Siemens SITRANS LR Instruction manual

Quick Start Manual 12/2012
SITRANS
Radar Transmitters
SITRANS Probe LR

IQ300IX.fm Page 5 Tuesday, October 2, 2001 1:43 PM

A5E32106153 SITRANS Probe LR – QUICK START MANUAL Page EN-1
mmmmm
English
SITRANS Probe LR Quick Start Manual
This manual outlines the essential features and functions of SITRANS Probe LR. We strongly
advise you to acquire the detailed version of the manual so you can use your instrument to its
fullest potential. The complete manual can be downloaded from the Siemens website at:
www.siemens.com/level. The printed manual is available from your local Siemens representative.
Questions about the contents of this manual can be directed to:
Siemens Milltronics Process Instruments
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: [email protected]om
MILLTRONICS is a registered trademark of Siemens Milltronics Process Instruments
Safety Guidelines1
Warning notices must be observed to ensure personal safety as well as that of others, and to
protect the product and the connected equipment. These warning notices are accompanied by
a clarification of the level of caution to be observed.
Copyright Siemens Milltronics
Process Instruments 2013.
All Rights Reserved
Disclaimer of Liability
We encourage users to purchase
authorized bound manuals, or to view
electronic versions as designed and
authored by Siemens Milltronics Process
Instruments. Siemens Milltronics
Process Instruments will not be
responsible for the contents of partial or
whole reproductions of either bound or
electronic versions.
While we have verified the contents of this manual
for agreement with the instrumentation described,
variations remain possible. Thus we cannot
guarantee full agreement. The contents of this
manual are regularly reviewed and corrections are
included in subsequent editions. We welcome all
suggestions for improvement.
Technical data subject to change.
1. This symbol is used when there is no corresponding caution symbol on the product.
WARNING: relates to a caution symbol on the product, and means that failure to
observe the necessary precautions can result in death, serious injury, and/or
considerable material damage.
WARNING1: means that failure to observe the necessary precautions can result
in death, serious injury, and/or considerable material damage.
Note: means important information about the product or that part of the operating manual.

Page EN-2 SITRANS Probe LR – QUICK START MANUAL A5E32106153
mmmmm
English
SITRANS Probe LR
SITRANS Probe LR is a 2-wire loop-powered, continuous level measuring instrument that
utilizes advanced pulse radar technology at 5.8 GHz (6.3 GHz in North America). The instrument
consists of an electronic component coupled to the antenna and process connection.
Communication is via HART1, and signals are processed using Sonic Intelligence®.
Specifications
For a complete listing, see the full manual for SITRANS Probe LR (Part#: 7ML19985HR0x). For
Approvals information, please refer to the device nameplate.2
Ambient/Operating Temperature
WARNING: Changes or modifications not expressly approved by Siemens could void
the user’s authority to operate the equipment.
Notes:
• This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case the
user will be required to correct the interference at his own expense.
• SITRANS Probe LR is to be used only in the manner outlined in this manual, otherwise
protection provided by the equipment may be impaired
• This product is intended for use in industrial areas. Operation of this equipment in a
residential area may cause interference to several frequency based communications..
1. HART®is a registered trademark of the HART Communication Foundation.
2. When the locking collar is secured, it prevents the enclosure rotating on the threaded connection.
Note: Process temperature and pressure capabilities are dependent upon information on
the process device tag. The reference drawing listed on the tag can be downloaded from the
Siemens website. Go to the SITRANS Probe LR product page at:
https://pia.khe.siemens.com/index.asp?Nr=11158.
process temperature
–40 to +80 °C (–40 to +176 °F)
ambient temperature
(surrounding enclosure volume)
–40 to +80 °C (–40 to +176 °F)
process device
tag
nameplate location
customer-supplied
flange
locking collar2over threaded connection;
secured by three 2 mm Allen set-screws
hand programmer

A5E32106153 SITRANS Probe LR – QUICK START MANUAL Page EN-3
mmmmm
English
Power
• Maximum 30 V DC
• 4 to 20 mA
Approvals
• General CSAUS/C, FM, CE, C-TICK
• Radio Europe (R&TTE), FCC, Industry Canada
• Hazardous Intrinsically Safe (Europe) ATEX II 1 G EEx ia IIC T4
(US/Canada) FM/CSA1: (barrier required)
Class I, Div. 1, Groups A, B, C, D
Class II, Div. 1, Groups E, F, G
Class III T4
(Australia) ANZEx Ex ia IIC T4
(Tamb = –40 to + 80 °C) IP67, IP68
(International) IECEx TSA 04.0020X Ex ia IIC T4
(Brazil) INMETRO: DNV 12.0068 X
Ex ia IIC T4 Ga
IP66/IP67/IP68
-40 ºC ≤T a ≤+80 ºC
DNV #OCP 0017
ABNT NBR IEC 60079-0:2008 e
ABNT NBR IEC 60079-11:2009
Non-incendive (US) FM2:
Class I, Div. 2, Groups A, B, C, D T5
• Marine Lloyd’s Register of Shipping
ABS Type Approval
Mechanical
• Process Connections:
threaded connection 1.5” NPT, BSP, or G (BS EN ISO 228-1)
•Antenna:
polypropylene rod hermetically sealed construction
Nominal 24 V DC at max. 550 Ohm
1. See
Wiring Drawing: Intrinsically Safe (FM ) on page 2 of Appendix A, for drawing number 23651611,
or Wiring Drawing: Intrinsically Safe (CSA) on page 3 of Appendix A, for drawing number 23651621.
2. See
Wiring Drawing: Non-incendive (FM) on page 1 of Appendix A, for drawing number 23650537.
Note: The use of approved watertight conduit hubs/glands is required for Type 4X /
NEMA 4X, Type 6 / NEMA 6, IP67, IP68 (outdoor applications).
Note: EN61000-4-3 (CE EMC) testing was conducted on the SITRANS Probe LR while
mounted in a metallic vessel.

Page EN-4 SITRANS Probe LR – QUICK START MANUAL A5E32106153
mmmmm
English
Process
• Temperature (at process connection): 40 to +80 °C (40 to +176 °F)
• Pressure (vessel): maximum 3 bar, gauge (43.5 psi, gauge)
Installation
Mounting location
Recommendations
• Ensure ambient temperature is within –40 to +80 °C (–40 to +176 °F).
• Provide easy access for viewing the display and programming via the hand programmer.
• Ensure the environment is suitable to the housing rating and materials of construction.
Precautions
• Avoid proximity to high voltage or current wiring, high voltage or current contacts, and to
variable frequency motor speed controllers.
• Avoid interference to the emission cone from obstructions or from the fill path.
• Avoid central locations on vessels.
WARNINGS:
• This product can only function properly and safely if it is correctly transported,
stored, installed, set up, operated, and maintained.
• Never attempt to loosen, remove, or disassemble process connection or instrument
housing while vessel contents are under pressure.
• This product is designated as a Pressure Accessory per Directive 97 / 23 / EC, and is
not intended for use as a safety device.
• Materials of construction are chosen based on their chemical compatibility (or
inertness) for general purposes. For exposure to specific environments, check with
chemical compatibility charts before installing.
• The user is responsible for the selection of bolting and gasket materials which will
fall within the limits of the flange and its intended use, and which are suitable for
the service conditions.
• Improper installation may result in loss of process pressure.
preferred undesirable
Coni
Fl at
Flat ParabolicConical
min. 300 mm (1 ft) for every
3 m (10 ft) of vessel height
beam
angle
28o
• Locate the antenna away from the side wall, to
avoid interference from indirect echoes.
• Avoid interference from objects such as ladders
or pipes, which can cause false echoes.
• Avoid interference from the fill path.

A5E32106153 SITRANS Probe LR – QUICK START MANUAL Page EN-5
mmmmm
English
Mounting instructions
• Before inserting SITRANS Probe LR into its mounting connection, check to ensure the
threads are matching to avoid damaging them.
• Simply screw SITRANS Probe LR into the process connection, and hand tighten.
• For pressure applications, it will be necessary to use PTFE tape (or other appropriate
thread-sealing compound) and tighten the process connection beyond hand-tight.
The maximum torque is 40 N-m (30 ft-lbs).
• To rotate the enclosure, use a 2 mm Allen key to loosen the three set-screws that secure
the locking collar. Once the enclosure is positioned as desired, tighten the set-screws.
Wiring
Power1
WARNINGS:
DC terminals shall be supplied from an SELV 1source in accordance with IEC-
1010-1 Annex H.
All field wiring must have insulation suitable for rated voltages.
1. Safety Extra Low Voltage
minimum
100 mm (4")
minimum
10 mm (0.4")
To provide optimum signal conditions on a manhole cover, locate the antenna off-center
relative to the cover, typically 100 mm (4”) from the side of the manhole.
• Use the 100 mm (4") shield on nozzles that are 100 mm (4") in length, or shorter.
• Use the 250 mm (10") shield on nozzles that are 250 mm (10") in length, or shorter.
Mounting on a nozzleMounting on a manhole cover

Page EN-6 SITRANS Probe LR – QUICK START MANUAL A5E32106153
mmmmm
English
Connecting SITRANS Probe LR1
1. If you want to rotate the instrument on the process connection, use the 2 mm Allen
key provided to loosen the 3 Allen set-screws securing the locking collar. Position
the unit, and retighten the screws.
2. Strip the cable jacket for approximately 70 mm (2.75") from the end of the cable, and
thread the wires through the strain relief2.
Notes:
• For detailed wiring instructions, please refer to the full Instruction Manual.
• Use shielded, twisted pair cable (wire gauge AWG14 to AWG22).
• Separate cables and conduits1may be required to conform to standard instrumentation
wiring practices, or electrical codes.
• The non-metallic enclosure does not provide a continuous ground path between conduit
connections: use grounding type bushings and jumpers.
1. If cable is routed through conduit, use only approved suitable-size hubs for waterproof application.
Note: Do not rotate the enclosure after programming and vessel calibration,
otherwise an error may occur, caused by a polarity shift of the transmit pulse.
2. If cable is routed through conduit, use only approved suitable-size hubs for waterproof applications.
locking collar
terminal block
lid screw (1 of 2)
Unscrew the two lid screws to release the
hinged lid and access the terminal block.
strain
relief (or
NPT cable
entry)

A5E32106153 SITRANS Probe LR – QUICK START MANUAL Page EN-7
mmmmm
English
3. Connect the wires to the terminals: the polarity is identified
on the terminal block.
4. Tighten the gland to form a good seal.
Close the lid and tighten screws: please do not overtighten
screws. (Recommended torque is 1.1 to 1.7 N-m (10 to 15 in-lb)
of torque)
RUN Mode and PROGRAM Mode
SITRANS Probe LR has two modes of operation: RUN and PROGRAM.
After you complete the installation procedures and power up SITRANS Probe LR, it starts in
RUN mode and detects the material level. It returns the distance (in meters) to the material
level referenced from Empty (process empty level). This is the default start-up display mode.
RUN Mode Display
Use the hand programmer to control the display.
If the echo confidence drops below the echo confidence threshold, the failsafe timer starts
running. When the timer expires, the letters LOE (Loss of Echo) alternate with the reading
every two seconds, and the Reliable Echo indicator is replaced by the Unreliable indicator.
When a valid reading is received, the level reading display returns to normal operation.
1 – Primary Reading (displays level, distance, or volume, in either units or percent)
2 – Secondary Reading (displays Parameter number for Auxiliary Reading)
3 – Echo status indicator: Reliable Echo or Unreliable Echo
4 – Units or Percent
5 – Active bar graph represents material level
6 – Auxiliary Reading (depending on the parameter selected, it displays milliAmp value,
distance, or echo confidence, with units where applicable)
m
m
Normal operation Failsafe operation
1
3
4
5
1
3
4
5
2
6
6

Page EN-8 SITRANS Probe LR – QUICK START MANUAL A5E32106153
mmmmm
English
PROGRAM Mode Display
Programming
• Set parameters to suit your specific application.
•ActivatePROGRAM mode at any time, to change parameter values and set operating
conditions.
• For local programming, use the Siemens hand programmer.
• For programming from a distance, use either a PC running SIMATIC1PDM or a HART
handheld communicator.
Hand programmer.
Note: Do not use the handheld programmer at the same time as SIMATIC PDM, or erratic
operation may result.
1. SIMATIC® is a registered trademark of Siemens AG.
1
23
6
1 – Primary Reading (displays parameter value)
2 – Secondary Reading (displays parameter number)
3 – Programming indicator
6 – Auxiliary Reading (displays parameter names for P001 to
P010, if a language is selected. It displays the index value
for indexed parameters, such as P054)
display
hand-held programmer
max. 600 mm
(2 ft)
Key Programming Mode
to Values
Decimal point
Negative value
CLEAR value
TOGGLE between Units and % on parameter
value
End PROGRAM session and enable RUN mode
Update echo quality parameters
Parameter scroll-up
Parameter scroll-down
DISPLAY opens parameter fields
ENTER the displayed value
For direct access to SITRANS Probe LR,
point the programmer at the
SITRANS Probe LR display and press
the keys. (For detailed instructions, see
the next page.)
