SignaMax 065-1530 User manual

Signamax Security Router
Model: 065-1530
Install Guide
Revision A1

1 SIGNAMAX LLC • www.signamax.eu
Table of Contents
OVERVIEW.......................................................................................................................... 3
H ARDWARE F EATURES ........................................................................................................ 3
065-1530 Signamax Security Router Appearance......................................................... 3
065-1530 S IGNAMAX S ECURITY R OUTER F RONT P ANEL .................................................... 4
065-1530 Signamax Security Router Backboard Interface ........................................... 5
065-1530 Signamax Security Router System................................................................. 5
065-1530 S IGNAMAX S ECURITY R OUTER F UNCTIONALITY ................................................ 6
065-1530 S IGNAMAX S ECURITY R OUTER M AIN B OARD ..................................................... 8
MODULES ...........................................................................................................................10
S YNC /A SYNC S ERIAL I NTERFACE M ODULE (SAE) S ERIES ................................................11
1-port High-speed V.24/V.35 Serial Module (1SAE) ....................................................11
1SAE Interface Module ........................................................................................................ 11
1SAE Interface Module Connected Cable ............................................................................ 11
1SAE Interface Attributes ..................................................................................................... 11
C HANNELIZED E1 M ODULE (CE1).....................................................................................12
1-port Channelized E1 Module (1CE1) .......................................................................12
1CE1 Interface & Indicator................................................................................................... 12
1CE1 Interface Connected Cable .................................................................................... 12
1CE1 Interface Attributes .................................................................................................. 12
N ON - CHANNELIZED E1 (E1) S ERIES ..................................................................................13
1-port Non-channelized E1 (1E1) ................................................................................13
1E1 Interface Module & Indicator..................................................................................... 13
1E1 Interface Connected Cable ....................................................................................... 13
1E1 Interface Attributes ..................................................................................................... 13
F REQUENCY - BAND MODEM M336 S ERIES .......................................................................14
1-port 33.6K Frequency-band MODEM (1M336)......................................................14
1M336 Interface & Dialup DIP............................................................................................. 14
1M336 Interface Module Connected Cable .......................................................................... 15
1M336 Interface Attributes ................................................................................................... 15
B ASE - BAND MODEM (M128) S ERIES ..............................................................................15
1-port 128K base-band MODEM (1M128)..................................................................15
1M128 Module, Indicator & DIP Switch .............................................................................. 15
1M128 Module Connected Cable ......................................................................................... 16
1M128 Interface Attributes ................................................................................................ 16
ISDN (U) S ERIES ...............................................................................................................16
1-port ISDN U Module (1U) ........................................................................................16
1U Module & Indicator......................................................................................................... 16
1U Module Connected Cable ................................................................................................ 17
1U Interface Attributes.......................................................................................................... 17
IP M ODULE (VOP/VOS) S ERIES .......................................................................................18
1-port IP Module (1VOP).............................................................................................18
1VOP Module Indicator........................................................................................................ 18
1VOP Module Connected Cable ........................................................................................... 18
1VOP Interface Attributes..................................................................................................... 18
2-port IP Phone Module (2VOP) .................................................................................19
2VOP Module & Indicator.................................................................................................... 19
2VOP Module Connected Cable ...................................................................................... 19
2VOP Module Interface Attributes.................................................................................... 19
1-port Switch IP Phone Module (1VOS) ......................................................................20
1VOS Module & Indicator.................................................................................................... 20

2 SIGNAMAX LLC • www.signamax.eu
1VOS Module Connected Cable........................................................................................... 20
1VOS Interface Attributes..................................................................................................... 20
2-port Switch IP Phone Module (2VOS) ......................................................................21
2VOS Module & Indicator.................................................................................................... 21
2VOS Module Connected Cable........................................................................................... 21
2VOS Module Interface Attributes ....................................................................................... 21
E THERNET M ODULE (ETE) S ERIES ....................................................................................22
1-port Ethernet Module (1ETE) ...................................................................................22
1ETE Module & Indicator .................................................................................................... 22
1ETE Module Connected Cable............................................................................................ 22
1ETE Module Interface Attributes ........................................................................................ 22
ISDN S/T M ODULE (ST) S ERIES .......................................................................................22
1-port ISDN S/T Module (1ST).....................................................................................22
1ST Module & Indicator ....................................................................................................... 23
1ST Module Connected Cable .............................................................................................. 23
1ST Module Interface Attributes........................................................................................... 23
SYSTEM INSTALLATION ................................................................................................24
P RECAUTIONS ....................................................................................................................24
E NVIRONMENT ..................................................................................................................24
Operating Environment................................................................................................24
Temperature & Humidity..............................................................................................25
Dust Prevention............................................................................................................25
R OUTERS & A CCESSORIES .................................................................................................25
C HASSIS I NSTALLATION .....................................................................................................25
Tools & Equipment.......................................................................................................25
Machine Installation ....................................................................................................26
Connecting Power Supply ............................................................................................26
Grounding Connection.................................................................................................27
Main Control Board Cable Connection .......................................................................27
Console Port Connection .............................................................................................27
Grounding Wire Connection.........................................................................................29
M ODULE I NSTALLATION ....................................................................................................29
Rack/Desk ....................................................................................................................29
Panel Wire Connection.................................................................................................29
Hardware Installation ..................................................................................................30
I NTERFACE C ABLE C ONNECTION .......................................................................................30
1SAE Module Cable Connection..................................................................................30
1SAE Module Cable Connection .......................................................................................... 32
1CE1/1E1 Module Cable Connection ..........................................................................32
1M336 Module Cable Connection ...............................................................................32
1M128 Module Cable Connection ...............................................................................32
1U Module Cable Connection......................................................................................33
1VOP/2VOP Module Cable Connection ......................................................................33
1VOS/2VOS Module Cable Connection .......................................................................33
1ETE Module Cable Connection..................................................................................33
1ST Module Cable Connection ....................................................................................33
INTERFACE CABLE SIGNALS .......................................................................................35
E THERNET C ABLE (T WISTED - PAIR I NTERFACE RJ45) ........................................................35
C ONSOLE P ORT C ABLE ......................................................................................................36

3 SIGNAMAX LLC • www.signamax.eu
Overview
065-1530 Signamax Security Router is a data communication product
that can be widely applied to finance, telecommunication, tax and
security industries, and large-medium-scale enterprises
065-1530 Signamax Security Router series modular router provides a set
of high efficiency and low-cost network connection solutions
065-1530 Signamax Security Router supports the following applications:
Computer network interconnection
Multi-service data integration
Branch institute dialup and dialup backup service
Internet and enterprise (Extranet) access
Hardware Features
065-1530 Signamax Security Router
Appearance

4 SIGNAMAX LLC • www.signamax.eu
065-1530 Signamax Security
Router Front Panel
Following are the indicators on the panel:
SYS & PWR (system and power supply indicator):
SYS - system status indicator
Fast shining: Loading
Slow shining: Load successful
PWR (system power supply indicator)
On: After power on
SLOT1 (slot 1 status indicator)
ACT - voice card module data
RDY - slot has voice card module link status
SLOT 0 (slot 0 status indicator)
ACT - insert module data indicator
RDY – inserting module link status
CONSOLE (console port)
TXD – sending console port data
RXD – receiving console port data
FETH1 (Ethernet interface1)
100M - 10/100M Ethernet interface data rate indicator
On: 100M
Off: 10M

5 SIGNAMAX LLC • www.signamax.eu
ACT - Ethernet interface data
FETH0 (Ethernet interface0):
100M - 10/100M Ethernet interface data rate indicator
On: 100M
Off: 10M
ACT - Ethernet interface data indicator
065-1530 Signamax Security Router
Backboard Interface
From left to right:
Interface Form Description Application
ON/OFF Power supply switch. Right
is OFF and left is ON.
INPU AC 100-240 1A input
SLO 1 Bus slot VOP/VOS voice
module
SLO 0 Interface module
decides interface
form
Fast serial, bus slot MIM module
SLOT1 - voice card module slot for VOP/VOS serial module
SLOT0 - MIM module slot, which adopts modular design
065-1530 Signamax Security Router
System
The following table explains 065-1530 Signamax Security Router basic
configuration and working environment:
Item Description
Console port One fixed, async D E working mode (RJ45)

6 SIGNAMAX LLC • www.signamax.eu
Ethernet port wo fixed 10/100Mbps fast Ethernet port (RJ45)
Voice card slot One voice card SLO 1
MIM slot MIM module SLO 0 supporting kinds of slot module
Processor High performance PowerPC processor
FLASH 8MB
SDRAM 64MB
Dimension
(W × D × H)
340 × 230 × 44 (mm)
Power supply input
voltage
AD: 100 – 240V - 50/60Hz
DC: － 40 ～ － 57V
Optional AC, DC power supply. Confirm before shipment
Environment
temperature
0-40°C
Environment
humidity
10-90%. Non-condensing
Power supply rating
power
45W
Maximum power
consumption
15W
065-1530 Signamax Security
Router Functionality
The following table explains 065-1530 Signamax Security Router
functionality, and supported protocols and services
Protocols & services Description
Network protocol WAN supports:
PPP
PPP compression
SLIP
CSLIP protocol
Frame relay
Frame relay switch
X.25
X.25 switch
HDLC
LAPB
ISDN
LAN is Ethernet supporting two kinds of link layer frame
format:

7 SIGNAMAX LLC • www.signamax.eu
Ethernet
-
II
Ethernet-SNAP
Dialup network MODEM dialup (call-in/call-out)
CALLBACK
Dial-on-demand
Dialup backup
Routing protocol Static routing
Dynamic routing:
RIPv1
RIPv2
OSPF
BGP
IRMP (compatible with CISCO EIGRP)
SNSP (compatible with CISCO ODR)
Dial-on-demand routing (DDR)
Policy routing
Multicast:
IGMP
PIM-SM
PIM － DM
DVMRP
Hot backup
VRRP
VBRP (compatible with CISCO HSRP)
Network service ARP
Proxy ARP
L2 P
Configure command-level protocol to guarantee
unauthenticated user not to intrude into router:
IP packet filter firewall
IP UNNUMBERED
IP policy routing
DHCP relay
PAP/CHAP validation
EASY IP
NA network concealing
RADIUS validation
IPsec data encryption
IKE
GRE
Load balance
MPLS

8 SIGNAMAX LLC • www.signamax.eu
QoS PQ
CQ
WFQ
CBWFQ
LLQ
WRED
CAR
Network management SNMPv1, SNMPv2, SNMPv3
Standard network management (compatible with CISCO)
Configuration via local console port
Local telnet login or remote login configuration
Configure command security isolation function
Provide Chinese/English prompt and help information
Debugging information
Login via telnet and manage other product
Download and upload configuration file and application
program via F P
Download and upload configuration file and application
program via F P
Colorful level debugging information support
Support log function
Security IP packet filter firewall, PAP/CHAP, MD5, NA , RADIUS,
ACACS and IPsec data encryption
065-1530 Signamax Security
Router Main Board
The 065-1530 Signamax Security Router main board comprises three
fixed interfaces, one voice card slot, one MIM slot, six indicators and
power supply jack and one fixed interface The 065-1530 Signamax
Security Router provides three fixed interfaces – one console port, two
Ethernet interfaces and their attributes:
Console port:
Attributes Description
Linker type RJ45
Interface standard RS232
BR 9600bps - 115200bps
Supported service Connects with character terminal
Connects with local PC serial and operates terminal emulation
program CLI
Ethernet interface:
Attributes Description

9 SIGNAMAX LLC • www.signamax.eu
Linker type RJ45
Interface number 2
Supported frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Working mode 10M/100M adaptive
Full/half duplex
Supports auto-crossing
Supported network
protocol
IP
Slots:
The 065-1530 Signamax Security Router has two slots - SLOT0 and
SLOT1 SLOT0 comprises MIM slots, which can be inserted into different
modules SLOT0 supports the following modules:
Ethernet interface module
Sync/async interface module
Async interface module
E1/CE1 interface module
U interface module
ST interface module
Base-band MODEM module
Frequency-band MODEM module
VOP/VOS module
SLOT1 is voice card slot used for VOP/VOS module, which can access the
phone in IP network via dialup or second dialup The user makes free
phone calls in IP network

10 SIGNAMAX LLC • www.signamax.eu
Modules
065-1530 Signamax Security Router is a modular router It provides two
slots SLOT1 is voice card slot for VOP and VOS serial voice module
SLOT0 is an MIM slot compatible with all interface modules of Signamax
routers
Following are the modules:
1SAE
1CE1
1E1
1M336
1M128
1U
1VOP
2VOP
1VOS
2VOS
1ETE
1ST

11 SIGNAMAX LLC • www.signamax.eu
Sync/Async Serial Interface
Module (SAE) Series
1-port High-speed V.24/V.35 Serial
Module (1SAE)
1SAE module is used for 065-1530 Signamax Security Router 1SAE
completes 1-port sync/async serial data flow -- receiving and sending
The port operates in synchronous mode:
DCE mode: 2 048Mbps
DTE mode: 8 Mbps
The port in asynchronous mode operates 115 2Kbps 065-1530
Signamax Security Router sync/async serial interface default working
mode is sync The sync serial interface is in DTE or DCE mode In DTE
mode, it receives external DCE clock such as external sync modem In
DCE mode, the router provides clock The V24/V35 mode switch
functions via panel
1SAE Interface Module
1-port high-speed V 24/V 35 serial module (1SAE)
1SAE Interface Module Connected Cable
1SAE interface cable is V35 DTE cable and V24 connected DTE cable
1SAE Interface Attributes
11-port high-speed V 24/V 35 serial module (1SAE) attributes:
Attributes Description
Sync Async

12 SIGNAMAX LLC • www.signamax.eu
ie-in DB25-DB25 DB25-DB25
Interface standard & working
mode
V.24 V.35 EIA/ IA-232
D E
DCE
D E
DCE
Minimum baud rate (bps) 1200 1200 300
Maximum baud rate (bps) 128K 8M 115.2K
Supported protocol & service X25
HDLC
PPP
SLIP
FR
LAPB
Dialup
Backup
HDLC
PPP
SLIP
Channelized E1 Module (CE1)
1-port Channelized E1 Module (1CE1)
The 1-port channelized E1 module provides 1984K multi-timeslot data
flow receiving and sending and processing port As CE1 interface, it
divides slot 1-31 to different groups and each group timeslot after using
binding as one interface
1CE1 Interface & Indi cator
1-port channelized E1 (1CE1) indicator:
LOS On: Cannot check frame sync signal
Off: After sync
1CE1 Interface Connected Cable
1CE1 and BNC pin coaxial cable and RJ45-RJ45 connected twisted-pair
1CE1 Interface Attributes
1-port Channelized E1 (1CE1) attributes:

13 SIGNAMAX LLC • www.signamax.eu
Attributes Description
Interface BNC, RJ45 (can not be used together)
Interface number 1 group
Interface standard G.703
Supported protocol PPP
X.25
HDLC
FR
Non-channelized E1 (E1) Series
1-port Non-channelized E1 (1E1)
The 1-port non-channelized E1 module provides a data transmission port
with 2 048Mbit/s bandwidth E1 is same as CE1 It can be divided into 32
timeslots, and timeslot 0 of E1 can be used to transmit data in unframed
mode to realize 2M transparent transmissions
1E1 Interface Module & Indicator
1E1 interface module:
1-port non-channelized E1 (1E1)
1-port non-channelized E1 (1E1) indicator:
LOS On: ransparent 2M transmission
On: Non-transparent and cannot check frame sync signal
Off: After sync
1E1 Interface Connected Cable
1E1 and BNC pin coaxial cable and RJ45-RJ45 connected twisted-pair
1E1 Interface Attributes
1-port non-channelized E1 (1E1) attributes:
Attributes Description

14 SIGNAMAX LLC • www.signamax.eu
Interface BNC, RJ45 (cannot be used together)
Interface
number
1 group
Interface
standard
G.703
Supported
service
X.25
FR
Supported
protocol
PPP
HDLC
Frequency-band MODEM M336
Series
1-port 33.6K Frequency-band MODEM
(1M336)
1-port 33 6-K frequency-band MODEM works in sync or async mode
1M336 Interf ace & Di alup DIP
1M336 interface module:
1-port 33 6K frequency-band MODEM (1M336)
DIP:
1-port 33 6K frequency-band MODEM (1M336) DIP:
Mode DIP switch
configuration
Description
1 2
Frequency-band
MODEM mode
OFF OFF LINE port used as inbuilt frequency-band
MODEM interface
Console port mode ON OFF LINE port used as CONSOLE port. Configure
router via dialup remote login

15 SIGNAMAX LLC • www.signamax.eu
1M336 Interf ace Module Connected Cabl e
1M336 module connected cable is RJ45 (4, 5 signal wire) or RJ11
telephone line
1M336 Interf ace Attributes
1-port 33 6K frequency-band MODEM (1M336) attributes:
Attributes Description
ie-in RJ45
Interface number 1
Supported link
protocol
PPP
Frame relay
X.25
HDLC
Supported network
protocol
IP
Base-band MODEM (M128)
Series
1-port 128K base-band MODEM (1M128)
1M128 Module, Indicator & DIP Switch
1M128 interface module:
1-port 128K base-band MODEM (1M128):
The 1-port 128K base-band MODEM (1M128) indicator:
AC On: Link established

16 SIGNAMAX LLC • www.signamax.eu
B1 B1 channel indicator
Light on: when using channel B1, and rate is 64K
B2 B2 channel indicator
Light on: when using channel B2, and the rate is 128K
DIP switch:
The 1-port 128K base-band MODEM (1M128) DIP:
Mode DIP switch configuration Description
1 2
Loopback ON Reservation
1M128 Module Connected Cable
1M128 module connected cable is RJ45 (4, 5 signal cable) or RJ11
line
1M128 Interface Attributes
1M128 interface attributes:
1-port 128K base-band MODEM (1M128) interface:
Attributes Description
ie-in RJ45
Interface number 1
Supported link
protocol
PPP
Frame relay
X.25
HDLC
Supported network
protocol
IP
ISDN (U) Series
1-port ISDN U Module (1U)
1-port ISDN U module connects DDN network and ISDN network
and not to connect modem
1U Module & Indicator
1U module:

17 SIGNAMAX LLC • www.signamax.eu
1-port ISDN U module (1U):
1-port ISDN U module (1U) indicator:
AC Light shines after link established
B1 B1 channel indicator
Light on: When using channel B1, and rate is 64K
B2 B2 channel indicator
Light on: When using channel B2, and the rate is 128K
1-port ISDN U module (1U) DIP switch:
Mode DIP switch configuration Description
1 2
Loopback ON Reservation
1U Module Connected Cable
1U module connected cable RJ45 (4, 5 signal cable) or RJ11 line
1U Interface Attri butes
1-port ISDN U module (1U) interface attributes:
Attributes Description
ie-in RJ45
Interface number 1
Supported link protocol PPP
Supported network
protocol
IP

18 SIGNAMAX LLC • www.signamax.eu
IP Module (VOP/VOS) Series
1-port IP Module (1VOP)
1-port IP phone module accesses any telephone via IP network The
user makes free phone calls via IP network
1VOP Module Indicat or
1VOP interface module:
1-port IP phone module (1VOP):
1-port IP phone module (1VOP) indicator:
V1 IP phone module indicator, and the light is on during the call
V2 1VOP module may not have this light, and if it has, the light will be not
on
1VOP Module Connect ed Cable
1VOP module connected cable is RJ45 (4, 5 signal cable) and RJ11
line
1VOP Interface Attributes
1-port IP phone module (1VOP) interface attributes:
Attributes Description
Interface RJ45 jack
Interface number 1
Supported
protocol
H.225
H.245
R P
R CP
G.711
G.723
G.729
