Silvercrest KH 2411 User manual

KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH2411-2/09-V2
BALARM RADIO
ALARM RADIO
Operating instructions
RÁDIO S BUDÍKOM
Návod k obsluze
RÁDIO S BUDÍKEM
Návod na obsluhu
KH 2411
CV_KH2411_DT26291_LB4B.qxd 25.03.2009 9:48 Uhr Seite 1

KH 2411
q
Awe
uiyrt
Bo
a
C
s
CV_KH2411_DT26291_LB4B.qxd 25.03.2009 9:48 Uhr Seite 4

- 1 -
Read the operating instructions carefully before using the appliance
for the first time and preserve this booklet for later reference. Pass the
manual on to whomsoever might acquire the scale at a later date.
CONTENT PAGE
Intended use 2
Items supplied 2
Technical data 2
Appliance description 2
Safety instructions 2
Inserting the batteries 3
Setting up 3
Reception mode 3
Adjusting the time functions 4
Cleaning and storage 5
Maintenance 5
Disposal 6
Importer 6
Warranty and Service 6
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 1

ALARM RADIO KH2411
Intended use
This appliance is intended for the reception of public radio transmissions
and for the amplification of sound signals from external playback devices
such as iPod, MP3 and CD players in domestic environments.
It is not intended for use in premises with high humidity or in commer-
cial and industrial applications.
Items supplied
1 x Appliance
1 x Operating instruction
• Check to ensure that the appliance is undamaged, all component parts
are present and that packaging remnants are removed from it.
- 2 -
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 2

Technical data
Reception range FM: 87,5 – 108 MHz
Reception range AM: 526,5 – 1606,5 kHz
Output level: approx. 500 mW
Audio connection: 3,5mm Jackplug
incl. firmly assembled cable
Batteries: 3 x 1.5 V Type “AAA”
Operating Temperature
Range : +5° – +40°C
Humidity: 5 – 90%
(No condensation)
Dimensions (LxWxH): 208 x 78 x 56 mm
Weight : approx. 255 g
CE- Conformity
This device has been tested and approved in accordance with the basic
requirements and other relevent regulations of the EMC Directive
2004/108/EC.
- 3 -
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 3

Appliance description
Fig. A:
Telescopic antenna
Connection cable for external audio device
Compartment for external audio device
“SET” button
“TUNING” tuning regulator
Slider switch AUX - AM - FM
Button “ALARM ON/OFF”
“OFF VOLUME” Regulator for volume, On/Off
Fig. B:
Frequency scale
Display
Fig. C:
Battery compartment cover
Safety instructions
• If you do not intend to use the appliance for an extended period,
remove the batteries – batteries can discharge themselves and then
leak.
• Should the batteries leak: Clean the battery compartment with a dry
cloth whilst wearing protective gloves. Use ONLY the type of battery
detailed in the Technical Data as replacements for discharged batte-
ries.
• Always exchange all batteries at the same time. Always use batteries
of the same type as replacements.
- 4 -
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 4

• Keep batteries and cells away from small children. Should a battery
be swallowed, seek medical attention IMMEDIATELY, as life is at
risk.
• Check to ensure that the appliance is in a service-able condition befo-
re taking it into use. Should there be visible damage to the applian-
ce, do not take it into use.
• Do not attempt to recharge batteries. There is a chance that they
could explode!
• Ensure that no direct sources of heat (e.g. radiators) can have an
effect on the device, it is not subject to direct sunlight, contact with
sprayed or dripping water is avoided (do not place waterfilled
objects, for example flower vases, on or next to the device) and that
no open fire sources (e.g. burning candles) are placed on or close
to the device. Also, avoid penetration by foreign objects.
• Do not permit small children to play with the plastic packaging.
There is a risk of suffocation!
Inserting the batteries
• Open the battery compartment cover and insert 3 x 1.5 V batteries
of the type AAA/Micro. Comply with the polarity markings indicated
in the battery compartment.
• Close the battery compartment. The device is now ready for use.
Setting up
• Draw out the telescopic antenna .
• Should you wish to playback an external audio device over the
radio, connect it with the connection cable at the rear.
- 5 -
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 5

• If the external audio device (e.g. iPod, MP3 player) fits into the
compartment at the rear, it can be placed there. Failing this, the
pocket can also be useful as a tidy for writing implements and
other utensils on the desk.
Reception mode
a) Switching the appliance on/off, sound volume
• To switch the device on, turn the regulator “VOLUME” from the
stop position “OFF” to the right. It can also be used to adjust the
sound volume level. With this you can also regulate the sound
volume.
• To switch the device off, turn the regulator “VOLUME” wholly to
the left, until it engages in the stop position “OFF”.
b) Adjusting the reception
• Select the reception range AM or FM by placing the slider switch 
into the appropriate position.
• Then search for the desired radio station by slowly turning the
tuning regulator “TUNING” until you have clear reception.
• You can read off the currently selected frequency from the frequen-
cy scale , the unit for VHF is shown in “MHz” (Megahertz), for
medium wave it is shown in “kHz” (Kilohertz).
c) Playback of an external audio device
• If an external audio device is connected, place the slider switch 
into the position “AUX”.
• Then start the playback on your external device.
- 6 -
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 6

Adjusting the time functions
a) Programming the alarm time
• Press the button “ALARM ON/OFF” .In the display all positions
blink and the indicator “AL ” (Alarm time) appears.
• Press once again on the button “ALARM ON/OFF” , until only
the figure for the hours (e.g. “1: A ”) is shown in the display and, at
the same time, the indicator “AL ” (Alarm time).
• Press repeatedly on the button “SET” until the correct hour figure
is shown in the display, e.g. “7: A ”. The letter “A ” behind the figure
means “AM” (forenoon), “P ” means “PM” (afternoon).
• Press again on the “ALARM ON/OFF” button, until only the figu-
res for the minutes are shown in the display (e.g. “:00 ”) and, at the
same time, the indicator “AL ” (Alarm time).
• Press repeatedly on the button “SET” until the correct minute figu-
re has been programmed in, e.g. “ :30 ”.
b) Setting the date
• Press again on the “ALARM ON/OFF” button until only the
number for the month is shown in the display, e.g. “1 ”.
• Press repeatedly on the button “SET” , until the month has been
programmed in, e.g. “12 ”.
• Press again on the “ALARM ON/OFF” button until only the
number for the day is shown in the display, e.g “ 1”.
• Press repeatedly on the button “SET” , until the date has been
programmed in, e.g. “ 31”.
- 7 -
IB_KH2411_DT26291_LB4B 25.03.2009 15:16 Uhr Seite 7

c) Setting the clock
• Press once again on the button “ALARM ON/OFF” , until only
the figure for the hours is shown in the display, e.g. “1: A ”. Make
sure that the indicator “AL ” does not appear, as you would then be
setting the alarm time, not the time display itself.
• Press repeatedly on the button “SET” , until the required hour figu-
re is shown, e.g. “10: A ”. The letter “A ” behind the figure means
“AM” (forenoon), “P ” means “PM” (afternoon) and “H ” indicate
the 24 hour display.
• Press again on the “ALARM ON/OFF” button until only the num-
ber for the minutes is shown in the display, e.g. “:01 ”. Make sure
that the indicator “AL ” does not appear, as you would then be
setting the alarm time, not the time display itself.
• Press repeatedly on the button “SET” until the required minute
figure has been programmed in, e.g. “15 ”.
d) Starting the clock
• Press the button “ALARM ON/OFF” ,to accept the programmed
minutes and to display the time, e.g. “ 10:15 ”.
• Press the button “SET” ,to accept the displayed time and to start
the clock. As a control, the double-point in the display  starts to
blink.
e) Alarm function and hour signal
• Press the button “ALARM ON/OFF” .In the display all positions
blink and the indicator “AL ” (Alarm time) appears.
• To switch the alarm function on, repeatedly press the button “SET”
until three lines are shown above the colon in the display. To
switch the alarm function off, repeatedly press the button until the
three lines are no longer indicated.
