SIGRIST ColorPlus 3 User manual

Document number: 14501E
Version: 2
Valid from: S/N 432010 /
SW V129
INSTRUCTION MANUAL
ColorPlus 3
Absorption Measuring Instrument

Copyright© SIGRIST-PHOTOMETER AG, subject to technical changes without notice 2/2020
SIGRIST-PHOTOMETER AG
Hofurlistrasse 1
CH-6373 Ennetbürgen
Switzerland
Tel. [phone]
Fax [phone]
[e-mail]
www.photometer.com

Contents Instruction Manual ColorPlus 3
14501E/2 3
Contents
1General user information...............................................................................................7
1.1 Terms used in this document (glossary) .............................................................7
1.2 Purpose of the Instruction Manual ....................................................................7
1.3 Target group of the documentation..................................................................7
1.4 Additional documentation ................................................................................7
1.5 Copyright provisions .........................................................................................7
1.6 Document storage location...............................................................................7
1.7 Order document ...............................................................................................8
1.8 Proper use ........................................................................................................8
1.9 User requirements ............................................................................................8
1.10 Declaration of conformity .................................................................................8
1.11 Use restrictions .................................................................................................8
1.12 Dangers when not used properly ......................................................................9
1.13 Meaning of the safety symbols .......................................................................10
1.14 Meaning of the pictograms.............................................................................10
2Instrument overview ....................................................................................................11
2.1 Overview of a measuring point .......................................................................11
2.2 Designation of the ColorPlus 3........................................................................12
2.3 Scope of supply and accessories......................................................................13
2.3.1 Standard scope of supply for the ColorPlus 3.............................................13
2.3.2 Optional accessories for the ColorPlus 3 ....................................................14
2.4 Technical data for the ColorPlus 3...................................................................15
3General safety points...................................................................................................17
3.1 Dangers when properly used ..........................................................................17
3.2 Residual risk....................................................................................................18
3.3 Warning and danger symbols on the instrument.............................................18
3.4 Preventing undesirable online access attempts................................................19
4Mounting ....................................................................................................................20
4.1 Mounting the ColorPlus 3...............................................................................20
4.2 Mounting the SICON (M) ................................................................................21
5Electrical installation ....................................................................................................22
5.1 Safety pointers for the electrical connection....................................................22
5.2 Opening the cover on the SICON (M)..............................................................23
5.3 Overview of the opened SICON (M) control unit .............................................24
5.4 Connecting the SICON (M) .............................................................................25
5.5 Connecting the instrument cable to the ColorPlus 3 .......................................26
5.5.1 Cable cross-sections over longer distances .................................................27
5.6 Connecting the connection box ......................................................................28
5.7 Connecting the optional flow meter ...............................................................29
5.8 Connecting the optional 24 VDC power supply ..............................................30
5.9 Connecting the field bus interfaces (optional) .................................................31
5.9.1 Overview of Profibus DP and Modbus RTU ................................................31
5.9.2 Connecting the Profibus DP or Modbus RTU..............................................31
5.9.3 Overview of Profinet IO .............................................................................32
5.9.4 Overview of HART .....................................................................................33
5.9.5 Connecting to HART..................................................................................33
5.10 Connecting the analog modules (optional) .....................................................34
5.10.1 Overview of 4-way current output .............................................................34
5.10.2 Connecting the 4-way current output .......................................................34
5.10.3 Overview of the 4-way current input .........................................................35
5.10.4 Connecting the 4-way current input..........................................................35

Instruction Manual ColorPlus 3 Contents
4 14501E/2
6Commissioning............................................................................................................36
7Operation ....................................................................................................................37
7.1 Operation basics .............................................................................................37
7.2 Control elements in measuring mode .............................................................38
7.3 Menu button ..................................................................................................38
7.4 Valu button ....................................................................................................38
7.5 Info button .....................................................................................................39
7.5.1 Page 1, Info button ...................................................................................39
7.5.2 Page 2, Info button ...................................................................................40
7.6 Diag button ....................................................................................................41
7.7 Functions of the log screen (Log button).........................................................42
7.8 Displays in measuring mode............................................................................43
7.9 Lock / unlock the touch screen........................................................................44
7.10 Switching to service mode ..............................................................................45
7.11 Control components in service mode ..............................................................46
7.11.1 Input elements in service mode..................................................................46
7.11.2 Numerical entry .........................................................................................47
7.11.3 Single selection of functions ......................................................................48
7.11.4 Multiple selection of functions...................................................................48
8Settings .......................................................................................................................49
8.1 Setting the operating language.......................................................................49
8.2 Setting the current outputs.............................................................................50
8.3 Setting the limits.............................................................................................51
8.3.1 Upper and lower threshold value of a limit ................................................52
8.3.2 Reading if limit exceeded or undershot ......................................................52
8.4 Setting the outputs .........................................................................................53
8.5 Activating the optional flow meter..................................................................54
8.6 Setting the date and time ...............................................................................55
8.7 Setting or changing the access code ...............................................................56
8.8 Backup configured data..................................................................................57
9Servicing......................................................................................................................58
9.1 Servicing schedule ..........................................................................................59
9.2 Cleaning the measuring cell............................................................................60
9.3 Replacing the desiccant ..................................................................................62
9.4 Recalibrating the photometer .........................................................................63
9.5 Carrying out the sensor check.........................................................................64
9.6 Replacing the filter cartridge on the filter unit.................................................65
9.7 Changing the battery in the SICON (M) ..........................................................66
10 Troubleshooting ..........................................................................................................67
10.1 Pinpointing faults............................................................................................67
10.1.1 Warning messages and effect on operation...............................................67
10.1.2 Fault messages and effect on operation.....................................................69
10.1.3 Prioritized fault messages and their effect on operation.............................71

Contents Instruction Manual ColorPlus 3
14501E/2 5
11 Customer service information ......................................................................................72
12 Decommissioning/Storage ...........................................................................................73
12.1 Decommissioning the photometer ..................................................................73
12.2 Storing the photometer ..................................................................................73
13 Packaging / Transport / Returning ................................................................................74
14 Disposal.......................................................................................................................75
15 Spare parts list .............................................................................................................76
16 Index ...........................................................................................................................78
Makro

Instruction Manual ColorPlus 3 Contents
6 14501E/2
This pageis i ntentionally blank
Makro

General user information Instruction Manual ColorPlus 3
14501E/2 7
1General user information
1.1 Terms used in this document (glossary)
Please refer to our website for specialist terms: www.photometer.com/en/glossary/
1.2 Purpose of the Instruction Manual
This Instruction Manual provides the user with helpful information about the entire life cycle
of the ColorPlus 3 and its peripheral devices. Before commissioning the instrument, you
should be completely familiar with the Instruction Manual.
1.3 Target group of the documentation
The Instruction Manual is intended for all persons who are responsible for the operation and
maintenance of the instrument.
1.4 Additional documentation
DOC. NO.
TITLE
CONTENT
14535E
Brief Instructions
The most important functions and the servicing
schedule.
14534E
Reference Handbook
More sophisticated menu functions and worksteps
for advanced users.
14723E
Data Sheet
Description of SAC 254 application in water.
15496E
Data Sheet
Description of nitrate application with in water.
14536E
Service Manual
Repair and conversion instructions for service engi-
neers.
14631DEF
Declaration of Con-
formity
Compliance with the underlying directives and
standards.
1.5 Copyright provisions
This document has been written by SIGRIST-PHOTOMETER AG. Copying or modifying the
content or giving this document to third parties is permitted only with the express consent of
SIGRIST-PHOTOMETER AG.
1.6 Document storage location
This document is part of the product. It should be stored in a safe place and always be close
at hand for the user.

Instruction Manual ColorPlus 3 General user information
8 14501E/2
1.7 Order document
The most recent version of this document can be downloaded at www.photometer.com
(first time registration required).
It can also be ordered from a SIGRIST representative in your country (Instruction Manual
“Customer service information”).
1.8 Proper use
The ColorPlus 3 and its peripherals are designed for measuring absorption in water.
1.9 User requirements
The instrument may be operated only by trained technical personnel who have read and un-
derstood the content of the Instruction Manual.
1.10 Declaration of conformity
Current technological principles were followed in designing and manufacturing the instru-
ment. They comply with the applicable guidelines concerning safety and duty to take due
care.
EU: The measuring instrument meets all applicable requirements within the European Union
(EU) for carrying the CE mark.
Please refer to the separate declaration of conformity for details. Section 1.4
1.11 Use restrictions
EXPLOSION
HAZARD!
Operation in an inappropriate environment.
Use in explosive areas can cause explosions, which can lead to the death of persons in the
vicinity.
It is not permitted to operate the instrument in explosion hazardous areas or rooms.
It is not permitted to use the instrument with explosive sample substances.

General user information Instruction Manual ColorPlus 3
14501E/2 9
1.12 Dangers when not used properly
DANGER!
Operation when not used properly.
Improper use of the instrument can cause injuries to persons, process-related consequential
damage and damage to the instrument and its peripherals.
In the following cases the manufacturer cannot guarantee the protection of persons and the
instrument and therefore assumes no legal responsibility:
The instrument is used in a way not included in the described area of application.
The instrument is not properly mounted, set up or transported.
The instrument is not installed and operated in accordance with the Instruction Manual.
The instrument has been operated with accessory parts which SIGRIST-PHOTOMETER
AG has not expressly recommended.
Improper changes to the instrument have been performed.
The instrument has not been operated within the specifications, in particular concerning
pressure and temperature.
The instrument is exposed to vibrations, shocks or other mechanical forces.

Instruction Manual ColorPlus 3 General user information
10 14501E/2
1.13 Meaning of the safety symbols
All danger symbols used in this document are explained below:
DANGER!
Danger due to electrical shock that may result in serious bodily injury or death.
Non-observance of this notice may lead to electrical shocks and death.
EXPLOSION
HAZARD!
Danger due to explosion that may result in serious bodily injury or death.
Non-observance of this notice may cause explosions resulting in serious property damage
and death.
WARNING!
Warning about bodily injury or hazards to health with long-term effects.
Non-observance of this warning may lead to injuries with possible long-term effects.
CAUTION!
Notice about possible material damage.
Non-observance of this notice may cause material damage to the instrument and its
peripherals.
1.14 Meaning of the pictograms
All pictograms used in this document are explained below:
Additional information about the current topic.
Practical procedures when working with the ColorPlus 3.
Manipulations on the touchscreen.
The screenshot is an example and may differ from current device.

Instrument overview Instruction Manual ColorPlus 3
14501E/2 11
2Instrument overview
2.1 Overview of a measuring point
Figure 1: Overview of a measuring point

SICON control unit

ColorPlus 3

Sample outlet

Measuring cell
(example: 100 mm path length)

Sample inlet

Plug connection

Connector, 4-pin


Instruction Manual ColorPlus 3 Instrument overview
12 14501E/2
2.2 Designation of the ColorPlus 3
The SICON control unit and ColorPlus 3 are each fitted with a rating plate:
Figure 2: Rating plates on the instruments

Manufacturer

Country of origin

Product name

Serial number

Date of manufacture

Service voltage

Frequency range

Power

Observe the Instruction Manual

Observe the disposal information

Instrument overview Instruction Manual ColorPlus 3
14501E/2 13
2.3 Scope of supply and accessories
2.3.1 Standard scope of supply for the ColorPlus 3
PCS.
ART. NO.
NAME
VIEW
VARIANT
1
See the
website
ColorPlus 3
UV:
Layer 100/10
mm
Layer 50/10 mm
Nitrate:
Layer 5/1.5 mm
1
118342
SICON control unit
1
120442
Device cable, 4-
pin, 10 m with
connector
PCS.
ART. NO.
NAME
VIEW
VARIANT
1
14501
Instruction Manual
German
French
English
1
14534
Reference Hand-
book
German
English
1
14535
Brief Instructions
German
French
English

Instruction Manual ColorPlus 3 Instrument overview
14 14501E/2
2.3.2 Optional accessories for the ColorPlus 3
PCS.
ART. NO.
NAME
VIEW
VARIANT
1
118442
Profibus DP inter-
faces print
For SICON (M) only
1
118445
Modbus RTU inter-
faces print
For SICON (M) only
1
119796
HART module
For SICON (M) only
1
119130
4-way current
output
For SICON (M) only
1
119795
4-way current in-
put
For SICON (M) only
1
119045
24 VDC mains de-
vice
20W, IP66, input
100 to 240 VAC
1
109534
Connection box
1
see the
website
Set for wall moun-
ting, with/ without
filter unit and flow
rate sensor
Incl. special wrench,
art. no.: 121039
1
190040
SICON M multi-
control unit
1
120538
Device cable, 4-
pin, 20 m with
connector
1
120539
Device cable, 4-
pin, 30 m with
connector

Instrument overview Instruction Manual ColorPlus 3
14501E/2 15
2.4 Technical data for the ColorPlus 3
Absorbance measu-
rement
Values
Measuring principle
Absorption
Measuring scope
UV 100 mm
0 .. 1 to 0 .. 30 E/m
UV 50 mm
0 .. 2 to 0 .. 60 E/m
Nitrate 5/1.5
mm
0 .. 100 mg/l NO3
Hazen
Depending on wavelength
Measuring ranges
8, freely configurable
Wavelength
1 .. 3 different wavelengths 200 –800 nm
Nitrate: 214 nm for nitrate and 254 nm for compensation
Resolution
UV: 0.001 E
Nitrate: 0.01 mg/l
Reproducibility
UV:
Extinction
Tolerance
0 .. 1 E
± 2 % of meas value, > 0,001 E
1 .. 2 E
± 3 % of meas value
2 .. 3 E
± 4 % of meas value
Nitrate:
+/- 0.1 mg/l or +/- 1 % from measuring value (whichever is
greater)
Linearity
Better than ± 0.5% transmission
ColorPlus 3
Values
Analog channels
2 x 0.4 .. 20 mA
Service voltage
24 VDC ± 10 %
Power consumption
3 W (photometer only)
Dimensions
See detailed dimension sheet
Weight
3.4 kg
Protection class
IP 67
Ambient temperature
- 20 .. 50 °C
Ambient humidity
0 .. 100% rel. Humidity
Photometer material
Stainless steel 1.4301

Instruction Manual ColorPlus 3 Instrument overview
16 14501E/2
Measuring cell data
Values
Material
PVC housing, stainless steel 1.4435
Window
Quartz glass
Plastic push-in connec-
tions
D = 8 mm / G ¼" thread
Max. medium tempe-
rature
0 .. 50 °C
Max. medium pressure
600 kPa (6 bar)
Flow rate
0.5 .. 1 l/min
SICON control unit
Values
Service voltage and
power consumption
24 VDC ± 10 %
5 W (only SICON)
Display
¼ VGA with touchscreen
Resolution: 320 x 240 pixels with 3.5" diagonal
Outputs/inputs
Outputs:
4 x 0/4 .. 20 mA, galvanically isolated up to max. 50 V relative
to ground and max. 500 Ω burden.
7 x digital outputs up to max. 30 VDC, freely configurable, 1
output as de-energized closed relay.
Inputs:
5 x digital inputs up to max. 30 VDC, freely configurable.
Interfaces
Ethernet, SD card (for logging, SW update, diagnostics), Modbus
TCP, optional: Modbus RTU, Profibus DP, HART, Profinet IO
Protection class
IP66
Weight
Approx. 0.6 kg
Dimensions
160 x 157 x 60 mm
Housing material
ABS
24 VDC mains device
Values
Service voltage
100 .. 240 VAC, 47 .. 63 Hz
Power consumption
Max. 25 W (the power consumption of the connected sensors
must not exceed 21 W)
Maximum operating
altitude
2,000 m above sea level
Protection class
IP66
Weight
0.66 kg
Dimensions
Approx. 130 x 155 x 55 mm (W x H x D)
Housing material
PC

General safety points Instruction Manual ColorPlus 3
14501E/2 17
3General safety points
3.1 Dangers when properly used
DANGER!
Damaged instrument or cabling.
Touching damaged cables may lead to electrical shocks or death.
The instrument may be operated only when the cables are undamaged.
The instrument may be operated only if it has been properly installed or repaired.
DANGER!
Dangerous voltage inside the instrument.
Touching live components inside the instrument may lead to electric shocks resulting in
death.
The instrument must not be operated when the housing is removed or opened.
DANGER!
Damage to the instrument due to incorrect service voltage.
If the instrument is connected to an incorrect service voltage, the instrument can be dam-
aged.
The instrument may be connected only to voltage sources as specified on the rating
plate.
DANGER!
Missing Instruction Manual after the instrument changes hands.
Operating the instrument without knowledge of the Instruction Manual may lead to injuries
to persons and damage to the instrument.
If the instrument changes hands, always include the Instruction Manual.
If the Instruction Manual is lost, you can request a replacement.
Registered users can download the current version at www.photometer.com.
CAUTION!
Escaping medium from leaks on the instrument or water connections.
Escaping medium can lead to flooding of the room and material damage to the building and
fittings.
Check that there are no leaks.
DANGER!
Manipulations on pressurized lines.
Improper manipulations on a pressurized line can lead to the sample escaping under pres-
sure, resulting in injuries, damage to the instrument and material damage on site.
Always consult the Instruction Manual before making any manipulations to pressurized
lines.
The medium line must be emptied before removing the instrument or opening the
measuring cell.

Instruction Manual ColorPlus 3 General safety points
18 14501E/2
CAUTION!
Eye injuries caused by UV radiation.
During operation, there is dangerous UV radiation that can cause eye damage.
Always interrupt the service voltage before opening the instrument.
Never look directly into the light beam.
Do not use any reflective objects when cleaning the measuring cell.
CAUTION!
Penetration of moisture as well as condensation on the electrical components dur-
ing servicing duty.
If moisture enters the instrument, the ColorPlus 3 can be damaged.
Work inside the instrument may be performed only in a dry room and at room tempera-
ture. The instrument should be at operating or room temperature (avoid condensation
on optical and electrical surfaces).
CAUTION!
The use of aggressive chemicals when cleaning.
Use of aggressive chemicals can cause damage to instrument components.
Do not use aggressive chemicals or cleaning agents when cleaning.
Should the instrument come in contact with aggressive chemicals, clean it thoroughly
with a neutral cleaning agent.
3.2 Residual risk
WARNING!
According to the risk assessment of the applied safety directive DIN EN 61010-1,
there remains the risk of the displayed measuring values being incorrect. This risk
can be reduced with the following measures:
Use an access code to prevent unauthorized persons from changing parameters.
Perform the specified servicing duties.
3.3 Warning and danger symbols on the instrument
WARNING!
There are no warning or danger symbols on the instrument.
Users must ensure that they observe the safety measures as specified in the Instruction Man-
ual at all times when working with the instrument and its peripheral equipment, even if no
warning or danger symbols are attached to the instrument.
The following sections must be internalized:
Section 1.11
Section 1.12
Section 1.13
Section 3.1
Section 3.2
Observe safety pointers when performing the described procedures.
Observe local safety pointers.

General safety points Instruction Manual ColorPlus 3
14501E/2 19
3.4 Preventing undesirable online access attempts
WARNING!
SIGRIST instruments are equipped with an integrated web user interface and Mod-
bus TCP interface, thus offering state-of-the-art administration and control possibil-
ities. However, if these are connected directly to the Internet, then any Internet us-
er can in principle access your instrument and change the configuration.
Please note the following points to prevent this:
Never connect the instrument directly to the Internet.
Operate it behind a firewall and block access to the instrument.
Only connect to branch offices via VPN.
Change the standard password on commissioning.
Always keep up to date with the latest changes regarding Internet security so that you
can react promptly in the event of alterations.
Install the latest updates immediately (also for the router and firewall).

Instruction Manual ColorPlus 3 Mounting
20 14501E/2
4Mounting
4.1 Mounting the ColorPlus 3
Note the following points when mounting the instrument:
The ColorPlus 3 must be installed horizontally. The sample outlet (Y) must be positioned
at the top so that the measuring cell can be well ventilated.
A regulator valve must be installed on the sample outlet (Y) so that counter pressure can
be generated (operation of the measuring cell under pressure so that disruptive air bub-
bles are eliminated).
Mount the ColorPlus 3 as follows:
WORKSTEP
ADDITIONAL INFO / IMAGES
1.
Install the ColorPlus 3 horizontally onto a wall
using two M6 screws on the fastening plate.
2.
Connect the hoses (D = 8 mm) to the sample
inlet and outlet.
X: Sample inlet
Y: Sample outlet
The G ¼" threads can be accessed by
removing the push-in connections (X, Y).
