SITRANS
Pressure transmitter
SITRANS P320/P420 (mA/HART)
Operating Instructions
7MF03.0
7MF04.0
06/2018
A5E44852162-AA
Getting Started 1
Introduction 2
Safety information 3
Description 4
Installing/mounting 5
Connecting 6
Operating 7
Commissioning 8
Parameter assignment 9
Functional Safety 10
Service and maintenance 11
Diagnostics and
troubleshooting 12
Technical data 13
Dimension drawings 14
Appendix A
List of abbreviations B

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions. Qualified
personnel are those who, based on their training and experience, are capable of identifying risks and avoiding
potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in
this publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E44852162
Ⓟ 05/2018 Subject to change
Copyright © Siemens AG 2018.
All rights reserved

Table of contents
1 Getting Started...........................................................................................................................................11
1.1 Commissioning the device with display..................................................................................11
1.2 Commissioning the device without display.............................................................................13
2 Introduction.................................................................................................................................................15
2.1 Purpose of this documentation...............................................................................................15
2.2 Document history...................................................................................................................15
2.3 Product compatibility..............................................................................................................15
2.4 Scope of validity of this document..........................................................................................15
2.5 Checking the consignment.....................................................................................................16
2.6 Transportation and storage....................................................................................................16
2.7 Notes on warranty..................................................................................................................17
3 Safety information.......................................................................................................................................19
3.1 Precondition for use...............................................................................................................19
3.1.1 Warning symbols on the device.............................................................................................19
3.1.2 Laws and directives................................................................................................................19
3.1.3 Conformity with European directives......................................................................................20
3.2 Requirements for special applications...................................................................................20
3.3 Use in hazardous areas.........................................................................................................21
4 Description..................................................................................................................................................23
4.1 Area of application.................................................................................................................23
4.2 Structure.................................................................................................................................25
4.3 Nameplate layout...................................................................................................................26
4.4 Functional principle................................................................................................................28
4.4.1 Overview of mode of operation..............................................................................................28
4.4.2 How the electronics work.......................................................................................................29
4.4.3 Measuring cell operation........................................................................................................30
4.4.3.1 Measuring cell for gauge pressure.........................................................................................31
4.4.3.2 Measuring cell for gauge pressure, front-flush membrane.....................................................32
4.4.3.3 Measuring cell for absolute pressure from the gauge pressure series..................................32
4.4.3.4 Measuring cell for absolute pressure, front-flush membrane.................................................33
4.4.3.5 Measuring cell for absolute pressure from the differential pressure series............................34
4.4.3.6 Measuring cell for differential pressure and flow rate.............................................................35
4.4.3.7 Measuring cell for level..........................................................................................................36
4.5 Remote seal...........................................................................................................................37
4.6 System configuration..............................................................................................................37
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 3

5 Installing/mounting......................................................................................................................................39
5.1 Basic safety instructions.........................................................................................................39
5.1.1 Installation location requirements...........................................................................................41
5.1.1.1 Devices with marine approval................................................................................................42
5.1.2 Proper mounting.....................................................................................................................42
5.2 Installation (except level)........................................................................................................43
5.2.1 Installation configuration........................................................................................................43
5.2.2 Installation (except level)........................................................................................................44
5.2.3 Fastening with the mounting bracket.....................................................................................45
5.3 Installation (level)...................................................................................................................46
5.3.1 Mounting on the container......................................................................................................47
5.4 Installing "Remote seal".........................................................................................................50
5.4.1 Remote seal installation.........................................................................................................50
5.4.2 Installation of the remote seal with the capillary line..............................................................51
5.5 Removing...............................................................................................................................54
5.6 Rotating the display................................................................................................................55
5.7 Rotating the enclosure...........................................................................................................57
6 Connecting.................................................................................................................................................59
6.1 Basic safety instructions.........................................................................................................59
6.2 Connecting the device............................................................................................................62
6.2.1 Opening the device................................................................................................................62
6.2.2 Connecting the device............................................................................................................63
6.2.3 Closing the device..................................................................................................................64
6.3 Connect the Han cable socket to the cable............................................................................65
6.4 Connect M12 cable socket to the cable.................................................................................66
7 Operating....................................................................................................................................................69
7.1 Introduction............................................................................................................................69
7.2 Operating the device with display..........................................................................................70
7.2.1 Display...................................................................................................................................70
7.2.2 Navigating in the views..........................................................................................................71
7.2.3 Measurement view.................................................................................................................72
7.2.3.1 Display of measured values...................................................................................................73
7.2.3.2 Navigating in the measurement view.....................................................................................74
7.2.4 Parameter view......................................................................................................................74
7.2.4.1 List of parameters on the display...........................................................................................74
7.2.4.2 Navigating in the parameter view...........................................................................................76
7.2.5 Edit view.................................................................................................................................76
7.2.5.1 Changing parameter values...................................................................................................77
7.3 Remote operation...................................................................................................................77
7.3.1 Requirements.........................................................................................................................77
7.3.2 SIMATIC PDM........................................................................................................................77
7.4 Locking the device.................................................................................................................78
7.4.1 Setting the jumper..................................................................................................................79
Table of contents
SITRANS P320/P420 (mA/HART)
4Operating Instructions, 06/2018, A5E44852162-AA

7.4.2 Enable user PIN.....................................................................................................................81
7.4.3 Enabling button lock...............................................................................................................81
8 Commissioning...........................................................................................................................................83
8.1 Basic safety instructions.........................................................................................................83
8.2 Switching on the supply voltage.............................................................................................84
8.3 Commissioning the device with display..................................................................................85
8.4 Commissioning the device without display.............................................................................87
8.5 Application examples.............................................................................................................88
8.5.1 gauge pressure, absolute pressure from the differential pressure series and absolute
pressure from the gauge pressure series..............................................................................88
8.5.1.1 Commissioning for gases.......................................................................................................88
8.5.1.2 Commissioning with steam or liquid.......................................................................................90
8.5.2 Differential pressure and volume flow....................................................................................91
8.5.2.1 Commissioning in gaseous environments..............................................................................91
8.5.2.2 Commissioning with liquids....................................................................................................92
8.5.2.3 Commissioning with vapor.....................................................................................................94
9 Parameter assignment...............................................................................................................................97
9.1 Overview of parameters and functions...................................................................................97
9.2 Parameter assignment over device with display..................................................................101
9.2.1 Pressure units [01]...............................................................................................................101
9.2.1.1 Display of the pressure units................................................................................................102
9.2.1.2 Setting the pressure units....................................................................................................103
9.2.2 Set lower range value [02]/Set upper range value [03]........................................................104
9.2.2.1 Set lower range value parameter [02]..................................................................................104
9.2.2.2 Set upper range value parameter [03].................................................................................104
9.2.2.3 Set lower range value/upper range value (without pressure available)...............................104
9.2.3 Damping value [04]..............................................................................................................105
9.2.3.1 Set damping value...............................................................................................................106
9.2.4 Application [05].....................................................................................................................106
9.2.4.1 Pressure measurement........................................................................................................108
9.2.4.2 Level measurement..............................................................................................................109
9.2.4.3 Volume and mass flow measurements................................................................................111
9.2.4.4 Volume measurement..........................................................................................................114
9.2.4.5 Set application......................................................................................................................115
9.2.5 Application point [06]............................................................................................................115
9.2.6 Zero point adjustment [07]...................................................................................................116
9.2.6.1 Adjusting zero point (gauge pressure).................................................................................116
9.2.6.2 Adjusting the zero point (differential pressure).....................................................................117
9.2.6.3 Adjusting zero point (absolute pressure)..............................................................................117
9.2.7 Apply lower range value [08]/Apply upper range value [09].................................................118
9.2.7.1 Apply lower range value parameter [08]..............................................................................118
9.2.7.2 Apply upper range value parameter [09]..............................................................................118
9.2.7.3 Apply lower range value/upper range value (with pressure present)...................................119
9.2.8 Select fault current [10]........................................................................................................120
9.2.9 Lower fault current [11]........................................................................................................120
9.2.10 Upper fault current [12]........................................................................................................121
9.2.11 Lower saturation limit [13]....................................................................................................121
9.2.12 Upper saturation limit [14]....................................................................................................122
Table of contents
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 5

9.2.13 SV selection [15]..................................................................................................................123
9.2.14 Units [16]..............................................................................................................................123
9.2.14.1 Level units [16].....................................................................................................................123
9.2.14.2 Volume units [16].................................................................................................................124
9.2.14.3 Volume flow units [16]..........................................................................................................124
9.2.14.4 Mass flow units [16]..............................................................................................................125
9.2.15 Temperature units [17].........................................................................................................126
9.2.16 Lower scaling point [18].......................................................................................................126
9.2.16.1 Set lower scaling point.........................................................................................................127
9.2.17 Upper scaling point [19].......................................................................................................128
9.2.17.1 Set upper scaling point.........................................................................................................128
9.2.18 Low flow cut-off [20].............................................................................................................128
9.2.19 Vessel dimension A [21].......................................................................................................129
9.2.20 Vessel dimension L [22].......................................................................................................129
9.2.21 Button lock [23]....................................................................................................................130
9.2.21.1 Enabling button lock.............................................................................................................130
9.2.21.2 Disabling button lock............................................................................................................131
9.2.22 Change user PIN [24]...........................................................................................................131
9.2.23 Recovery ID [25]..................................................................................................................132
9.2.23.1 Display Recovery ID.............................................................................................................132
9.2.24 PIN recovery [26].................................................................................................................133
9.2.24.1 Recovering the user PIN......................................................................................................133
9.2.25 User PIN [27]........................................................................................................................134
9.2.25.1 Enable user PIN...................................................................................................................134
9.2.25.2 Disable user PIN..................................................................................................................135
9.2.26 Active device mode [28].......................................................................................................136
9.2.27 Functional Safety [29]..........................................................................................................136
9.2.28 Display test [30]....................................................................................................................136
9.2.29 Loop test [31].......................................................................................................................137
9.2.29.1 Loop test with preset loop current value..............................................................................137
9.2.29.2 Loop test with user defined loop current value.....................................................................138
9.2.30 Start view [32]......................................................................................................................138
9.2.31 Pressure reference [33]........................................................................................................139
9.2.32 Identify the device [34].........................................................................................................139
9.2.33 Reset [35].............................................................................................................................140
9.2.33.1 Reset to sensor calibration...................................................................................................140
9.2.33.2 Reset DAC trim to the factory setting...................................................................................140
9.2.33.3 Restore ordered configuration..............................................................................................141
9.2.33.4 Restore factory settings.......................................................................................................141
9.3 Parameter assignment over remote operation.....................................................................142
9.3.1 Introduction..........................................................................................................................142
9.3.2 Quick start............................................................................................................................142
9.3.3 Identification.........................................................................................................................143
9.3.4 Simulation............................................................................................................................143
9.3.4.1 Simulate constant pressure values .....................................................................................144
9.3.4.2 Simulate ramp function........................................................................................................145
9.3.4.3 Simulate diagnostics............................................................................................................145
9.3.5 Customized characteristic curve..........................................................................................146
9.3.5.1 Introduction..........................................................................................................................146
9.3.5.2 "Custom units" parameter....................................................................................................147
9.3.5.3 Set customized characteristic curve.....................................................................................147
9.3.6 Sensor calibration................................................................................................................148
Table of contents
SITRANS P320/P420 (mA/HART)
6Operating Instructions, 06/2018, A5E44852162-AA

9.3.7 Diagnostics functions...........................................................................................................149
9.3.7.1 Limit monitoring and event counter......................................................................................149
9.3.7.2 Trend log..............................................................................................................................152
10 Functional Safety......................................................................................................................................153
10.1 Safety concept.....................................................................................................................153
10.1.1 Random and systematic errors............................................................................................153
10.1.2 SIL-compliant product version..............................................................................................153
10.1.3 Safety function.....................................................................................................................154
10.1.3.1 Device statuses....................................................................................................................156
10.1.3.2 Safety parameters................................................................................................................156
10.1.4 Operating modes of the device............................................................................................157
10.1.5 Device mode........................................................................................................................157
10.1.5.1 Validation.............................................................................................................................158
10.1.5.2 Safety-related parameters....................................................................................................159
10.1.5.3 Device mode "Functional Safety enabled"...........................................................................159
10.2 Enabling Functional Safety..................................................................................................160
10.2.1 Enabling Functional Safety over device with display...........................................................160
10.2.2 Enabling Functional Safety over remote operation..............................................................163
10.3 Acknowledging safety-related errors....................................................................................168
10.3.1 "Safety critical error" device mode.......................................................................................168
10.3.2 Acknowledging safety-related errors via remote operation..................................................169
10.4 Disabling Functional Safety over device with display...........................................................170
10.5 Disabling Functional Safety over remote operation.............................................................171
10.6 Proof test..............................................................................................................................172
10.6.1 Intervals and rules for proof test...........................................................................................172
10.6.2 Documenting a proof test.....................................................................................................173
10.7 Repair and service...............................................................................................................173
11 Service and maintenance.........................................................................................................................175
11.1 Basic safety instructions.......................................................................................................175
11.2 Cleaning...............................................................................................................................176
11.2.1 Cleaning the enclosure........................................................................................................176
11.2.2 Servicing the remote seal measuring system......................................................................176
11.3 Maintenance and repair work...............................................................................................177
11.3.1 Defining the maintenance interval........................................................................................177
11.3.2 Checking the gaskets...........................................................................................................178
11.3.3 Check cable glands..............................................................................................................179
11.4 Return procedure.................................................................................................................180
11.5 Disposal...............................................................................................................................180
12 Diagnostics and troubleshooting..............................................................................................................181
12.1 Device status symbols.........................................................................................................181
12.2 Diagnostic messages...........................................................................................................184
12.3 Troubleshooting...................................................................................................................190
12.3.1 Troubleshooting Functional Security....................................................................................190
Table of contents
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 7

13 Technical data..........................................................................................................................................191
13.1 Input.....................................................................................................................................191
13.1.1 Gauge pressure...................................................................................................................191
13.1.2 Gauge pressure with front-flush diaphragm.........................................................................192
13.1.3 Gauge pressure from the differential pressure series..........................................................193
13.1.4 Absolute pressure from the gauge pressure series.............................................................194
13.1.5 Absolute pressure with front-flush diaphragm......................................................................195
13.1.6 Absolute pressure from the differential pressure series.......................................................196
13.1.7 Differential pressure and flow...............................................................................................197
13.1.8 Level.....................................................................................................................................198
13.2 Measuring accuracy of SITRANS P320...............................................................................199
13.2.1 Reference conditions...........................................................................................................199
13.2.2 Effect of auxiliary power supply............................................................................................199
13.2.3 Gauge pressure...................................................................................................................199
13.2.4 Gauge pressure from the differential pressure series..........................................................201
13.2.5 Absolute pressure from gauge and differential pressure series...........................................202
13.2.6 Absolute pressure with front-flush diaphragm......................................................................203
13.2.7 Gauge pressure with front-flush diaphragm.........................................................................204
13.2.8 Differential pressure and flow...............................................................................................205
13.2.9 Level.....................................................................................................................................208
13.3 Measuring accuracy of SITRANS P420...............................................................................209
13.3.1 Reference conditions...........................................................................................................209
13.3.2 Effect of auxiliary power supply............................................................................................209
13.3.3 Gauge pressure...................................................................................................................209
13.3.4 Gauge pressure from the differential pressure series .........................................................210
13.3.5 Absolute pressure from gauge and differential pressure series...........................................212
13.3.6 Absolute pressure with front-flush diaphragm......................................................................213
13.3.7 Gauge pressure with front-flush diaphragm.........................................................................214
13.3.8 Differential pressure and flow...............................................................................................214
13.3.9 Level.....................................................................................................................................218
13.4 Output..................................................................................................................................219
13.5 Operating conditions............................................................................................................219
13.6 Vibration resistance..............................................................................................................224
13.7 Construction.........................................................................................................................225
13.8 Torques................................................................................................................................229
13.9 Display, keyboard and auxiliary power.................................................................................229
13.10 Certificates and approvals....................................................................................................230
14 Dimension drawings.................................................................................................................................233
14.1 SITRANS P320/P420 for gauge pressure and absolute pressure from the gauge
pressure series.....................................................................................................................233
14.2 SITRANS P320/P420 for differential pressure, gauge pressure, flow and absolute
pressure from the differential pressure series......................................................................235
14.3 SITRANS P 320/P420 for level............................................................................................237
14.4 SITRANS P320/P420 (front-flush).......................................................................................238
Table of contents
SITRANS P320/P420 (mA/HART)
8Operating Instructions, 06/2018, A5E44852162-AA

14.4.1 Note 3A and EHDG..............................................................................................................239
14.4.2 Connections as per EN and ASME......................................................................................239
14.4.3 F&B and pharma flange.......................................................................................................240
14.4.4 PMC Style............................................................................................................................244
14.4.5 Special connections.............................................................................................................245
A Appendix...................................................................................................................................................247
A.1 Technical support.................................................................................................................247
A.2 Certificates...........................................................................................................................248
A.3 QR code label......................................................................................................................248
A.4 Checklist for Functional Safety.............................................................................................248
B List of abbreviations..................................................................................................................................251
B.1 Pressure transmitter abbreviations......................................................................................251
Glossary...................................................................................................................................................253
Index.........................................................................................................................................................257
Table of contents
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 9

Table of contents
SITRANS P320/P420 (mA/HART)
10 Operating Instructions, 06/2018, A5E44852162-AA

Getting Started 1
1.1 Commissioning the device with display
Introduction
In this section, you will learn how to commission the device step-by-step.
Before you start, please read the following safety information:
● General safety information (Page 19)
● Basic safety information: Installing/mounting
● Basic safety information: Connecting
● Basic safety information: Commissioning
Read the entire device manual in order to achieve the optimum performance of the device.
Procedure
1. Mount the device.
Installation (except level) (Page 43)
Installation (level) (Page 46)
2. Connect the device.
Connecting the device (Page 62)
3. Switch on the power supply.
Switching on the supply voltage (Page 84)
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 11

4. Open the cover of the buttons:
Figure 1-1 Top view
5. Set the measuring range.
Set lower range value/upper range value (without pressure available) (Page 104)
Apply lower range value/upper range value (with pressure present) (Page 119)
6. Set the pressure unit.
Setting the pressure units (Page 103)
7. Set the application of your device.
Set application (Page 115)
8. Set the scaling points.
Set lower scaling point (Page 127)
Set upper scaling point (Page 128)
9. Set the zero point.
Adjusting zero point (gauge pressure) (Page 116)
Adjusting the zero point (differential pressure) (Page 117)
Adjusting zero point (absolute pressure) (Page 117)
10.Lock the device.
Locking the device (Page 78)
11.Enable Functional Safety (for devices with Functional Safety).
Enabling Functional Safety over device with display (Page 160)
You can find additional functions in the section Parameter assignment (Page 97)
Getting Started
1.1 Commissioning the device with display
SITRANS P320/P420 (mA/HART)
12 Operating Instructions, 06/2018, A5E44852162-AA

1.2 Commissioning the device without display
Introduction
In this section, you will learn how to commission the device step-by-step.
Before you start, please read the following safety information:
● General safety information (Page 19)
● Basic safety information: Installing/mounting
● Basic safety information: Connecting
● Basic safety information: Commissioning
Read the entire device manual in order to achieve the optimum performance of the device.
Procedure
1. Mount the device.
Installation (except level) (Page 43)
Installation (level) (Page 46)
2. Connect the device.
Connecting the device (Page 62)
3. Switch on the power supply.
Switching on the supply voltage (Page 84)
Getting Started
1.2 Commissioning the device without display
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 13

4. Open the cover of the buttons:
Figure 1-2 Top view
5. Operate the buttons as follows:
Apply lower range value (with pressure applied) Hold down the button for 3 seconds.
Apply upper range value (with pressure applied) Hold down the button for 3 seconds.
Zero point adjustment Hold down the buttons and for 3 seconds.
Set Upper fault current Hold down the button for 3 seconds.
Set Lower fault current Hold down the button for 3 seconds.
Additional functions are available with remote operation.
Parameter assignment (Page 97)
See also
Set lower range value/upper range value (without pressure available) (Page 104)
Getting Started
1.2 Commissioning the device without display
SITRANS P320/P420 (mA/HART)
14 Operating Instructions, 06/2018, A5E44852162-AA

Introduction 2
2.1 Purpose of this documentation
These instructions contain all information required to commission and use the device. Read
the instructions carefully prior to installation and commissioning. In order to use the device
correctly, first review its principle of operation.
The instructions are aimed at persons mechanically installing the device, connecting it
electronically, configuring the parameters and commissioning it, as well as service and
maintenance engineers.
2.2 Document history
The overview below summarizes the most important changes in the documentation when
compared to the previous edition.
Edition Note
06/2018 First edition
2.3 Product compatibility
The following table describes the compatibility between the edition of this manual, the device
revision, the engineering system and the associated EDD.
Edition Comments Product compatibility Compatibility with device integra‐
tion package
06/2018 First edition HART 7
FW: 1.00.08 or higher
HW: 1.00.00 or higher
Device version 1
SIMATIC PDM V9.0 or higher
AMS Device Manager V13 or high‐
er
DTM Pactware V4.1 SP4
FC475 V3.9 or higher
2.4 Scope of validity of this document
Variant SITRANS P320 mA/HART SITRANS P420 mA/HART
Gauge pressure 7MF0300 7MF0400
Gauge pressure from the differential
pressure series
7MF0310 7MF0410
Absolute pressure from the gauge pres‐
sure series
7MF0320 7MF0420
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 15

Variant SITRANS P320 mA/HART SITRANS P420 mA/HART
Absolute pressure from the differential
pressure series
7MF0330 7MF0430
Differential pressure and flow rate,
PN 160 (MAWP 2320 psi)
7MF0340 7MF0440
Differential pressure and flow rate, PN
420 (MAWP 6092 psi)
7MF0350 7MF0450
Level 7MF0360 7MF0460
2.5 Checking the consignment
1. Check the packaging and the delivered items for visible damages.
2. Report any claims for damages immediately to the shipping company.
3. Retain damaged parts for clarification.
4. Check the scope of delivery by comparing your order to the shipping documents for
correctness and completeness.
WARNING
Using a damaged or incomplete device
Risk of explosion in hazardous areas.
● Do not use damaged or incomplete devices.
See also
Return procedure (Page 180)
Technical data (Page 191)
2.6 Transportation and storage
To guarantee sufficient protection during transport and storage, observe the following:
● Keep the original packaging for subsequent transportation.
● Devices/replacement parts should be returned in their original packaging.
● If the original packaging is no longer available, ensure that all shipments are properly
packaged to provide sufficient protection during transport. Siemens cannot assume liability
for any costs associated with transportation damages.
NOTICE
Insufficient protection during storage
The packaging only provides limited protection against moisture and infiltration.
● Provide additional packaging as necessary.
Introduction
2.6 Transportation and storage
SITRANS P320/P420 (mA/HART)
16 Operating Instructions, 06/2018, A5E44852162-AA

Special conditions for storage and transportation of the device are listed in Technical data
(Page 191).
2.7 Notes on warranty
The contents of this manual shall not become part of or modify any prior or existing agreement,
commitment or legal relationship. The sales contract contains all obligations on the part of
Siemens as well as the complete and solely applicable warranty conditions. Any statements
regarding device versions described in the manual do not create new warranties or modify the
existing warranty.
The content reflects the technical status at the time of publishing. Siemens reserves the right
to make technical changes in the course of further development.
Introduction
2.7 Notes on warranty
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 17

Introduction
2.7 Notes on warranty
SITRANS P320/P420 (mA/HART)
18 Operating Instructions, 06/2018, A5E44852162-AA

Safety information 3
3.1 Precondition for use
This device left the factory in good working condition. In order to maintain this status and to
ensure safe operation of the device, observe these instructions and all the specifications
relevant to safety.
Observe the information and symbols on the device. Do not remove any information or symbols
from the device. Always keep the information and symbols in a completely legible state.
3.1.1 Warning symbols on the device
Symbol Explanation
Consult operating instructions
3.1.2 Laws and directives
Observe the safety rules, provisions and laws applicable in your country during connection,
assembly and operation. These include, for example:
● National Electrical Code (NEC - NFPA 70) (USA)
● Canadian Electrical Code (CEC) (Canada)
Further provisions for hazardous area applications are for example:
● IEC 60079-14 (international)
● EN 60079-14 (EU)
SITRANS P320/P420 (mA/HART)
Operating Instructions, 06/2018, A5E44852162-AA 19

3.1.3 Conformity with European directives
The CE mark on the device is a sign of conformity with the following European directives:
Electromagnetic compatibility EMC
2014/30/EU
Directive of the European Parliament and of the Council on the harmonization
of the laws of the Member States relating to electromagnetic compatibility
Atmosphère explosible ATEX
2014/34/EU
Directive of the European Parliament and the Council on the harmonization of
the laws of the Member States concerning equipment and protective systems
intended for use in potentially explosive atmospheres
Pressure Equipment Directive
PED
2014/68/EU
Directive of the European Parliament and of the Council on the harmonization
of the laws of the Member States relating to the making available on the market
of pressure equipment
The directives applied can be found in the EU declaration of conformity for the associated
device.
WARNING
Improper device modifications
Risk to personnel, system and environment can result from modifications to the device,
particularly in hazardous areas.
● Only carry out modifications that are described in the instructions for the device. Failure
to observe this requirement cancels the manufacturer's warranty and the product
approvals.
3.2 Requirements for special applications
Due to the large number of possible applications, each detail of the described device versions
for each possible scenario during commissioning, operation, maintenance or operation in
systems cannot be considered in the instructions. If you need additional information not
covered by these instructions, contact your local Siemens office or company representative.
Note
Operation under special ambient conditions
We highly recommend that you contact your Siemens representative or our application
department before you operate the device under special ambient conditions as can be
encountered in nuclear power plants or when the device is used for research and development
purposes.
Safety information
3.2 Requirements for special applications
SITRANS P320/P420 (mA/HART)
20 Operating Instructions, 06/2018, A5E44852162-AA
