Silvercrest SQWC A1 User manual

WIRELESS QI CHARGER
SQWC A1
IAN 305943
WIRELESS QI CHARGER
Operation and Safety Notes
TRÅDLØS QI-
OPLADNINGSMÅTTE
Betjenings- og sikkerhedsbemærkninger
CHARGEUR SANS FIL QI
Instructions d‘utilisation et consignes
de sécurité
DRAADLOZE QI-OPLADER
Gebruik en veiligheidsrichtlijnen
KABELLOSES QI-LADEGERÄT
Bedienungs- und Sicherheitshinweise

GB/IE/NI
Operation and Safety Notes Page 5
DK
Betjenings- og sikkerhedsbemærkninger Side 22
FR/BE
Instructions d‘utilisation et consignes de sécurité Page 40
NL/BE
Bedienings- en veiligheidsinstructies Pagina 58
DE/AT/CH
Bedienungs- und Sicherheitshinweise Seite 77

4
3
2
1

5GB/IE/NI
Warnings and symbols used..... Page 6
Introduction ...................................... Page 7
Intended use..................................... Page 8
Trademark notices......................... Page 8
Safety notes...................................... Page 9
Description of parts ...................... Page 12
Technical data ................................. Page 13
Scope of delivery ........................... Page 13
Before use ......................................... Page 14
Operation.......................................... Page 14
Troubleshooting.............................. Page 17
Storage when not in use............. Page 18
Cleaning ............................................. Page 19
Disposal.............................................. Page 19
Simplified EU declaration
of conformity.................................... Page 20
Warranty ........................................... Page 21

6GB/IE/NI
Warnings and symbols used
These instructions for use contain the following
symbols and warnings:
DANGER! This symbol with the
signal word “DANGER“ indicates
a hazard with a high level of risk
which, if not avoided, will result in
serious injury or death.
WARNING! This symbol with the
signal word “WARNING“ indicates
a hazard with a medium level of risk
which, if not avoided, could result in
serious injury.
CAUTION! This symbol with the
signal word “CAUTION“ indicates a
hazard with a low level of risk which,
if not avoided, could result in minor
or moderate injury.
ATTENTION! This symbol with the
signal word“ ATTENTION“ indicates
a potential property damage, if not
avoided, could result in property
damage.

7GB/IE/NI
NOTE: This symbol with the signal
word “NOTE“ provides additional
useful information.
Direct current
WWatt (power)
“Qi“ and the Qi logo mark are
trademark of the Wireless Power
Consortium (WPC)
This symbol means that the operating
instructions must be observed when
using the product.
WIRELESS QI CHARGER
PIntroduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product.
They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety

8GB/IE/NI
information and instructions for use. Only use
the product as described and for the specified
applications. If you pass the product on to anyone
else, please ensure that you also pass on all the
documentation with it.
PIntended use
The WIRELESS QI CHARGER (hereinafter referred
to as the „Product“) is an information electronics
device. This product is only for charging mobile
devices that use Qi technology. Other devices
cannot be charged with the product. The product
is intended for private use only and not for
commercial use. The manufacturer accepts no
liability for damage resulting from unauthorised
modifications or improper use.
PTrademark notices
 USB®is a registered trademark of USB
Implementers Forum, Inc.
 “Qi“ and the Qi logo mark are trademark of
the Wireless Power Consortium (WPC)
 The SilverCrest trademark and trade name is the
property of their respective owners.
 Any other names and products are trademarks
or registered trademarks of their respective
owners.

9GB/IE/NI
Safety notes
Before using the product, please familiarize
yourself with all of the safety instructions and
instructions for use! When passing this product on
to others, please also include all the documents!
WARNING! DANGER TO LIFE AND
RISK OF ACCIDENT FOR INFANTS AND
CHILDREN!
DANGER! RISK OF SUFFOCATION!
Never leave children unsupervised with the
packaging material. The packaging material
poses a suffocation hazard. Children frequently
underestimate the dangers. The packaging material
is not a toy.
 This product may be used by children age
8 years and up, as well as by persons with
reduced physical, sensory or mental capacities
or lacking experience and/or knowledge, so
long as they are supervised or instructed in the
safe use of the product and understand the
associated risks. Do not allow children to play
with the product. Cleaning and user maintenance
should not be performed by children without
supervision. The product is not a toy.

10 GB/IE/NI
ATTENTION! Damage to property
 Check the product before every use!
Discontinue use if any damage to the product or
the connection cable is detected!
 This product does not contain any parts which
can be serviced by the user.
 Keep the product away from moisture, dripping
and splash water!
 Do not place burning candles or other open fire
on or next to the product.
 If you notice smoke or unusual noise or odour,
immediately disconnect the USB connection.
 Sudden temperature changes may cause
condensation inside the product. In this case,
allow the product to acclimate for some time
before using it again to prevent short circuits!
 Do not operate the product near heat sources,
e.g. radiators or other devices emitting heat!
 Do not throw the product into fire and do not
expose to high temperatures.
 Never open the product. It has no internal parts
requiring maintenance.

11GB/IE/NI
 The product must not be covered during
operation, no foreign objects may be
introduced into the product, no foreign objects
may lie on the Qi charging surface during
operation.
 The product should never be charged at a PC
or notebook, because due to the high power
consumption, the PC or notebook could be
damaged.
ATTENTION! Radio interference
 Do not use the product on aeroplanes, in
hospitals, service rooms, or near medical
electronic systems. The wireless signals
transmitted could impact the functionality of
sensitive electronics.
 Keep the product at least 20 cm from
pacemakers or implantable cardioverter
defibrillators, as the electromagnetic radiation
may impair the functionality of pacemakers.
 The radio waves transmitted could cause
interference in hearing aids.
 Never use the product near flammable gases
or potentially explosives areas (e.g. paint
shops), as the radio waves emitted can cause
explosions and fire.

12 GB/IE/NI
 The OWIM GmbH & Co KG is not responsible
for interference with radios or televisions due
to unauthorised modification of the product.
The OWIM GmbH & Co KG further assumes
no liability for using or replacing cables and
products not distributed by OWIM.
 The user of the product is solely responsible for
rectifying malfunctions caused by unauthorized
changes to the product and the replacement of
such modified products.
PDescription of parts
Please refer to the fold out page.
1LED indicator
2Qi Charging area
3USB plug
4Instructions for use

13GB/IE/NI
PTechnical data
Dimensions: approx. 126 x 112 x
8mm
Weight: approx. 180 g
Operating temperature: 0 – 35 °C
Storage temperature: 0 – 45 °C
Humidity(no condensation): 10 – 70 %
Cable length: approx. 1.5 m
Input voltage/ current: 5 V 2 A
Output voltage/ current: 5 V 1 A
Wireless charging power: 5 W
OR
Input voltage/ current: 9 V 1.7 A
Output voltage/ current: 9 V 1.1 A
Wireless charging power: 10 W
Frequency band: 121.63 - 170.03 kHz
Transmitted maximum radio
frequency power (H-field): -3.42 dBuA/m at
10m distance
Wireless charging distance: ≤ 5 mm
The specification and design may be changed
without notification.
PScope of delivery
1 Wireless Qi charger
1 Instructions for use

14 GB/IE/NI
PBefore use
NOTE:
 Before use, verify the package contents are
complete and undamaged!
 All parts have to be unpacked and the
packaging material has to be removed
completely.
POperation
ATTENTION! The product must not be
charged from a PC or notebook.
NOTE:
 The product only supports devices with Qi
wireless technology.
Charge your device
1. Plug the USB plug 3into the USB port on a
suitable USB adapter (not included).

15GB/IE/NI
2. Plug the USB adapter (not included) into an
easily accessible mains socket.
3. Place the mobile device on the Qi charging
surface. Make sure the center of the device
is aligned over the center of the Qi charging
surface 2. Charging will begin on contact. The
LED 1lights up blue when charging is active.

16 GB/IE/NI
Protective covers that protect the mobile device
may interfere with the charging process. In this
case, the mobile device must be removed from
the protective cover.
NOTE:
 The user may not see LED 1during the
charging process depending on the used mobile
device.
LED indicator 1status
The product has an LED that indicates its
operational status:
LED indicator Status
Blue light for 1 second, then
Green light for 1 second, then
both Blue and Green light for
1 second, then LED off
Starting process
(Boot phase)
LED off Off / Standby
Blue light Charging
Blue and Green light flashing
alternatively Input overvoltage
Blue light flashing Fault condition
Green light Full Charge

17GB/IE/NI
PTroubleshooting
What should I do if the LED indicator
of the product is not lit during starting
process (Boot phase)?
 Check the USB cable connection between USB
adapter (not included) and the product. The
USB cable must be firmly connected.
 Check the connection between the mains socket
and the USB adapter (not included).
 Alternatively, the user must try another mains
socket.
What should I do if the mobile device
does not get charging ?
 Check that the mobile device have Qi wireless
charging technology.
 Check the mobile device is placed horizontally
on the center position of the charging pad.
 Check that no foreign object blocking the
charging.
 Check whether the mobile device is removed
from the protective cover.

18 GB/IE/NI
What should I do if the LED indicator
flashes Blue and Green alternatively?
 This indicates input overvoltage occurred.
 Disconnect the USB connection immediately.
 Check if you use a suitable USB adapter.
 Alternatively, the user must try another USB
adapter.
What should I do if the LED indicator
flashes blue?
 This indicates a fault condition occurred.
 Disconnect the USB connection immediately.
 Check that no foreign object blocking the
charging.
 Let the product cool down for a while and try to
use it again.
PStorage when not in use
Store the product in a dry environment, protected
from dust and direct sunlight.

19GB/IE/NI
PCleaning
This product has no internal parts requiring
maintenance. Moisture entering the product
may result in damage.
Ensure no moisture enters the product during
cleaning to prevent damaging the product
beyond repair.
Do not use abrasive, solvent-based or
aggressive cleaners. These can damage the
surface of the product.
Only clean the product with a slightly damp
cloth and mild washing-up liquid.
PDisposal
Packaging:
The packaging is made of environmentally friendly
materials, which may be disposed of through your
local recycling facilities.
Product:
Contact your municipality for information on how
to dispose of your worn-out product.
The adjacent symbol of a crossed out
dustbin on wheels indicates this product
is subject to Directive 2012/19/EU. This
directive states at the end of the life this

20 GB/IE/NI
product must not be disposed of through regular
household refuse but must be returned to special
collection sites, recycling depots or waste
management companies.
This disposal is free of charge to you.
Protect the environment and dispose of properly.
The product is recyclable, subject to extended
manufacturer responsibility, and collected
separately.an be obtained from your local
authority.
PSimplified EU declaration of
conformity
Hereby, OWIM GmbH & Co. KG, Stiftsbergstraße
1, DE-74167 Neckarsulm, GERMANY, declares
that the product WIRELESS QI CHARGER
HG04114A / HG04114B, is in compliance with
Directives 2014/53/EU and 2011/65/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
www.owim.com

21GB/IE/NI
PWarranty
The product has been manufactured to strict quality
guidelines and meticulously examined before
delivery. In the event of product defects you have
legal rights against the retailer of this product.
Your legal rights are not limited in any way by our
warranty detailed below.
The warranty for this product is 3 years from the
date of purchase. Should this product show any
fault in materials or manufacture within 3 years
from the date of purchase, we will repair or replace
it – at our choice – free of charge to you.
The warranty period begins on the date of
purchase. Please keep the original sales receipt
in a safe location. This document is required as
your proof of purchase. This warranty becomes
void if the product has been damaged, or used or
maintained improperly.
The warranty applies to defects in material
or manufacture. This warranty does not cover
product parts subject to normal wear, thus
possibly considered consumables (e.g. batteries)
or for damage to fragile parts, e.g. switches,
rechargeable batteries or glass parts.
