SafeRing / SafePlus
Retrofit of opening coil Y1 and auxiliary switch S7
F, C and SI Modules with latched mechanism
Installation instructions
www.abb.com
Edition
1.0 Document status RELEASED Responsible NODIS
Location Date Name
Language
EN/NO
Prepared NODIS 2008-12-11 BJGU/GUSO
Checked NODIS 2008-12-16 MARE
Approved NODIS 2008-12-16 OLGR
Title
SAFERING / SAFEPLUS
RETROFIT OF
OPENING COIL Y1 AND
AUXILIARY SWITCH S7
F, C AND SL MODULES
ABB ABB Technology Ltd. Document No.
1VDD200027 Sheet No. 1/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
General Safety Instructions!
- Check that the installation, putting into service and
maintenance of this apparatus is carried out by qualified
personnel with knowledge of the apparatus to be installed. All
the procedures as laid out in this installation and service
instruction manual must be known.
- To perform the following installation requires a vocational
training (electrician, electrical engineer) and some years of
experience.
- Make sure the standard and legal prescriptions are adhered to
during the installation, putting into service and maintenance.
All procedures must be carried out in strict compliance to the
rules of good working practice and safety at the work site.
- Please read this instruction manual and plan the work before
starting the installation.
- Strictly follow the information given in this instruction manual.
- Pay special attention to the danger notes as indicated in this
manual by the following symbol:
- Check and ensure that the personnel operating the apparatus
have the instruction manual at hand, as well as the necessary
information for correct installation.
- Before starting the retrofit upgrade the switchgear must be de-
energized. The switchgear is de-energized by operating the
switches to disconnected position.
- Check that all mechanism springs are discharged. If in doubt,
close and open the switch.
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 2/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
Sikkerhetsinstruks!
- Sørg for at installasjon, idriftsettelse og vedlikehold er utført
av kvalifisert personell som har kjennskap til utstyret som blir
installert. Vedkommende må også kjenne til prosedyrer som
er beskrevet i dette installasjonsheftet.
- For å utføre følgende installasjon kreves yrkesfaglig erfaring
som elektriker, elektroingeniør eller liknende.
- Sørg for at sikkerheten rundt installasjonsarbeidet er ivaretatt
i henhold til nasjonale normer og forskrifter. Arbeidet utføres
av en fagperson.
- Les manualen nøye før arbeidet påbegynnes.
- Utfør installasjonen nøyaktig som beskrevet i denne
manualen.
- Vær spesielt nøye med å lese og følge anvisninger når det er
indikert med fare symbolet:
- Sørg for at betjeningspersonell har dette installasjonsheftet
og har fått nødvendig informasjon når de betjener det
installerte utstyret.
- Før installasjonen påbegynnes, sørg for at avgangen det skal
jobbes på er strømløs og at bryterne er utkoblet.
- Alle fjærer på mekanismene må være avspent. For å forsikre seg
om dette kan bryteren lukkes og åpnes.
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 3/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
Installation procedure
The pictures and drawings are for an F module, but this document is also valid for C and Sl modules
with latched mechanism
Bilder og tegninger er av et F-felt, men dette dokumentet er også gyldig for C- og Sl-felt med forspent
fjær
Operating
springs
not charged
Koblingsfjærer
ikke forspent
Operating
springs
charged
Koblingsfjærer
forspent
Operating
springs
not charged
Operating
springs
charged
Koblingsfjærer
ikke forspent Koblingsfjærer forspent
Used until May 2007
Brukt inntil mai 2007 Existing front covers
Dagens frontdeksler
1. Operate the switch-fuse-disconnector to open position
Betjen lastbryteren til utkoblet stilling
2. Verify that the operating springs are not charged
Kontroller at koblingsfjærene ikke er forspente
3. Operate the earthing switch to closed position
Betjen jordslutter til innkoblet posisjon
4. Unscrew the fixing screw and remove the upper front cover
Løsne festeskruen og fjern det øvre frontdekselet
5. Open the lower front cover
Åpne det nedre frontdekselet
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 4/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
6
*
6. Unscrew and remove the bracket for capacitive voltage indication
Skru av braketten for kapasitiv spenningsindikering
*Depending on SafeRing / SafePlus production year, the position
indicator may be different compared to the drawing above. Please
refer to Appendix A, if your position indicator is different
*Avhengig av når SafeRing / SafePlus anlegget er produsert, kan
stillingsindikeringen være forskjellig fra tegningen over. Hvis dette er
tilfelle, vennligst se Appendix A for eldre stillingsindikatorer
7. Unscrew and remove the padlock bracket
Skru av hengelåsbraketten
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 5/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
8. Unscrew and remove the bracket for the push buttons
Skru av braketten for trykknapper
9
9. Snap on protection on the edges of the mechanism to avoid
damage of wires
Monter kantbeskyttelse på mekanismen for å unngå skade på
ledninger
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 6/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
10.Pull the position indicator maximum 2 mm out and fit the bracket for the
auxiliary switch marked S7 behind the camshaft, as shown in the picture
Fix the auxiliary switch with 2 pieces of M4x10 screws
Dra ut stillingsindikeringen maksimalt 2 mm og vipp braketten med
signalvenderen merket S7 bak kamakselen, som vist in på bildet
Fest signal-venderen med 2 stk M4x10 skruer
11.Fix the bracket for the terminals marked X1 to the mechanism with
2 pieces of M6x10 screws
Fest braketten med rekkeklemmene merket X1 til mekanismen med
2 stk M6x10 skruer
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 7/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 8/15
12.Fix the opening coil marked Y1 to the mechanism using a lock
washer and 2 pieces of M5x10 screws
Snap on electrical connections X4 to terminals X1
Strap wires away from moving parts
Fest utspolen Y1 til mekanismen ved hjelp av en låseskive og 2
stk M5x10 skruer
Koble hurtigkobling X4 til rekkeklemme X1
Strips ledningene vekk fra bevegelige deler
X1
M5x10
12
Lock washer
Låseskive
S7
Y1

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
13.Re-place the bracket for the push-buttons, which was removed during step 8
Skru fast braketten med trykknapper som ble fjernet i punkt 8
14.Re-place the padlock bracket, which was removed during step 7
Skru fast hengelåsbraketten som ble fjernet under punkt 7
X1
S7
S10
15.Re-place the bracket for the capacitive voltage indication
Sett tilbake braketten for den kapasitive spenningsindikatoren
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 9/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
16.Re-place and fix the front covers
Sett tilbake og fest frontdekslene
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 10/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
Appendix A
Y
1
S7
Y
1
S7
Used until December 2002
Brukt inntil desember 2002
Used until May 2007
Brukt inntil mai 2007
7. Unscrew and remove the position indicator
Skru av stillingsindikeringen
8. Unscrew and remove the padlock bracket
Skru av hengelåsbraketten
9. Unscrew and remove the bracket for push buttons
Skru av og fjern braketten for trykknappene
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 11/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
10
10. Snap on protection on the edges of the mechanism to avoid
damage of wires
Monter kantbeskyttelse på mekanismen for å unngå skade på
ledninger
Y
1
X1
S7
M4x10
11. Fix the bracket for auxiliary switch S7 using 2 pieces of M4x10
Fest braketten med signalvender S7 med 2 stk M4x10
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 12/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
X1
12
M6x10
S7
12.Fix the bracket with terminals marked X1 to the mechanism using
2 pieces of M6x10 screws
Skru fast braketten med rekkeklemmer merket X1 til mekanismen
med 2 stk M6x10 skruer
X1
M5x10
Lock washer
Låseskive 13
S7
13.Fix the opening coil marked Y1 to the mechanism using a lock
washer and 2 pieces of M5x10 screws
Snap on electrical connections X4 to terminals X1
Strap wires away from moving parts
Fest utspolen Y1 til mekanismen ved hjelp av en låseskive og
2 stk M5x10 skruer
Koble hurtigkobling X4 til rekkeklemme X1
Strips ledningene vekk fra bevegelige deler
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 13/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
14.Re-place the bracket for the push-buttons, which was removed
during step 9
Skru fast trykknappenes brakett som ble fjernet i punkt 9
15.Re-place the padlock bracket, which was removed during step 8
Skru fast hengelåsbraketten som ble fjernet under punkt 8
16.Re-place the bracket for capacitive voltage indicator
Sett tilbake braketten for kapasitiv spenningsindikator
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 14/15

We reserve all rights in this document and in the information contained therein: Reproduction, use or disclosure to third
parties without express authority is strictly forbidden. © ABB Technology Ltd.
Cog wheel arrow
shall point to the
straight line
Pilen i tannhjulet
skal peke mot
den rette linjen
17.Fix the position indicator
Skru fast stillingsindikatoren
18.Re-place and fix the front covers
Sett tilbake og fest frontdekslene
ABB ABB Technology Ltd. Edition
1.0 Document No. 1VDD200027 Sheet No. 15/15
