1Semi-Recessed Sink Installation Instructions
Read entire Semi-Recessed Sink Installation
Instructions. Observe all local building and
safety codes.
TOOLS AND MATERIALS:
BEFORE INSTALLING INSTALLATION
1. Carefully turn the sink over to rest upside down on the vanity top.
2. Apply a continuous bead of silicone to the outer edge of the
sink where it will contact the vanity top.
3. Turn the sink back over, placing it inside the sink cutout and
position until centered.
4. Remove any excess silicone with a cloth moistened with water or
mineral spirits. Let silicone dry for 24 hours. If a lavatory drain is
included, move on to the Drain Installation section.
Silicone
Sealant
INSTRUCTIONS
Unpack and inspect the product for any shipping
damages. If you find damages, do not install. Contact
Customer Service at 1-866-855-2284. If you need
assistance or have questions while installing your sink,
contact Customer Service.
For this installation it is assumed that the vanity top has
been cut to the dimensions of the sink. We recom-
mend consulting a professional if you are unfamiliar
with this type of installation, Signature Hardware
accepts no liability for any damages to the floor, walls,
plumbing or for personal injury during installation.
Damp Cloth
SEMI-RECESSED SINK
Thread
Sealant
Basin Wrench
24 hr

2Semi-Recessed Sink Installation Instructions
1. Disassemble the drain by removing the threaded
tail piece, rubber sealing gaskets, friction washer,
and lock nut from the drain body.
2. Place thread sealant on the threaded section of
the tail piece and reattach to the drain body. Slide
the flat rubber sealing gasket up the tail piece to the
top of the drain body. This gasket will create a water
tight seal between the drain flange and sink.
3. Place the drain in the drain hole in the sink. On the
underside of the counter, attach the tapered rubber
gasket. With the flat side facing down, slide the
gasket up the threaded shank until it makes contact
with the bottom of the sink.
4. Slide the friction washer up to meet the rubber
gasket. Thread the lock nut onto the threaded
shank. Hand-tighten and make sure that the drain is
properly aligned. When ready, finish tightening with
a basin wrench to secure the drain.
Flat Rubber Sealing Gasket
Drain Body
Tapered Rubber Sealing
Friction Washer
Lock Nut
Tail Piece
DRAIN INSTALLATION
DRAIN INSTALLATION
