Silvercrest SLS 2200 C2 User manual

SOLAR CHARGER SLS 2200 C2
SOLAR CHARGER
Operating instructions
SOLARLADEGERÄT
Bedienungsanleitung
ŁADOWARKA SOLARNA
Instrukcja obsługi
IAN 273541

GB/IE Operating instructions Page 1
PL Instrukcja obsługi Strona 21
DE/AT/CH Bedienungsanleitung Seite 41
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie
proszę zapoznać się z wszystkimi funkcjami urządzenia.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

SOLAR CHARGER SLS 2200 C2
SOLAR CHARGER
Operating instructions
SOLARLADEGERÄT
Bedienungsanleitung
ŁADOWARKA SOLARNA
Instrukcja obsługi
IAN 273541

GB│IE │ 1 ■
SLS 2200 C2
Contents
Introduction.................................2
Information concerning these operating instructions .........2
Copyright ..........................................2
Notes on trademarks .................................2
Intended use........................................3
Warnings used ......................................3
Safety .....................................4
Basic safety guidelines ................................4
Description of components ....................7
Operation ..................................7
Unpacking .........................................7
Check the package contents ...........................8
Disposal of packaging materials ........................8
Attaching the suction cups .............................9
Charging with the solar panel .........................11
Charging with the USB cable..........................12
Handling and operation......................13
Switch the device on/off .............................13
Display charge level.................................13
Compatible devices .................................14
Charging external devices ............................14
Troubleshooting ............................15
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Storage when not in use .....................16
Disposal...................................17
Appendix..................................18
Technical data .....................................18
Notes on the EU Declaration of Conformity...............19
Warranty.........................................19
Service ...........................................20
Importer..........................................20

■ 2 │ GB│IE SLS 2200 C2
Introduction
Information concerning these operating
instructions
Congratulations on the purchase of your new device.
You have selected a high-quality product. The operating instructions
are part of this product. They contain important information about
safety, usage and disposal. Before using the product, familiarise
yourself with all operating and safety instructions. Use the product
only as described and for the specified areas of application.
Keep these operating instructions as a reference and store them
near the product. Please also pass on these operating instructions
to any future owner.
Copyright
This documentation is protected by copyright.
Any copying or reproduction, including in the form of extracts, or
any reproduction of images (even in a modified state), is permitted
only with the written authorisation of the manufacturer.
Notes on trademarks
USB®is a registered trademark of USB Implementers Forum, Inc.
All other names and products may be trademarks or registered
trademarks of their respective owners.

GB│IE │ 3 ■
SLS 2200 C2
Intended use
This information technology device is designed solely for the charg-
ing of batteries in mobile phones, MP3 players, digital cameras
or other battery-powered devices. To do this, the device converts
sunlight into electrical energy and stores it in its internal battery. The
device is not intended for any other purpose, nor for use beyond
the scope described. The device is not intended for use in com-
mercial or industrial environments. The manufacturer accepts no
responsibility for damage caused by failure to observe these instruc-
tions, improper use or repairs, unauthorised modifications or the use
of unapproved replacement parts. The risk shall be borne solely by
the user.
Warnings used
The following warning notice types are used in these operating
instructions:
DANGER
A warning notice at this hazard level indicates a
potentially hazardous situation.
Failure to avoid this hazardous situation could result in severe
injuries or even death.
► Follow the instructions in this warning notice to avoid the risk
of serious injuries or death.

■ 4 │ GB│IE SLS 2200 C2
CAUTION
A warning notice at this hazard level indicates a
potential for property damage.
Failure to avoid this situation could result in property damage.
► Follow the instructions in this warning notice to prevent
property damage.
NOTE
► A note provides additional information that will assist you in
using the device.
Safety
This section contains important safety instructions for using the
product. This product complies with statutory safety regulations.
Improper use may result in personal injury and property damage.
Basic safety guidelines
To ensure safe operation of the product, follow the safety guide-
lines set out below:
■ This device may be used by children aged 8 years and above
and by persons with limited physical, sensory or mental capabil-
ities, or lack of experience and knowledge, provided that they
are under supervision or have been told how to use the device
safely and are aware of the potential risks. Children must not
use the device as a plaything. Cleaning and user maintenance
tasks may not be carried out by children unless they are super-
vised.

GB│IE │ 5 ■
SLS 2200 C2
■ DANGER! Do not allow children to play with the packaging
material! Keep all packaging materials away from children.
Risk of suffocation!
■ Check the device for visible external damage before use.
Do not operate a device that has been damaged or dropped.
■ Do not expose the device to water spray or dripping water,
and do not place liquid-filled objects such as vases or open
drink containers on or near the device.
■ DANGER! Be sure to provide sufficient air circulation to
avoid a heat build-up. Never cover the device! Risk of fire!
■ Never operate the device in the vicinity of naked flames
(e.g. candles), and do not place burning candles on or next
to the device. This will help to prevent fires.
■ Do not operate the device near heat sources such as radiators
or other heat-generating devices.
■ Never expose the device to extreme heat. This particularly
applies to storage in a car. Extreme temperatures can occur in
car interiors and glove compartments during long periods of
immobilisation. Remove electrical and electronic devices from
the vehicle.
■ DANGER! Never open the housing of the device.
There are no user-serviceable or replaceable components
inside the device.
■ Do not make any unauthorised modifications or alterations to
the device.
■ All repairs must be carried out by authorised specialist com-
panies or by the Customer Service department. Improper repairs
may put the user at risk. It will also invalidate any warranty
claims.

■ 6 │ GB│IE SLS 2200 C2
■ Repairs to the device during the warranty period may only be
carried out by a customer service department authorised by
the manufacturer. Otherwise, no warranty claims will be held
for any subsequent damages.
■ Switch the device off immediately and disconnect any con-
nected charging cables from the device if you smell fumes or
notice any smoke. Have the device checked by a qualified
specialist before using it again.
■ If you are using a USB power supply, the mains socket used
must always be easily accessible so that the USB power supply
can be quickly disconnected from the socket in a hazardous
situation. You should also observe the operating instructions
for the USB power supply.
■ DANGER! Mishandling the batteries can cause fires, explo-
sions, leakages or other hazards! Do not throw the device into
a fire, since the integrated battery may explode.
■ Comply with all conditions for and prohibitions on use for
battery-powered devices in locations with specific hazard risks,
such as petrol stations, aeroplanes, hospitals, etc.

GB│IE │ 7 ■
SLS 2200 C2
Description of components
(See fold-out page for illustrations)
Solar panel
Solar LED
LED (5V USB active output)
ON/OFF button
Charge level LEDs
USB port (output: 5 V , 1000 mA)
Micro-USB port (input: 5 V , 500 mA)
Brackets for suction cups
Suction cups
USB cable (USB to micro-USB)
Operating instructions
Operation
Unpacking
♦ Remove all parts and the operating instructions from the
packaging.
♦ Remove all packaging material.

■ 8 │ GB│IE SLS 2200 C2
Check the package contents
(See fold-out page for illustrations)
The product includes the following components:
▯ Solar charger SLS 2200 C2
▯ USB cable
▯ 2 x brackets for suction cups
▯ 4 x suction cups
▯ These operating instructions
NOTE
► Check the package for completeness and for signs of visible
damage.
► If the delivery is incomplete or damage has occurred as a
result of defective packaging or during transport, contact
the Service hotline (see section Service).
Disposal of packaging materials
The packaging protects the device from damage during transport.
The packaging materials have been selected for their environmental
friendliness and ease of disposal, and are therefore recyclable.
Returning the packaging into the material cycle con-
serves raw materials and reduces the amount of waste
generated. Dispose of packaging materials that are no
longer needed in accordance with applicable local
regulations.

GB│IE │ 9 ■
SLS 2200 C2
Attaching the suction cups
NOTE
► To make sure that the suction cups hold firmly, the surface
must be completely free of dust, oil and grease.
Variant A
Variant A is suitable for attaching the device to a flat, level surface.
♦ Attach all four suction cups to the underside of the device,
as shown in “Figure A”.
♦ Push the suction cups into the large holes.
♦ Now fasten the suction cups by sliding them into the narrow
openings.
Figure A
♦ You can now attach the device on a flat, level using the suction
cups .

■ 10 │ GB│IE SLS 2200 C2
Variant B
Variant B is suitable for attaching the device to a pane of glass.
♦ Attach the four suction cups to the two brackets ,as
shown in “Figure B”.
♦ Push the suction cups into the large holes.
♦ Now fasten the suction cups by sliding them into the narrow
openings.
♦ Now mount the brackets on the underside of the device by
pushing the retaining lugs into the corresponding slots on the
rear of the device and locking them in place.
Figure B
♦ You can now attach the device to a pane of glass using the
suction cups .

GB│IE │ 11 ■
SLS 2200 C2
Charging with the solar panel
CAUTION
► Ensure that the ambient temperature does not exceed 45°C.
This is particularly important when using the device inside a
motor vehicle.
You can charge the battery of the device with the solar panel .
Ensure that the solar panel is receiving sufficient sunlight.
As soon as there is sufficient sunlight, the solar LED lights up
orange to show that the battery is being charged. If the solar
LED does not light up, there is not enough sunlight available.
In this case, change the location of the device or place the device
in direct sunlight. Once the solar LED lights up green, the battery
is fully charged.

■ 12 │ GB│IE SLS 2200 C2
Charging with the USB cable
If there is no sunlight available, you can charge the battery of the
device with the USB cable . To do this, connect the micro-USB
plug of the charging cable to the device’s micro-USB port .
Connect the USB plug of the USB cable to a USB port on your
computer. The charging progress will be indicated by means of
the charge level LEDs .
Charge level LEDs Charge level
One LED is flashing < 25%
One LED is on, the second LED is flashing 25–49%
Two LEDs are on, the third LED is flashing 50–74%
Three LEDs are on, the fourth LED is flashing 75–99%
All LEDs are on 100%
NOTE
► Some computers deactivate the power supply to the USB
ports when they are switched off. If the solar charger’s
battery is not being charged, check to see whether your
computer is turned on.
► Alternatively, you can charge the battery of the solar charger
with an external USB power supply (not supplied).
To do this, use the USB cable supplied with the product.
You can purchase a suitable 5 V USB power adapter with
an output of at least 500mA from most electronics stores.

GB│IE │ 13 ■
SLS 2200 C2
Handling and operation
Switch the device on/off
Switching on
♦ Press the ON/OFF button briefly to switch on the device.
The charge level LEDs light up for about 10 seconds.
The LED lights up blue as long as a connected device
is being charged.
Automatic switch-off
♦ If no device is connected for charging within 10 seconds, the
charger switches off automatically to conserve its battery.
Switching off
♦ Press and hold the ON/OFF button for at least 3 seconds
to switch off the device and stop the charging process.
The LED goes out.
Display charge level
♦ Press the ON/OFF button briefly to show the charge level
of the non-loaded battery for a few seconds. The charge level
LEDs show you the charge level.
Charge level LEDs Charge level
All LEDs are on 75 -100 %
Three LEDs are on 50 -74 %
Two LEDs are on 25 -49 %
One LED is on 5 -24 %
One LED is flashing < 5 %
All LEDs off 0 %

■ 14 │ GB│IE SLS 2200 C2
Compatible devices
You can use the solar charger to charge end devices that require
a charging current of at least 60 mA and a maximum of 1A.
If the connected end device requires a current of less than 60 mA
or more than 1A, the solar charger will switch itself off immedi-
ately after being switched on with the ON/OFF button . In this
case, check the charger’s suitability for your end device on the
basis of the technical data of your end device.
Charging external devices
Connect the charging cable of your end device to the USB port
on the solar charger and to your end device.
♦ If charging does not start automatically, press the ON/OFF
button briefly to start the charging process.
The LED lights up for as long as the connected device
is being charged. Once your device is fully charged, the solar
charger switches off. To interrupt the charging process, you can
disconnect the end device. If your end device is not fully charged
and the LED goes out during charging, this means the solar
charger’s battery is discharged. The solar charger’s battery must
be recharged again before you can charge end devices.
Simultaneous charging of the built-in battery and a connected
device is only possible in solar operation. Simultaneous charging
of the built-in battery via the micro-USB port and a connected
device is not possible.

GB│IE │ 15 ■
SLS 2200 C2
Troubleshooting
A connected device is not charging.
♦ Press the ON/OFF button briefly to start the charging process.
♦ The solar charger’s battery is empty. Charge the battery.
♦ No connection to the device. Check the connection.
♦ The solar charger can be used for end devices that require a
charging current of no more than 1A. If the connected end
device requires a current of more than 1A, the solar charger
will switch itself off immediately after being switched on with
the ON/OFF button . In this case, check the charger’s suit-
ability for your end device on the basis of the technical data
of your end device.
The solar charger’s battery is not charging via the solar
panel.
♦ Check that the solar panel is receiving sufficient sunlight.
The solar charger’s battery is not charging via the USB
cable.
♦ Connection is faulty. Check the connection.
♦ Some computers deactivate the power supply to the USB ports
when they are switched off. If the solar charger’s battery is not
being charged, check to see whether your computer is turned on.
NOTE
► If the above-mentioned solutions do not resolve the problem,
please contact Customer Service (see chapter Service).

■ 16 │ GB│IE SLS 2200 C2
Cleaning
CAUTION
Damage to the device!
► To avoid irreparable damage to the device, ensure that no
moisture can penetrate the device during cleaning.
► Do not use caustic, abrasive or solvent-based cleaning
materials. These can damage the surfaces of the device.
♦ Clean the surfaces of the device with a soft, dry cloth. For stub-
born dirt, use a slightly damp cloth with a mild detergent.
Storage when not in use
♦ If you do not intend to use the device for a long time, store it in
a clean, dry place away from direct sunlight.
♦ If the solar charger is not going to be used for some time, the
battery should be recharged at regular intervals. This helps to
preserve battery performance.

GB│IE │ 17 ■
SLS 2200 C2
Disposal
The adjacent symbol of a crossed-out wheelie bin
means that this device is subject to Directive
2012/19/EU. This directive states that this device
may not be disposed of in the normal household
waste at the end of its useful life, but must be handed over to
specially set-up collection locations, recycling depots or disposal
companies.
This disposal is free of charge for the user. Protect
the environment and dispose of this device properly.
You can obtain further information from your local disposal com-
pany or the city or local authority.
