Siemens SIMATIC HMI User manual

Preface
Overview 1
Safety instructions,
standards and notes 2
Planning application 3
Installation and connection 4
Operator controls and
displays 5
Configuring the operating
system 6
Commissioning the HMI
device 7
Fail-safe mode 8
Operating a project 9
Operating alarms 10
Operating recipes 11
Maintenance and care 12
Technical specifications 13
Appendix B
Abbreviations C
SIMATIC HMI
HMI device
Mobile Panel 277F IWLAN
Operating Instructions
12/2007
A5E01003940-01
Order No.: 6AV6691-1DQ01-2AA0

Safety Guidelines
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The device/system may only be set up and used in conjunction with this documentation. Commissioning and
operation of a device/system may only be performed by qualified personnel. Within the context of the safety notes
in this documentation qualified persons are defined as persons who are authorized to commission, ground and
label devices, systems and circuits in accordance with established safety practices and standards.
Prescribed Usage
Note the following:
WARNING
This device may only be used for the applications described in the catalog or the technical description and only
in connection with devices or components from other manufacturers which have been approved or
recommended by Siemens. Correct, reliable operation of the product requires proper transport, storage,
positioning and assembly as well as careful operation and maintenance.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Automation and Drives
Postfach 48 48
90327 NÜRNBERG
GERMANY
Ordernumber: A5E01003940-01
Ⓟ 01/2008
Copyright © Siemens AG 2007.
Technical data subject to change

Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 3
Preface
Purpose of the operating instructions
These operating instructions provide information based on the requirements defined by DIN
EN 62079 for mechanical engineering documentation. This information relates to the place of
use, transport, storage, mounting, use and maintenance.
These operating instructions are intended for the following user groups:
● Operators
The operator operates and monitors the system during the process control phase. The
following chapters are relevant to the operator:
– Operator controls and displays
– Fail-safe operation
– Operating a project
– Operating recipes
– Operating alarms
● Commissioning engineers
The commissioning engineer integrates the HMI device into the system and ensures the
operating capability of the HMI device for the process control phase.
All the operating instructions are relevant for the commissioning engineer.
Depending on the use of the HMI device, certain chapters may not be of relevance to the
commissioning engineer, for example the chapter "Maintenance and servicing".
● Service technicians
Service technicians rectify faults that occur during the process control phase.
The entire set of operating instructions is relevant to service technicians in principle.
Depending on the use of the HMI device, however, certain chapters may not be relevant
to them, for example the chapter on "Maintenance and care".
● Maintenance technicians
Maintenance technicians carry out regular maintenance work during the process control
phase. The chapter on "Maintenance and care" is relevant to maintenance technicians.
The chapter "Safety instructions, standards and information" should be particularly heeded
by all person groups.
The help integrated in WinCC flexible, the WinCC flexible Information System, contains
detailed information. The information system contains instructions, examples and reference
information in electronic form.

Preface
Mobile Panel 277F IWLAN
4 Operating Instructions, 12/2007, A5E01003940-01
Basic knowledge required
General knowledge of automation technology and process communication is needed to
understand the operating instructions.
It is also assumed that those using the manual have experience in using personal computers
and knowledge of Microsoft operating systems.
Scope of the operating instructions
These operating instructions apply to the Mobile Panel 277F IWLAN HMI device in
combination with the WinCC flexible software package.
For fail-safe operation, the information in the function manual "Fail-safe operation of the
Mobile Panel 277F IWLAN" applies.
Position in the information landscape
These operating instructions form part of the SIMATIC HMI documentation. The following
information provides you with an overview of the SIMATIC HMI information landscape.
User manuals
● WinCC flexible Micro
Describes basic principles of configuration using the WinCC flexible Micro Engineering
System.
● WinCC flexible Compact/ Standard/ Advanced
Describes basic principles of configuration using the WinCC flexible Compact
Engineering System/WinCC flexible Standard/WinCC flexible Advanced.
● WinCC flexible Runtime
Describes how to commission and operate your runtime project on a PC.
● WinCC flexible Migration
– Describes how to convert an existing ProTool project or WinCC project to
WinCC flexible.
● Communication
– Communication Part 1 describes the connection of the HMI device to SIMATIC PLCs.
– Communication Part 2 describes the connection of the HMI device to third-party PLCs.
Getting started
● WinCC flexible for first time users
Based on an example project, this is a step-by-step introduction to the basics of
configuring screens, alarms, recipes and screen navigation.
● WinCC flexible for power users
Based on an example project, this is a step-by-step introduction to the basics of
configuring logs, project reports, scripts, user management, multilingual projects and
integration in STEP 7.
● WinCC flexible options

Preface
Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 5
Based on an example project, this is a step-by-step introduction to the basics of
configuring the WinCC flexible Sm@rtServices, Sm@rtAccess and OPC server options.
● Mobile Panel 277 IWLAN
Introduces project design for WLAN communication step by step using a sample
structure.
Operating instructions
● Operating instructions for SIMATIC HMI devices
– OP 73, OP 77A, OP 77B
– TP 170micro, TP 170A, TP 170B, OP 170B
– OP 73micro, TP 177micro
– TP 177A, TP 177B, OP 177B
– TP 270, OP 270
– TP 277, OP 277
– MP 270B
– MP 277
– MP 370
– MP 377
● Operating instructions for mobile SIMATIC HMI devices
– Mobile Panel 177
– Mobile Panel 277
– Mobile Panel 277 IWLAN
– Mobile Panel 277F IWLAN
● Operating instructions (compact) for SIMATIC HMI devices
– OP 77B
– Mobile Panel 177
– Mobile Panel 277
● Operating instructions for SIMATIC accessories
– Industrial USB Hub 4
● Function manual
– Fail-safe operation of the Mobile Panel 277F IWLAN
Online availability
Technical documentation on SIMATIC products and SIMATIC systems is available in PDF
format in various languages at the following addresses:
● SIMATIC Guide Technical Documentation in German:
"http://www.ad.siemens.de/simatic/portal/html_00/techdoku.htm"
● SIMATIC Guide for Technical Documentation in English:
"http://www.ad.siemens.de/simatic/portal/html_76/techdoku.htm"

Preface
Mobile Panel 277F IWLAN
6 Operating Instructions, 12/2007, A5E01003940-01
Photos
The HMI device is sometimes shown in the form of photographs in these operating
instructions. The photographs of the HMI device may differ slightly from the factory state of
the HMI device.
Conventions
Configuration and runtime software differ with regard to their names as follows:
● "WinCC flexible 2007" for example, refers to the configuration software
The term "WinCC flexible" is used in a general context. The full name, for example
"WinCC flexible 2007", is always used when it is necessary to differentiate between
different versions of the configuration software.
● "WinCC flexible Runtime" refers to the runtime software that can run on HMI devices
The name "Mobile Panel 277 Wireless" is the collective term for the following HMI devices:
● Mobile Panel 277 IWLAN
● Mobile Panel 277F IWLAN
The following text notation will facilitate reading these operating instructions:
Notation Scope
"Add screen" •Terminology that appears in the user interface, for example
dialog names, tabs, buttons, menu entries
•Inputs required, for example limit values, tag values
•Path information
"File > Edit" Operational sequences, for example, menu commands, context
menu commands
<F1>, <Alt+P> Keyboard operation
Please observe notes labeled as follows:
Note
Notes contain important information concerning the product, its use or a specific section of
the documentation to which you should pay particular attention.
Registered trademarks
Names labeled with a ® symbol are registered trademarks of the Siemens AG. Other names
used in this documentation may be trademarks, the use of which by third parties for their
own purposes could violate the rights of the owner.
● HMI®
● SIMATIC®
● SIMATIC HMI®
● SIMATIC ProTool®
● WinCC®

Preface
Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 7
Representatives and offices
If you have any further questions relating to the products described in this manual, please
contact your local representative at the Siemens branch nearest you.
Your Siemens representative can be found at "http://www.siemens.com/automation/partner".
Training center
Siemens AG offers a variety of training courses to familiarize you with automation systems.
Please contact your regional training center, or our central training center in 90327
Nuremberg, Germany, for details.
Phone: [phone]
Internet: "http://www.sitrain.com"
Technical support
You can find technical support for all A&D projects
● Using the support request form on the web at:
"http://www.siemens.de/automation/support-request"
● Phone: + 49 180 5050 222
● Fax: + 49 180 5050 223
Further information about our technical support is available on the Internet at
"http://www.siemens.com/automation/service".
Service & Support on the Internet
Service & Support provides additional comprehensive information on SIMATIC products
through online services at "http://www.siemens.com/automation/support":
● Newsletters with the latest information about your products
● A large document base is available using our Service & Support search engine
● A forum for global exchange of information by users and experts
● Current product information, FAQs and downloads
● Your local Automation & Drives representative
● Information about field service, repairs, spare parts and much more under the heading
"Services"
Recycling and disposal
Due to the low levels of pollutants in the HMI devices described in these operating
instructions, they can be recycled. For environment-friendly recycling and disposal of your
old equipment, contact a certified disposal facility for electronic scrap.

Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 9
Table of contents
Preface ...................................................................................................................................................... 3
1 Overview.................................................................................................................................................. 17
1.1 Product overview .........................................................................................................................17
1.2 Design of the HMI device.............................................................................................................18
1.2.1 Mobile Panel 277F IWLAN...........................................................................................................18
1.2.2 Supplementary pack and other accessories................................................................................20
1.2.3 Battery..........................................................................................................................................22
1.2.4 Charging station...........................................................................................................................22
1.3 Configuration and process control phase ....................................................................................24
1.4 Transponder.................................................................................................................................25
1.5 Ranges in the plant ......................................................................................................................27
1.6 Fail-safe operation .......................................................................................................................28
1.7 Functional scope with WinCC flexible..........................................................................................29
1.8 Software options ..........................................................................................................................32
1.9 Communication ............................................................................................................................32
2 Safety instructions, standards and notes ................................................................................................. 35
2.1 Safety instructions........................................................................................................................35
2.2 Standards, certificates and approvals..........................................................................................37
2.3 Operating safety...........................................................................................................................39
2.4 Power supply................................................................................................................................40
2.5 Notes about usage.......................................................................................................................42
2.6 Risk analysis ................................................................................................................................43
2.7 Safety functions of the emergency stop button............................................................................43
2.8 Enabling button ............................................................................................................................44
2.9 Electromagnetic compatibility ......................................................................................................46
2.10 Transport and storage conditions ................................................................................................48
3 Planning application................................................................................................................................. 51
3.1 Application and ambient conditions .............................................................................................51
3.2 Mounting location and clearance of charging station ..................................................................54
3.3 Information on insulation tests, protection class and degree of protection..................................56
3.4 Rated voltages .............................................................................................................................57
3.5 Required properties of the WLAN connection .............................................................................57
3.6 Effective ranges and zones..........................................................................................................58

Table of contents
Mobile Panel 277F IWLAN
10 Operating Instructions, 12/2007, A5E01003940-01
3.6.1 Division of the system into effective ranges and zones .............................................................. 58
3.6.2 Distance measurement between HMI device and transponder.................................................. 61
3.6.3 Planning effective ranges............................................................................................................ 62
4 Installation and connection ...................................................................................................................... 65
4.1 Checking the package contents..................................................................................................65
4.2 Mounting the charging station..................................................................................................... 66
4.3 Setting transponder ID and inserting the battery ........................................................................ 66
4.4 Mounting the transponder ........................................................................................................... 69
4.5 Electrical installation.................................................................................................................... 69
4.6 Connection of the charging station to the power supply ............................................................. 70
4.7 Connecting the HMI device......................................................................................................... 71
4.7.1 Opening and closing the terminal compartment ......................................................................... 71
4.7.2 Interfaces of the HMI device ....................................................................................................... 76
4.7.3 Connecting the configuring PC ................................................................................................... 77
4.7.4 Connecting the PLC.................................................................................................................... 79
4.7.5 Connecting the printer................................................................................................................. 80
4.7.6 Connecting USB devices ............................................................................................................ 81
4.7.7 Connecting the tabletop power supply unit................................................................................. 82
4.8 Inserting, charging and changing the battery.............................................................................. 83
4.8.1 Safety instructions....................................................................................................................... 83
4.8.2 Inserting batteries for the first time.............................................................................................. 85
4.8.3 Displaying battery status............................................................................................................. 87
4.8.4 Changing the main battery.......................................................................................................... 88
4.8.5 Changing the bridging battery..................................................................................................... 89
4.9 Switching on and testing the HMI device.................................................................................... 91
5 Operator controls and displays ................................................................................................................ 95
5.1 Overview ..................................................................................................................................... 95
5.2 Displays on the Mobile Panel 277F IWLAN................................................................................ 96
5.3 Power management.................................................................................................................... 98
5.4 Safety-related operator controls................................................................................................ 100
5.4.1 Emergency stop button ............................................................................................................. 100
5.4.2 Enabling button ......................................................................................................................... 102
5.5 Operator controls ...................................................................................................................... 104
5.5.1 Handwheel ................................................................................................................................ 104
5.5.2 Key-operated switch.................................................................................................................. 105
5.5.3 Illuminated pushbutton.............................................................................................................. 106
5.5.4 Evaluation of the operator controls ........................................................................................... 107
5.5.4.1 Overview ................................................................................................................................... 107
5.5.4.2 Evaluating operator controls as direct keys .............................................................................. 107
5.5.4.3 Activation of function key LEDs using system functions........................................................... 110
5.5.4.4 Evaluation of the handwheel with system functions ................................................................. 111
5.5.4.5 Evaluation of the key-operated switch with system functions................................................... 112
5.5.4.6 Evaluation and activation of the illuminated pushbuttons ......................................................... 112
5.6 Using a memory card with the HMI device ............................................................................... 113
5.7 Labeling the function keys......................................................................................................... 116

Table of contents
Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 11
5.8 Holding the mobile panel and fixing it to the wall.......................................................................118
5.9 Charging station.........................................................................................................................120
5.9.1 Charging batteries in the charging compartment.......................................................................120
5.9.2 Displays on the charging station................................................................................................122
5.9.3 Locking the charging station ......................................................................................................123
6 Configuring the operating system .......................................................................................................... 125
6.1 Loader........................................................................................................................................125
6.2 WLAN.........................................................................................................................................128
6.2.1 Overview ....................................................................................................................................128
6.2.2 Parameterizing the WLAN connection.......................................................................................131
6.3 Control Panel .............................................................................................................................135
6.3.1 Overview ....................................................................................................................................135
6.3.2 Reference...................................................................................................................................136
6.3.3 Operating the Control Panel ......................................................................................................137
6.4 Changing settings for operation.................................................................................................140
6.4.1 Configuring the screen keyboard...............................................................................................140
6.4.2 Setting the character repeat rate of the screen keyboard .........................................................141
6.4.3 Setting the double-click..............................................................................................................143
6.4.4 Calibrating the touch screen ......................................................................................................144
6.5 Changing password protection ..................................................................................................146
6.6 Changing HMI device settings ...................................................................................................147
6.6.1 Setting the date and time...........................................................................................................147
6.6.2 Changing regional settings ........................................................................................................149
6.6.3 Backup registry information .......................................................................................................150
6.6.4 Changing screen settings ..........................................................................................................151
6.6.5 Setting the screen saver ............................................................................................................152
6.6.6 Changing the printer properties .................................................................................................154
6.6.7 Restarting the HMI device..........................................................................................................156
6.6.8 Displaying information about the HMI device ............................................................................157
6.6.9 Displaying system properties.....................................................................................................158
6.6.10 Activating vibration alarm...........................................................................................................159
6.7 Programming the data channel..................................................................................................160
6.8 Setting the delay time ................................................................................................................162
6.9 Setting the PROFIsafe address .................................................................................................164
6.10 Enabling PROFINET IO.............................................................................................................165
6.11 Configuring network operation...................................................................................................167
6.11.1 Overview of network operation ..................................................................................................167
6.11.2 Setting the device name of the HMI device ...............................................................................168
6.11.3 Changing the network configuration ..........................................................................................169
6.11.4 Changing the logon data............................................................................................................171
6.11.5 Changing e-mail settings ...........................................................................................................172
6.12 Changing internet settings .........................................................................................................173
6.12.1 Changing internet settings .........................................................................................................173
6.12.2 Setting the proxy server .............................................................................................................174
6.12.3 Changing data protection settings .............................................................................................175
6.12.4 Importing and deleting certificates .............................................................................................176
6.13 Backing up and restoring with an external memory medium ....................................................177

Table of contents
Mobile Panel 277F IWLAN
12 Operating Instructions, 12/2007, A5E01003940-01
6.14 Displaying battery status........................................................................................................... 181
6.15 Activate memory management ................................................................................................. 182
7 Commissioning the HMI device ............................................................................................................. 185
7.1 Overview ................................................................................................................................... 185
7.2 Operating modes....................................................................................................................... 186
7.3 Using existing projects .............................................................................................................. 187
7.4 Data transmission options......................................................................................................... 188
7.5 Preparing and backing up a project .......................................................................................... 189
7.5.1 Overview ................................................................................................................................... 189
7.5.2 Transfer..................................................................................................................................... 190
7.5.2.1 Overview ................................................................................................................................... 190
7.5.2.2 Starting manual transfer............................................................................................................ 190
7.5.2.3 Starting automatic transfer........................................................................................................ 191
7.5.2.4 Starting backtransfer ................................................................................................................. 193
7.5.3 Testing a project........................................................................................................................ 194
7.5.4 Acceptance of the system......................................................................................................... 196
7.5.4.1 Overview ................................................................................................................................... 196
7.5.4.2 Accepting effective ranges and transponders........................................................................... 196
7.5.4.3 Testing effective ranges............................................................................................................ 199
7.5.5 Testing zones............................................................................................................................ 200
7.5.6 Backup and restore ................................................................................................................... 200
7.5.6.1 Overview ................................................................................................................................... 200
7.5.6.2 Backup and restore using WinCC flexible................................................................................. 201
7.5.6.3 Backup and restore using ProSave .......................................................................................... 203
7.5.7 Updating the operating system ................................................................................................. 204
7.5.7.1 Overview ................................................................................................................................... 204
7.5.7.2 Updating the operating system using WinCC flexible............................................................... 206
7.5.7.3 Updating the operating system using ProSave......................................................................... 207
7.5.7.4 Resetting to factory settings with WinCC flexible...................................................................... 208
7.5.7.5 Resetting to factory settings with ProSave ............................................................................... 210
7.5.8 Installing and removing options ................................................................................................212
7.5.8.1 Overview ................................................................................................................................... 212
7.5.8.2 Installing and removing options using WinCC flexible .............................................................. 212
7.5.8.3 Installing and removing options using ProSave........................................................................ 214
7.5.9 Transferring and transferring back license keys ....................................................................... 215
7.5.9.1 Overview ................................................................................................................................... 215
7.5.9.2 Transferring and transferring back license keys ....................................................................... 216
8 Fail-safe mode....................................................................................................................................... 219
8.1 Organizational measures .......................................................................................................... 219
8.2 Switch-off behavior.................................................................................................................... 220
8.3 Integrating the HMI device ........................................................................................................ 222
8.4 Removing the HMI device......................................................................................................... 223
8.5 Logging onto and off from the effective range .......................................................................... 224
8.6 "Override" mode........................................................................................................................ 226
9 Operating a project ................................................................................................................................ 231
9.1 Starting the project .................................................................................................................... 231

Table of contents
Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 13
9.2 Error cases.................................................................................................................................232
9.3 Direct keys .................................................................................................................................234
9.4 Operator input options ...............................................................................................................235
9.5 Function keys.............................................................................................................................237
9.6 Setting the project language ......................................................................................................238
9.7 Input ...........................................................................................................................................239
9.7.1 Overview ....................................................................................................................................239
9.7.2 Entering and editing numerical values.......................................................................................240
9.7.3 Entering and editing alphanumerical values..............................................................................242
9.7.4 Entering the date and time.........................................................................................................243
9.7.5 Entering symbolic values ...........................................................................................................244
9.8 Displaying infotext......................................................................................................................244
9.9 Device-specific displays.............................................................................................................246
9.9.1 Displaying battery status............................................................................................................246
9.9.2 Displaying WLAN quality............................................................................................................246
9.9.3 Displaying the effective range name..........................................................................................247
9.9.4 Displaying the effective range quality ........................................................................................248
9.9.5 Displaying zone names..............................................................................................................249
9.9.6 Displaying zone quality ..............................................................................................................250
9.10 Bar and gauge ...........................................................................................................................251
9.11 Operating the slider control........................................................................................................252
9.12 Operating the switch ..................................................................................................................253
9.13 Operating the trend view............................................................................................................254
9.14 Operating the Status Force........................................................................................................256
9.14.1 Overview ....................................................................................................................................256
9.14.2 Operation ...................................................................................................................................258
9.15 Operating the Sm@rtClient view ...............................................................................................259
9.15.1 Overview ....................................................................................................................................259
9.15.2 Operation ...................................................................................................................................260
9.16 Project security ..........................................................................................................................261
9.16.1 Overview ....................................................................................................................................261
9.16.2 User view ...................................................................................................................................263
9.16.3 User logon..................................................................................................................................264
9.16.4 User logoff..................................................................................................................................266
9.16.5 Creating users............................................................................................................................266
9.16.6 Changing user data....................................................................................................................268
9.16.7 Deleting users ............................................................................................................................269
9.17 Closing the project .....................................................................................................................269
10 Operating alarms ................................................................................................................................... 271
10.1 Overview ....................................................................................................................................271
10.2 Recognizing pending alarms......................................................................................................272
10.3 Displaying alarms.......................................................................................................................273
10.4 Display infotexts for an alarm.....................................................................................................275
10.5 Acknowledge alarm....................................................................................................................275

Table of contents
Mobile Panel 277F IWLAN
14 Operating Instructions, 12/2007, A5E01003940-01
10.6 Edit alarm .................................................................................................................................. 276
11 Operating recipes .................................................................................................................................. 277
11.1 Overview ................................................................................................................................... 277
11.2 Structure of a recipe.................................................................................................................. 277
11.3 Recipes in the project................................................................................................................ 279
11.4 Recipe displays ......................................................................................................................... 280
11.5 Recipe values in the HMI device and the PLC.......................................................................... 283
11.6 Operating the recipe view ......................................................................................................... 284
11.6.1 Overview ................................................................................................................................... 284
11.6.2 Creating a recipe data record.................................................................................................... 285
11.6.3 Editing a recipe data record ...................................................................................................... 286
11.6.4 Deleting a recipe data record.................................................................................................... 287
11.6.5 Synchronizing tags.................................................................................................................... 288
11.6.6 Reading a recipe data record from the PLC ............................................................................. 289
11.6.7 Transferring a recipe data record to the PLC............................................................................ 290
11.7 Operating the simple recipe view.............................................................................................. 290
11.7.1 Overview ................................................................................................................................... 290
11.7.2 Creating a recipe data record.................................................................................................... 292
11.7.3 Editing a recipe data record ...................................................................................................... 293
11.7.4 Deleting a recipe data record.................................................................................................... 294
11.7.5 Reading a recipe data record from the PLC ............................................................................. 295
11.7.6 Transferring a recipe data record to the PLC............................................................................ 295
11.8 Exporting a recipe data record.................................................................................................. 296
11.9 Importing a recipe data record .................................................................................................. 297
11.10 Examples................................................................................................................................... 298
11.10.1 Entering a recipe data record.................................................................................................... 298
11.10.2 Manual production sequence.................................................................................................... 299
12 Maintenance and care ........................................................................................................................... 301
12.1 Maintenance and care............................................................................................................... 301
12.2 Spare parts and repairs............................................................................................................. 302
13 Technical specifications......................................................................................................................... 305
13.1 Dimension drawings.................................................................................................................. 305
13.1.1 Mobile Panel 277F IWLAN........................................................................................................305
13.1.2 Charging station ........................................................................................................................ 307
13.1.3 Transponder.............................................................................................................................. 308
13.2 Specifications ............................................................................................................................ 308
13.2.1 Mobile Panel 277F IWLAN........................................................................................................308
13.2.2 Batteries .................................................................................................................................... 311
13.2.3 Charging station ........................................................................................................................ 312
13.2.4 Transponder.............................................................................................................................. 312
13.2.5 Description of interfaces on the HMI device ............................................................................. 313
13.3 Radiation characteristic............................................................................................................. 314
13.3.1 Radiation characteristic of the transponder .............................................................................. 314
13.3.2 Radiation characteristic of HMI device...................................................................................... 316
B Appendix................................................................................................................................................ 321

Table of contents
Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 15
B.1 ESD guideline ............................................................................................................................321
B.2 System alarms ...........................................................................................................................323
C Abbreviations......................................................................................................................................... 325
C.1 Abbreviations .............................................................................................................................325
Glossary ................................................................................................................................................ 327
Index...................................................................................................................................................... 335

Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 17
Overview 1
1.1 Product overview
Expanded possible fields of application – with Mobile Panel 277F IWLAN
The Mobile Panel 277F IWLAN offers the option of implementing mobile safety functions
(emergency stop and enabling) at any point of a machine or system.
An effective range limit has been implemented for the Mobile Panel 277F IWLAN. Depending
on his or her location, the operator receives a secure, electronically monitored operator
control enable.
The HMI device communicates with the F-CPU via WLAN. This enables the operator to
operate different machines or systems without cables getting in the way.
The Mobile Panel 277F IWLAN is characterized by short commissioning times, a large user
memory and high performance, and is optimized for projects based on WinCC flexible.
The Mobile Panel 277F IWLAN has the following features:
● Safety-related operator controls:
– Emergency stop button
– Enabling button
● Effective range concept
● Wireless operation with
– IWLAN interface via PROFINET
– Battery operation
● 7.5" TFT screen with 64k colors
● 18 function keys with LED
● Extended HMI functions

Overview
1.2 Design of the HMI device
Mobile Panel 277F IWLAN
18 Operating Instructions, 12/2007, A5E01003940-01
1.2 Design of the HMI device
1.2.1 Mobile Panel 277F IWLAN
Introduction
The Mobile Panel 277F IWLAN is available in two design variations:
● With enabling button and emergency stop button
● With enabling button, emergency stop button, handwheel, key-operated switch and two
illuminated pushbuttons
Note
The Mobile Panel 277F IWLAN is intended to be battery-operated.
Front view
The following figure shows the Mobile Panel 277F IWLAN.
This can vary, depending on the delivery status of the HMI device.
① Emergency stop button
② LEDs
③ Display with touch screen
④ ON/OFF button
⑤ Covers for the labeling strip guides
⑥ Key-operated switch, optional

Overview
1.2 Design of the HMI device
Mobile Panel 277F IWLAN
Operating Instructions, 12/2007, A5E01003940-01 19
⑦ Illuminated pushbutton, optional
⑧ Membrane keyboard
⑨ Handwheel, optional
Side view



① Fall protection for the emergency stop button
② Enabling buttons, positioned on both sides of the Mobile Panel 277F IWLAN
③ Handle
Rear view
On the reverse side you will find the type plate and approvals.
 





Overview
1.2 Design of the HMI device
Mobile Panel 277F IWLAN
20 Operating Instructions, 12/2007, A5E01003940-01
① Handle
② Connection bay cover
③ Connection for tabletop power supply unit
④ Battery compartment cover
⑤ Charging contacts for charging station
⑥ USB connector
The Mobile Panel 277F IWLAN can be securely hooked into a charging station.
1.2.2 Supplementary pack and other accessories
Accessory kit
The accessory kit is supplied with the HMI device.
The accessories pack for the HMI device contains the following:
● Main battery
● Bridging battery
● Cover cap with rubber seal
● Screws for fixing the cover cap
● Label for cover cap
● Function manual "Fail-safe operation of the Mobile Panel 277F IWLAN", in German
● CD
The CD includes:
– Function manual "Fail-safe operation of the Mobile Panel 277F IWLAN", in German,
English and Japanese
– F-FBs for the Mobile Panel 277F IWLAN
Additional documents may be enclosed with the accessory kit.
Protective foil
A protective foil kit for the HMI device can be ordered. Use order number 6AV6 671-5BC00-
0AX0.
The protective foil prevents the touch screen from being scratched or soiled.
Labeling strips
Labeling strips can be ordered as accessories. Use order number 6AV6 671-5BF00-0AX0.
Stickers for the cover caps can also be supplied, in addition to the labeling strips. The cover
caps cover the slot openings for the labeling strips.
