HP E1403C and HP E1407A
C-Size Active Adapter Module
Installation and User’s Manual
HP 75000 Series C

Manual Part Number: E1403-90034
Printed in U.S.A. E0397
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents
Contents 1
Warranty .......................................................................................................................3
Safety Symbols .............................................................................................................4
WARNINGS.................................................................................................................4
Declaration of Conformity............................................................................................5
Reader Comment Sheet ................................................................................................7
Chapter 1
General Information ......................................................................................................9
Introduction...................................................................................................................9
C-Size Adapter Description..........................................................................................9
HP E1403C Adapter Description ..........................................................................9
HP E1407A Adapter Description ........................................................................10
Chapter 2
Installation/Removal Instructions ..............................................................................11
Preparing for Installation ............................................................................................11
Installing A-Size VMEbus Modules (HP E1403C Only)...........................................11
Installing an Adapter Module with a B-Size VXIbus Module ...................................12
Removing the Adapter Module and B-Size Module ..................................................15
Chapter 3
Using the Adapters ......................................................................................................17
HP E1403C Block Diagram........................................................................................17
HP E1403C Connector Pinout....................................................................................18
HP E1407A Block Diagram .......................................................................................19
HP E1407A Connector Pinout....................................................................................20
Installing the J2 Connector Cable (HP E1407A Only)...............................................21
Purpose of the J2 Cable .......................................................................................21
Install the J2 Cable ..............................................................................................21
Ribbon Cable (J2) Connector Pinout ..................................................................23
Selecting the TTL Trigger Direction (HP E1407A Only)..........................................24
Selecting the ECL Trigger Direction (HP E1407A Only)..........................................25
SUMBUS Configurations (HP E1407A Only)...........................................................26
Disconnecting the SUMBUS ..............................................................................26
Adding Buffer Circuitry to the SUMBUS ...........................................................26
Appendix A
HP E1403C and HP E1407A Specifications ..............................................................27
Product Characteristics...............................................................................................27
Power Requirements...................................................................................................27
Cooling Requirements ................................................................................................27
Index ................................................................................................................................29
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2 Contents
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
Certification
Hewlett-Packard Company certifies that this product met its published specifications at the time of shipment from the factory. Hewlett-
Packard further certifies that its calibration measurements are traceable to the United States National Institute of Standards and
Technology (formerly National Bureau of Standards), to the extent allowed by that organization’s calibration facility, and to the
calibration facilities of other International Standards Organization members.
Warranty
This Hewlett-Packard product is warranted against defects in materials and workmanship for a period of three years from date of shipment.
Duration and conditions of warranty for this product may be superseded when the product is integrated into (becomes a part of)other HP
products. During the warranty period, Hewlett-Packard Company will, at its option, either repair or replace products which prove to be
defective.
For warranty service or repair, this productmust be returned to a service facility designated by Hewlett-Packard (HP). Buyer shall prepay
shipping charges to HP and HP shall pay shipping charges to return the product to Buyer. However, Buyer shall pay all shipping charges,
duties, and taxes for products returned to HP from another country
HP warrants that its software and firmware designated by HP for use with a product will execute its programming instructions when
properly installed on that product. HP does not warrant that the operation of the product, or software, or firmware will be uninterrupted
or error free.
Limitation Of Warranty
The foregoing warranty shall not apply todefects resulting from improper or inadequate maintenance by Buyer, Buyer-supplied products
or interfacing, unauthorized modification or misuse, operation outside of the environmental specifications for the product, or improper
site preparation or maintenance.
The design and implementation of any circuit on this product is the sole responsibility of the Buyer. HP does not warrant the Buyer’s
circuitry or malfunctions of HP products that result from the Buyer’s circuitry. In addition, HP does not warrant any damage that occurs
as a result of the Buyer’s circuit or any defects that result from Buyer-supplied products.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. HP SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES. HP SHALL NOT BE LIABLE FOR
ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT,
TORT, OR ANY OTHER LEGAL THEORY.
Notice
The information contained in this document is subject to change without notice. HEWLETT-PACKARD (HP) MAKES NO
WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. HP shall not be liable for errors
contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material. This
document contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company. HP assumes
no responsibility for the use or reliability of its software on equipment that is not furnished by HP.
U.S. Government Restricted Rights
The Software and Documentation have been developed entirely at private expense. They are delivered and licensed as "commercial
computer software" as defined in DFARS 252.227- 7013 (Oct 1988), DFARS 252.211-7015 (May 1991) or DFARS 252.227-7014
(June 1995), as a "commercial item" as defined in FAR 2.101(a), or as "Restricted computer software" as defined in FAR 52.227-19
(June 1987)(or any equivalent agency regulation or contract clause), whichever is applicable. You have only those rights provided for
such Software and Documentation by the applicable FAR or DFARS clause or the HP standard software agreement for the product
involved
HP E1403C/E1407A User’s Manual
Edition 4
Copyright © 1997 Hewlett-Packard Company. All Rights Reserved.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
Safety Symbols
Instruction manual symbol affixed to
product. Indicates that the user must refer to
the manual for specific WARNING or
CAUTION information to avoid personal
injury or damage to the product.
Alternating current (AC)
Instruction manual symbol affixed to
product. Indicates that the user must refer to
the manual for specific WARNING or
CAUTION information to avoid personal
injury or damage to the product.
Indicates the field wiring terminal that must
be connected to earth ground before
operating the equipmentÅprotects against
electrical shock in case of fault.
Direct current (DC).
Indicates hazardous voltages.
or Frameor chassisgroundterminal—typically
connects to the equipment's metal frame.
WARNING Calls attention to a procedure, practice, or
condition that could cause bodily injury or
death.
CAUTION Calls attention to a procedure, practice, or
conditionthatcouldpossiblycausedamageto
equipment or permanent loss of data.
WARNINGS
The following general safety precautions must be observed during all phases of operation, service, and repair of this product. Failure to
comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and
intended use of theproduct. Hewlett-Packard Company assumes no liability for the customer's failure to comply with these requirements.
Ground the equipment: For Safety Class 1 equipment (equipment having a protective earth terminal), an uninterruptible safety earth
ground must be provided from the mains power source to the product input wiring terminals or supplied power cable.
DO NOT operate the product in an explosive atmosphere or in the presence of flammable gases or fumes.
For continued protection against fire, replace the line fuse(s) only with fuse(s) of the same voltage and current rating and type. DO NOT
use repaired fuses or short-circuited fuse holders.
Keep away from live circuits: Operating personnel must not remove equipment covers or shields. Procedures involving the removal of
covers or shields are for use by service-trained personnel only. Under certain conditions, dangerous voltages may exist even with the
equipment switched off. To avoid dangerous electrical shock, DO NOT performprocedures involving cover or shield removal unless you
are qualified to do so.
DO NOT operate damaged equipment: Whenever it is possible that the safety protection features built into this product have been
impaired, either through physical damage, excessive moisture, or any other reason, REMOVE POWER and do not use the product until
safe operation can be verified by service-trained personnel. If necessary, return the product to a Hewlett-Packard Sales and Service Office
for service and repair to ensure that safety features are maintained.
DO NOT service or adjust alone: Do not attempt internal service or adjustment unless another person, capable of rendering first aid and
resuscitation, is present.
DO NOT substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install substitute parts
or perform any unauthorized modification to the product. Return the product to a Hewlett-Packard Sales and Service Office for service
and repair to ensure that safety features are maintained.
Documentation History
All Editions and Updates of this manual and their creation date are listed below. The first Edition of the manual is Edition 1. The Edition
number increments by 1 whenever the manual is revised. Updates, which are issued between Editions, contain replacement pages to
correct or add additional information to the current Edition of the manual. Whenever a new Edition is created, it will contain all of the
Update information for the previousEdition. Each new Edition or Update also includes a revised copy of this documentation history page.
Edition 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .May 1993
Edition 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . January 1995
Edition 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . December 1996
Edition 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . March 1997
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
Declaration of Conformity
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name: Hewlett-Packard Company
Loveland Manufacturing Center
Manufacturer’s Address: 815 14th Street S.W.
Loveland, Colorado 80537
declares, that the product:
Product Name: A/B to C-Size Active Adapter
Model Number: HP E1403C/HP E1407A
Product Options: All
conforms to the following Product Specifications:
Safety: IEC 1010-1 (1990) Incl. Amend 1 (1992)/EN61010-1 (1993)
CSA C22.2 #1010.1 (1992)
UL 3111-1 (1994)
EMC: CISPR 11:1990/EN55011 (1991): Group1 Class A
EN50082-1:1992
IEC 801-2:1991: 4kVCD, 8kVAD
IEC 801-3:1994: 3 Vm
IEC 801-4:1988: 1 kV Power Line, 0.5 kV Signal Lines
ENV50141: 1993/prEN50082-1 (1995): 3 Vrms
ENV50142: 1994/prEN50082-1 (1995): 1 kVCM, 0.5 kVDM
IEC1000-4-8:1993/prEN50082-1 (1995): 3 A/m
EN61000-4-11: 1994/prEN50082-1 (1995): 30%, 10ms 60%, 100 ms
Supplementary Information: The product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/EEC (inclusive 93/68/EEC) and carries the "CE" marking accordingly.
Tested in a typical configuration in an HP C-Size VXI mainframe.
May 1, 1996
European contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH, Depart-
ment HQ-TRE, Herrenberger Straße 130, D-71034 Böblingen, Germany (FAX [phone])
Jim White, QA Manager
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
Notes:
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

General Information 9Chapter 1
Chapter 1
General Information
Introduction
The manual is separated into the following chapters.
Chapter 1 - General Information. Describes the different adapters.
Chapter 2 - Installation/Removal Instructions. This chapter shows how
to install/remove B-Size VXIbus modules into/from the HP E1403C or
HP E1407A C-Size Adapter Module, and how to install/remove the adapter
module into a C-Size VXIbus Mainframe.
Chapter3 -Usingthe Adapters. This chaptershows how touse the adapter
modules. It includes a block diagram for both the HP E1403C and
HP E1407A Adapter Modules. The chapter also includes, for the
HP E1407A Adapter Module, instructions on how to use and install the J2
Connector Cable, how to select the direction (to or from the mainframe’s
backplane) of the trigger signals on theECL and TTL trigger lines, and how
to select unbuffered or buffered SUMBUS connections. Connector pinout
diagrams for both the HP E1403C and HP E1407A are also provided.
Appendix A - Specifications. This appendix details specifications for the
HP E1403C and HP E1407A C-Size Adapter Module.
C-Size Adapter Description
The HP E1403C and HP E1407A Adapter Modules allow an A- or B-Size
VMEbus/VXIbus module to connect to a C-Size VXIbus Mainframe. The
regular adapters connect a single slot VMEbus/VXIbus module to the
mainframe. Option 10 connects two-slot modules to the mainframe
(however, it only connects the module to the P1 and/or P2 connector of only
one slot). The following gives the features of the adapters.
HP E1403C Adapter
Description Use this adapter to make buffered connections between an A-size or B-size
module’s J1 connector and the mainframe’s P1 connector. The adapter has
the following features:
•Mounts with the VMEbus/VXIbus module’s front panel flush with the
front of the adapter.
•Provides direct access to the VMEbus/VXIbus module’s front panel
I/O connections.
•Provides connections to the J1 connector with pin-to-pin compatibility
to the mainframe’s P1 connector.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 General Information Chapter 1
•Meets VMEbus driving and loading specifications.
•Provides proper timing for data Transfer Acknowledgment (DTACK)
and Interrupt Signals (IRQ).
•Provides connectivity for HP B-size modules or any P1-only VXIbus
slave module (Bus Master signals are not provided. These include:
BBSY*, BLCR*, BR0*, BR1*, BR2*, BR3*, SERCLK, SERDAT.)
HP E1407A Adapter
Description Use this adapter to make buffered connections between an A-size or B-size
module’s J1 connector and the mainframe’s P1 connector, and buffered
connections between aB-size module’s J2 connector and the mainframe’s P2
connector. The adapter has the following features:
•Mounts with the VMEbus/VXIbus module’s front panel flush with the
front of the adapter.
•Provides direct access to the VMEbus/VXIbus module’s front panel
I/O connections.
•Provides connections to the J1 connector with pin-to-pin compatibility
to the mainframe’s P1 connector.
•Provides direct connections to the J2 connector with pin-to-pin
compatibility to the mainframe’s P2 connector.
•Provides buffered data, address, and trigger lines (either ECL or TTL).
•Provides direct SUMBUS connections, or provides fused±12V power
supply connections to add user provided circuitry (op-amps, for
example) for buffered SUMBUS connections (jumper selectable).
•Provides access to the pins on the outer rows of the J2 connector for
VME modules. These pins may be isolated from the backplane.
•Meets VMEbus driving and loading specifications.
•Provides proper timing for data Transfer Acknowledgment (DTACK)
and Interrupt Signals (IRQ).
•Provides connectivity for HP B-size modules or any P1-only VXIbus
slave module (Bus Master signals are not provided. These include:
BBSY*, BLCR*, BR0*, BR1*, BR2*, BR3*, SERCLK, SERDAT.)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Installation/Removal Instructions 11Chapter 2
Chapter 2
Installation/Removal Instructions
This chapter shows how to install/remove B-sizeVXIbus modules into/from
the HP E1403C or HP E1407A C-Size Adapter Module, and how to
install/remove the adapter module into a C-Size VXIbus Mainframe.
Note The procedures in this chapter shows installation/removal of the Adapter
Module into/from the HP E1401A High Power Mainframe. The
procedures for other mainframes are similar to these procedures.
Preparing for Installation
•Be sure to set the logical address of the module to be installed into the
adapter to the correct address (see the module manual).
•Be sure to use clean handling and anti-static handling of the module.
•Be sure there are no external connections to the modules.
Installing A-Size VMEbus Modules (HP E1403C Only)
Install A-Size VMEbus Modules only in the HP E1403C Adapter Module.
Use the following B-Size Module installation procedure to install an A-Size
Module into the adapter module.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12 Installation/Removal Instructions Chapter 2
Installing an Adapter Module with a B-Size VXIbus
Module
The procedure starting on the nextpage shows how to install an HP E1403C
or HP E1407A C-Size Adapter Module into an HP E1401A Mainframe.
(Theinstallationproceduresforothermainframesissimilar.) Theprocedure
then shows how to install a B-Size VXIbus Module into the adapter module.
Note During power-up, the resource manager recognizes a module in the slot
with the HP E1403C or HP E1407A Adapter Module installed with or
without a B-Size module installed in the adapter module. Thus, to prevent
any error generation, be sure a B-Size module is installed in the adapter
module before power-up.
1Line up the C-Size Adapter Module’s Rails with the Module Guides of an Empty
Slot in the Mainframe.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Installation/Removal Instructions 13Chapter 2
Slide the C-Size Adapter Module into the Mainframe.
2
3Line up the B-Size Module with the C-Size Adapter Module’s Front Slot and the
Mainframe’s Module Guides.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14 Installation/Removal Instructions Chapter 2
4Slide the B-Size Module into the C-Size Adapter Module.
Tighten the B-Size Module’s Upper and Lower Retainer Screws.
5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Installation/Removal Instructions 15Chapter 2
Removing the Adapter Module and B-Size Module
The following procedure shows how to remove a B-Size VXIbus Module
from an HP E1403C or HP E1407A C-Size Adapter Module and the adapter
module from the mainframe.
Continued on Next Page
Loosen the Upper and Lower Retainer Screws of the B-Size Module inside the
C-Size Adapter Module.
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16 Installation/Removal Instructions Chapter 2
UsingthehandlesontheB-SizeModule,pulltheModuleoutoftheC-SizeAdapter
Module.
2
NOTE:
When removing the B-size
Module from the Adapter
Module, the Adapter Module
may be pulled out of the
mainframe. If that happens,
carefullypull theB-sizeModule
out of the Adapter Module,
withoutdamaginganyexposed
components on the B-size
Module.
Using the “D” Ring, pull the C-Size Adapter Module out of the Mainframe.
3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Using the Adapters 17Chapter 3
Chapter 3
Using the Adapters
This chapter shows how to use the adapter modules. It includes a block
diagram for both the HP E1403C and HP E1407A Adapter Modules as well
as connector pinouts. This chapter also includes, for the HP E1407A
Adapter Module, instructions on how to use and install the J2 connector
cable, how to select the direction (to or from the mainframe’s backplane) of
the trigger signals on the ECL and TTL trigger lines, and how to select
unbuffered or buffered SUMBUS connections.
HP E1403C Block Diagram
Figure 3-1 shows the block diagram for the HP E1403C C-Size Adapter
Module.
Figure 3-1. HP E1403C Block Diagram
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18 Using the Adapters Chapter 3
HP E1403C Connector Pinout
Figure 3-2 shows the P1 and J1 connector’s pinout for the HP E1403C
Adapter Module.
Figure 3-2. HP E1403C P1 and J1 Connector Pinout
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Using the Adapters 19Chapter 3
HP E1407A Block Diagram
Figure 3-3 shows the block diagram for the HP E1407A C-Size Adapter
Module.
Figure 3-3. HP E1407A Block Diagram
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
