Signode BXT 10 Instruction Manual

OPERATION, PARTS
AND SAFETY MANUAL
BXT 10
BATTERY-HAND TOOL FOR PLASTIC STRAPPING
IMPORTANT!
DO NOT DESTROY
It is the customer’s responsibility to
have all operators and servicemen
read and understand this manual.
Contact your local Signode representa-
tive for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS SIGNODE PRODUCT
SIGNODE • 3610 W. LAKE AVENUE • GLENVIEW, ILLINOIS 60025 U.S.A.
BUY AT ALLSTRAP [phone]

205.07
TABLE OF CONTENTS
Page
1 Technical data 3
2 General information 4
2.1 Information on environmental protection 4
3 Safety instructions 5
3.1 Safety instructions for battery
charger and battery 5
4 Description 6
4.1 Major components 6
4.2 Operating panel 6
4.3 Function 6
4.4 Battery charger indicators 7
5 Initial operation 8
5.1 Battery charger 8
5.2 First battery charge 8
5.3 Charging the battery 8
6 Operating instructions 9
6.1 Operating the tool 9
6.2 Strap seal inspection 10
6.3 Operating panel 11
6.3.1 Checking battery charge 11
6.3.2 Setting strap tension 11
6.3.3 Setting welding time 11
6.4 Setting strap width 12
7 Preventiveandcorrectivemaintenance13
7.1 Cleaning/replacing tension wheel 13
7.2 Cleaning/replacing tooth plate 13
7.3 Replacing cutting knife 13
8 Recommended spare parts 14
8.1 Parts list 14
Exploded drawing 17
BUY AT ALLSTRAP [phone]

3
05.07
1TECHNICAL DATA
Weight 3.5 kg (7.7 lbs) (incl. battery)
Dimensions Length 375 mm (14.7“)
Width 130 mm (5.1“)
Height 140 mm (5.5“)
Strap tension 0–700 N (0–155 lbs)
Tension speed 330 mm/s (12.9“/s)
Sealing Friction welded
BATTERY CHARGER / BATTERY
Voltage Battery charger, 100/240 V
(AL 60 DV 1419)
Bosch 12 V / 2.4 Ah / NiCd
Charging time 60 minutes
Strappings with
one battery charge Up to 300 depending on
strap, strap tension and
package
Service life Up to approx 2000
chargings
PLASTIC STRAP
Strap quality Polypropylene (PP)
Polyester (PET)
Strap width
adjustable to 9–11 mm (3/8“) (PP, PET)
12–13 mm (1/2“) (PP)
Strap thickness 0.5–0.8 mm (.019“–.031“)
BUY AT ALLSTRAP [phone]

405.07
CAUTION!
Used where there is dan-
ger to life and health.
WARNING!
Used for danger which
can cause material
damage.
2 GENERAL INFORMATION
These operating instructions are intended to sim-
plify familiarisation with the strapping tool and its
proper use for the intended purpose. The operating
instructions contain important information concern-
ing the safe, proper and efficient use of the strap-
ping tool. Compliance with the instructions will help
to avoid danger, reduce repairs and stoppages and
increase the reliability and service life of the strap-
ping tool.
The operating instructions must always be avail-
able at the place of operation of the strapping tool.
They must be read and observed by all persons
concerned with work on the strapping tool. This
work specifically includes operation, refilling of op-
erating material, fault elimination and maintenance.
In addition to the operating instructions and the
regulations for accident prevention effective in the
country of use and place of application, the recog-
nised technical regulations for safety and proper
operation must also be observed.
2.1 INFORMATION ON ENVIRONMEN-
TAL PROTECTION
This tool is manufactured without any physical or
chemical substances which could be dangerous to
health.
For disposal of all the parts, the governmental in-
structions must be observed. The electrical assem-
blies should be dismantled so that the mechanical,
electro-mechanical and electronic components can
be disposed of separately.
Dealers provide an environmentally- friendly
battery disposal service
• Do not open the battery.
• Do not throw the used battery into household
waste, fire or water.
Defective or used batteries undergo a complete
recycling process.
WARNING
BUY AT ALLSTRAP [phone]

5
05.07
Original spare parts must be
used exclusively!
Not using original spare parts
will dissolve the warranty and
the liability.
Use for the intended purpose
This tool is designed for strapping packages, pallet
loads and the like.
The tool was designed and manufactured to provi-
de safe handling during the strapping operation.
The tool is designed for use with plastic straps
(polypropylene and polyester).
Possible misuse
The use of steel straps is not possible.
3.1 SAFETY INSTRUCTIONS FOR
BATTERY CHARGER AND BATTERY
Always inspect the electrical plug
and cable before use. If damaged,
they must be replaced by qualified
personnel.
• Do not charge other types of batteries (see
chapter 5.1) and use original accessories only.
• Keep the battery charger slot free of foreign
objects and protect against dirt.
• Protect the battery charger against humidity and
use it in dry areas only.
• Do not open the battery. Protect the battery
against impact, heat and fire. Risk of explosion!
• When the battery is outside the battery charger,
cover its battery terminals to avoid short circuits
with metal objects. Risk of fire and explosion!
• Keep battery dry and protected against frost. Do
not store it at temperatures over 50°C (122°F) or
below 10°C (50°F).
• Damaged batteries should not be used longer.
3SAFETY INSTRUCTIONS
Inform yourself!
Read the operating instructions
carefully.
Preventive and corrective main-
tenance on the tool may only be
carried out by trained personnel.
Protect yourself!
When operating the tool, wear
eye, face and hand protection
(cut-proof gloves).
Power source!
Before starting preventive or
corrective maintenance, remove
battery from the tool.
Warning:
Strap will snap forward!
When cutting the strap, hold the
upper portion and stand safely
away from the strap.
Caution:
The lower strap will snap
forward.
Warning:
Strap could break!
Do not stand in line with the strap
while it is tensioned. The strap
could break!
Caution:
Only strap packed goods!
Do not put hands or other parts of
the body between the strap and
the package during the strapping
process.
Caution:
Danger of squeezing!
Do not put your fingers into the
tension wheel area.
Do not use water!
Do not use water or steam to
clean the tool.
WARNING
BUY AT ALLSTRAP [phone]

605.07
4DESCRIPTION
7 6 5 4 3 2 1
Fig. 1
1
2
3
4
5
6
7
89
12
34
Fig. 3
Fig. 2
7 6 5 4 3 2 1
1
2
3
4
5
6
4.3 FUNCTION
– Clamping of the straps by tooth plate on rocker
(3/1).
– Tensioning by feed wheel (3/2) anti-clockwise.
– Friction welding (3/3) of the straps.
– Upper strap is cut by knife (3/4).
4.1 MAJOR COMPONENTS
1 Operating panel
2 Strap tensioning push button
3 Handle
4 Battery
5 Rocker lever
6 Welding/cutting button
7 Welding/Cutting
8 Tensioning
9 Battery charger
4.2 OPERATING PANEL
1 Welding time push button
2 Strap tension push button
3 Battery push button
4 LED-indicators 1–7
Green = Strap tension setting
Red = Battery empty indicator
5 Setting – push button
6 Setting + push button
For detailed information of the operating panel,
refer to chapter 6.3.
BUY AT ALLSTRAP [phone]

7
05.07
Flashing
green light
Continuous
green light
Continuous
green light
Flashing
green light
Double flashing
green light
No indicator illu-
minated
4.4 BATTERY CHARGER INDICATORS
Ready for charging
Battery not inserted, mains
supply is connected.
Rapid charging
Rapid charging operates
until the battery is fully
recharged. The battery
charger then switches
automatically to trickle
charging.
Trickle charging
Battery is fully charged.
The battery charger is
delivering only a trickle
charge.
Temperature
Warning: the battery is too
hot (or too cold). Trickle
charging only.
The battery charger
switches automatically to
rapid charging when the
temperature is within the
permitted range again.
Error message
Warning: battery cannot
be charged (battery or
temperature sensor
defective or not a BOSCH
battery).
Mains supply not
connected:
electrical plug, cable or
battery charger defective.
For detailed information, refer to the operating
instructions for the battery charger.
Fig. 4
BUY AT ALLSTRAP [phone]

805.07
5INITIAL OPERATION
Fig. 5
Input 230 V 50/60 Hz / 44 W
Output 7.2-14.4 V 1.9 A
Fig. 6
176
177
5.1 BATTERY CHARGER
The mains supply must comply with the specificati-
ons on the rating plate (Fig. 5).
The battery charger is suitable only for charging
batteries from the Bosch range of tools (NiCd/
NiMH) with voltages between 7.2 V and 14.4 V.
5.2 FIRST BATTERY CHARGE
NOTE:
Please observe the following points in order to
ensure optimum battery life:
– Connect battery charger (177) to mains supply.
– Insert battery (176) into battery charger slot.
For the first charge, leave the battery in the
charger for at least five hours, regardless of the
battery indicator (the charging time for all subse-
quent charges is about 60 minutes).
For all subsequent charges, only recharge the
battery when the LED indicator on the tool indi-
cates battery empty (see Chapter 6.3). Avoid
charging when the battery is not yet dischar-
ged. This will ensure optimum battery capacity
and life.
Maximum battery output will be reached after four
or five charging/discharging cycles.
5.3 CHARGING THE BATTERY
The charging process and error functions are indi-
cated by a green light (see chapter 4.4).
The charging time is approximately 60 minutes.
The maximum charging current flows when the
tem-perature of the battery is between 15–40°C.
Avoid charging the battery at temperatures below
0°C and above 40°C.
NOTE:
If the battery is not to be used for a longer
period (several days), it should be removed
from the tool and charged/stored in the battery
charger.
The intelligent charger with fuzzy control charges
the battery with the optimum rapid charging current,
depending on temperature and capacity. If fully
charged, a preserving charge will prevent selfdi-
scharge and thus guarantee a long battery life.
Green LED
BUY AT ALLSTRAP [phone]

9
05.07
6OPERATING INSTRUCTIONS
Fig. 7 Place strap around package
1
Fig. 9 Strap tensioning
1
Fig. 8 Slide straps into tool
1
6.1 OPERATING THE TOOL
– Insert charged battery (7/1) into strapping tool.
– Place strap round goods to be packaged, so that
the straps lie one above the other on top of
package. The beginning of the strap is under-
neath. Hold the straps with the left hand so that
the strap beginning is approximately 20 cm (8“)
ahead of the hand.
– Take the tool in the right hand and lift the rocker
lever (8/1) towards the handle.
– Slide the straps, one on top of the other, into the
tool up to the stop.
NOTE:
The strap lead is now approximately 5 cm (2“)
beyond the tool.
– Release the rocker lever.
– Press the push button (9/1). The strap is ten-
sioned until the required or pre-selected strap
tension is reached.
– The strap tension can be adjusted on the
operating panel (see Chapter 6.3.2).
– The strap can be re-tensioned at any time.
Releasing strap tension
In order to release the strap tension after the
tensioning process, lift rocker lever (8/1) against
handle.
NOTE:
Tensioning – welding:
The welding may also be started before the strap
has been tensioned. However, the tensioning
button must be pressed briefly before welding.
WARNING
Wear safety glasses. Stand to one side of the strap when tensioning.
Make sure all bystanders are clear before proceeding.
BUY AT ALLSTRAP [phone]

10 05.07
+
~2 sec.
– Depress button (10/1) completely to the stop.
The straps are welded together and the upper
strap is cut off. The LED indicator (10/2) indica-
tes the cooling time of the sealing:
LED flashing
After finishing the friction
welding, the green LED flashes
for approx. two seconds.
Do not remove the tool during
this time!
Continuous LED and audible
signal
The sealing cycle is finished.
If the straps have not been welded and an
audible signal sounds, this means the tension
button was not depressed.
– After the LED has stopped flashing and the
audible signal sounds, raise the rocker lever up
to the handle.
– Swing the tool away from the strapping back-
wards and to the right.
– Check the seal (refer to chapter 6.2).
If the tool is used in a dirty environment, it is
recommended that it should be cleaned daily. In
particular the tension wheel and the tooth plate
should be checked for damage and kept clean.
This is best performed by blasting with compressed
air (wear goggles).
Fig. 10 Welding straps
1
2
Fig. 11 Removing tool
6.2 STRAP SEAL INSPECTION
– Check appearance of seal (see fig. 12) regularly.
If the straps are poorly welded, check the
welding time setting (refer to chapter 6.3.3).
1 Poorly welded seal (not welded over the com-
plete surface), welding time too short.
2Good seal (the complete surface is cleanly
welded without excess material being forced out
sideways).
3 Poorly welded seal (excess material is forced out
sideways), welding time too long.
An incorrectly welded strapping cannot
secure the package and can thus lead
to injuries.
Never transport or move packaged
goods with incorrectly welded seals.
Fig. 12 Checking of seal
123 1 23
POLYPROPYLENE (PP) POLYESTER (PET)
BUY AT ALLSTRAP [phone]

11
05.07
6.3 OPERATING PANEL
a) Standard indication (green)
The current strap tension setting is monitored with
inserted and charged battery.
1 = minimum strap tension (approx. 100 N) (22 lbs)
7 = maximum strap tension (approx. 700 N) (155 lbs)
– For adjustment of strap tension, refer to chapter
6.3.2
b) Battery empty indication (red)
If the inserted battery is empty, the LED switches to
red and the battery must be charged, refer to chapter
5.3.
6.3.1 CHECKING BATTERY CHARGE
– Depress battery push button (14/1) briefly. Read
off battery charge on LED indicator (14/2).
1 = empty battery
1–3 = minimum charge (battery must be charged
soon)
1–5=decreasingcharge(chargingpossible)
1–6 = good charge (charging would damage the
battery)
1–7 = maximum battery charge (charging would
damage the battery)
6.3.2 SETTING STRAP TENSION
– Depress strap tension push button (15/1) briefly
until LED indicator (15/3) flashes.
– Depress –or +push button (15/2) until flashing
LED indicator shows required strap tension (wait
two seconds until new setting is saved).
1 = minimum strap tension (approx. 100 N)
(22 lbs)
7 = maximum strap tension (apprrox. 700 N)
(155 lbs)
6.3.3 SETTING WELDING TIME
– Depress welding time push button (16/1) briefly
until LED indicator (16/3) flashes.
– Depress –or +push button (16/2) until flashing
LED indicator shows required welding time (wait
two seconds until new setting is saved).
1 = minimum welding time
7 = maximum welding time
NOTE:
Cutting
The cutting of the strap is influenced by the welding
time. If the tool cuts badly, extend the welding time
by one interval.
Fig. 14
7 6 5 4 3 2 1
max. min.
red
12
Fig. 15
12
7 6 5 4 3 2 1
green
max. min.
3
Fig. 16
12
red
max. min.
3
7 6 5 4 3 2 1
Fig. 13
7 6 5 4 3 2 1
a) Standard indication
green
red
b) Battery empty indication
max. min.
7 6 5 4 3 2 1
7 6 5 4 3 2 1
BUY AT ALLSTRAP [phone]

12 05.07
6.4 SETTING STRAP WIDTH
NOTE:
The tool can be used with two different strap
widths 9–11 mm (3/8“) or 12–13 mm (1/2“).
Strap width 12–13 mm (1/2“) only for PP straps!
a) Change strap width from 9–11 mm to
12–13 mm
– Remove battery from tool.
– Release sunk screw (47) and remove strap
stop 10 mm (43) (12–13 mm without strap
stop).
– Lift the rocker lever towards the handle, release
sunk screw (47) and remove strap guide
10 mm (104).
Mount strap guide 13 mm (102). Secure sunk
screw (47) with Loctite 222.
– Release sunk screw (103) and cylinder screw
(153) and remove cover (146).
– Release cylinder screw (154) turn strap stop
(18/2) 180° and remount it.
– Unscrew threaded bolt eight turns with screw-
driver (190).
– Pull down strap guide (147) and turn it 180° until
13 mm indicator appears.
– Tighten threaded bolt with screwdriver (190) and
mount cover (146).
– Secure screws (153) and (103) with Loctite 222.
b) Change strap width from 12–13 mm to
9–11 mm
– Sequence as described under point a).
– Mount 10 mm strap stop (43) and secure sunk
screw (47) with Loctite 222.
– Mount 10 mm strap guide (104) and secure sunk
screw (47) with Loctite 222.
– Turn strap stop (148).
– Turn strap guide (147) until “10“ indicator
appears.
180°
180°
8 x
10/13
Fig. 18
153
148
103
146
154
147
190
Fig. 17
43 47 102 104 47
BUY AT ALLSTRAP [phone]

13
05.07
7PREVENTIVE AND CORRECTIVE MAINTENANCE
7.1 CLEANING/REPLACING
TENSION WHEEL
Removal
– Remove battery from tool.
– Release three sunk screws (104) and remove
cover (100) with ball bearing.
– Lift rocker lever (109) and remove tension wheel
(38).
– Clean the tension wheel with compressed air
(wear goggles).
– If the tension wheel teeth are covered with heavy
dirt, they must be carefully cleaned with the wire
brush supplied.
– Check tension wheel for worn teeth. If a few
teeth are broken, replace tension wheel (observe
rotating direction, see arrow).
Installation
– Install the parts in reverse order.
– Grease gear teeth of tension wheel lightly with
KlübergreaseGBUY131(Microlube).
– When mounting tension wheel lift rocker lever.
– Secure sunk screw (104) with Loctite 222.
7.2 CLEANING/REPLACING
TOOTH PLATE
Removal
– Remove battery from tool.
– Release sunk screw (47) and remove tooth
plate (46).
– Clean tooth plate with compressed air (wear
goggles).
– If the tooth plate teeth are covered with heavy
dirt, they must be carefully cleaned with the wire
brush supplied or a sharp tool.
– Check tooth plate for worn teeth, if necessary
replace tooth plate.
Installation
– Install the parts in reverse order.
– Secure sunk screw (47) with Loctite 222.
7.3 REPLACING CUTTING KNIFE
Removal
– Remove battery from tool.
– Release sunk screw (103) and cylinder screw
(153) and remove cover (146).
– Release cylinder screw (97) and remove cutting
knife (95) with flanged bushing (96). Replace
cutting knife.
Installation
– Install the parts in reverse order.
– Before install cutting knife, check that the com-
pressing spring on top of knife is still mounted.
– Secure screw (153), (103) and (97) with
Loctite222.
All preventive maintenance tasks can be performed
with a Phillips screw driver!
Fig. 20
47
46
Fig. 21
153 103
146
95
96
97
The tension wheel must not be cleaned
while it is rotating. There is a risk
breaking teeth!
Fig. 19 (2 = Tension wheel type for BXT 10)
104
38
100
1
109
BUY AT ALLSTRAP [phone]

14 05.07
8RECOMMENDED SPARE PARTS
When ordering please indicate part number.
KEY QTY PART # DESCRIPTION
38 1 427508 Tension wheel
46 1 427509 Tooth plate
95 1 427510 Cutter knife
8.1 PARTS LIST BXT
1 1 427511 Base plate complete, incl.
pos.3-5
2
3 2 425758 Slide bearing, Ø10/12 x 15
4 2 425759 Slide bearing, Ø12/14 x 8
5 1 427512 Cylinderpin,Ø8h6x55
6
7 1 425731 Toothplatebelow
8 1 425715 Setscrew
9
10 1 425686 Bevel wheel with pinion
11
12 1 425755 Ball bearing, Ø10/22 x 6
13 1 425739 Spacer ring
14 1 427513 Blocking wheelcomplete,
incl. pos. 16
15
16 1 427405 Needlebushing,Ø10/14x10
17 1 423759 Free-wheel needle bearing,
Ø10/14x10
18 1 425753 Ball bearing, Ø10/14 x 12
19 1 426482 Retaining ring, Ø10
20 2 427514 Spacerdisk,Ø10/22x0.5
21
22 3 427515 Planetary wheel 1. Step
23 1 425737 Planetary support complete
24
25
26
27 1 425756 Needle bushing,
Ø10/14x15
28 1 425839 Spacerdisk,Ø12/24x0.5
29
30 1 427516 Flange complete,
31
32
33
34 5 427517 Cylinder screw, M4x12
35 1 425743 Cam disk
36 2 426808 Ball bearing, Ø35/47 x 7
37 3 425685 Planetarywheel2.Step
38 1 427508 Tension wheel
39
40 1 427519 Rocker
41 1 427520 Stop
42 1 427521 Cylinder pinØ4m6x10
43 1 427522 Strap stop, front, 10 mm
44
45 6 425842 Counter sunk screw, M3 x 8
46 1 427509 Tooth plate
47 2 426809 Counter sunk screw, M4 x 6
48
49 1 427524 Motorcompl.
50
51
52
53 1 427525 Carrier
54 3 425751 Ball bearing, Ø15/24 x 5
55 1 427526 Tothed belt wheel complete,
incl. pos. 54, 57
56
57 1 425844 Bushing,Ø6/10x12
58 1 425687 Bevel wheel complete,
incl. pos. 54, 60
59
60 1 425845 Bushing,Ø6/10x15
61
62
63 1 426201 Bushing complete,
incl. pos. 77
64
77 1 425846 Ridget pin, Ø 3x8 DIN 1469
65 1 426202 Needlebushing,
Ø12/18x12
66 1 425754 Ball bearing, Ø12/24 x 6
67 1 425847 Retaining ring, J Ø24
68 1 426203 Eccentric shaft
69 1 427527 Pinion
70 1 427528 Disk
71
72 2 427529 Cylinderscrew, M5x12
73 1 425688 Tothedbelt
74 3 427530 Cylinderscrew, M5x20
75 1 425722 Swivelbearing complete,
incl. pos. 77
76
77 1 425950 Ridget pin, Ø3x8 DIN 1469
78 1 425677 Tension spring
KEY QTY PART # DESCRIPTIONKEY QTY PART # DESCRIPTION
Bold = Recommended spare parts
BUY AT ALLSTRAP [phone]

15
05.07
79 1 425951 Retaining ring, A Ø23
80 1 425952 Retaining ring, A Ø12
81 1 426772 Connecting rod
82 1 426773 Shaft
83 1 426813 Ball bearing, Ø9/26 x 8
84 1 425679 Washer
85 2 427521 Cylinder screw, M4x10
86 2 427532 Counter sunk screw, M3 x 8
87 1 426776 Welding shoe
88 1 427533 Ovalheadscrew,M3x5
89 1 425718 Safety plate
90 2 425714 Ballbushing
91 1 425711 Cover plate
92
93 1 425712 Tooth plate top
94 1 427534 Compression spring
95 1 427510 Cutter knife
96 1 425713 Flangedbushing
97 1 426777 Welding shoe complete,
incl. pos. 81,82,83,87,88,89
98
99
100 1 427536 Cover tensioning
101
102 1 425749 Strap guide, 13 mm
103 1 426816 Counter sunk screw, M4 x 16
104 1 427537 Strap guide, 10 mm
105 3 427538 Counter sunk screw, M4 x 12
106
107
108
109 1 427539 Rocker lever complete,
incl.pos.111-113
110
111 1 427540 Bolt, Ø8/h9
112 1 427541 Pin, Ø4/h9 x 32.5
113 1 427542 Pin, Ø4/h9 x 30
114 1 427543 Blocking paw
115 1 427544 Bolt
116 1 425736 Toothed segment
117 2 425961 Spacer disk, Ø10/16 x 0.5
118 1 427545 Retaining ring, Ø8
119 1 427546 Cylinder screw, M4x25
120 1 425682 Tension spring bolt
121 1 425678 Tension spring
122
123 1 425964 Globule hardened, Ø8
124 1 425671 Compression spring
125 1 426818 Threaded bolt, M10
126 1 427547 Cam bolt complete, incl. pos.
128,129,143
127 1 426819 Welding bouton-set,incl. 156
128
129
130 1 425729 Cam
131 1 427548 Set screw, M5 x 8
132 1 425692 Micro switch, welding
133 2 427549 Oval head screw, M2 x 10
134 1 427550 Shim plate
135 1 425725 Spring bow
136 1 425726 Roller
137 1 425727 Shaft
138 1 425728 Pressure bolt
139 1 425674 Spring
140 1 427557 Lock nut, M6
141 2 425970 Retaining ring, Ø4
142 1 425680 Shaft
143
144
145
146 1 427552 Cover welding
147 1 427553 Strap guide, 10/13 mm
148 1 427554 Strap stop 10/13 mm
149 1 427555 Hook
150 1 425746 Threaded bolt
151 1 425748 Pin screw
152 1 425675 Compression spring
153 1 427556 PT-Screw, KA 35x25
154 1 427557 PT-Screw, KA 30x14
155 1 427558 Gear cover
156 6 426823 Oval head screw, M4 x 10
157
158 1 427559 Housing part right, black
159
160 1 427560 Housing part left, black
161
162 10 425976 PT-Screw, KA 35x20
163
164 1 425703 Protection cover
165
166 1 425689 Switch button, red
167 1 425673 Compression spring
168 1 425691 Micro switch, tensioning
169
170 1 425977 Motor cover complete, black
171 1 425694 Contact plate complete
172 1 427575 Printed circuit board digital
173 2 425978 PT-Screw, KA 30x10
174
175 2 Washer, M 3
176 1 425769 Battery 12V 2,4 Ah
177 1 427561 Charger AL60DV,1419,EU
177 1 425767 Charger AL60DV,1419, USA
177 1 427562 ChargerAL 60DV,1419,
Japan
180
181 1 427564 Indication plate
182 1 427565 Indication plate
183 1 427566 Name plate
KEY QTY PART # DESCRIPTION KEY QTY PART # DESCRIPTION
Bold = Recommended spare parts
BUY AT ALLSTRAP [phone]

16 05.07
184 1 427567 Name plate
185 1 427568 Indication plate
186 1 427569 Indication plate
1 425982 Tool-set
190 1 425983 Screwdriver (Phillips)
191 1 425697 Wire brush
425765 Option: protection plate-
set
193 1 425984 Protection plate
194 4 426824 Counter sunk screw, M 5 x 8
196 425764 Option: suspension bow-
set
200 427570 Option: protection cover-
set
427571 Spare part-set: strap
guide 10/13 mm
43 1 427522 Strap stop, front, 10 mm
102 1 425749 Strap guide, 13 mm
104 1 427537 Strap guide, 10 mm
47 2 426809 Counter sunk screw
Spare part-set:
housing parts
1 425991 Housing parts, black, incl.
pos. 158/160
When ordering please indicate part number.
KEY QTY PART # DESCRIPTION
BUY AT ALLSTRAP [phone]

17
05.07
WARNING
Inspect all parts daily and replace them if they
are worn or broken. Failure to do this can affect
a product’s operation and could result in
serious personal injury.
91
86
54
58 60
54
73
55 57
54
a)45
53
49
a)85
70 69
68 67 66
80
10
12
13
17
14
22
23
28
27
30
a)34
35
36
37
38
36
100 a)105
138
139
135
140
141
137
136
142
63
78 77
65
75
79
(83)
(81) 84
a)85
(a)88)
(89)
(82)
a)72
77
a)74
74 124
123 120
a)153
5
40
a)47 43
10 mm (3/8")
a)47
46
1
a)156
155
115
3
4
8
113
c)111
109
114
7
a)119
112
94
95
96
a)156
86 93
(87)
90
121
7
6
5
4
3
2
1
156
162
172
170
162
158
176
171
160
164
166
167
168
162
177
154
148
147
146
150
152
149
151
a)156
127
116
117
118
130
07.03.07
BXT 10
a)103
a)Loctite 222 b)Loctite 243 c)Loctite 638 *Optionen/Options
a)47
102 13 mm (1/2")
141 a)131
126
117
42
88
104 10 mm (3/8")
16
41
190
175
173
191
18 19
20
200*
196*
a)125
133
132
134
97 (incl. 81,82,83,87,88,89)
BUY AT ALLSTRAP [phone]

18 05.07
EU DECLARATION OF CONFORMITY
We take sole responsibility for declaring that the tool to which this declaration refers, is in full
compliance with the current requirements of the guidelines laid down by the council on 22th June
1998 (98/37/EEC), “Machine Guidelines“ and on 3th May 1989 (89/336/EEC), “EMV Guidelines“.
Machine Description: BXT 10
Machine Type: Battery-hand tool for plastic strapping
Provisions with which machine complies: 98/37/EEC, 73/23/EEC, 89/336/EEC
Harmonized Euro-Norms with
which machine complies: EN ISO 12100-1, EN ISO 12100-2, EN 349, EN 1050,
EN 61000-6-1, EN 61000-6-3
Technical Standards with
which machine complies: NA
Signature: Sales Manager General Manager Products
Packaging Technology: Packaging Technology:
R. Kieffer M. Binder
Date: 11.10.2005
SIGNODE ENGINEERED PRODUCTS
Hand Tool Division
3610 W. Lake Avenue,
Glenview, Illinois 60025
BUY AT ALLSTRAP [phone]

20 05.07
SIGNODE
NEW TOOL WARRANTY
Signode Engineered Products Warrants that a new Signode strapping tool will operate per functional
specifications for a period of sixty (60) days after the date of shipment to the owner’s place of
business. Normal wearing parts, as outlined in the Operation, Parts & Safety manual, are covered
by a thirty (30) day warranty unless, in Signode’s judgement, these parts have been subjected to
abnormal or extreme usage. Signode’s sole liability hereunder will be to repair or replace, without
charge, F.O.B. Signode’s Glenview,Illinois plant, any tool which proves to not operate per functional
specifications within the stated period. Signode reserves the right to replace any tool which proves not
to operate per functional specifications with a new or like-new tool of the same model if in Signode’s
judgement such replacement is appropriate.
Any new replacement tool provided to an owner will carry a full sixty (60) day warranty. Any warranty
repaired tool or like-new replacement tool will carry a warranty for the balance of the time remaining
on the initial sixty (60) day warranty. This warranty will be extended to compensate for the time the
tool is in Signode’s possession for warranty repairs.
This warranty is void as to any tool which has been: (I) subjected to mis-use, misapplication, accident,
damage, or repaired with other than genuine Signode replacement parts, (II) improperly maintained,
or adjusted, or damaged in transit or handling; (III) used with improperly filtered, unlubricated air or
improper strapping material, (IV) in Signode’s opinion, altered or repaired in a way that affects or
detracts from the performance of the tool.
SIGNODE MAKES NO WARRANTY, EXPRESSED OR IMPLIED, RELATING TO MERCHANTA-
BILITY, FITNESS OR OTHERWISE EXCEPT AS STATED ABOVE AND SIGNODE’S LIABILITY
AS ASSUMED ABOVE IS IN LIEU OF ALL OTHERS ARISING OUT OF OR IN CONNECTION
WITH THE USE AND PERFORMANCE OF THE TOOL. IT IS EXPRESSLY UNDERSTOOD
THAT SIGNODE SHALL IN NO EVENT BE LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL
DAMAGES INCLUDING, BUT NOT LIMITED TO, DAMAGES WHICH MAY ARISE FROM LOSS OF
ANTICIPATED PROFITS OR PRODUCTION, SPOILAGE OF MATERIALS, INCREASED COSTS OF
OPERATION OR OTHERWISE.
Considerable effort has be made to ensure that this product conforms to our high quality standards.
However, should you experience any difficulties, please contact your Sales Representative providing
samples and the manufacturing code specified on the tool.
Thank you for your help.
SIGNODE ENGINEERED PRODUCTS
Hand Tool Division
3620 W. Lake Avenue, Glenview, Illinois 60025
PART # DESCRIPTION AREA OF USE
LUBRICANTS
008556 LS-1236 AIR LINE OIL AIR MOTORS, AIR VALVES
422792 WHITE LUBRIPLATE GR-132 GREASE PNEUMATIC PARTS, AIR CYLINDERS, AIR VALVES, O-RINGS
422793 BLACK LUBRIPLATE 3000W GREASE MOVING EXTERNAL PARTS, JAWS, LINKS
425239 RED MOBILITH SHC 007 GREASE INTERNAL GEARS
432322 EP ACCROLUBE GREASE HIGH FRICTION CONTACT PARTS
ADHESIVES
274111 LOCTITE #380 BLACK MAX PERMANENT, FLAT SURFACE PART CONTACT
422794 LOCTITE #222 PURPLE LOW STRENGTH, SCREWS 1/4“ (6MM) OR SMALLER SIZES
422795 LOCTITE #242 BLUE MEDIUM STRENGTH SCREWS 5/16“ (8MM) OR LARGER SIZES
422796 LOCTITE #271 RED HIGH STRENGTH, SEMI-PERMANENT SCREWS APPLICATION
422797 LOCTITE #609 GREEN PERMANENT, CURVED SURFACE PART CONTACT
CLEANING BRUSHES
023963 SMALL BRUSH FEEDWHEEL & GRIPPER TEETH
269589 LARGE BRUSH FEEDWHEEL & GRIPPER TEETH
BUY AT ALLSTRAP [phone]
