SimpliFire GI-32-ZC User manual

1
SimpliFire • IS-36-GI32, IS-42-GI32 Installation Insructions • 2048-922 Rev. B • 10/22
IS-36-GI32, IS-42-GI32
Model: GI-32-ZC
Installation Instructions -
INTRODUCTION
The surround is an optional nishing method of the GI-32-
ZC. The surround is designed to overlap the opening of
the existing replace or constructed chase.
Leave this manual with party responsible for use
and operation.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
SURROUND KIT COMPONENTS
• (1) Top
• (1) Left Side
• (1) Right Side
• (1) Bottom
• (12) ST4X8 Screws
TOOLS NEEDED
• Magnetic Phillips Screwdriver
CAUTION! Do not install damaged components.
Surround Assembly
1. Remove the kit components from the packaging.
2. Attached Right and Left Sides to the Top using 8
screws. See Figure 2.
3. If 4-Sided surround is desired, leave the bottom side
unattached, and proceed to Surround Installation.
ATTACH USING
FOUR (4) SCREWS
Figure 2 Surround Assembly
Figure 1 Surround Components
TOP
LEFT SIDE
RIGHT SIDE
BOTTOM
IF 4-SIDED SURROUND, WAIT TO ATTACH THE BOTTOM
UNTIL AFTER THE 3-SIDED ASSEMBLY HAS BEEN
INSTALLED ONTO THE APPLIANCE.

SimpliFire • IS-36-GI32, IS-42-GI32 Installation Insructions • 2048-922 Rev. B • 10/222
Figure 3 3-Sided Surround Installation
3-SIDED SURROUND INSTALLATION
Figure 4 4-Sided Surround Installation
1. Slide the assembled 3-sided suround over the top of
the appliance behind the appliance side anges. See
Figure 3.
2. Secure the surround to the appliance side anges in
four (4) locations with the sheetmetal screws pro-
vided with the surround. The screws will be installed
from the rear of the appliance. Note, leave the 4 larger
holes empty as they may be used for attaching the appli-
ance to framing. See Figure 3.
Surround Installation 3. (Optional) If the optional bottom is to be used.
align the bottom surround piece, with the bottom
of the installed 3-sided surround. Attach the bottom
with four (4) screws provided with the surround. See
Figure 4.
4. Secure the surround to the appliance side anges in
four (4) locations with the screws provided with the
surround. The screws will be installed from the rear of
the appliance. See Figure 3.
FOUR (4) SCREWS
4-SIDED SURROUND INSTALLATION
FOUR (4) SCREWS

3
SimpliFire • IS-36-GI32, IS-42-GI32 Installation Insructions • 2048-922 Rev. B • 10/22
SimpliFire, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
Please contact your SimpliFire dealer
For the location of your nearest SimpliFire dealer,
please visit www.hearthnhome.com.
W
H1
H2
Figure 5 Surround Dimensions
MODEL SURROUND
SIZE
SURROUND
SKU
WIDTH 3-SIDED
H1
4-SIDED
H2
SURROUND
DEPTH
W
GI-32-ZC
SMALL IS-36-GI32 In. 36-1/2 27-1/4 31-1/4 13/16
mm 927 692 794 20
LARGE IS-42-GI32 In. 42-1/2 28-3/4 32-3/4 13/16
mm 1080 730 832 20
