Features
Panel mounted modules provides fire alarm
system status using the ASHRAE BACnet
building automation communication protocol
BACnet (Building Automation Control Network)
protocol reference:
Communications are via BACnet IP (internet protocol)
Reference: ANSI/ASHRAE Standard 135
Connections:
To fire alarm system via RS-232 port B, configured
for Computer Port Protocol (see page 3 for model
number reference per panel)
Output port provides Ethernet LAN (local area
network) connection
BACpac Ethernet Module is pre-programmed:
Module is pre-programmed with digital pseudo points
linked to BACnet objects
Up to 1000 status changes (monitor point status) can
be recognized from the fire alarm control panel
Compatible Simplex®fire alarm control panels:
4100ES and 4100U Series fire alarm control panels
and Network Display Units (NDU)
4010ES Series fire alarm control panels
Installed legacy Models 4100/4100+ and 4120 Series
fire alarm control panels and NDU (software revision
updating may be required
Listings reference:
UL listed to Standard 864
ULC listed to Standard S527
Description
The BACpac Ethernet module provides a supplementary
communications interface that converts computer terminal
information from a compatible Simplex fire alarm control
panel into the building automation protocol of BACnet.
With this module, status information from the fire alarm
control panel can be provided to other components of the
building automation network with the detail and
information format required.
Providing this information allows other systems to
properly respond to fire alarm system activity in addition
to the primary fire alarm response that is under the control
of the fire alarm control panel.
ALARMFIRE
PULL DOWN
ALARMFIRE
PULL DOWN
LAN Connected BACnet System Controllers
Facility LAN
System
Workstation
Fire Alarm
Network
Fire alarm
initiating devices
Simplex Fire Alarm
Control Panel
Fire Alarm System
ALARM
ALARM
4100-6069 BACpac
Ethernet Module
Facility LAN
FireControl
FIREALARM
CONTROL
DISCONNECT
POWERBEFORE
SERVICING
CAUTION
**SYST EM ISNOR MAL **
12:02:15pm Mon8-Mar-99
SUP
V
ACK
SYSTEM
SUPERVISOR
Y
ALARM
ACK
FIRE
ALARM
TROUBLE
ACK
SYSTEMTROUBL
E
ALARM
SILENCE
ALARM
SILENCED
SYSTEMRESE
T
AC
POWER
Typical Building Automation LAN with
Simplex Fire Alarm Control Panel and BACpac Portal
(shown with 4100ES panel for reference)
This document is a summary of the flexibility available
with BACnet communications. Please contact your local
Simplex product supplier for further information
concerning your specific application.
*This product has been approved by the California State Fire Marshal (CSFM) pursuant to
Section 13144.1 of the California Health and Safety Code. See CSFM Listing
7165-0026:0251 (4100 Series) or 7165-0026:0369 (4010ES) for allowable values and/or
conditions concerning material presented in this document. It is subject to re-examination,
revision, and possible cancellation. This product was not approved by FM, or accepted by
MEA (NYC) as of document revision date. Additional listings may be applicable; contact
your local Simplex product supplier for the latest status. Listings and approvals under
Simplex Time Recorder Co. are the property of Tyco Fire Protection Products.
Fire Control Panels
UL, ULC, CSFM Listed* BACpacEthernet Portal Modules
Model 4100-6069 and 4010-9915
S4100-0051-3 9/2012

Systems Responsibilities
Fire Detection and Alarm Systems are distributed
throughout buildings to monitor for indications of the
presence of smoke or fire. When a fire alarm condition is
determined, the fire alarm system communicates that
information with sufficient detail to allow the proper fire
response to begin. The fire alarm system may perform
other control functions such as fan shutdown and elevator
recall, or those actions may be performed by other
systems that also handle those functions for normal
conditions as well as for abnormal conditions.
Building Automation Systems. As buildings increase
in size and complexity, control of the electrical and
mechanical systems requires coordination. This process
has evolved into the general category of Building Systems
Automation and includes systems such as heating,
ventilation, and air conditioning (HVAC), elevator
controls, security controls, lighting controls, and other
similar building functions.
Typical responses to fire alarm system status changes
might include: HVAC fan control operation, elevator
capture, lighting control, and security system awareness.
Specific examples could include turning on lighting
where needed, aiming security cameras on specific areas,
providing door release, and implementing detailed fan
exhaust and/or pressurization instructions.
Systems Communications
Communications Between Systems. Traditional
communication between systems has included simple relay
interfaces, proprietary (and complicated) interface devices
(gateways), as well as using a single supplier for all of the
building automation functions. Each of these compromises
has its limitations. With the Simplex BACpac Ethernet
module, BACnet protocol communications allows a
Simplex fire alarm system to provide pertinent status to
compatible systems using standardized formats.
Communications Example
The example to the right shows how a smoldering fire
located on the first floor can be detected by the fire alarm
control panel, processed by the BACpac Ethernet module,
and then sent to the building automation system using the
BACnet protocol over a LAN connection. It is the
responsibility of the fire alarm control panel to initiate the
required notification and related fire responses. However,
when connected to a BACpac Ethernet module, the fire
alarm system can make status information available to the
other building systems allowing them to be informed
about facility fire detection activity.
Diagnostic Reference
This module uses a BACnet protocol converter from
Fieldserver Technologies. PC compatible diagnostic
programs are available at www.fieldserver.com.
HVAC
Smoke
Control
System
System
Workstation
FIRST FLOOR SMOKE ALARM
Smoldering fire
Location M1-1
BACnet Instance 1
BACnet protocol format
FIRST
FLOOR
ALARM
LOCATION M1-1
Facility LAN
Facility LAN
4010ES Fire
Alarm Panel
4010-9915 BACpac Ethernet
Module and 4010-9918
RS-232 Module
Typical BACpac Ethernet Module
Alarm Process Reference
(shown with 4010ES panel for reference)
2 S4100-0051-3 9/2012

3 S4100-0051-3 9/2012
Category Implementation
BACnet Standardized Device Profile
(Annex L)
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)
BACnet Application Specific Controller (B-ASC)
BACnet Interoperability Building Blocks
Supported (Annex K)
K.1.2 BIBB -Data Sharing -ReadProperty-B (DS-RP-B)
K.1.8 BIBB -Data Sharing -WriteProperty-B (DS-WP-B)
K.5.2 BIBB -Device Management -Dynamic Device Binding-B (DM-DDB-B)
Segmentation Capability None
Standard Object Types Supported
Device Object
Analog Input
Analog Output
Analog Value
Binary Input
Binary Output
Binary Value
Multi State Input Output
Multi State Output
Multi State Value
Additional Property Details
Properties NOT
supported
BACnet CreateObject
BACnet DeleteObject
Any optional properties
Additional
Property Details
No additional writeable properties exist
No proprietary properties exist
No range restrictions exist
Data Link Layer Options MS/TP master (Clause 9), baud rate up to 76,800 bps
MS/TP slave (Clause 9), baud rate up to 76,800 bps
Device Address Binding Not supported
Character Sets Supported
ANSI X3.4
ISO 10656 (ICS-4)
ISO 10656 (UCS-2)
ISO 8859-1
IBM/Microsoft DBCS
Model Description Required RS-232 Module
(ordered separately)* Additional Data Sheet Reference Installation Instructions
4100-6069 BACpac Ethernet Module for 4100ES, 4100U, 4100/4100+, and 4120 Series fire
alarm control panels; single slot (2”) module
4100ES or
4100U 4100-6038 S4100-0031 579-842
4100, 4100+,
or 4120 4100-0113
4010-9915 BACpac Ethernet Module for 4010ES Series fire alarm control panels; single block
module (4x5) 4010-9918
S4010-0004
(S4010-0006 for
international
applications)
579-1051
* Note: BACpac modules connect to Port B of these RS-232 modules.
BACnet Protocol Implementation Conformance (PIC) Reference
Product Selection

Input Power Voltage 24 VDC from fire alarm panel; operation range 9 to 30 VDC Current 123 mA maximum from 24 VDC fire alarm panel supply
Connections Wires to pluggable terminal block, harness included
Data Input
Note: Connect to
Port B of RS-232
Module
Data Type RS-232 Computer Port Protocol from fire alarm control panel
Connections Pluggable terminal block (same terminal block as used for input power) connects to
RS-232 module in fire alarm control panel, harness included
Panel 4100ES 4010ES 4100U 4100/4100+/4120
RS-232 Module 4100-6038 4010-9918 4100-6038 4100-0113
Data Output Data Type Ethernet compatible communications formatted as BACnet IP (internet protocol)
Connections Ethernet RJ-45 jack located on LAN suppressor module (part of module assembly);
LAN Ethernet output connector to be supplied separately
BACnet Default Settings Device Instance = 32400; IP Address = 192.168.1.24; Subnet Mask = 255.255.255.0
Status LED Indications Power, TX, RX, RTX, CTS, DTR, DSR, DCE, and RI; located on the processor assembly
4100-6069 Module Size 2” Slot type module, components are mounted on a metal bracket;
bracket dimensions: 2” W x 10-7/16” H x 4” deep (51 mm x 265 mm x 102 mm)
4010-9915 Module Size Single block module (4 x 5); uses the modules shown in the diagram below, but packaged
differently
Module Description RS-232 communications and power are connected to the on-board pc board assembly for
processing; a pluggable harness (supplied) connects to a grounded LAN suppressor
mounted on the chassis; standard Ethernet LAN cable is supplied separately
Operating Temperature Range 32F to 120F (0C to 49C)
Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C) maximum
TYCO, SIMPLEX, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. ASHRAE and BACnet are trademarks
of ASHRAE, American Society of Heating, Refrigeration, and Air Conditioning Engineers.
Tyco Fire Protection Products • Westminster, MA • 01441-0001 • USA S4100-0051-3 9/2012
www.simplexgrinnell.com
© 2012 Tyco Fire Protection Products. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
Processor assembly
Interconnection cable
LAN Ethernet cable
connection location, RJ-45
(cable supplied separately)
Power and data connection terminal strip
2” Slot mounting bracket (shown
rotated from mounting orientation)
LAN Suppressor Assembly
Suppressor
grounding
connection
Specifications
BACpac Ethernet Module Details (4100-6069 shown for reference)
