Silvercrest SSM 200 A1 User manual

IAN 96255
SORBET MAKER SSM 200 A1
SORBET MAKER
Operating instructions SORBETMASKINE Betjeningsvejledning
SORBET-MAKER
Bedienungsanleitung
SORBET MAKER
Gebruiksaanwijzing

GB/IE Operating instructions Page 1
DK Betjeningsvejledning Side 11
NL/BE Gebruiksaanwijzing Pagina 21
DE/AT/CH Bedienungsanleitung Seite 31
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

A
B C

1
SSM 200 A1
GB
IE
Contents
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preparing ingredients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cleaning and care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty and service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Recipes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Tropicana sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Melon & berry sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Banana & pineapple sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Banana sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Kiwi-Mango Sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Strawberry and pineapple sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pistachio & berry sorbet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chocolate kiwi sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Raspberry & pear sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Peach & banana sorbet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2SSM 200 A1
GB
IE
Introduction
Congratulations on the purchase of your new
appliance.
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information on safety, usage
and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines.
Use the product only as described and for the range
of applications specified. Please also pass these
operating instructions on to any future owner(s).
Intended use
This appliance is intended exclusively for making
sorbet from frozen fruit. This appliance is intended
solely for use in private households. Do not use it
for commercial purposes.
Package contents
Sorbet Maker
Operating instructions
Description of the appliance
1On/Off switch
2Feeding tube
3Roller housing
4Drive shaft
5Blade roller
6Pusher
7Pusher lid
8End cap
9Outlet
0Motor unit
qCable storage compartment
Technical data
Rated voltage: 220 - 240 V ∼, 50 Hz
Rated input: 200 W
Protection class: II
CO time: 2 minutes
CO time
The CO time (continuous operation time) is the
amount of time an appliance can be operated
without the motor overheating and becoming dam-
aged. After the appliance has run for this length of
time, it must be switched off for about 1 minute to
allow the motor to cool down.

3
SSM 200 A1
GB
IE
Safety guidelines
RISK OF ELECTRIC SHOCK
► Connect the appliance only to mains power sockets supplying a mains
power voltage of 220 - 240 V ~, 50 Hz.
► To prevent accidents, have defective plugs and/or power cables replaced
immediately by an authorised specialist technician or our Customer Service
department.
► In event of operating malfunctions and before cleaning the appliance,
remove the power plug from the mains power socket.
► Always remove the power cable from the socket by pulling on the plug, not
on the power cable itself.
► Do not kink or crush the power cable, and route the cable so that it cannot
be stepped on or tripped over.
► Do not expose the appliance to humidity and do not use it outdoors.
If liquid gets into the housing, disconnect the appliance from the mains
power socket immediately and have it repaired by a qualified technician.
► NEVER take hold the motor unit, the power cable or the power plug with
wet hands.
► If the power cable or the motor unit are damaged, you must have the appli-
ance repaired by qualified technicians before using it again.
► Do not open the housing of the appliance motor unit. Doing so can lead
to risks and also invalidates the warranty.
► Disconnect the appliance from the mains power source immediately after
use. The appliance is completely free of electrical power ONLY when
unplugged.
Never immerse the motor unit of the appliance in liquid and do not allow
any liquids to enter the housing of the motor unit.

4SSM 200 A1
GB
IE
WARNING! RISK OF INJURY!
► This appliance should not be used by children.
► Keep the appliance and its cord out of reach of children.
► This appliance may be used by persons with limited physical, sensory or
mental capabilities or lack of experience and knowledge, provided that
they are under supervision or have been told how to use the appliance
safely and are aware of the potential risks.
► Children must not use the appliance as a plaything.
► Handle the sharp blades with caution as they could cause injuries.
Reassemble the appliance after using and/or cleaning it so that you do not
injure yourself with the exposed blades. Keep the blades out of the reach
of children.
► The appliance and its connecting cable must be kept away from children.
► The appliance should always be disconnected from the mains when un-
attended and before assembly, disassembly or cleaning.
► Never put your hand into the openings of the appliance. Do not insert any
objects of any kind into the openings – except for the pusher and the food-
stuffs to be processed. If you do, there will be a serious risk of accidents!
► Before changing accessories or additional parts that are in motion dur-
ing operation, the appliance must be switched off and disconnected from
mains power.
CAUTION! MATERIAL DAMAGE!
► Do not try to use the appliance to crush ice cubes! This will irreparably
damage the appliance!

5
SSM 200 A1
GB
IE
Assembly
1) Remove all packaging materials and any stickers
from the appliance.
2) Clean the appliance as described in the section
“Cleaning and Care”.
3) Place the motor unit 0on a flat surface.
4) Push the knife roller 5into the roller housing 3.
The drive shaft 4must project into the opening
of the roller housing 3.
5) Screw the end cap 8onto the roller housing 3,
until the outlet 9is pointing downwards and
the end cap 8no longer turns. In doing so,
turn the end cap 8in clockwise direction.
6) Push the assembled roller housing 3into the
motor unit 0, so that the feed tube 2is slightly
offset (see Figure B on the fold-out page). The
locking mechanisms on the roller housing 3
must reach into the slots on the motor unit 0.
Turn the roller housing 3, so that the feed tube 2
is facing upwards and the roller housing 3
snaps into place (see Figure C on the fold-out
page).
7) Place the pusher 6into the feed tube 2.
NOTE
► The pusher lid 7can be removed.
For removal:
–Turn the pusher lid 7anticlockwise until it
allows itself to be removed.
For set up:
–Place the pusher lid 7on the pusher 6,
so that both locking mechanisms on the
pusher lid 7slide through the slots on the
pusher 6and then turn the pusher lid 7
in clockwise direction so that it is firmly
held in place.
8) Insert the plug into a mains power socket.
The appliance is now ready for use.
Preparing ingredients
CAUTION! MATERIAL DAMAGE!
► Do not process fruits with stones or cores.
► Do not process whole nuts.
► Do not process ice cubes.
♦ Peel fruits such as bananas or kiwis.
♦ Remove cores, stones or stems from the fruit.
♦ Cut the fruit into small pieces so that it will easily
fi
t through the feed tube 2.
♦ Ingredients such as such as cooking chocolate
must be crushed into small pieces.
♦ Put the prepared fruit in freezer bags or plastic
tubs and place them into the freezer for approxi-
mately 24 hours (-18°C).
NOTE
► Instead of freezing fresh fruit, you can use fruit
that has already frozen from the deep-freezer.
Using the appliance
1) Take the fruits out of the freezer about 10–
20 minutes before use.
2) Place a suitable bowl under the outlet 9.
3) Remove the pusher 6from the feed tube 2.
4) Add the prepared fruits into the feed tube 2.
5) Switch on the appliance using the on/off
switch 1(position I).

6SSM 200 A1
GB
IE
6) Applying light pressure, use the pusher 6to
push the fruit into the appliance. The chopped
fruit will come out of the outlet 9after a short
time. If the pusher 6cannot be pressed further
down, remove it and add a little more fruit or
ingredients.
NOTE
► If you want to make a sorbet from several
different fruits/ingredients, add the different
fruits alternately into the feed tube 2. In this
way, the fruits will be mixed directly.
7) Once all the fruits are chopped, stop the appli-
ance by moving the on/off switch 1to the O
position.
8) Remove the power plug from the socket.
9) Unscrew the end cap 8and pull the blade
roller 5carefully out of the roller housing 3.
10) Use a knife to scrape any remaining fruit
residue from between the blades on the blade
roller 5and add this to the bowl.
11) Mix the fruit in the bowl.
You can now serve the sorbet.
Cleaning and care
RISK OF ELECTRIC SHOCK
► Always remove the plug from the mains power
socket before you clean the appliance.
Ensure you never submerse the motor unit 0
in liquid, and never allow liquid to enter the
motor unit housing 0.
WARNING! RISK OF INJURY!
► Take great care when handling the blade
roller 5.
♦ Clean the motor unit 0with a moist cloth after
every use . If there is heavy soiling, add mild
detergent to the cloth. Rinse detergent residues
off with clear water. Ensure that there are no
detergent residues on the appliance, and that the
appliance is completely dry before renewed use.
♦ Remove the pusher lid 7from the pusher 6for
cleaning purposes.
♦ Wash the pusher 6, the pusher lid 7, the
blade roller 5, the end cap 8and the roller
housing 3in lukewarm water with a little
detergent.
♦ Ensure that all parts are completely dry before
re-use.
NOTE
► You can also wash the pusher 6, the pusher
lid 7, the end cap 8and the roller housing 3
in the dishwasher.
Place the parts, where possible, in the upper
basket and ensure that none of the parts can
get stuck. Otherwise they could get bent or
otherwise deformed.

7
SSM 200 A1
GB
IE
Storage
♦ Always clean the appliance thoroughly before
storing.
♦ Push the power cable and plug into the cable
storage compartment qon the underside of the
appliance.
♦ Store the appliance in a clean and dry location.
Warranty and service
You are provided a 3-year warranty on this
appliance, valid from the date of purchase.
This appliance has been manufactured with care
and inspected meticulously prior to delivery.
Please retain your receipt as proof of purchase. In
the event of a warranty claim, please contact your
Customer Service unit by telephone. This is the
only way to guarantee free return of your goods.
The warranty only covers claims for material and
manufacturing defects, not for damage sustained
during carriage, components subject to wear and
tear or damage to fragile components such as
switches or rechargeable batteries. This appliance
is intended solely for private use and not for com-
mercial purposes.
The warranty shall be deemed void in cases of
misuse or improper handling, use of force and
interventions which have not been carried out by
one of our authorised Service centres.
Your statutory rights are not restricted by this
warranty.
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must be
reported immediately after unpacking, but no later
than two days after the date of purchase. Repairs
carried out after expiry of the warranty period shall
be subject to charge.
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
IAN 96255
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: k[email protected]
IAN 96255
Hotline availability:
Monday to Friday 08:00 - 20:00 (CET)
Disposal
Never dispose of the appli-
ance in the normal domestic
waste. This product is subject
to the provisions of European
Directive 2012/19/EU.
Dispose of the appliance via an approved waste
disposal company or your municipal waste disposal
facility. Please observe applicable regulations.
Please contact your waste disposal facility if you
are in any doubt.
The packaging is made from environ-
mentally friendly material and can be
disposed of at your local recycling plant.
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
