Silvercrest SPB 2.6 A1 Instruction sheet

V1.11
English.................................................................. 2
Hrvatski ............................................................. 17
Română ............................................................. 31
Ελληνικά ............................................................ 45
Deutsch .............................................................. 61

SilverCrest SPB 2.6 A1
2 - English
Table of Contents
Introduction.......................................................... 3
Intended use ........................................................ 3
Package contents ................................................. 4
Technical specifications......................................... 4
Safety instructions ................................................ 5
Overview of the operating controls...................... 9
Before you start ................................................. 10
Getting started ................................................... 10
Charging the power bank .....................................................10
Checking the state of charge ................................................11
Charging external devices.....................................................12
Troubleshooting ................................................. 13
Environmental regulations and disposal
information ........................................................ 13
Conformity notes................................................ 14
Warranty and Service Information..................... 15


SilverCrest SPB 2.6 A1
English - 3
Introduction
Thank you for choosing a SilverCrest product. The SilverCrest
Power Bank SPB 2.6 A1 allows you to recharge the empty
battery of e.g. a mobile phone while on the move, even if there
is no power socket available.
Intended use
The SilverCrest Power Bank SPB 2.6 A1 is an information
technology product. It allows you to recharge mobile devices
that have a USB charging socket. The SilverCrest Power Bank
has not been designed for corporate or commercial
applications. Use the power bank for private use only. Any use
other than that mentioned above does not correspond to the
intended use. The power bank fulfils all relevant norms and
standards concerning CE conformity. Any modifications to the
power bank other than recommended changes by the
manufacturer may result in these standards no longer being
met. The manufacturer shall not be liable for any damage or
malfunctions resulting therefrom. Observe the regulations and
laws in the country of use.

SilverCrest SPB 2.6 A1
4 - English
Package contents
A Power Bank SPB 2.6 A1
B USB charger cable
C These operating instructions (line-art illustration)
Technical specifications
Built-in battery pack 3,6V / 2600mAh
Input 5 V , 0.5 A
Output 5 V , 1 A
Dimensions (W x H x D) approx. 2.3 x 2.3 x 10.3 cm
Weight approx. 75 g
Operating temperature 5 °C to 45 °C
Operating humidity max. 85 % rel. humidity
(non-condensing)
Permissible storage
conditions
-5 °C to +50 °C,
max. 85 % rel. humidity
(non-condensing)
The technical specifications and design can be changed
without prior notice.

SilverCrest SPB 2.6 A1
English - 5
Safety instructions
Before you use the power bank for the first time, please
carefully read the following instructions even if you are familiar
with handling electronic devices. Keep these operating
instructions in a safe place for future reference. If you sell the
power bank or pass it on, it is essential that you also hand over
this manual, as it is part of the product.
CAUTION! This icon alerts you about a potential
dangerous situation. Ignoring it can lead to severe
injury or even death.
WARNING! This symbol denotes important
information for the safe operation of the product
and user safety.
This symbol denotes further information on the
topic.
Copyright
All the contents of this user manual are protected by copyright
and provided to the reader for information only. Copying data
and information without the prior explicit written consent of the
author is strictly forbidden. This also applies to any commercial
use of the contents and information. All texts and diagrams are
up-to-date as of the date of printing.

SilverCrest SPB 2.6 A1
6 - English
Operating environment
The device is not designed for use in environments with high
humidity (e.g. bathrooms) or excessive levels of dust.
Operating temperature and operating humidity: +5 to +45 °C,
max. 85 % relative humidity. Please note that when using the
product in a car, especially behind the windscreen, the
temperature can significantly increase above +45 °C.
Always make sure that
the device is not exposed to direct heat sources (e.g.
radiators)
the device is not exposed to strong artificial light
contact with water spray and drops and aggressive fluids is
avoided and the device is never operated near water, the
device is never submerged (do not place any items
containing liquids, such as drinks, vases, etc. on or near the
device).
the device is never placed near magnetic fields (e.g.
speakers)
no naked flames (e.g. burning candles) are placed on or
near the device
no foreign bodies can penetrate into the device
the device is not subjected to any major temperature
fluctuations as this can cause condensation and short-
circuiting. If the device has been exposed to strong

SilverCrest SPB 2.6 A1
English - 7
temperature fluctuations, wait for it to reach the ambient
temperature before switching it on (about 2 hours).
the device should not be subjected to excessive shocks and
vibrations
the device or the optional USB power adapter is not used
during thunderstorms and unplug the optional USB power
adapter from the mains
when using a USB power adapter the power socket used
must be easily accessible at all times and cables are laid so
they do not present a trip hazard
the device is not covered. Heat can accumulate when the
device is covered, therefore there is a risk of fire.
Failure to heed the warnings above may result in damage to
the device or injury.
Caution – danger of explosion
Never throw the device into a fire and do not deform the
device or the built-in battery, as this could cause the battery to
explode.
Please note the usage restrictions and regulations relating to
battery-powered devices in dangerous places, such as petrol
stations, aircraft, hospitals, etc.

SilverCrest SPB 2.6 A1
8 - English
Children and persons with
disabilities
Electrical devices are not suitable for children. People with
disabilities should only use electrical devices in appropriate
circumstances. Do not allow children or persons with disabilities
to use electrical devices unsupervised. They may not
comprehend the potential risks. Batteries and small parts
represent potential choking hazards.
Keep the packaging away from children and
persons with disabilities.
There is a risk of suffocation.
Cables
Always hold cables by the plug and never pull on the cable
itself. Never place heavy objects or furniture on the cables and
take care that the cord does not become trapped, especially at
the plug and sockets. Never tie knots in a cable and do not tie
them to other cables. All cables must be laid so that nobody
can trip over them or be obstructed by them.
Maintenance / cleaning
Repairs are required if this device has been damaged in any
way, for example if the device housing is damaged, if liquids or

SilverCrest SPB 2.6 A1
English - 9
objects have penetrated the device or if the product has been
exposed to rain or moisture. Repairs are also necessary if the
product is not working properly or has been dropped. If you
notice any smoke, unusual noises or strange smells, unplug all
cables immediately and disconnect the optional USB power
adapter from the power supply. If this occurs, do not continue
to use the device and have it checked out by an expert. All
repairs must be carried out by qualified service personnel.
Never open the housing of the device. Only use a clean, dry
cloth for cleaning. Never use aggressive liquids. Do not attempt
to open the housing of the device, this will void your warranty.
Overview of the operating controls
An illustration of the operating controls and their corresponding
numbers can be found on the inside page of the fold-out cover
of this user manual.
1 State of charge /
START pushbutton
2 LED
3 LED
4 LED
5 LED

SilverCrest SPB 2.6 A1
10 - English
6 USB socket (output): Here
you connect the device to
be charged.
7 Micro USB port: Charging
socket (input)
Before you start
Remove the power bank and its accessories from the package
and remove the plastic films.
Getting started
The power bank must never be charged and be
used to recharge an external device at the same
time.
Charging the power bank
To charge the built-in battery of your power bank, use the
supplied USB charging cable (B) to connect the power bank to
a free USB port of your powered-on computer. To do so, insert
the Micro USB plug of the USB charging cable (B) into the
power bank Micro USB socket (7) and then connect the USB
plug into a free USB port of your computer. During the

SilverCrest SPB 2.6 A1
English - 11
charging process, the LEDs (2, 3, 4, 5) inform you about the
current state of charge of the power bank.
LED indicator State of charge
LED 2 flashes, 0 – 25 %
LED 2 lit, LED 5 flashes 25 – 50 %
LEDs 2 and 5 lit, LED 4 flashes 50 – 75 %
LEDs 2, 5 and 4 lit, LED 3 flashes 75 – 100 %
LEDs 2, 5, 4, 3 lit 100 %
Alternatively, you can use an external USB power
adapter (not included) to charge the battery of your
power bank.
Checking the state of charge
You can also check the state of charge of your power bank
when it is not being charged or discharged. To do this, press
the State of charge / START pushbutton (1) briefly. The LEDs
(2, 3, 4, 5) will indicate the state of charge of the power bank
for approx. 5 seconds.
LED indicator State of charge
LEDs 2, 5, 4, 3 lit 75 – 100 %
LEDs 2, 5, 4 lit 50 – 75 %
LEDs 2, 5 lit 25 – 50 %
LED 2 lit 0 – 25 %
All LEDs off 0 %

SilverCrest SPB 2.6 A1
12 - English
Charging external devices
To charge an external device with your power bank, use the
supplied USB charging cable (B) to connect the power bank
to the external device. To do so, insert the Micro USB plug of
the USB charging cable (B) into the Micro USB socket of
your external device and then connect the USB plug into the
USB port (6) of your power bank. If the charging process
doesn’t start automatically, press the State of charge /
START pushbutton (1) briefly to start the charging process.
Alternatively you can also use the charging cable of the
external device manufacturer (USB connection).
During the charging process, the LEDs (2, 3, 4, 5) inform you
about the current state of charge of the power bank.
LED indicator State of charge
LEDs 2, 5, 4, 3 lit 75 – 100 %
LEDs 2, 5, 4 lit 50 – 75 %
LEDs 2, 5 lit 25 – 50 %
LED 2 lit 0 – 25 %
All LEDs off 0 %
You can stop the charging process at any time by
unplugging the USB charging cable (B) or by keeping
pressed (for approx. 3 seconds) the State of charge / START
pushbutton (1).

SilverCrest SPB 2.6 A1
English - 13
Troubleshooting
The power bank is not charging
Faulty connection, double-check the connection.
Some computers do not supply USB power while they are
turned off. If the battery of your power bank does not
charge, make sure your computer is powered on.
A connected device is not charging.
The battery of your power bank is empty; recharge it.
No connection to the external device, double-check the
connection.
Press the State of charge / START pushbutton (1) briefly to
start the charging process.
Environmental regulations and disposal
information
Devices marked with this symbol are subject to
the European Directive 2012/19/EU. All
electrical and electronic devices must be
disposed of separately from household waste
at official disposal centres. Proper disposal of
old devices prevents damage to the
environment or your health. For further information about

SilverCrest SPB 2.6 A1
14 - English
proper disposal, contact your local council, recycling centre or
the shop where you bought the device.
The built-in rechargeable battery cannot be
removed for disposal.
Dispose of all packaging in an environmentally friendly
manner. Cardboard packaging can be taken to paper
recycling centres or public collection points for recycling. Any
film or plastic contained in the packaging should be taken to
your public collection points for disposal.
Conformity notes
This device complies with the basic and other
relevant requirements of EMC Directive
2004/108/EC and the RoHs Directive
2011/65/EU. The Declaration of Conformity can also be
found at the end of this Manual.

SilverCrest SPB 2.6 A1
English - 15
Warranty and Service Information
Warranty of TARGA GmbH
This device is sold with three years warranty from the date of
purchase. Please keep the original receipt in a safe place as
proof of purchase. Before using your product for the first time,
please read the enclosed documentation. Should any problems
arise which cannot be solved in this way, please call our
hotline. Please have the article number and, if available, the
serial number to hand for all enquiries. If it is not possible to
solve the problem on the phone, our hotline support staff will
initiate further servicing procedures depending on the fault.
Within the warranty period the product will be repaired or
replaced free of charge as we deem appropriate. No new
warranty period commences if the product is repaired or
replaced. Consumables such as batteries, rechargeable
batteries and lamps are not covered by the warranty.
Your statutory rights towards the seller are not affected or
restricted by this warranty.

SilverCrest SPB 2.6 A1
16 - English
Service
Phone: 0207 – 36 50 744
E-Mail: [email protected]
Phone: 01 – 242 15 83
E-Mail: [email protected]
Phone: 800 – 62 175
E-Mail: [email protected]
Phone: 800 – 92 496
E-Mail: [email protected]
IAN: 101433
Manufacturer
TARGA GmbH
Coesterweg 45
59494 SOEST
GERMANY

SilverCrest SPB 2.6 A1
Hrvatski - 17
Popis sadržaja
Uvod.................................................................. 18
Namjenska uporaba.......................................... 18
Isporučena oprema............................................ 19
Tehničke karakteristike ..................................... 19
Sigurnosne napomene ....................................... 20
Pregled upravljačkih elemenata ........................ 24
Prije početka...................................................... 24
Početak rada ..................................................... 25
Punjenje vanjske baterije .......................................................25
Provjera stanja punjenja ........................................................26
Punjenje vanjskih uređaja......................................................26
Otklanjanje neispravnosti.................................. 27
Zaštita okoliša i informacije o zbrinjavanju ....... 28
Napomene o sukladnosti ................................... 28
Jamstvene i servisne informacije........................ 29


SilverCrest SPB 2.6 A1
18 - Hrvatski
Uvod
Hvala vam na odabiru proizvoda tvrtke SilverCrest. Vanjska
baterija SilverCrest SPB 2.6 A1 omogućava punjenje prazne
baterije, na primjer, mobitela dok ste na putu ili ako električna
utičnica nije na raspolaganju.
Namjenska uporaba
SilverCrest Power Bank SPB 2.6 A1 proizvod je informatičke
tehnologije. Uređaj omogućava punjenje mobilnih uređaja koji
imaju USB utičnicu za punjenje. Vanjska baterija SilverCrest
nije namijenjena uporabi u poslovne ili komercijalne svrhe.
Vanjska baterija namijenjena je samo uporabi u privatne svrhe.
Svaka uporaba koja nije gore navedena smatra se
nenamjenskom uporabom. Vanjska baterija udovoljava svim
bitnim normama i standardima u vezi s CE sukladnosti. Izmjene
vanjske baterije koje ne preporučuje proizvođač mogu
rezultirati kršenje navedenih normi. Proizvođač neće
odgovarati za štete ili neispravnosti koje iz toga proiziđu.
Poštujte propise i zakone u državi uporabe proizvoda.
