Silvercrest KH 206 User manual

Wireless Doorbell
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH206-06/10-V2
KH 206
Wireless Doorbell
Operating instructions
Dzwonek do drzwi sterowany radiowo
Instrukcja obsługi
Ajtócsengő
Használati utasítás
CV_KH206_53464_GB_PL_HU.indd 1-3CV_KH206_53464_GB_PL_HU.indd 1-3 19.07.2010 16:17:02 Uhr19.07.2010 16:17:02 Uhr

KH 206
23
5
6
7
48
9
0
q
w
e
r
t
1
A
B
CV_KH206_53464_GB_PL_HU.indd 4-6CV_KH206_53464_GB_PL_HU.indd 4-6 19.07.2010 16:17:02 Uhr19.07.2010 16:17:02 Uhr

- 1 -
Read these operating instructions carefully before using the appliance for
the first time and preserve this booklet for later reference. Pass this booklet
on to whoever might acquire the appliance at a future date.
INDEX PAGE
Intended Use 2
Items supplied 2
Technical data 3
Safety instructions 3
The appliance parts 5
Taking the appliance into use 6
Maintenance 10
Cleaning and Care 10
Disposal 11
CE Conformity 12
Importer 12
Warranty and Service 12
LB4A.indb 1LB4A.indb 1 20.07.2010 10:35:41 Uhr20.07.2010 10:35:41 Uhr

- 2 -
Intended Use
This appliance serves as a radio doorbell system for wireless
visitor signalisation and thus makes possible the operation of
a door bell without wiring. The appliance is intended for
domestic use only, not for commercial or industrial applications.
No warranty is provided for damages resulting from improper
use of the appliance!
Items supplied
1 Receiver
1 Transmitter
2 1.5 V Batteries, Type "AA/Mignon/LR6"
1 3 V Battery, Type CR2032
1 Stand for the receiver
1 Screw for fixing the transmitter on to the assembly plate
5 Nameplates
1 Plastic cover for the nameplate
2 Wallplugs with screws for transmitter assembly
1 Wallplug with a screw for receiver suspension
1 Operating manual
LB4A.indb 2LB4A.indb 2 20.07.2010 10:35:41 Uhr20.07.2010 10:35:41 Uhr

- 3 -
Technical data
Power supply
Receiver: 2 x 1.5V Type "AA/Mignon/LR6"
Transmitter: 1 x 3V Type CR2032
Type of transmitter
protection: IP X4
Transmission frequency: 433 MHz
Range: 100 m (Free-space range)
Ring-tone volume: min. 73dB(A) in 1 m (on max. setting)
Safety instructions
Do not permit children to handle electrical appliances•
without supervision, as they cannot correctly assess the
possible dangers of injury.
Check the appliance and all parts for visible damages.•
If the appliance is damaged, arrange for it to be checked
by Customer Services.
NEVER open the appliance. There are no user-serviceable•
elements inside.
Risk of accidents and injury!
This appliance is not intended for use by individuals (including•
children) with restricted physical, physiological or intellectual
abilities or deficiences in experience and/or knowledge
unless they are supervised by a person responsible for their
safety or receive from this person instruction in how the appli-
ance is to be used.
LB4A.indb 3LB4A.indb 3 20.07.2010 10:35:41 Uhr20.07.2010 10:35:41 Uhr

- 4 -
Children should be supervised to ensure that they do not play•
with the appliance.
Keep batteries well away from children. Children can put bat-•
teries into their mouths and swallow them. If a battery is swal-
lowed, medical assistance must be sought IMMEDIATELY.
For the handling of batteries please observe the following:
Risk of explosion!
Do not throw batteries into a fire.•
Do not recharge the batteries.•
Never open batteries, never solder or weld batteries.•
The risk of explosions and injuries exists!
Regularly check the condition of the batteries. Leaking•
batteries can cause damage to the appliance.
If you do not intend to use the appliance for an extended•
period, remove the batteries.
Damage on the appliance
Avoid the simultaneous usage of batteries of varying•
types resp. capacities.
Do not use any aggressive chemical substances for•
cleaning.
NEVER submerse the appliance in water. Wipe it only•
with a slightly damp cloth.
LB4A.indb 4LB4A.indb 4 20.07.2010 10:35:41 Uhr20.07.2010 10:35:41 Uhr

- 5 -
Protect the receiver against moisture. Use it only in dry•
rooms, do not use it when it is raining outdoors or when
close to liquids.
Ensure that, when the receiver is in use, it cannot become•
wet or moist and that it cannot be damaged.
The appliance parts
Receiver (Fig. A)
qSignal indicator
w:Synchronisation button, Receiver
eVOL.: Button for sound volume control
r: Button for melody selection
t: Signal type switch (optical/acoustic)
ySpeaker
uStand
iBattery compartment - receiver
oLoop for suspension of the receiver
aBattery compartment cover - receiver
Transmitter (Fig. B)
sBell button
dNameplate
fIndicator for signal confirmation
gBattery compartment - Transmitter
hAssembly plate - Transmitter
LB4A.indb 5LB4A.indb 5 20.07.2010 10:35:41 Uhr20.07.2010 10:35:41 Uhr

- 6 -
Taking the appliance into use
Take the appliance out of the carton and remove all packaging
materials.
Inserting the batteries in the receiver
Open the battery compartment>ion the rear of the
appliance.
Insert 2 x 1.5V batteries of the type "AA/Mignon/LR6">
as per the insertion markings shown in the battery
compartment i.
Replace the battery compartment cover>a.
Inserting the battery in the transmitter
Remove the assembly plate>hfrom the transmitter.
Insert a 3 V battery of type CR2032 into the battery>
compartment g. The side marked with "+" must be
facing up.
Replace the assembly plate>hback onto the transmitter.
Should the performance of the appliance diminish or fall
away completely, it means the batteries are exhausted. The
used batteries should then be changed for new ones of the
same type.
LB4A.indb 6LB4A.indb 6 20.07.2010 10:35:41 Uhr20.07.2010 10:35:41 Uhr

- 7 -
Selecting the signal type
The receiver can indicate the reception of a door-ring signal
either optically, acoustically or optically and acoustically. To
select, bring the signal type switch tinto the desired position:
- only acoustic ring indications, the selected melody
sounds,
- only optical ring indications, the signal indicator blinks,
- optical and acoustic ring indications.
Adjusting the signal sound volume
To select the desired signal sound volume, press the VOL.
button erepeatedly until the desired volume level is set.
Loud Medium Quiet
Selecting the call melody
There are 36 different call melodies stored in the appliance.
Repeatedly press the button for melody selection>r.
When the desired melody sounds, stop the selection.>
The appliance will utilise the last melody it played as the
call melody.
LB4A.indb 7LB4A.indb 7 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 8 -
Synchronising the transmitter and receiver
The transmitter and receiver of this doorbell system can com-
municate with each other on a variety of different frequencies.
Consequently, up to four transmitters can be operated with
one receiver. The precondition for this is that the transmitter and
receiver within a system are working on the same frequency.
For this, you must synchronise the appliances as follows:
Press the synchronisation button on the receiver>w.
The red signal indicator qnow glows.
Now press the bell button>s on the transmitter.
If the synchronisation has been a success, the receiver notifies
you of the programmed call signal. The appliances terminate
the synchronisation mode and the signal indicator qgoes
out. Should the receiver not react as described, repeat the
synchronisation.
The transmitter shows, with a brief glowing of the indica-
tor fwhen being activated, the transmission of the signal
to the receiver.
LB4A.indb 8LB4A.indb 8 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 9 -
Installing the appliance
Select a suitable positioning for the transmitter, close to>
your outer door.
Using the assembly plate>hof the transmitter, mark the
positions required for the two boreholes (spacing approx.
68 mm) and then bore the holes for the enclosed wallplugs.
Screw the assembly plate>honto the wall.
Write the name(s) of the residents on the nameplate>d
and then place the plastic covering.
Place the transmitter on the assembly plate>hand
secure it, with the enclosed small screw, to the assembly
plate h.
You can install the receiver at a suitable location either>
suspended by its loop oor make use of the stand u.
Bear in mind that the given range refers to the free-space
range. If being utilised in a building, this range is reduced
quite distinctly.
To suspend the receiver, fix the enclosed screw, with the>
wallplug, at a suitable location on the wall and hang the
appliance from it.
LB4A.indb 9LB4A.indb 9 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 10 -
Maintenance
Important!
NEVER open any parts of the doorbell system! Arrange
for the appliance to be repaired by specialists only.
The appliance is maintenance-free. No form of maintenance,
either on or in the appliance, is intended for execution by
the user. In the event of malfunction or apparent damage,
make contact with Customer Services. If the appliance is not
to be in use for an extended period, remove the batteries.
Cleaning and Care
Important!
NEVER submerse the appliance or its components in water•
or other fluids!
Do not allow any liquids to penetrate into the appliance•
housing. If they do, there is a risk that the appliance could
be damaged.
Cleaning the appliance:
Clean the appliance only with a dry or lightly moistened>
cloth. Do not use aggressive cleaning agents!
These could damage the plastic upper surfaces.
In the event of the batteries leaking acids, put on a pair>
of protective gloves. Then clean the battery compartment
and the battery contacts with a dry cloth.
LB4A.indb 10LB4A.indb 10 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 11 -
Disposal
Do not, under any circumstances, dispose
of the appliance in your household refuse.
This appliance is subject to the provisions of
European Guidelines 2002/96/EC.
Transmitter and receiver units
Arrange for the product, or parts of it, to be disposed of•
by a professional disposal company or by your communal
waste facility.
Observe the currently applicable regulations. In case of•
doubt, please contact your waste disposal centre.
Batteries/rechargeable batteries
Used batteries/rechargeable batteries may not be dis-•
posed of in household waste.
Batteries can contain poisons which are damaging to•
the environment. Therefore, dispose of the batteries/
rechargeable batteries in accordance with statutory
regulations.
Every consumer is legally obligated to surrender batteries/•
rechargeable batteries to a community collection centre
in their district or to a dealer. The purpose of this obligation
is to ensure that batteries are disposed of in a non-polluting
manner.
Dispose of all packaging materials in an
environmentally friendly manner.
LB4A.indb 11LB4A.indb 11 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 12 -
CE Conformity
This appliance conforms with the fundamental requirements and
other relevant regulations of the R&TTE Directive 1999/5/EC.
A complete copy of the original conformity declaration is
available from the importer.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
Warranty and Service
The warranty for this appliance is for 3 years from the date
of purchase. The appliance has been manufactured with
care and meticulously examined before delivery. Please
retain your receipt as proof of purchase. In the event of a
warranty claim, please make contact by telephone with our
Service Department. Only in this way can a post-free des-
patch for your goods be assured. The warranty covers only
claims for material and manufacturing defects, but not for
transport damage, for wearing parts or for damage to frag-
ile components, e.g. buttons or batteries. This product is for
private use only and is not intended for commercial use.
LB4A.indb 12LB4A.indb 12 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 13 -
The warranty is void in the case of abusive and improper
handling, use of force and internal tampering not carried
out by our authorized service branch. Your statutory rights
are not restricted in any way by this warranty. The warranty
period will not be extended by repairs made under war-
ranty. This applies also to replaced and repaired parts. Any
damage and defects extant on purchase must be reported
immediately after unpacking the appliance, at the latest,
two days after the purchase date. Repairs made after the
expiration of the warranty period are subject to payment.
DES UK Ltd
Tel.: [phone] (£ 0.10 / minute)
e-mail: suppor[email protected]
Kompernass Service Ireland
Tel.: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: suppor[email protected]
LB4A.indb 13LB4A.indb 13 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 14 -
LB4A.indb 14LB4A.indb 14 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 15 -
Przed pierwszym użyciem zapoznaj sięz instrukcjąobsługi i zachowaj ją
w celu późniejszego wykorzystania. Przekazując urządzenie innej osobie
należy jej równieżudostępnićniniejsząinstrukcjęobsługi.
SPIS TREŚCI STRONA
Zastosowanie zgodnie z przeznaczeniem 16
Zakres dostawy 16
Dane techniczne 17
Wskazówki bezpieczeństwa 17
Części urządzenia 19
Uruchamianie urządzenia 20
Konserwacja 24
Czyszczenie i konserwacja 24
Utylizacja 25
Deklaracja zgodności CE 26
Importer 26
Gwarancja i serwis 26
LB4A.indb 15LB4A.indb 15 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 16 -
Zastosowanie zgodnie z przeznaczeniem
Produkt służy jako bezprzewodowy dzwonek drzwiowy do
sygnalizowania lokatorom przybycia gości. Urządzenie jest
przewidziane wyłącznie do użytku prywatnego domowego,
nie zaśdo komercyjnego ani przemysłowego.
Za szkody, powstałe w wyniku zastosowania niezgodnego
z przeznaczeniem, producent nie ponosi żadnej odpowie-
dzialności!
Zakres dostawy
1 Odbiornik
1 Nadajnik
2 Baterie 1,5 V, typ „AA/Mignon/LR6”
1 Bateria 3 V, typ CR2032
1 Podstawka na odbiornik
1 Śruby do przymocowania nadajnika do płytki montażowej
5 Tabliczki opisowe
1 Plastikowa osłona na tabliczkęz nazwiskiem
2 Kołki ze śrubami do montażu nadajnika
1 Kołek ze śrubądo zawieszenia odbiornika
1 Instrukcja obsługi
LB4A.indb 16LB4A.indb 16 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr

- 17 -
Dane techniczne
Zasilanie
Odbiornik: 2 x 1,5 V typ „AA/Mignon/LR6”
Nadajnik: 1 x 3 V typ CR2032
Klasa ochrony
nadajnika: IP X4
Częst. nadajnika: 433 MHz
Zasięg: 100 m (zasięg na odkrytym polu)
Głośność dzwonka: min. 73 dB(A) na 1 m
(przy ustawieniu maks.)
Wskazówki bezpieczeństwa
Nie pozwól aby dzieci mogły same korzystaćz urzą-•
dzeńelektrycznych, ponieważnie potrafiąone jeszcze
samodzielnie oceniaćryzyka odniesienia obrażeńciała.
Sprawdzaćurządzenie oraz wszelkie jego elementy•
pod kątem widocznych uszkodzeń. W przypadku stwier-
dzenia uszkodzenia produktu, oddaj go do sprawdzenia
w punkcie serwisowym.
Nigdy nie otwieraj urządzenia. We wnętrzu nie ma•
żadnych elementów obsługowych.
Niebezpieczeństwo wypadku i odniesienia
obrażeń!
Urządzenie nie jest przeznaczone do użytkowania przez•
osoby (w tym dzieci) z ograniczonąsprawnościąfizyczną,
ruchowąbądźumysłowąlub nieposiadające doświad-
czenia i / lub wiedzy, chyba że będąone przebywały pod
LB4A.indb 17LB4A.indb 17 20.07.2010 10:35:42 Uhr20.07.2010 10:35:42 Uhr
