Simrad AP48 User manual

1. Display unit and removable bezels
2. Micro-C drop cable - 4.5 m (15’)
3. Micro-C T-connector
4. Panel mounting kit
5. Suncover
6. Documentation pack
AP48
INSTALLATION GUIDE
Parts
1
4
5
3
2
ENGLISH
InstallationManual
bandg.com
ENGLISH
InstallationManual
bandg.com
ENGLISH
InstallationManual
bandg.com
ENGLISH
InstallationManual
bandg.com
6

System wiring example
12/24 V
DC
12 V DC
A
UT
O
PI
LO
T
CO
M
PU
TE
R
COMPASS
SPEED / DEPTH
SENSOR
DRIVE UNIT
RUDDER
FEEDBACK
AP48
AUTOPILOT
CONTROLLER
AUTOPILOT
CONTROLLER
Micro-C T-connector Micro-C
terminator, 120 Ohm Micro-C
power cable NMEA 2000
backbone Micro-C drop cable
MASTHEAD
UNIT
GPS
SENSOR
T
T
T
MULTIFUNCTION
DISPLAY

=IPX7
-25°C to +65ºC
-13°F to +149 ºF
177.0mm
(6.97")
56.1mm
(2.21")
23.1mm
(0.91") 33.0mm (1.30")
55.4mm
(2.18")
115.0mm
(4.53")
Mounting Mounting
204.8mm
(8.06")
56.1mm
(2.21")
55.4mm
(2.18")
84.6mm
(3.33")
124.5mm
(4.90")
2
4
1
Dimensions with bracket (sold separately)
3
Dimensions
2
4
1
3
=IPX7
-25°C to +65ºC
-13°F to +149 ºF
