Silvercrest SEM 120 A1 User manual

95 mm
100 mm
IAN 305932
ELECTRIC CARVING KNIFE
SEM 120 A1
ELECTRIC CARVING KNIFE
Operation and safety notes

95 mm
210 mm
GB/IE/NI Operation and safety notes Page 5

100 mm95 mm
A1
5 10
3 2 4
679 8
2

100 mm
B
C
D
E

5GB/IE/NI
Warnings and symbols used..................................... Page 6
Introduction.............................................................................. Page 7
Intended use ....................................................................................... Page 7
Scope of delivery ............................................................................... Page 7
Description of parts............................................................................ Page 7
Technical data .................................................................................... Page 7
Safety advice.......................................................................... Page 8
Before first use ...................................................................... Page 11
Operation .................................................................................. Page 11
Select the right blade type ................................................................ Page 12
Attach/detach blades........................................................................ Page 12
Insert/remove the blades................................................................... Page 12
Cutting................................................................................................. Page 13
After use.............................................................................................. Page 13
Cleaning and maintenance ......................................... Page 13
Storage........................................................................................ Page 13
Disposal....................................................................................... Page 14
Warranty.................................................................................... Page 14

6 GB/IE/NI
Warnings and symbols used
The following warnings are used in this user manual:
DANGER! This symbol with the signal word “Danger”
indicates a hazard with a high level of risk which, if not
avoided, will result in serious injury or death.
WARNING! This symbol with the signal word “Warning”
indicates a hazard with a medium level of risk which, if not
avoided, could result in serious injury or death.
CAUTION! This symbol in combination with “Caution”
marks a low-risk hazard that if not prevented could result in
minor or moderate injury.
Voltage (AC)
Hertz (supply frequency)
Watts
NOTE: This symbol with the signal word “Note” provides
additional useful information.
Use the product in dry indoor spaces only.
Symbol for a protection class II product.
DANGER! Product contains sharp elements.

7GB/IE/NI
ELECTRIC CARVING KNIFE
Introduction
We congratulate you on the purchase of your new product. You have
chosen a high quality product. The instructions for use are part of the
product. They contain important information concerning safety, use and
disposal. Before using the product, please familiarise yourself with all of
the safety information and instructions for use. Only use the product as
described and for the specified applications. If you pass the product on to
anyone else, please ensure that you also pass on all the documentation
with it.
Intended use
This product is intended for cutting food. Do not use it for any other
purpose. The product is designed for household use; it is not suitable for
commercial use. The manufacturer accepts no liability for damages caused
by improper use.
Scope of delivery
After unpacking the product, verify that the delivery is complete and that
all parts are in proper condition. Remove all packaging materials before
use.
1 x Electric carving knife
2 x 2 blades in protective foils
1 x Instruction manual
Description of parts
1(on/off)
2Blade release
3Blade holder
4/ (Switch-on lock)
5Power cord with power plug
6Engaging bolt
7Blade handle
8Blades
9Rivet and stud
10
Protective sleeves for blade storage
Technical data
Input 220–240 V~, 50/60 Hz
Power consumption 120 W
Protection class II

8 GB/IE/NI
Safety instructions
BEFORE USE, BECOME ACQUAINTED WITH
ALL THE PRODUCT’S SAFETY AND OPERATING
INSTRUCTIONS! IF YOU GIVE THE PRODUCT
TO A THIRD PARTY, ALSO INCLUDE ALL
DOCUMENTATION!
The warranty becomes void in the event of
damages due to a failure to comply with the user
manual! No liability is accepted for consequential
damage! No liability is accepted for personal or
property damage due to improper use or failure to
comply with the safety instructions.
m WARNING! RISK OF DEATH AND
ACCIDENT FOR INFANTS AND
CHILDREN! Do not allow children to play
with the packaging materials unsupervised. The
packaging materials pose a suffocation hazard.
Children often underestimate the associated
risks. Keep packaging materials out of the reach
of children at all times.
m DANGER! Risk of electric shock! Never
attempt to repair the product yourself. In case
of malfunction, repairs are to be conducted by
qualified personnel only.
m WARNING! Risk of electric shock! Do
not immerse the product’s electrical components
in water or other liquids. Never hold the product
under running water.
m CAUTION! Risk of electric shock! Never
use a damaged product.

9GB/IE/NI
Disconnect the product from the power supply
and contact your retailer if the product is
damaged.
m WARNING! Risk of injury! Turn off the
product and disconnect it from the power supply
before cleaning and when the product is not in
use.
m WARNING! Improper use may result in
personal injury. Use the product only as
described in the user manual. Never attempt to
alter the product in any way.
Safety instructions for electric knives
This product shall not be used by children. Keep
the product and its cord out of reach of children.
This product can be used by persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and if they understand the hazards involved.
Children shall not play with the product.
The continuous operating time may not exceed
2 minutes. Let the product rest between 2 cycles
for at least 1 minute! After 5 consecutive
operating cycles, the product must be allowed
to cool to room temperature before continued
use.
WARNING! Improper use can lead to injuries!

10 GB/IE/NI
Handle sharp knives with care!
Do not cut on sensitive or hard surfaces to
prevent damages. Always use a suitable cutting
surface (e.g. cutting board).
Always disconnect the product from the
power supply when it is not supervised, before
assembly, disassembly and cleaning.
Switch off the product and disconnect from
supply before changing accessories or
approaching parts that move in use.
Clean all parts that come into contact with
food/cooking oil with a neutral detergent. Rinse
all parts thoroughly with clear water and dry
them.
Do not make any modifications to the product.
Only use attachments and accessory parts
recommended by the manufacturer.
Electrical safety
Before connecting the product to the power
supply, make sure that the nominal voltage
on the rating plate complies with your mains
network.
Do not use the product if the plug or power
cord are damaged, the product does not work
properly or is otherwise damaged.
Protect the power cord from damage.

11GB/IE/NI
Do not let the power cord hang over sharp
corners and do not bend it. Keep the power
cord away from hot surfaces and make sure that
no one can trip over it.
If the power cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
Do not insert any fingers or objects into the
interior of the product and do not block its air
vents.
Protect the product from heat. Do not place the
product directly next to heat sources such as
stoves or heaters.
Before first use
Remove the packing materials. Make sure that all the parts are present
(Fig. A).
Clean the product and the accessories (see “Cleaning and care”).
Operation
mDANGER! Always follow the safety instructions
while operating the product:
Only use identical blades as a pair.
Never insert a single blade.
Always heed the correct orientation of the
blades
8
(up/down).
Press the blades
8
by the blade handles
7
firmly into the blade holder
3
. Both blades
8
must noticeably click into place.

12 GB/IE/NI
Keep your hands away from the blades
8
. They
are very sharp and may cause serious injury.
Always first unplug the product before changing
the blades
8
.
Select the right blade type
There are 2 blade types available:
Blade type Fig. Suitable for
Serrated knife B Firm foods
(e.g. meat, roast, bread)
Multi-function blade C Soft foods
(e.g. fruit, vegetables, cake, pie)
Attach/detach blades
The blades
8
attach to one another at the front via a stud
9
and
rivet
9
.
Attach the blades
Guide the rivet
9
of the left blade into the stud
9
of the right blade
(Fig. D).
Place the blades
8
parallel to one another (Fig. E).
Detach the blades
Slide the right blade forward.
Remove the rivet
9
from the stud
9
.
Insert/remove the blades
Insert the blades
Unplug the plug
5
from the power outlet.
Hold the attached blades
8
by the blade handles
7
.
Insert both blades
8
into the blade holder
3
on the product.
Press the blades
8
by the blade handles
7
firmly into the blade
holder
3
.
Both blades
8
must noticeably click into place. Try to pull out the
blades
8
by the handles
7
. If you cannot remove the blades, they
are firmly inserted.
Remove the blades
Unplug the plug
5
from the power outlet.
Press the blade
8
releases
2
together.
Pull the blades
8
by the blade handles
7
from the blade holder
3
.

13GB/IE/NI
Cutting
Plug the power plug
5
into an appropriate socket.
Hold the product by the housing. Your thumb is on the switch-on
lock
4
. Your index finger and your middle finger are on the button
1
.
Hold the blades
8
on the food.
Slide the switch-on lock
4
with your thumb to .
Turn on the product: Press the button
1
.
Turn off the product: Release the button
1
.
After use
Slide the switch-on lock
4
with your thumb to .
Unplug the plug
5
from the power outlet.
Food residue may contain or form acids. These may damage the
blades
8
. Always clean the product after use (see “Cleaning and
maintenance”).
Store the product at a location out of the reach of children.
Cleaning and maintenance
mDANGER! Risk of electric shock and injury! Always
disconnect the power plug
5
from the outlet before cleaning the
product.
mWARNING! Risk of injury! The blades
8
are very sharp and
may cause serious injury.
NOTE: The product and its accessories are not dishwasher-safe. Do
NOT use the dishwasher.
Do not use any abrasive, aggressive cleaners or hard brushes to clean
the product.
Part Cleaning
Housing Wipe down the product with a slightly damp cloth.
Do not let any water or other liquids enter the
product interior.
Blades
8
Remove the blades
8
from the blade holder
3
.
Detach the blades
8
from each other.
Clean the blades
8
like regular knives.
Let all parts dry completely after cleaning.
Storage
Store the blades
8
in their protective sleeves
10
.
Store the product in the original packaging when it is not in use.
Store the product at a dry location out of the reach of children.
Make sure the power cord
5
is rolled up evenly and without kinks.

14 GB/IE/NI
Disposal
The packaging is made entirely of recyclable materials, which you may
dispose of at local recycling facilities.
Observe the marking of the packaging materials for waste
separation, which are marked with abbreviations (a) and
numbers (b) with following meaning: 1–7: plastics / 20–22:
paper and fibreboard / 80–98: composite materials.
The product and packaging materials are recyclable, dispose of
it separately for better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal authority for more details of
how to dispose of your worn-out product.
To help protect the environment, please dispose of the product
properly when it has reached the end of its useful life and not in
the household waste. Information on collection points and their
opening hours can be obtained from your local authority.
Warranty
The product has been manufactured to strict quality guidelines and
meticulously examined before delivery. In the event of product defects you
have legal rights against the retailer of this product. Your legal rights are
not limited in any way by our warranty detailed below.
The warranty for this product is 3 years from the date of purchase. Should
this product show any fault in materials or manufacture within 3 years from
the date of purchase, we will repair or replace it – at our choice – free of
charge to you.
The warranty period begins on the date of purchase. Please keep the
original sales receipt in a safe location. This document is required as your
proof of purchase. This warranty becomes void if the product has been
damaged, or used or maintained improperly.
The warranty applies to defects in material or manufacture. This warranty
does not cover product parts subject to normal wear, thus possibly
considered consumables (e.g. batteries) or for damage to fragile parts,
e.g. switches, rechargeable batteries or glass parts.

100 mm 100 mm
IAN 305932
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
GERMANY
Model-Nr.: HG04158-BS
Version: 07/2018
Page size: 100 mm x 210 mm done by Impala Services Limited
