SkyLink MT-18 User manual

1. INTRODUCTION
Motorcycle Garage Door
Remote Control Model MT-18
2. INSTALLATION
In this package, you will find a transmitter with 12V alkaline battery and a
mounting bracket, a garage door receiver, a red / black wire.
The following instructions will show you how to install the receiver.After
installing, the transmitter (already programmed to the receiver) can be
used to operate your garage door opener.
You need to locate 2 things inside your garage to install the receiver:
1) the wall-mounted door control;
2) an electrical outlet, select an electrical outlet different from the one
already connected to the power cord of the garage door opener to
reduce the chance of interference. The further distance between
the receiver and the garage door opener, the less interference
between 2 devices.
Note: The length of the red/black wire is 20ft, so the receiver must be
plugged into an electrical outlet that is within 20ft of the wall mounted
door control. If there is no electrical outlet within 20ft of the wall mounted
door control, an extension cord can be used for temporary installation.
1Remove the wall-mounted door control from the wall by removing
the screws.Connect the stripped ends of the Red/Black wire to the
2 terminals (2 screws) on the back of the wall mounted door
control. (Polarity does not matter.)
Unplug the power cord of your garage door opener before
installation to ensure power is not connected.
Wall Mounted
Door Control
Electrical
Outlet
2. INSTALLATION (CONT)
2
3
4
5
WARNING
Remove power cord of garage
dooropenerbefore installation.
Red /
Black wire
Note: There should be another
pair of wires connected to the 2
terminals already. Do not remove/
disconnect these existing wires.
Note: If you see no screws mounting the wall mounted door control,
the screws are probably underneath the front cover. Remove the
front cover by pressing onto the tabs on top of the cover.
Remove front
cover first
3. TROUBLE SHOOTING
Q: Door opener does not react after pressing the button on the transmitter ?
A: - Ensure when the button on the transmitter is pressed, the red light on the
bracket comes on. Otherwise, check if the battery is inserted properly.
- If the red light on the receiver flashes when you press the button on the
transmitter, but the door opener does not respond, please ensure the
red/black wire is successfully connected from the receiver to the wall
mounted door control.
- Ensure the wires that are previously connected to the wall mounted door
control are not loose.
- Ensure the transmitter has been programmed to the receiver. Refer
to section 4 for how to program a transmitter to the receiver.
Existing
wires
RED/BLACK WIRE
RECEIVER
Existing wires connected
to garage door opener.
(Do not remove)
Different wall-mounted door controls
Note: Alternative wiring options are available, the receiver can be
connected directly to the opener’s motor. Please contact customer
service for further information regarding alternative wiring options.
Red/Black Wire
Plug in the connector end of the Red/Black wire to the MT-18R
receiver. Note the orientation of the male & female connector.
Plug the receiver into an electrical outlet inside the garage.
The red light on the receiver should be on after being plugged into an
electrical outlet.
Re-connect the power cord of the Garage Door Opener.
The transmitter has been programmed to operate the receiver.
Activate the button on the transmitter will trigger the receiver
therefore opens the garage door.
Garage
Door
Receiver
6The activation switch and its bracket can be installed on the handle-
bar of your motorcycle. Remove the screw from the mounting bracket
and place the cushion (included) between the mounting bracket and
the handlebar. Adjust the tightness of the mounting bracket so it is
securely fastened on the handlebar, then fasten the screw on the
mounting bracket. You may now attach the transmitter unit to your
motorcycle by hook and loop (included). It is recommended to place
the transmitter unit at where it will not be exposed to water.
Activating the switch on the mounting bracket will cause the trans-
mitter to transmit a signal to the receiver.
Keychain
Transmitter
(Battery inside)
Attach the transmitter
on your motorcycle
Mount the bracket
on the handlebar
10
20
30
40 50
6
070
80
90
100
11 0 0
7

If, within one year from date of purchase, this product should become defective
(except battery), due to faulty workmanship or materials, it will be repaired or
replaced, without charge. Proof of purchase and a Return Authorization are required.
10. WARRANTY
You can add up to 15 transmitters as you want to
control the same receiver. Simply program the
transmitters to the receiver.
7. ADDITIONAL TRANSMITTER
9. FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However,thereis noguaranteethat interference will not occur in a particular installation. If this equipment does
causeharmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
12 volt alkaline battery (size 23A)
(included).
It is time to change the battery
when the red LED on the trans-
mitter does not turn on when
either button is pressed.
6. BATTERY
11. CUSTOMER SERVICE
CUSTOMER SERVICE
17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3
Email:[email protected]
http://www.skylinkhome.com
P/N. 101A367
US Patent. D380895
©2005 SKYLINK GROUP
If you would like to order Skylink’s products or have difficulty getting them to work,
please :
1. visit our FAQ website at www.skylinkhome.com , or
2. email us at [email protected], or
3. call our toll free at 1-800-304-1187 from Monday to Friday, 9 am to 5 pm EST.
Fax [phone]
RISK OF ELECTRICAL SHOCK. FOR INDOOR USE ONLY.
CAUTION : DISCONNECT POWER BEFORE SERVICING.
Maximum Rating:
Input : 120VAC 60Hz 2W
8. CAUTION
Plug the receiver into an electrical socket.
Press and hold the learn button on the left hand side of the receiver.
The red LED on the receiver will flash.
Press the button of the transmitter you want to program to the
receiver.
The receiver red LED will go off indicates the programmingiscompleted.
2
1
3
4
5. REMOVE TRANSMITTER FROM THE RECEIVER
You can delete the transmitter from a receiver.
Unplug the receiver from the electrical socket.
Press and hold the learn button on the left hand side of the receiver
when plugging the receiver into an electrical socket, the red LED on the
receiver will flash rapidly. All the transmitters are deleted.
2
1
+_
The transmitter in this kit has been programmed to the receiver in the
factory. You need to do the programming only if you add additional
transmitters to the receiver.
4. PROGRAM A TRANSMITTER TO THE RECEIVER
Learn
Button
