Sinoboom TB24E Plus User manual

TB24E Plus/TB800E Plus
TB26EJ Plus/TB860EJ Plus
TB26E Plus/TB850E Plus
TB28EJ Plus/TB910EJ Plus
Operation
Manual
Part No.514004100002
Rev: A
Oct 2021
GTJZ
0608E (2132E)
GTJZ
0808E (2732E)
GTJZ
0808E (2732E)
GTJZ
0808E (2732E)
长沙市宁乡高新技术产业园区金洲大道东
128 号
0731-87116111 hr@sinoboom . c om . cn ww w .sinoboom . c om . cn
Al w ays F or B e t t er A cc ess Solution s
我们一直在追求新的高 度
尺寸 ：
210×285mm
20mm
20mm
产品说明书
PRODU C T MAN U AL

Operating, servicing and maintaining this vehicle or
equipment can expose you to chemicals including engine
exhaust, carbon monoxide, phthalates, and lead, which
are known to the State of California to cause cancer and
birth defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the engine
except as necessary, service your vehicle or equipment in
a well-ventilated area and wear gloves or wash your
hands frequently when servicing. For more information
go to: www.P65warnings.ca.gov.

Please contact us:
Website : www.sinoboom.com
E-mail : [email protected]
Sales Tel : [phone]
Service Tel : [phone]
Address : No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha,
Hunan, China
Zip Code : 410600
Copyright © Hunan Sinoboom Intelligent Equipment Co., Ltd. All Rights Reserved
The final interpretation right of this manual belongs to Hunan Sinoboom Intelligent Equipment Co., Ltd.
Manual revision history：
REV DATE DESCRIPTION REMARK
AOct. 2021 Original issue

APPLICATION
Use the following table to identify the specific serial number for
models included in this manual. Check the model of your machine before
consulting the manual, and then use the correct manual according to the
serial number of the model. See the nameplate on your machine to
identify the model and serial number.(See Decals/Nameplate Inspection
of the Operation Manual for details.)
Model
Trade Identification
Serial No.
Metric Imperial
TB24E Plus TB24E Plus TB800E Plus From 1400300100 to present
TB26EJ Plus TB26EJ Plus TB860EJ Plus From 1400400100 to present
TB26E Plus TB26E Plus TB860E Plus From 1401100100 to present
TB28EJ Plus TB28EJ Plus TB910EJ Plus From 1400700100 to present
NOTE:
•Product model is applied in product nameplate for distinction of products of different main
parameters.
•Product trade identification is applied in marketing and machine decals for distinction of products of
different main parameters, and can be classified as metric type and imperial type: The metric type of
trade identification is applicable to machines for countries/regions using metric system or as
specially required by customers; The imperial type of trade identification is applicable to the
machines for countries/regions using imperial system or as specially required by customers.

This Page Intentionally Left Blank

STATEMENTS
Hunan Sinoboom Intelligent Equipment Co., Ltd. (Hereinafter referred to as Sinoboom) will upload the
latest product manual information to the website www. sinoboom. com as soon as possible. However,
due to continuous product improvement, the information in this manual is subject to change without prior
notice.
This manual covers the basic parts information of one or more products. Therefore, please use this
manual according to your needs. If you find problems in the manual or have suggestions for improve-
ment, feel free to share your feedback with Sinoboom, and we will address these issues as soon as
possible.
Feel free to consult and download the Operation Manual,Maintenance Manual and Parts Manual of the
products you need online at www.sinoboom.com.
Hunan Sinoboom Intelligent Equipment Co., Ltd. retains the right of final interpretation of the manual.

This Page Intentionally Left Blank

TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual i© Oct 2021
TABLE OF CONTENTS
Introduction ............................. iii
1 Machine Specifications ........ 1-1
2 Machine Components .......... 2-1
3 Safety............................... 3-1
Safety Definitions . . . . . . . . .. . . . . . . . . . . . 3-1
Reporting Accidents. . . . . . . . . . . . . . . . . . . 3-1
Electrocution Hazards. . . . . . . . . . . . . . . . . 3-2
Tipping Hazards and Rated Load . . . . . 3-2
Jobsite Hazards . . . . . . . . . . . . . . . . . .. . . . . 3-4
Unsafe Operation Hazards. . . . . . . . . . . . 3-6
FallHazards...........................3-7
Collision Hazards . . . . . . . . . . . . . . . . . . . . . 3-7
Crush Hazards . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Explosion and Fire Hazards. . . . . . . . . . . 3-9
Damaged Machine Hazards . . . . . . . . . . 3-9
Bodily Injury Hazards . . . . . . . . . . . . . . . . . 3-9
Battery Hazards . . . . . . . . . . . . . . . . . .. . . .3-10
Hydraulic Hazards . . . . . . . . . . . . . . . . . . .3-12
Welding and Polishing Requirements3-12
After Using the Machine. . . . . . . . . . . . . .3-12
4 Jobsite Inspection............... 4-1
5 Pre-operation Inspection ...... 5-1
Tips for Conducting a Pre-operation
Inspection.............................5-1
Inspecting Parts . . . . . . . . . . . . . . . . . .. . . . . 5-2
Inspecting Entire Machine . . . . . . . . . . . . 5-2
Inspect Hydraulic Oil Level. . . . . . . . . . . . 5-2
Inspecting the Battery . . . . . . . . . . . . . . . . . 5-3
6 Pre-operation Function Test .. 6-1
Preparing for a Pre-operation
Function Test. . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Testing the Ground Controller . . . . . . . . . 6-1
Testing the Platform Controller . . . . . . . . 6-6
Testing the Drive Speed. . . . . . . . . . . . . .6-12
Testing the Emergency Lowering
Function..............................6-12
Testing the Tilt Protection System. . . .6-13
Testing the Envelope Restriction . . . . .6-13
Testing the Weighing System . . . .. . . .6-14
7 Operating the Machine ......... 7-1
Stability................................7-1
Emergency Stop . . . . . . . . . . . . . . . . . . . . . . 7-3
Emergency Lowering . . . . . . . . . . . . . . . . . 7-4
Emergency Operating. . . . . . . . . . . . . . . . . 7-4
Emergency Towing/Dragging . . . . . . . . . 7-4
Operation from Ground . . . . . . . . . . . . . . . 7-5
Operation from Platform . . . . . . . . . . . . . . 7-6
Driving on a Slope. . . . . . . . . . . . . . . . . . . . . 7-7
Charging the Battery . . . . . . . . . . . . . . . . . . 7-8
8 Transporting and Lifting the
Machine........................... 8-1
Lifting the Machine with a Crane . . . . . . 8-2
Transporting the Machine . . . . . . . . . . . . . 8-3
9 Decals/Nameplates Inspection9-1
Decals/Nameplates(GB). . . . . . . . . . . . 9-2
Decals/Nameplates(CE-Metric) . . . . 9-5
Decals/Nameplates(CE-Imperial) . . 9-8
Decals/Nameplates(ANSI). . . . . . . . . 9-11
Decals/Nameplates (CSA) . . . . . . . .9-14
10 Maintenance.................... 10-1
Conducting a Pre-delivery Inspection 10-1
Following a Maintenance Schedule . .10-2
Completing a Repair & Inspection
Report................................10-2
Appendix 1: Symbols and
Description.......................A-1

© Oct 2021 ii TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual
Appendix 2: Prepare the Work
Record Before Delivery ....... A-3
Appendix 3: Repair & Inspection
Report .............................A-5

TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual iii © Oct 2021
INTRODUCTION
Thank you for choosing and using the machinery of
Hunan Sinoboom Intelligent Equipment Co., Ltd. Al-
ways read, understand and become familiar with the
operation requirements of the machine and its associ-
ated safety procedures before operating, maintaining
and repairing the machine. Operating the machine with-
out becoming familiar with its specific operation require-
ments and safety procedures poses serious risks.
Operators who follow safety rules and operate the ma-
chine carefully and effectively will prevent personal in-
jury, property loss and accidents.
Use this machine only to transport tools to work loca-
tions and for performing tasks on the work platform. Op-
erators must be competent and must obtain training to
carefully use the machine and follow safety procedures.
Only trained and authorized personnel may operate the
machine.
This manual guides the operator in operating and using
the machine. The operator is responsible for reading,
understanding and implementing the operation and
safety procedures in this manual and for following the
manufacturer’s instructions before beginning any work.
Read, understand and follow all safety rules and oper-
ating instructions. The operator must also consider the
machine’s uses and limitations and the conditions at
the jobsite before using this machine. Strictly following
all safety requirements in this manual is critical.
Consider this manual a part of the machine, along with
Maintenance Manual and Parts Manual, and always
keep the manuals with the machine. The owner or ad-
ministrator of the machine shall offer all manuals and
other necessary information provided by the machine
manufacturer regarding the daily inspection and main-
tenance to each of the renters. If the machine is sold,
the owner or administrator must pass along the man-
uals and other necessary information to the purchaser.
The owner or administrator of the machine shall also
provide the manufacturer’s maintenance information to
the person responsible for maintaining the machine.
If you have any questions, contact Hunan Sinoboom In-
telligent Equipment Co., Ltd..

© Oct 2021 iv TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual
This Page Intentionally Left Blank

TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual 1-1 © Oct 2021
1MACHINE SPECIFICATIONS
Table 1-1 TB24E Plus specifications
MEASURE TB24E Plus (METRIC) TB800E Plus (IMPERIAL)
DIMENSION
Max platform height 24.4m 80ft 0.6in
Max working height 26.4m 86ft 7in
Max horizontal reach (restricted/
unrestricted) 19.18m/21.5m 62ft 11in/70ft 6in
Overall length(stowed) 11.55m 37ft 11in
Overall width(stowed) 2.49m 8ft 2in
Overall height (stowed) 2.88m 9ft 5in
Wheelbase 3m 9ft 10in
Ground clearance 0.36m 1ft 2in
Tire size (spec / type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted) 454 kg (3 people & tools) 1000lb (3 people & tools)
Rated platform capacity
(unrestricted) 300 kg (2 people & tools) 661 lb (2 people & tools)
Turntable rotation / continuous 360°/continuous
Platform rotation 160°
Max drive speed (stowed) 4.8km/h 3mph
Max drive speed (raised) 1.1km/h 0.68mph
Drive mode (drive×steer) 4WD×2WS
Gradeability 45%/24°
Turntable tailswing 1.45m 4ft 9in
Max allowable inclination 5°
Turning radius (inside) 3.65m 12ft
Turning radius (outside) 6.91m 22ft 8in
Max allowable side force(restricted/
unrestricted) 600N/400N 135 lbf/90 lbf

© Oct 2021 1-2 TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual
MACHINE SPECIFICATIONS
Table 1-1 TB24E Plus specifications (continued)
MEASURE TB24E Plus (METRIC) TB800E Plus (IMPERIAL)
Max operating noise level 79dB
IP grade IP65
POWER
Motor (Volts/kW) 53V AC/15 kW
Hydraulic tank capacity 170L 37.4gal (UK)/44.9gal (US)
Hydraulic system pressure 21MPa 3045Psi
Battery (number×voltage, capacity) 2×40V, 480Ah (lead-acid battery)
2×40V, 500Ah (lithium battery)
Power system voltage 80V DC
Control system voltage 12V DC
Charger (input voltage/output
current) 100～240V AC/40 A
GROUND BEARING DATA
Max tire load 9620kg 21208 lb
Pressure against ground 730kPa 105.9Psi
ENVIRONMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280ft
Allowable ambient temperature
(lead-acid battery) -10℃～40℃14℉～104℉
Allowable ambient temperature (-
lithium battery) -20℃～40℃-4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃to 50℃(-4℉to 122℉) in a well-ventilated environment with
90% relative humidity (20℃[68℉]), and away from rain, sun, corrosive
gas,inflammables and explosives.
WEIGHT
Gross weight (unladen) 17589kg 38777 lb
Table 1-2 TB26EJ Plus specifications
MEASURE TB26EJ Plus (METRIC) TB860EJ Plus (IMPERIAL)
DIMENSION
Max platform height 26.3m 86ft 3in
Max working height 28.3m 92ft 10in
Max horizontal reach (restricted/
unrestricted) 18.65m/20.6m 61ft 2in/67ft 7in

MACHINE SPECIFICATIONS
TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual 1-3 © Oct 2021
Table 1-2 TB26EJ Plus specifications (continued)
MEASURE TB26EJ Plus (METRIC) TB860EJ Plus (IMPERIAL)
Overall length(stowed) 12.5m 41ft
Overall width(stowed) 2.49m 8ft 2in
Overall height (stowed) 2.88m 9ft 5in
Wheelbase 3m 9ft 10in
Ground clearance 0.36m 1ft 2in
Tire size (spec / type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted) 454 kg (3 people & tools) 1000lb (3 people & tools)
Rated platform capacity
(unrestricted) 300 kg (2 people & tools) 661 lb (2 people & tools)
Turntable rotation / continuous 360°/continuous
Platform rotation 160°
Max drive speed (stowed) 4.8km/h 3 mph
Max drive speed (raised) 1.1km/h 0.68 mph
Drive mode (drive×steer) 4WD×2WS
Gradeability 45%/24°
Turntable tailswing 1.45m 4ft 9in
Max allowable inclination 5°
Turning radius (inside) 3.65m 12 ft
Turning radius (outside) 6.91m 22ft 8in
Max allowable side force(restricted/
unrestricted) 600N/400N 135 lbf/90 lbf
Max operating noise level 79dB
IP grade IP65
POWER
Motor (Volts/kW) 53V AC/15 kW
Hydraulic tank capacity 170L 37.4gal (UK)/44.9gal (US)
Hydraulic system pressure 21MPa 3045Psi
Battery (number×voltage, capacity) 2×40V, 480Ah (lead-acid battery)
2×40V, 500Ah (lithium battery)

© Oct 2021 1-4 TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual
MACHINE SPECIFICATIONS
Table 1-2 TB26EJ Plus specifications (continued)
MEASURE TB26EJ Plus (METRIC) TB860EJ Plus (IMPERIAL)
Power system voltage 80V DC
Control system voltage 12V DC
Charger (input voltage/output
current) 100～240V AC/40 A
GROUND BEARING DATA
Max tire load 9620kg 21208 lb
Pressure against ground 730kPa 105.9 Psi
ENVIRONMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280ft
Allowable ambient temperature
(lead-acid battery) -10℃～40℃14℉～104℉
Allowable ambient temperature (-
lithium battery) -20℃～40℃-4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃to 50℃(-4℉to 122℉) in a well-ventilated environment with
90% relative humidity (20℃[68℉]), and away from rain, sun, corrosive
gas,inflammables and explosives.
WEIGHT
Gross weight (unladen) 18059kg 39813lb
Table 1-3 TB26E Plus specifications
MEASURE TB26E Plus (METRIC) TB850E Plus (IMPERIAL)
DIMENSION
Max platform height 25.8m 84ft 8in
Max working height 27.8m 91ft 2in
Max horizontal reach (restricted/
unrestricted) 19.18m/21.5m 62ft 11in/70ft 6in
Overall length(stowed) 11.55m 37ft 11in
Overall width(stowed) 2.49m 8ft 2in
Overall height (stowed) 2.88m 9ft 5in
Wheelbase 3m 9ft 10in
Ground clearance 0.36m 1ft 2in
Tire size (spec / type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)

MACHINE SPECIFICATIONS
TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual 1-5 © Oct 2021
Table 1-3 TB26E Plus specifications (continued)
MEASURE TB26E Plus (METRIC) TB850E Plus (IMPERIAL)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted) 454 kg (3 people & tools) 1000lb (3 people & tools)
Rated platform capacity
(unrestricted) 300 kg (2 people & tools) 661 lb (2 people & tools)
Turntable rotation / continuous 360°/continuous
Platform rotation 160°
Max drive speed (stowed) 4.8km/h 3mph
Max drive speed (raised) 1.1km/h 0.68mph
Drive mode (drive×steer) 4WD×2WS
Gradeability 45%/24°
Turntable tailswing 1.45m 4ft 9in
Max allowable inclination 5°
Turning radius (inside) 3.65m 12ft
Turning radius (outside) 6.91m 22ft 8in
Max allowable side force(restricted/
unrestricted) 600N/400N 135 lbf/90 lbf
Max operating noise level 79dB
IP grade IP65
POWER
Motor (Volts/kW) 53V AC/15 kW
Hydraulic tank capacity 170L 37.4gal (UK)/44.9gal (US)
Hydraulic system pressure 21MPa 3045Psi
Battery (number×voltage, capacity) 2×40V, 480Ah (lead-acid battery)
2×40V, 500Ah (lithium battery)
Power system voltage 80V DC
Control system voltage 12V DC
Charger (input voltage/output
current) 100～240V AC/40 A
GROUND BEARING DATA
Max tire load 9620kg 21208 lb
Pressure against ground 730kPa 105.9Psi
ENVIRONMENT

© Oct 2021 1-6 TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual
MACHINE SPECIFICATIONS
Table 1-3 TB26E Plus specifications (continued)
MEASURE TB26E Plus (METRIC) TB850E Plus (IMPERIAL)
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280ft
Allowable ambient temperature
(lead-acid battery) -10℃～40℃14℉～104℉
Allowable ambient temperature (-
lithium battery) -20℃～40℃-4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃to 50℃(-4℉to 122℉) in a well-ventilated environment with
90% relative humidity (20℃[68℉]), and away from rain, sun, corrosive
gas,inflammables and explosives.
WEIGHT
Gross weight (unladen) 17589kg 38777 lb
Table 1-4 TB28EJ Plus specifications
MEASURE TB28EJ Plus (METRIC) TB910EJ Plus (IMPERIAL)
DIMENSION
Max platform height 27.6m 90ft 7in
Max working height 29.6m 97ft 1in
Max horizontal reach (restricted/
unrestricted) 19.4m/20.6m 63ft 3in/67ft 7in
Overall length(stowed) 12.5m 41ft
Overall width(stowed) 2.49m 8ft 2in
Overall height (stowed) 2.88m 9ft 5in
Wheelbase 3m 9ft 10in
Ground clearance 0.36m 1ft 2in
Tire size (spec / type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted) 454 kg (3 people & tools) 1000lb (3 people & tools)
Rated platform capacity
(unrestricted) 300 kg (2 people & tools) 661 lb (2 people & tools)
Turntable rotation / continuous 360°/continuous
Platform rotation 160°

MACHINE SPECIFICATIONS
TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual 1-7 © Oct 2021
Table 1-4 TB28EJ Plus specifications (continued)
MEASURE TB28EJ Plus (METRIC) TB910EJ Plus (IMPERIAL)
Max drive speed (stowed) 4.8km/h 3 mph
Max drive speed (raised) 1.1km/h 0.68 mph
Drive mode (drive×steer) 4WD×2WS
Gradeability 45%/24°
Turntable tailswing 1.45m 4ft 9in
Max allowable inclination 5°
Turning radius (inside) 3.65m 12 ft
Turning radius (outside) 6.91m 22ft 8in
Max allowable side force(restricted/
unrestricted) 600N/400N 135 lbf/90 lbf
Max operating noise level 79dB
IP grade IP65
POWER
Motor (Volts/kW) 53V AC/15 kW
Hydraulic tank capacity 170L 37.4gal (UK)/44.9gal (US)
Hydraulic system pressure 21MPa 3045Psi
Battery (number×voltage, capacity) 2×40V, 480Ah (lead-acid battery)
2×40V, 500Ah (lithium battery)
Power system voltage 80V DC
Control system voltage 12V DC
Charger (input voltage/output
current) 100～240V AC/40 A
GROUND BEARING DATA
Max tire load 9620kg 21208 lb
Pressure against ground 730kPa 105.9 Psi
ENVIRONMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280ft
Allowable ambient temperature
(lead-acid battery) -10℃～40℃14℉～104℉
Allowable ambient temperature (-
lithium battery) -20℃～40℃-4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃to 50℃(-4℉to 122℉) in a well-ventilated environment with
90% relative humidity (20℃[68℉]), and away from rain, sun, corrosive
gas,inflammables and explosives.

© Oct 2021 1-8 TB24E Plus&26EJ Plus&26E Plus&28EJ Plus Operation Manual
MACHINE SPECIFICATIONS
Table 1-4 TB28EJ Plus specifications (continued)
MEASURE TB28EJ Plus (METRIC) TB910EJ Plus (IMPERIAL)
WEIGHT
Gross weight (unladen) 18059kg 39813lb
Note：
a) The working height adds 2m(6ft7in) of human height to platform height。
b) The ground bearing data is approximate value, not factoring the different options,thus it serves only in adequately safe
conditions
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubrication should be added in accordance with the
environmental temperature.
d) In cold weather, auxiliary devices are needed to start the machines.
e) Rated platform capcity represents the rated load of the platform, including the loads of persons, materials, tools, platform
accessories and other objects borne by the platform.
