Sierra Wireless AirLink RV50 Series Installation manual

AirLink RV50 Series
Hardware User Guide
4117313
Rev 3

Preface
Rev 3 Dec.16 3
Important
Notice
Due to the nature of wireless communications, transmission and reception of data
can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be
totally lost. Although significant delays or losses of data are rare when wireless
devices such as the Sierra Wireless modem are used in a normal manner with a
well-constructed network, the Sierra Wireless modem should not be used in
situations where failure to transmit or receive data could result in damage of any
kind to the user or any other party, including but not limited to personal injury,
death, or loss of property. Sierra Wireless accepts no responsibility for damages
of any kind resulting from delays or errors in data transmitted or received using
the Sierra Wireless modem, or for failure of the Sierra Wireless modem to
transmit or receive such data.
Safety and
Hazards
Do not operate the Sierra Wireless modem in areas where blasting is in progress,
near medical equipment, near life support equipment, or any equipment which
may be susceptible to any form of radio interference. In such areas, the Sierra
Wireless modem MUST BE POWERED OFF. The Sierra Wireless modem can
transmit signals that could interfere with this equipment.
The driver or operator of any vehicle should not operate the Sierra Wireless
modem while in control of a vehicle. Doing so will detract from the driver or
operator's control and operation of that vehicle. In some states and provinces,
operating such communications devices while in control of a vehicle is an offence.
The RV50 Series platform is classified to ANSI/ISA 12.12.01-2016 and CSA
C22.2#213 and are suitable for use in Class 1, Division 2, Groups A, B, C and D
T4, and Class I Zone 2 Group IIC T4 classified Hazardous Locations.
The following warnings and instructions apply:
Warning: EXPLOSION HAZARD–SUBSTITUTION OF COMPONENTS MAY IMPAIR
SUITABILITY FOR CLASS I, DIVISION 2 and CLASS I, ZONE 2.
Avertrissement: RISQUE D’EXPLOSION-LA SUBSTITUTION DE COMPOSANTS
PEUT RENDRE CE MATERIEL INACCEPTABLE POUR LES EMPLACEMENTS DE
CLASSE I, DIVSION 2 et CLASSE I, ZONE 2.
Warning: EXPLOSION HAZARD–DO NOT DISCONNECT WHILE CIRCUIT IS LIVE
UNLESS THE AREA IS KNOWN TO BE NON-HAZARDOUS.
Avertrissement: RISQUE D’EXPLOSION-NE PAS DEBRANCHER TANT QUE LE
CIRCUIT EST SOURS TENSION, A MOINES QU’IL NE S’AGISSE D’UN
EMPLACEMENT NON DANGEREUX.
Warning: DO NOT USE THE USB CONNECTOR IN A HAZARDOUS AREA.
Avertrissement: NE PAS UTILISER DE CONNECTEUR USB DANS LES
ENVIRONNEMENTS DANGEREUX.

AirLink RV50 Series Hardware User Guide
4 4117313
Warning: DO NOT USE THE RESET BUTTON IN A HAZARDOUS AREA.
Avertrissement: NE PAS UTILISER LE BOUTON DE RESET DANS UN
ENVIRONNEMENT DANGEREUX.
Limitation of
Liability
The information in this manual is subject to change without notice and does not
represent a commitment on the part of Sierra Wireless. SIERRA WIRELESS AND
ITS AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL
DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL,
PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO,
LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE
ARISING OUT OF THE USE OR INABILITY TO USE ANY SIERRA WIRELESS
PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE
FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY.
Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its
affiliates aggregate liability arising under or in connection with the Sierra Wireless
product, regardless of the number of events, occurrences, or claims giving rise to
liability, be in excess of the price paid by the purchaser for the Sierra Wireless
product.
Patents This product may contain technology developed by or for Sierra Wireless Inc. This
product includes technology licensed from QUALCOMM®. This product is
manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more
patents licensed from InterDigital Group and MMP Portfolio Licensing.
Copyright © 2016 Sierra Wireless. All rights reserved.
Trademarks Sierra Wireless®, AirPrime®, AirLink®, AirVantage®and the Sierra Wireless logo
are registered trademarks of Sierra Wireless.
Windows®and Windows Vista®are registered trademarks of Microsoft
Corporation.
Macintosh®and Mac OS X®are registered trademarks of Apple Inc., registered in
the U.S. and other countries.
QUALCOMM®is a registered trademark of QUALCOMM Incorporated. Used
under license.
Other trademarks are the property of their respective owners.

Preface
Rev 3 Dec.16 5
Contact
Information
Sales information and technical
support, including warranty and returns
Web: sierrawireless.com/company/contact-us/
Global toll-free number: 1-877-687-7795
6:00 am to 6:00 pm PST
Corporate and product information Web: sierrawireless.com

AirLink RV50 Series Hardware User Guide
6 4117313

Rev 3 Dec.16 7
Contents
Introduction to the RV50 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Gateway Configuration and Management . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Saving Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sample Power Consumption Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Dual SIM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Network Operator Switching. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Specifications at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Installation and Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Tools and Materials Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 1 — Insert the SIM Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 2 — Connect the Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Step 3 — Connect the Data Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Step 4 — Connect the Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cable Strain Relief . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Fusing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
DC Voltage Transients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Grounding the RV50 Series Gateway Chassis . . . . . . . . . . . . . . . . . . . .30
Power Connector on the RV50 Series Gateway . . . . . . . . . . . . . . . . . . .30
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
I / O Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

AirLink RV50 Series Hardware User Guide
8 4117313
Step 5 — Check the gateway operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
LED Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Ethernet LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Step 6 — Startup and Software Configuration . . . . . . . . . . . . . . . . . . . . . . . 42
Configuring with AMM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Transitioning from a Raven Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Step 7 — Mounting the RV50 Series Gateway . . . . . . . . . . . . . . . . . . . . . . . 45
Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Flat Surface Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
DIN Rail Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Reboot the RV50 Series Gateway. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Reset the RV50 Series Gateway to Factory Default Settings . . . . . . . . . . . 48
Recovery Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
RV50 Series Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Radio Frequency Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Radio Module Conducted Transmit Power . . . . . . . . . . . . . . . . . . . . . . . . . 56
Carrier Aggregation Combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
GNSS Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
SIM Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Reliability Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Mechanical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Important Information for North American Users. . . . . . . . . . . . . . . . . . . . . 63
RF Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
EU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
DC Power Cable (Black Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Contents
Rev 3 Dec.16 9
AC Power Adapter (Black Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
AC Power Adapter Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
AC Power Adapter Environmental Specifications . . . . . . . . . . . . . . . . . .68
AC Power Adapter Reliability and Quality Control . . . . . . . . . . . . . . . . . .69
AC Power Adapter Safety Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
AC Power Adapter EMC Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
AC Power Adapter Hazardous Substances . . . . . . . . . . . . . . . . . . . . . . .69
AC Power Adapter Energy Efficiency . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

AirLink RV50 Series Hardware User Guide
10 4117313

Rev 3 Apr. 13 11
1
1: Introduction to the RV50 Series
This hardware user guide is for the Sierra Wireless®AirLink®RV50
and the RV50X gateways. Table 1-1 compares the two gateways.
Features and specifications described in this user guide apply to both
gateways unless otherwise notes.
The RV50 Series gateways are compact, intelligent and fully-featured
communications platform that provides real-time wireless capabilities
for fixed and mobile applications. They are intended for use in
industrial settings such as:
•Remotely monitoring and controlling infrastructure and surveil-
lance equipment on pipelines, meters, pumps and valves in any
energy, utility, or industrial application
•Tracking the location of heavy equipment and assets in the field
•Providing reliable Internet access to a mobile workforce
The RV50 Series gateway has multiple communication ports
including serial, Ethernet, and USB ports. The power connector has
one GPlO pin for remote monitoring and control and one ignition
sense pin to turn the gateway on and off.
The RV50 is an LTE cellular gateway that supports a variety of radio
band options, including 3G HSPA+ or CDMA EV-DO mobile
broadband technology.
The RV50X is an LTE-Advanced cellular gateway that supports LTE
and HSPA+ radio bands.
The RV50 Series gateways, with their rich feature set, configurable
with the included ALEOS software, is the perfect choice for a broad
set of IoT solutions.
Key Features
•High-performance LTE-Advanced support (RV50X only)
•LTE performance at 2G power consumption (less than 1 W in idle
mode)
Table 1-1: Product Comparison
Feature RV50 RV50X
Supported Radio
Frequency Band
LTE, with fallback to
HSPA and CDMA
LTE-Advanced, with
fallback to HSPA+
Maximum Data
Throughput
100 Mbps 300 Mbps

AirLink RV50 Series Hardware User Guide
12 4117313
•State of the art LTE coverage:
·RV50—11 LTE frequency bands
·RV50X—21 LTE frequency bands
•Product variants:
·RV50: Single product variant for all major North American operators
·RV50X: Two variants —One for North America and Europe and one for
Asia Pacific
•Fully automatic network operator switching; just insert the SIM card
•Provides network connectivity via Ethernet, Serial, and USB
•Gigabit Ethernet support (10/100/1000)
•Remote configuration, software update, and monitoring with AirLink
Management Service (ALMS)
•Meets industrial-grade certifications including Class 1 Div 2, Class I Zone 2,
MIL-STD-810G, IP64 ingress protection
•Supports to 5 VPN tunnels to support secure communications over cellular
networks
•Events engine for alert reporting to third party server platforms
•ALEOS Application Framework (AAF) offers real-time onboard data
processing
•Built-in, class-leading voltage transient protection provides superior reliability
and continuous operation
•E-Mark and SAEJ1455 for shock and vibration
•Active GNSS for tracking equipment
•Preprogrammed low voltage disconnect to prevent battery drain
•Security via Remote Authentication (RADIUS, TACACS+, LDAP) to centrally
manage gateway access
•Industry leading warranty includes support, software updates, and advance
replacement
•Power Saving Features, including:
·Processor Power Saving Mode
·LED power saving mode
·Standby mode
·Power saving strategies such as turning off unused interfaces (USB, Serial,
Ethernet), turning off GNSS, and adjusting the Ethernet data rate
•Multi-function digital input, analog input, switchable low side current sink, and
high side configurable pull-up
For information on configuring these features, refer to the ALEOS Software
Configuration User Guide.

Introduction to the RV50 Series
Rev 3 Apr. 13 13
Description
Figure 1-1: RV50 Series Gateway Connectors, LEDs and SIM Card Holder
Power Connector
(See Connect the Power on page 29.)
SIM Card holder (See Insert the
SIM Card on page 18)
Front Panel
Cellular Antenna Connector Diversity
Antenna Connector
Back Panel
9-pin RS-232 Serial Port
USB 2.0 Micro-AB Port
(See Ethernet Port on page 28.)
(See Connect the Antennas
on page 25.)
(See Connect the Antennas on page 25.) (See Serial Port on page 28.)
(See USB Port on page 27.)
Reset button
(See Reboot the RV50 Series Gateway and
Reset the RV50 Series Gateway to Factory
Default Settings on page 48.)
RJ-45 Ethernet Port
GPS Antenna Connector
LEDs (See LED Behavior on page 41.)
(See Connect the Antennas on page 25.)

AirLink RV50 Series Hardware User Guide
14 4117313
Gateway Configuration and Management
You can configure and manage your RV50 Series gateway using:
• ACEmanager —a browser-based gateway management application
Refer to the ALEOS Software Configuration User Guide available for down-
load at source.sierrawireless.com.
• AirLink Management Service (ALMS)—a cloud-based gateway
management service provided by Sierra Wireless
For more information, visit www.sierrawireless.com/ALMS or contact your
Sierra Wireless distributor.
• AirLink Mobility Manager (AMM)—a Network Management solution that
provides a consolidated view of the entire vehicle fleet and enables simplified
management, control and monitoring of connected AirLink routers.
• AT Commands
For a complete list of AT Commands, refer to the ALEOS Software Configura-
tion User Guide.
Power Modes
The AirLink RV50 Series gateway has three power modes:
•On—The CPU and the radio are on. The current draw is 900 mW (75 mA @
12 VDC) when the gateway is idle (i.e. no traffic is being sent or received).
•Standby—The CPU and the radio are off, but can be woken by an I/O input
or at a configured time. Current draw is 53 mW (4.4 mA @ 12 VDC).
•Off—All power is switched off. Ignition is low, but Vin remains connected.
Current draw is 11 mW (0.9 mA @ 12 VDC).
Power Saving Features
Table 1-2 provides a quick reference to the RV50 Series power saving features.
For more information, refer to the ALEOS Software Configuration User Guide.
If you are transitioning from a Raven XT or Raven XE to the RV50 Series gateway
and require the RV50 Series gateway to operate with a comparable level of power
consumption, see Transitioning from a Raven Gateway on page 44.

Introduction to the RV50 Series
Rev 3 Apr. 13 15
Table 1-2: Power Saving Features
Feature Where to configure
in ACEmanager
Notes
Processor Power
Savings Mode
Services > Power
Management
This feature optimizes idle power consumption.
Recommended for customers who require the best power
consumption efficiency, for example in battery or solar
powered applications. Enabling this feature saves energy by
reducing performance where possible.
LED Power Saving In LED power saving mode:
•Signal LED is off when the signal strength is good or
average, but still alerts you when there is no signal or a
poor signal.
•Network LED is off when there is a network connection,
but alerts you when the gateway is connecting to a
network and when there is a problem with the network
connection.
For more details, see LED Behavior on page 41.
Disable USB Port LAN > USB
Disable Ethernet Port LAN > Ethernet
Set Ethernet Data Rate LAN > Ethernet >
Advanced
Ethernet data rates can be set to Auto, 100 Mbits, 10 Mbits. If
your use case does not require a Gigabit Ethernet connection,
choosing a slower rate results in substantial power savings.
When set to 10 or 100 Mbits, both sides of the link must be set
to the same fixed speed and duplex settings. If you are unable
to ensure that both sides of the link have exactly the same
fixed settings, it is best to use Auto.
Disable Serial Port Serial > Port
Configuration
Disable GNSS GPS > Global Settings GNSS is disabled by default.
Ignition Shutdown Delay Services > Power
Management
If the RV50 Series gateway is installed in a vehicle, connect
the ignition sense pin (Pin 3) on the DC power cable to the
vehicle ignition and configure the RV50 Series gateway to shut
down after a configured delay once the ignition is turned off.
Low Voltage Disconnect The RV50 Series gateway enters standby mode when the
voltage reaches a user-defined threshold to prevent excessive
battery drain in battery-operated systems.
Standby (Time-based) The RV50 Series gateway is in standby mode and
automatically wakes up periodically, for example hourly or
daily.
Standby (I /O-based) The RV50 Series gateway is in standby mode and
automatically wakes up on configured I / O input.

AirLink RV50 Series Hardware User Guide
16 4117313
Sample Power Consumption Scenarios
Dual SIM
The AirLink RV50 Series gateway has two SIM card slots. You can decide which
slot is the Primary SIM card. When the gateway is powered on or reboots, it
automatically connects to the network associated with the Primary SIM card. If no
card is present in that slot, it connects to the network associated with the
Secondary SIM card. If configured to do so, data usage is tracked independently
on both SIM cards. SIM PIN configuration is also available for both SIM cards.
This feature allows users to install SIM cards for two different network operators,
use one SIM card initially and later change network operators by configuring the
new SIM card to be the Primary SIM card.
Table 1-3: Power Consumption Scenarios
Scenario Radio Ethernet Serial USB GNSS Processor
Power
Saving
Mode
LED
Power
Saving
Mode
Powera
Standby Mode — — — — — — — 53 mW
(4.4 mA)
Low Power —
S e r i a l
Idle
Attached
Disabled Enabled Disabled Disabled Enabled Enabled 885 mW
(73.7 mA)
Low Power —
E t h e r n e t
Idle
Attached
10 BaseT
Full duplex
Disabled Disabled Disabled Enabled Enabled 900 mW
(75 mA)
Typical
without Power
Saving
Features
Attached
and
connected
(+20 dBm
LTE)
100 BaseT
Full duplex
Enabled
Idle
Enabled
Idle
Enabled
Active
antenna
Disabled Disabled 3700 mW
(308.3 mA)
RV50X Only —
Maximum
without Power
Saving
Features
Attached
and
connected
(+23 dBm
LTE-A)
1000
BaseT Full
duplex
(maximum
throughput)
Enabled Enabled Enabled
Active
antenna
Disabled Disabled 5500 mW
(458.3 mA)
RV50 Only —
Peak without
Power Saving
Featuresb
Attached
and
connected
(+32 dBm
1 up/
1 down
GSM/
GPRS/
EDGE
bursts)
1000
BaseT Full
duplex
(maximum
throughput)
Enabled Enabled Enabled
Active
antenna
Disabled Disabled 8000 mW
(666.6 mA)
Inrush Current 1.5 A @ 12 V (Averaged over 100 μs)
a. Power consumption was measured at 12 V.
b. Peak without power saving is similar to Maximum without power saving, but measured as a maximum burst over a limited time.

Introduction to the RV50 Series
Rev 3 Apr. 13 17
Network Operator Switching
The North American AirLink RV50 Series gateway comes preloaded with multiple
versions of radio module firmware. When the gateway is powered on, it checks
the stored radio module firmware versions and automatically loads the
appropriate version for the installed Primary SIM card onto the radio module.
While Network Operator Switching is in progress, the LEDs sequentially flash
green (green LED chase).
If there is no SIM card installed in the Primary SIM card slot, the gateway uses
the firmware associated with the SIM card in the Secondary SIM card slot.
This feature, which is intended for North American products, makes it possible to
use a single hardware variant on multiple operator networks.
Accessories
The following items come with the RV50 Series gateway:
•DC power cable
•Mounting screws
•Quick Start Guide
The following items can be ordered separately from Sierra Wireless:
•Universal AC power adapter
·Voltage input: 100–240 VAC
·Current output: 1.5 A
·Part number: 2000492
•DIN rail mounting bracket (See DIN Rail Mount on page 46.)
Warranty
The RV50 Series gateway comes with a 3-year warranty, and have an optional 2-
year warranty extension.

AirLink RV50 Series Hardware User Guide
18 4117313

Rev 3 Apr. 13 19
2
2: Specifications at a Glance
This chapter gives a brief summary of RV50 Series gateway features.
For additional information see RV50 Series Specifications on
page 51.
Table 2-1: Specifications at a Glance
Certification and
Interoperability
Emissions / Immunity •CE (Including EMC Test case for vehicle installation EN302489)
•ACMA RCM
•FCC
•Industry Canada
Safety •CB Scheme
•UL 60950
Industry Certification
for Vehicles
•E-Mark (UN ECE Regulation 10.04), ISO7637-2
•SAE J1455 (Shock & Vibration)
Environmental
Compliance
•RoHS 2011/65/EU (RoHS 2)
•WEEE
•REACH
•Halogen-free PCB
Hazardous
Environments
•Class 1 Div 2 and Class I Zone 2: C22.2 No. 213 (Canada) and
ISA 12.12.01
GSM/UMTS
Certifications
•PTCRB
•GCF-CC
•R&TTE

AirLink RV50 Series Hardware User Guide
20 4117313
Environmental
Testing
Vibration (operational) •MIL-STD-810G, test method 514.6
•IEC 60068-2-64
Shock (operational) MIL-STD-810G, test method 516.6
SAE J1455 (Shock and
Vibration) for heavy-
duty vehicles
•Vibration: Section 4.10.4.2 Cab Mount
•Shock: Section 4.11.3.4 Operational Shock
Temperature
(operational)
MIL-STD-810G, test methods 501.5, 502.5
(-40° to +70°C)
Temperature
(non-operational)
MIL-STD-810G, test methods 501.5, 502.5
(-40° to +85°C)
Thermal shock MIL-STD-810G, test method 503.5
Humidity (operational) MIL-STD-810G, test method 507.5
95% RH @ 60°C
IP rating IP64
Drop ISTA 2A 2001, test categories 1, 4, 5, and 6
Mobile Network Operator Certification: RV50
(Pending for the RV50X)
•Verizon Wireless
•AT&T
•Sprint
•T-Mobile USA
•US Cellular
•Rogers
•Bell
•Te l u s
Network Technology See Radio Frequency Bands on page 51.
Host Interfaces •10/100 / 1000 Base-T RJ-45 Ethernet
•RS-232 serial port
•USB 2.0 Micro-AB connector
•3 SMA antenna connectors (LTE, Diversity, Active GNSS)
SIM Card Interface Two mini-SIM (2FF) slots
Input / Output
For more information, see page 35.
Configurable I / O pin on power connector
•Digital Input
•High side configurable internal pull-up (to Vin) resistor
•Analog input
•Open collector output / low side sink
Power Adapter Pins 4-Pin connector:
•Power
•Ground
•Configurable digital I/O and analog voltage input sensing
•Configurable ignition sense
Table 2-1: Specifications at a Glance (Continued)
