SIGMA TEK PL 221 User manual

PL 221
S-DIAS Pixel LED Module
Instruction Manual
Date of creation: 13.03.2018
Version date: 26.07.2023
Article number: 20-018-221-E

Publisher: SIGMATEK GmbH & Co KG
A-5112 Lamprechtshausen
Tel.: [phone]
Fax: [phone]
Email: [email protected]
WWW.SIGMATEK-AUTOMATION.COM
Copyright © 2018
SIGMATEK GmbH & Co KG
Translation of the Original Instructions
All rights reserved. No part of this work may be reproduced, edited using an electronic system, duplicated or dis-
tributed in any form (print, photocopy, microfilm or in any other process) without the express permission.
We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi-
ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through
use of this handbook.

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 1
S-DIAS Pixel LED Module PL 221
with control for 2x RGB pixel LED strips and 2x 24 V PWM LED
strips
With the S-DIAS Pixel LED module PL 221, two pixel LED strips with a
maximum of 512 pixel RGB LEDs each and two +24 V PWM dimmable
white LED strips can be controlled.
The +5 V supply for the pixel LEDs is provided an internal switching
regulator from the externally powered +24 V supply. The +5 V supply is
protected against short circuit and overload.
The +24 V supply for the +24 V PWM dimmable white LED strips is pro-
vided by the external +24 V supply. The outputs are protected against
short circuit and overload.
The external +24 V supply is monitored for undervoltage.

PL 221 S-DIAS PIXEL LED MODULE
Page 2 26.07.2023
Contents
1Introduction............................................................................. 5
1.1 Target Group/Purpose of this Operating Manual......................5
1.2 Important Reference Documentation .........................................5
1.3 Contents of Delivery.....................................................................5
2Basic Safety Directives .......................................................... 6
2.1 Symbols Used...............................................................................6
2.2 Disclaimer......................................................................................8
2.3 General Safety Directives ............................................................9
2.4 Software/Training .......................................................................10
3Standards and Directives......................................................11
3.1 Directives.....................................................................................11
3.1.1 EU Conformity Declaration................................................................11
4Type Plate...............................................................................12
5Technical Data .......................................................................13
5.1 Pixel LED Outputs Specifications.............................................13
5.2 24 V PWM LED Outputs Specifications....................................13
5.3 Electrical Requirements.............................................................14
5.4 Miscellaneous .............................................................................16
5.5 Environmental Conditions.........................................................16
6Mechanical Dimensions........................................................17

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 3
7Connector Layout..................................................................18
7.1 Status LEDs.................................................................................19
7.2 Applicable Connectors...............................................................20
7.3 Labeling Field..............................................................................21
8Wiring.....................................................................................22
8.1 Wiring Example...........................................................................22
8.2 Notes............................................................................................23
9Assembly/Installation ...........................................................24
9.1 Check Contents of Delivery.......................................................24
9.2 Mounting......................................................................................25
10 Addressing.............................................................................27
11 Supported Cycle Times ........................................................33
11.1 Cycle Times below 1 ms (in µs).................................................33
11.2 Cycle Times equal to or higher than 1 ms (in ms)...................33
12 Hardware Class PL221..........................................................34
12.1 General.........................................................................................35
12.2 LED Pixel Output.........................................................................35
12.3 PWM Output ................................................................................37
12.4 Communication Interfaces.........................................................37
12.5 Global Methods...........................................................................38
12.5.1 ChangeIndividualLED....................................................................... 38
12.5.2 ChangeAllLEDs................................................................................. 39

PL 221 S-DIAS PIXEL LED MODULE
Page 4 26.07.2023
12.5.3 SetWholeStripe..................................................................................40
12.6 Private Methods..........................................................................41
12.6.1 IndividualStripeConfig........................................................................41
12.7 Internal Properties......................................................................42
12.7.1 Setting the Color Resolution..............................................................42
12.7.2 Explanation of the methods ChangeAllLEDs and
ChangeIndividualLED........................................................................43
12.7.3 Use of the chaser with the Parameter dStartOffset or the Server
StartRollingAddrStripe1,2..................................................................45
13 Transport/Storage..................................................................47
14 Storage ...................................................................................47
15 Maintenance...........................................................................48
15.1 Service.........................................................................................48
15.2 Repair...........................................................................................48
16 Disposal..................................................................................48

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 5
1 Introduction
1.1 Target Group/Purpose of this Operating Manual
This operating manual contains all information required for the operation of the product.
This operating manual is intended for:
•Project planners
•Technicians
•Commissioning engineers
•Machine operators
•Maintenance/test technicians
General knowledge of automation technology is required.
Further help and training information, as well as the appropriate accessories can be found
on our website www.sigmatek-automation.com.
Our support team is happily available to answer your questions.
Please see our website for our hotline number and business hours.
1.2 Important Reference Documentation
This and additional documents can be downloaded from our website or obtained through
support.
1.3 Contents of Delivery
1x PL 221

PL 221 S-DIAS PIXEL LED MODULE
Page 6 26.07.2023
2 Basic Safety Directives
2.1 Symbols Used
The following symbols are used in the operator documentation for warning and danger
messages, as well as informational notes:
DANGER
Danger indicates that death or serious injury will occur, if the speci-
fied measures are not taken.
To avoid death or serious injuries, observe all guidelines.
Danger indique une situation dangereuse qui, faute de prendre les
mesures adéquates, entraînera des blessures graves, voire mortelles.
Respectez toutes les consignes pour éviter des blessures
graves, voire mortelles.
WARNING
Warning indicates that death or serious injury can occur, if the speci-
fied measures are not taken.
To avoid death or serious injuries, observe all guidelines.
Avertissement d’une situation dangereuse qui, faute de prendre les
mesures adéquates, entraînera des blessures graves, voire mortelles.
Respectez toutes les consignes pour éviter des blessures
graves, voire mortelles.
CAUTION
Caution indicates that moderate to slight injury can occur, if the speci-
fied measures are not taken.
To avoid moderate to slight injuries, observe all guidelines.
Attention indique une situation dangereuse qui, faute de prendre les
mesures adéquates, peut entraîner des blessures assez graves ou
légères.
Respectez toutes les consignes pour éviter des blessures
graves, voire mortelles.

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 7
INFORMATION
Information
Provides important information on the product, handling or rele-
vant sections of the documentation, which require attention.

PL 221 S-DIAS PIXEL LED MODULE
Page 8 26.07.2023
2.2 Disclaimer
INFORMATION
The contents of this operating manual were prepared with the greatest
care. However, deviations cannot be ruled out. This operating manual
is regularly checked and required corrections are included in the sub-
sequent versions. The machine manufacturer is responsible for the
proper assembly, as well as device configuration. The machine opera-
tor is responsible for safe handling, as well as proper operation.
The current operating manual can be found on our website. If neces-
sary, contact our support.
Subject to technical changes, which improve the performance of the
devices. The following operating manual is purely a product descrip-
tion. It does not guarantee properties under the warranty.
Please thoroughly read the corresponding documents and this operat-
ing manual before handling a product.
SIGMATEK GmbH & Co KG is not liable for damages caused
through, non-compliance with these instructions or applicable
regulations.

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 9
2.3 General Safety Directives
The Safety Directives in the other sections of this operating manual must be observed.
These instructions are visually emphasized by symbols.
INFORMATION
According to EU Directives, the operating manual is a component of a
product.
This operating manual must therefore be accessible in the vicinity of
the machine since it contains important instructions.
This operating manual should be included in the sale, rental or transfer
of the product, or its online availability indicated.
Regarding the requirements for Safety and health connected to the use
of machines, the manufacturer must perform a risk assessment in
accordance with machine directives 2006/42/EG before introducing a
machine to the market.
Operate the unit with devices and accessories approved by SIG-
MATEK only.

PL 221 S-DIAS PIXEL LED MODULE
Page 10 26.07.2023
CAUTION
Handle the device with care and do not drop or let fall.
Prevent foreign bodies and fluids from entering the device.
The device must not be opened!
Manipulez l’appareil avec précaution et ne le laissez pas tomber.
Empêchez les corps étrangers et les liquides de pénétrer dans
l’appareil.
L’appareil ne doit pas être ouvert!
If the device does not function as intended or has damage that could
pose a danger, it must be replaced!
En cas de fonctionnement non conforme ou de dommages pouvant
entraîner des risques, l'appareil doit être remplacé!
The module complies with EN 61131-2.
In combination with a facility, the system integrator must comply with
EN 60204-1 standards.
For your own safety and that of others, compliance with the environ-
mental conditions is essential.
Le module est conforme à la norme EN 61131-2.
En combinaison avec une équipement, l’intégrateur de système doit
respecter la norme EN 60204-1.
Pour votre propre sécurité et celle des autres, le respect des conditions
environnementales est essential.
2.4 Software/Training
The application is created with the software LASAL CLASS 2 and LASAL SCREEN Editor.
Training for the LASAL development environment, with which the product can be config-
ured, is provided. Information on our training schedule can be found on our website.

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 11
3 Standards and Directives
3.1 Directives
The product was constructed in compliance with the following European Union directives
and tested for conformity.
3.1.1 EU Conformity Declaration
EU Declaration of Conformity
The product PL 221 conforms to the following European directives:
•2014/35/EU Low-voltage Directive
•2014/30/EU Electromagnetic Compatibility (EMC Directive)
•2011/65/EU “Restricted use of certain hazardous substances in
electrical and electronic equipment” (RoHS Directive)
The EU Conformity Declarations are provided on the SIGMATEK website.
See Products/Downloads or use the search function and the keyword “EU
Declaration of Conformity”.

PL 221 S-DIAS PIXEL LED MODULE
Page 12 26.07.2023
4 Type Plate
HW: Hardware version
SW: Software version

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 13
5 Technical Data
5.1 Pixel LED Outputs Specifications
Number of channels
2
Short-circuit and overload protec-
tion
yes (short-circuit or overload can be read from software through a latched
status bit)
Supported pixel LEDs
WS2812B, WS2813
Maximum number of pixel LEDs
512 pixel LEDs
Data rate Pixel LED control
800 kB/s
Update frequency
circa 115 Hz @ 288 pixel LEDs, 800 kB/s
(the update rate is calculated from the number of pixel LEDs and the
fixed update rate, if a higher update rate is required, then the number of
pixel LEDs per string must be reduced)
Data width per LED
24 bit (8 bit red/green/blue)
Maximum load capacity +5 V
max. 4.5 A at 50 °C environmental temperature
max. 4.0 A at 55 °C environmental temperature
5.2 24 V PWM LED Outputs Specifications
Number
2
Short-circuit and overload protec-
tion
yes (short-circuit or overload can be read from software through a latched
status bit)
Maximum permissible continuous
load current/channel
2.0 A
Maximum total current
4 A (100% of on-time)
PWM pulse width
0-100 % adjustable in 1 % increments
PWM frequency
adjustable 100 Hz - 2 kHz
Residual current output
(off)
≤10 µA

PL 221 S-DIAS PIXEL LED MODULE
Page 14 26.07.2023
5.3 Electrical Requirements
External +24 V supply
+18-30 V DC
External current consumption
+24 V
max. total current 5.4 A
(2x pixel LED total current max. 1.4 A,
2x PWM output total current max. 4 A)
Voltage supply from S-DIAS bus
+5 V
Current consumption on the
S-DIAS bus
(+5 V power supply)
typically 90 mA
maximum 100 mA
Voltage supply from S-DIAS bus
+24 V
Current consumption on the
S-DIAS bus
(+24 V power supply)
typically 6 mA
maximum 8 mA
INFORMATION
If this S-DIAS module is connected to an S-DIAS supply module with
several S-DIAS modules, the total current of the modules used must be
determined and checked.
The total current of the +24 V supply cannot exceed 1.6 A!
The total current of the +5 V supply cannot exceed 1.6 A!
The specification for the current can be found in the module-specific
documentation under "Electrical Requirements".

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 15

PL 221 S-DIAS PIXEL LED MODULE
Page 16 26.07.2023
5.4 Miscellaneous
Article number
20-018-221
Approvals
CE, UKCA
5.5 Environmental Conditions
Storage temperature
-20 ... +85 °C
ambient temperature
0 ... +55 °C
Humidity
0-95 %, non-condensing
Installation altitude above sea
level
0-2000 m without derating
> 2000 m up to a maximum of 5000 m with derating of the maximum
environmental temperature by 0.5 °C per 100 m
Operating conditions
pollution degree 2
EMC resistance
in accordance with EN 61000-6-2 (industrial area)
EMC noise generation
in accordance with EN 61000-6-4 (industrial area)
Vibration resistance
EN 60068-2-6
3.5 mm from 5-8.4 Hz
1 g from 8.4-150 Hz
Shock resistance
EN 60068-2-27
15 g
Protection type
EN 60529
IP20

S-DIAS PIXEL LED MODULE PL 221
26.07.2023 Page 17
6 Mechanical Dimensions

PL 221 S-DIAS PIXEL LED MODULE
Page 18 26.07.2023
7 Connector Layout
INFORMATION
The connections of the +24 V supply (X4: pin 1 and pin 2) or the GND
supply (X4: pin 3 and pin 4) are internally bridged. To supply the mod-
ule, only one connection to a +24 V pin (pin 1 or pin 2) and a GND pin
(pin 3 or pin 4) is required. The bridged connections may be used for
further looping of the +24 V supply and the GND supply. However, it
must be taken into account that a total current of 6 A per connection is
not exceeded by the forward looping!
