Silvercrest SUL 1000 A1 User manual

Universal USB Charger SUL 1000 A1
6
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: SUL 1000 A1-11/10-V2
IAN: 61187
Universal USB Charger
Operating instructions
CV_SUL1000A1_61187_LB6.indd 1-3CV_SUL1000A1_61187_LB6.indd 1-3 16.12.2010 15:19:30 Uhr16.12.2010 15:19:30 Uhr

SUL 1000 A1
1
2
3
45
CV_SUL1000A1_61187_LB6.indd 4-6CV_SUL1000A1_61187_LB6.indd 4-6 16.12.2010 15:19:30 Uhr16.12.2010 15:19:30 Uhr

- 1 -
CONTENT PAGE
Read the operating instructions carefully
before using the device for the first time and
preserve this manual for later reference.
Pass this manual on to whoever might acquire
the device at a future date.
Intended use 2
Warning Notice 3
Safety instructions 3
Items supplied 6
Device description 6
Technical Data 7
Notes on the EG conformity
declaration 7
Start-up 8
Cleaning 9
Disposal 9
Warranty & Service 10
Importer 11
IB_SUL1000A1_61187_LB6.indd 1IB_SUL1000A1_61187_LB6.indd 1 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 2 -
Universal USB Charger
Intended use
This universal USB power adapter is designed
especially for devices that receive their power
via a USB connector, such as MP3 players,
mobile phones or iPod/iPhone.
The device is intended solely for private, non-
commercial use. Any other use apart from
those mentioned is regarded as unintended
use and can lead to damage and injuries.
No liability will be accepted for damage
caused by misuse or improper handling, use
of force or unauthorised modifications.
iPod and iPhone are trademarks of Apple Inc.
– registered in the USA and other countries
„Made for iPod“ and “Made for iPhone“
mean that an electronic accessory has been
designed to connect specifically to iPod or
iPhone respectively, and has been certified
by the developer to meet Apple performance
standards.
IB_SUL1000A1_61187_LB6.indd 2IB_SUL1000A1_61187_LB6.indd 2 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 3 -
Apple is not responsible for the operation of
this device or its compliance with safety and
regulatory standards.
Please note that the use of this accessory with
iPod or iPhone may affect wireless performance.
Warning Notice
In the current operating instructions the
following warnings are used:
Danger!:
A warning of this danger level signifies a life
threatening dangerous situation.
Warning:
A warning of this danger level signifies
possible property damage.
Safety instructions
For safe handling of the device observe the
following safety information:
• NEVER open the housing of the appliance,
it contains no user-serviceable parts! If the
housing is opened, there is a risk of receiv-
ing a potentially fatal electric shock.
IB_SUL1000A1_61187_LB6.indd 3IB_SUL1000A1_61187_LB6.indd 3 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 4 -
• In the event of a thunderstorm and/
or lightning, equipment connected to a
mains power supply could be damaged.
Therefore, always unplug the appliance
from the mains power supply during a
thunderstorm.
• Before use check the device for visible
external damage. Do not operate a
damaged device or one that has been
dropped.
• Always grasp the power cable by the
plug. Do not pull on the cable itself and
never touch the power cable with wet
hands, this could result in a short circuit or
you receiving an electrical shock.
• Do not place objects, furniture items or
similar on the cable and ensure that it
cannot become jammed.
• NEVER make a knot in the power cable
and do NOT bind it together with other
cables. Place the power cable so that no
one can step on or stumble over it.
• Damaged cables or connections should be
replaced by authorised qualified personal
or by the customer service department.
IB_SUL1000A1_61187_LB6.indd 4IB_SUL1000A1_61187_LB6.indd 4 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 5 -
• This device is not intended for use by indi-
viduals (including children) with restricted
physical, physiological or intellectual
abilities or deficiences in experience and/
or knowledge unless they are supervised
by a person responsible for their safety
or receive from this person instructions on
how the device is to be used.
• Only permit children to use the device
under supervision.
• Protect the device from moisture and liquid
penetration.
• Disconnect the device from the mains
power socket before any cleaning. There
is a risk of receiving an electric shock!
• The device is intended for indoor use
only .
• The device must only be connected to
a properly installed mains power socket.
• The mains power socket must at all times
be easily accessible, so that the appliance
can be easily and quickly disconnected in
the event of an emergency.
IB_SUL1000A1_61187_LB6.indd 5IB_SUL1000A1_61187_LB6.indd 5 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 6 -
• The appliance is always “live”, even
when it is not connected to a device to
be charged. Thus, the appliance should
always be unplugged when it is not in
use. To completely separate the appliance
from the mains voltage, e.g. in emergencies,
it must be removed from the mains power
socket.
Items supplied
Universal USB Charger SUL 1000 A1
Connection cable USB type A to type Mini-B
Connection cable USB Type A to iPod/iPhone
These operating instructions
Device description
(see fold-out page)
1Universal USB Charger SUL 1000 A1
2LED operating indicator
3USB port
4Connection cable USB type A to type Mini-B
5 Connection cable USB Type A to iPod/iPhone
IB_SUL1000A1_61187_LB6.indd 6IB_SUL1000A1_61187_LB6.indd 6 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 7 -
Technical Data
Input voltage: 100-240 V~60/50 Hz
Max. current
consumption: 0,13 A
Power consumption
(no load): 0,3 W
Protection class: II /
Output voltage: 5 V
Max. output current: 1 A
Operating
temperature: 15° - 35°C
Storage temperature: -20° - 50°C
Dimensions: 7.2 x 7.1 x 5.1 cm
Weight: 58 g approx.
Notes on the EG conformity
declaration
This device conforms regarding
compliance to the basic require-
ments and other relevent regulations of the
low-voltage directive 2006/96/EC, the EMV
directive 2004/108/EC as well as the
Ecological design directive 2009/125/EC
(Ordinance 1275/2008 supplement II,
Number 1 and Ordinance 278/2009
supplement I, Number 1a).
IB_SUL1000A1_61187_LB6.indd 7IB_SUL1000A1_61187_LB6.indd 7 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 8 -
Start-up
Warning: Before initial use of your
device with the USB Mains Adaptor observe,
without fail, the specifications for power sup-
ply in the operating instructions of the device
you want to connect.
• Connect your switched off device to the
USB Mains Adaptor 1.
• For this, use either the USB connection
cable 4, the iPod/iPhone connection
cable 5or plug your device directly to
the USB port 3. Do not use force or exces-
sive pressure under any circumstances.
• Plug the USB Mains Adaptor 1into a
properly installed mains power socket.
The LED 2lights up green.
• Now you can switch your device on for
further use.
Warning: If you are using the USB
Mains Adaptor for the recharging of built-in
rechargeable batteries in, for example, MP3
players observe, without fail, the maximum
allowed charging time of the rechargeable
batteries!
IB_SUL1000A1_61187_LB6.indd 8IB_SUL1000A1_61187_LB6.indd 8 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 9 -
Cleaning
Danger! Before any cleaning pull the
device out of the mains power socket. There
is a danger of electric shock! Make sure that,
during cleaning, no moisture penetrates into
the device!
Clean the housing of the USB Mains Adaptor
exclusively with a dry cloth. Under no circum-
stances should you use abrasive or chemical
cleaners.
Disposal
Under no circumstances may
you dispose of the device in
your normal household waste.
This product is subject to the
provisions of the European
directive 2002/96/EC.
Dispose of the device through an approved
disposal centre or at your community waste
facility. Observe the currently applicable
regulations.
In case of doubt, please contact your waste
disposal centre.
Take all of the packaging materials to
an environmentally friendly disposal
facility.
IB_SUL1000A1_61187_LB6.indd 9IB_SUL1000A1_61187_LB6.indd 9 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 10 -
Warranty & Service
You receive a 3-year warranty for this device
as of the purchase date. This device has been
manufactured with care and meticulously
examined before delivery. Please retain your
receipt as proof of purchase.
In the case of a warranty claim, please get
in touch, by telephone, with our service
department. Only in this way can a post-free
dispatch for your goods be assured.
The warranty covers only claims for material
and maufacturing defects, not for transport
damage, wear and tear or for damage to
fragile components, e.g. switches or recharge-
able batteries. This product is for private use
only and is not intended for commercial ap-
plications. If this product has been subjected
to improper or inappropriate handling, abuse
or interventions not carried out by one of our
authorised sales and service outlets, the war-
ranty will be considered void.
Your statutory rights are not restricted in any
way by this warranty. The warranty period
is not extended through repairs made under
warranty.
IB_SUL1000A1_61187_LB6.indd 10IB_SUL1000A1_61187_LB6.indd 10 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr

- 11 -
This applies also for replaced or repaired parts.
Any damages or deficiencies found on pur-
chase must be reported as soon as possible
after unpacking, at the latest two days after
the purchase date. After expiry of the warranty
period all repairs carried out are to be paid for.
DES UK LTD
Tel.: [phone] (£ 0.10 / minute)
E-Mail: [e-mail]
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
E-Mail: [e-mail]
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_SUL1000A1_61187_LB6.indd 11IB_SUL1000A1_61187_LB6.indd 11 20.12.2010 10:16:52 Uhr20.12.2010 10:16:52 Uhr
