to 85 °C (185 °F)
1.2 Description
The RUGGEDCOM RSG2288 features various ports, controls and indicator LEDs on
the display panel for connecting, configuring and troubleshooting the device. The
display panel can be located on the rear, front or top of the device, depending on the
mounting configuration.
2
5
6
4
1
7
9
8
3
1 Fiber or Copper Ethernet Ports
2 Copper Ethernet Port
3 BNC Ports
4 Port Status Indicator LEDs
5 Mode Button
2RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Introduction
1.3Required Tools and Materials
6 RS-232 Serial Console Port (RJ45)
7 Display Mode Indicator LEDs
8 Alarm Indicator LED
9 Power Module Indicator LEDs
Figure1.1 RUGGEDCOM RSG2288
Communication Ports Ports for communicating with other devices or accessing the
RUGGEDCOM RSG2288 operating system are described in
"Communication Ports (Page 29)".
Port Status Indicator LEDs Port status indicator LEDs indicate the operational status of each
port, dependent on the currently selected mode.
Mode Color/State Description
Green (Solid) Link detected
Green (Blinking) Link activity
Status
Off No link detected
Green Full duplex mode
Orange Half duplex mode
Duplex
Off No link detected
Green (Solid) 100 Mbps
Green (Blinking) 1000 Mbps
Orange (Solid) 10 Mbps
Speed
Off No link detected
Display Mode Indicator LEDs The display mode indicator LEDs indicate the current display mode
for the port status indicator LEDs (i.e. Status, Duplex or Speed).
Mode Button The Mode button sets the display mode for the port status indicator
LEDs (i.e. Status, Duplex or Speed). It can also be used to reset the
device if held for 5 seconds.
Alarm Indicator LED The alarm indicator LED illuminates when an alarm condition exists.
Power Module Indicator LEDs The power module indicator LEDs indicate the status of the power
modules.
•Green – The power supply is supplying power
•Red – Power supply failure
•Off – No power supply is installed
RS-232 Console Port The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page 27)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM RSG2288:
Tools/Materials Purpose
AC power cord (16 AWG) For connecting power to the device.
CAT-5 Ethernet cables For connecting the device to the network.
Flathead screwdriver For mounting the device to a DIN rail.
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 3

Introduction
1.4Decommissioning and Disposal
Tools/Materials Purpose
Phillips screwdriver For mounting the device to a panel.
4 x #8-32 screws For mounting the device to a panel.
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated Configuration Manual.
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related
accessories, contact a facility certified to dispose of waste electrical and electronic
equipment. Recycling and disposal must be done in accordance with local
regulations.
1.5 Cabling Recommendations
Before connecting the device, be aware of the recommendations and considerations
outlined in this section.
1.5.1 Protection On Twisted-Pair Data Ports
All copper Ethernet ports on RUGGEDCOM products include transient suppression
circuitry to protect against damage from electrical transients and conform with
IEC 61850-3 and IEEE 1613 Class 1 standards. This means that during a transient
electrical event, communications errors or interruptions may occur, but recovery is
automatic.
Siemens also does not recommend using copper Ethernet ports to interface with
devices in the field across distances that could produce high levels of ground
potential rise (i.e. greater than 2500 V), during line-to-ground fault conditions.
4RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Introduction
1.5.2Gigabit Ethernet 1000Base-TX Cabling Recommendations
1.5.2 Gigabit Ethernet 1000Base-TX Cabling Recommendations
The IEEE 802.3ab Gigabit Ethernet standard defines 1000 Mbit/s Ethernet
communications over distances of up to 100 m (328 ft) using all 4 pairs in category
5 (or higher) balanced, unshielded twisted-pair cabling. For wiring guidelines,
system designers and integrators should refer to the Telecommunications Industry
Association (TIA) TIA/EIA-568-A wiring standard that characterizes minimum cabling
performance specifications required for proper Gigabit Ethernet operation. For
reliable, error-free data communication, new and pre-existing communication paths
should be verified for TIA/EIA-568-A compliance.
The following table summarizes the relevant cabling standards:
Cabling
Category
1000Base-
TX Compliant
Required Action
< 5 No New wiring infrastructure required.
5 Yes Verify TIA/EIA-568-A compliance.
5e Yes No action required. New installations should be designed with
Category 5e or higher.
6 Yes No action required.
> 6 Yes Connector and wiring standards to be determined.
Follow these recommendations for copper data cabling in high electrical noise
environments:
• Data cable lengths should be as short as possible, preferably 3 m (10
ft) in length. Copper data cables should not be used for inter-building
communications.
• Power and data cables should not be run in parallel for long distances, and
should be installed in separate conduits. Power and data cables should intersect
at 90° angles when necessary to reduce inductive coupling.
• Shielded/screened cabling can be used when required. Care should be taken to
avoid the creation of ground loops with shielded cabling.
1.5.3 Supported Fiber Optic Cables
The following fiber optic cable types are supported under the stated conditions.
Distance (m)Cable Type Wavelength (nm) Modal Bandwidth
(MHz·km) 100Base-FX 1000Base-SX 10GBase-SR
850 200 — 275 33OM1 (62.5/125)
1300 500 2000 — —
850 500 — 550 82OM2 (50/125)
1300 500 2000 — —
850 1500 — 550 300OM3 (50/125)a
1300 500 2000 — —
OM4 (50/125)a850 3500 — 550 400
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 5

Introduction
1.6Precision Time Protocol (PTP) Support
Distance (m)Cable Type Wavelength (nm) Modal Bandwidth
(MHz·km) 100Base-FX 1000Base-SX 10GBase-SR
1300 500 2000 — —
aLaser optimized.
1.6 Precision Time Protocol (PTP) Support
The Precision Time Protocol (PTP) module adds the ability to provide time
synchronization via Ethernet using the Precision Time Protocol (PTP) and Network
Time Protocol (NTP), and to synchronize with an external IRIG-B source or GPS
network.
The PTP module features BNC ports for AM OUT, TTL IN/OUT and GPS IN. It also
includes an LED to indicate when synchronization has been achieved.
Note
The PTP module can only be installed in slot 6. For more information, refer to
"Communication Ports (Page 29)".
1 2 3 4
1 AM OUT Port
2 TTL OUT Port
3 TTL IN Port
4 GPS IN Port
Figure1.2 PTP Module
For more information about the BNC ports, refer to "BNC Ports (Page 32)".
1.6.1 Supported Time Synchronization Sources
The following time synchronization sources are supported by the RUGGEDCOM
RSG2288, with or without the PTP card:
Synchronization Source Without PTP Card With PTP Card Description
NTP ü ü NTP (Network
Time Protocol)
is the standard
for synchronizing
the clocks of
computer systems
throughout the
6RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Introduction
1.6.1Supported Time Synchronization Sources
Synchronization Source Without PTP Card With PTP Card Description
Internet and
is suitable for
systems that
require accuracies
in the order of 1
ms.
IEEE 1588 v2 ü ü IEEE 1588
is designed
to provide
networked,
packet-based time
synchronization
between different
networking nodes
(PTP devices).
The RUGGEDCOM
RSG2288 supports
PTP v2, which is
defined in the
IEEE 1588-2008
standard. IEEE
1588 is designed
to fill a niche not
well served by
either of the two
older, dominant
protocols, NTP and
IRIG-B. IEEE 1588
is also designed
for applications
that cannot bear
the cost of a GPS
receiver at each
node or for which
GPS signals are
inaccessible.
The RUGGEDCOM
RSG2288 supports
ordinary clock,
boundary clock
and transparent
clock modes. An
ordinary clock
can be configured
as either a
Grandmaster Clock
(GM) or a Slave
Clock (SC) within
the master-slave
hierarchy.
Every Ethernet
port on the
RUGGEDCOM
RSG2288 supports
IEEE 1588. For
more information,
refer to "IEEE 1588
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 7

Introduction
1.6.2IEEE 1588 Support
Synchronization Source Without PTP Card With PTP Card Description
Support (Page
8)".
GPS û ü The Global
Positioning System
(GPS), as a source
of accurate
time, requires
an external GPS
antenna input to
provide accurate
time signals
comparable
to 500 ns. The
RUGGEDCOM
RSG2288 can use
the GPS receiver
on the PTP module
to provide the
time base for the
system.
IRIG-B PWM û ü IRIG-B time
synchronization
is an even older,
established,
inter-device time
synchronization
mechanism
providing
accuracy in sub-
milliseconds.
IRIG-B AM OUT û ü AM (Amplitude
Modulation)
OUT outputs IRIG
Standard 200-04
compliant signals
to synchronized
external devices.
PPx (Configurable PPS) û ü PPx provides a
generic pulse
per X second
to sychronize
external devices.
1.6.2 IEEE 1588 Support
RUGGEDCOM RSG2288 supports various IEEE 1588 time synchronization capabilities
and provides synchronization in 2-step mode.
Supported Clock Types
IEEE 1588 Clock Type Without PTP Card With PTP Card
Grandmaster Clock (GMC) û ü
8RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Introduction
1.6.3AM and TTL Outputs
IEEE 1588 Clock Type Without PTP Card With PTP Card
Master Clock ü ü
Boundary Clock ü ü
Transparent Clock ü ü
Transparent/Slave Clock ü ü
Supported IEEE 1588 Profiles
Profile IEC/IEEE Standard Without PTP Card With PTP Card
Power Profile C37.238-2011 ü ü
Utility Profile Level 1 IEC/IEEE 61850-9-3
Edition 1
ü ü
Default P2P Profile IEEE 1588-2008 ü ü
Default E2E Profile IEEE 1588-2008 ü ü
Telecom Profile
(Slave Clock)
ITU-T G.8265.1 Annex A ü ü
Custom Profile {User Defined} ü ü
1.6.3 AM and TTL Outputs
The PTP card provides AM (Amplitude Modulated) and TTL (Transistor-Transistor
Logic) outputs.
The AM OUT port supports the IRIG-B AM signal format, while the TTL OUT port
supports the IRIG-B PWM and PPS signal formats. Enabling/disabling the output ports
and – in the case of TTL OUT – selecting the signal format is controlled through the
RUGGEDCOM RSG2288 operating system.
NOTICE
The input impedance of third-party AM inputs must be 100 Ω minimum.
The number of devices that can be connected to the AM OUT and TTL Out ports is
dependent on the cabling type and length, as well as the input impedances of the
devices. The following simplified circuit schematic shows the interface between an
IRIG-B source and connected devices.
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 9

Introduction
1.6.3AM and TTL Outputs
VS
RSRC
RL/N
321
1 Source
2 Cabling
3 Device
Figure1.3 IRIG-B Simplified Circuit Schematic
The maximum number of devices (N) that can be connected to the source is
determined by checking if the source current (IS) required to drive the connected
devices is less than the maximum drive current the source can provide, and verifying
that the load voltage (VL) the connected devices see is greater than the minimum
required voltage.
10 RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17

Installing the Device 2
The following sections describe how to install the device, including mounting the
device, installing/removing modules, connecting power, and connecting the device
to the network.
DANGER
Electrocution hazard – risk of serious personal injury and/or damage to
equipment.
Before performing any maintenance tasks, make sure all power to the device has
been disconnected and wait approximately two minutes for any remaining energy
to dissipate.
WARNING
Radiation hazard – risk of serious personal injury
This product contains a laser system and is classified as a CLASS 1 LASER PRODUCT.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
NOTICE
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens AG could invalidate
specifications, test results, and agency approvals, and void the user's authority to
operate the equipment.
NOTICE
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17 11
