Simrad PI REMOTE - REV A User manual

CATCH MONITORING
PI Spread and Remote sensors
MAXIMIZING YOUR PERFORMANCE AT SEA
www.simrad.com
Check the trawl doors!
This dynamic duo tells you the exact
distance between the trawl doors.
Used on bottom and pelagic trawls the
Spread and Remote sensors provide
crucial information about your trawl
behaviour. On a twin trawl, simply add
a Remote sensor and you have both
openings covered!
?
12
S3 [m]
69.5

Applications
(855-165198 / Rev.A / April 2005)
Specifications
PI Systems: PI32, PI44 or PI54
Update rates:
• Fast: Every 5,5 second (approx.)
• Normal: Every 14 second (approx.)
• Slow: Every 34 second (approx.)
Default update rate: Fast
Lifetime between each recharge:
• Fast update rate: 45 hours
• Normal update rate: 100 hours
• Slow update rate: 150 hours
Communication frequency range: 43,5 to 49,5 kHz
Accuracy: 0,2 %
Maximum range: 350 meters
Physical properties (Spread/Remote):
• Length: 298 / 248 mm
• Width: 149 / 121 mm
• Thickness: 120 / 98 mm
• Weight in water: 2,7 / 1,3 kg
• Weight in air: 5,7 / 2,9 kg
Charging time with PI Charger:
• To 70% capacity: 1 hour
• To 100% capacity: 4 hours
Charging time with PS Charger:
• To 100% capacity: 16 hours
Specifications can be altered without prior notification.
Simrad Horten AS
Strandpromenaden 50
P.O.Box 111
NO-3191 Horten
Norway
Telephone: [phone]
Facsimile: [phone]
MAXIMIZING YOUR PERFORMANCE AT SEA
www.simrad.com
These two sensors always work in pairs.
They are used to monitor the physical
distance between the trawl doors during
bottom and pelagic trawling.
Use a Spread sensor on the port door and a
Remote sensor on the starboard door. Both sensors
are normally mounted in special adapters, but you
may also attached them to the wing-end or warp
using snap hooks or rope.
The Spread sensor communicates with the Remote
sensor using a special transverse communication link.
By means of this link it measures the excact distance
(maximum 350 meters) between the two sensors.
The information is is transmitted to the vessel by the
Spread sensor.
As you already know, correct door spread is
important in order to obtain the correct sweep-angle,
as this ensures optimal trawl performance. Door
behavior and stability during shooting and towing is
also monitored by these sensors. Many regard this
pair of sensors one of the most important sensors to
obtain efficient trawling.
