Skymsen Ta-04mb-n User manual

- Besides this equipment, a complete range of other products are manufactured, consult our dealers.

- Due to the constant improvements introduced to our equipments,

the informaon contained in the present Instrucon Manual may be modiﬁed without previous noce.

49254.0 - INGLÊS

METALÚRGICA SIEMSEN LTDA.

CNPJ: 82.983.032/0001-19

Rodovia Ivo Silveira - km 12, nº 9525, Galpão 1 - Bairro: Bateas - CEP: 88355-202

Brusque - Santa Catarina - Brasil

Fone: +55 47 3211 6000 - Fax: +55 47 3211 6020

www.siemsen.com.br - comercial@siemsen.com.br

Data de Correção: 10/01/2014 HIGH ROTATION STAINLESS STEEL BLENDER,SEAMLESS

STAINLESS STEEL CUP

MODEL

TA-04MB-N

2

SUMÁRIO

1. Introducon ......................................................................................3

1.1 Safety .................................................................................................................... 3

1.2 Main Components ................................................................................................. 6

1.3 Technical Characteristcs ......................................................................................... 7

2. Instalaon and Pre-Operaon ...........................................................7

2.1 Installaon ............................................................................................................ 7

2.2 Pre Operaon ........................................................................................................ 8

3. Operaon ..........................................................................................9

3.1 Starng.................................................................................................................. 9

3.2 Feeding Procedures ............................................................................................... 9

3.3 Cleaning................................................................................................................11

3.4 Cauons with Stainless Steel: ...............................................................................12

4. General Safety Pracces .................................................................. 13

4.1 Basic Operaon Pracces......................................................................................13

4.2 Safety Procedures and Notes before Switching the Machine ON ...........................14

4.3 Roune Inspecon................................................................................................15

4.4 Operaon .............................................................................................................15

4.5 Aer Finishing The Work.......................................................................................15

4.6 Maintenance ........................................................................................................16

4.7 Advice ..................................................................................................................16

5. Analysis and Problems Solving ........................................................ 17

5.1 Problem, causes and soluons . ............................................................................17

6. Norms ............................................................................................. 19

7. Maintenance ................................................................................... 19

8. Electric Diagram............................................................................... 20

23

___________________________________________________________

22

___________________________________________________________

3

1. Introducon

1.1 Safety

This equipment if not correctly used is potenally dangerous, Maintenance, cleaning or any

other services shall be performed by a qualiﬁed person, with the equipment unplugged.

To avoid accidents respect the following instrucons:

1.1.1 Read completely these instrucons.

1.1.2 To avoid to risk electric shocks and damage to the equipment never use it with wet

clothes or shoes and/or standing on wet ﬂoors. Do not plunge it into water nor any other

liquid, do not spray water directly to the equipment.

1.1.3 When the equipment is in operaon the operator shall supervise it , principally

when children might be near.

1.1.4 Unplug the equipment when: It is not in use, before to clean it, before to remove or

to place some accessory. Before maintenance or any other service.

1.1.5 Do not operate the equipment if the cord or plug are damaged. Do not lean the

cord on table edges, nor let them lie on hot surfaces.

1.1.6 When the equipment may have fall, have been damaged any way, or simply does

not work, take it to Technical Assistance to check.

1.1.7 The use of accessories not recommended by the manufacturer may cause corporal

damages.

1.1.8 Keep the hands or any other object away from moving parts while the equipment is

in operaon.

1.1.9 During operaon, never wear loose clothes with wide sleeves principally around

the wrists.

1.1.10 Make sure the equipment voltage and the network voltage are the same, and the

equipment has been solidly grounded.

1.1.11 Knife blades are very sharp, handle with care.

1.1.12 Always place the Cup Lid # 02 (Pic. 01) on the lid before to switch ON the blender.

1.1.13 Always hold the Cup # 03 (Pic. 01) as long the blender is operang. If the Cup turns

4

loose switch immediately OFF the blender.

1.1.14 When blending hot liquids, remove the Cap # 01 (Pic 01) and keep the hands oﬀ the

Lid oriﬁce avoiding occasional burnings.

1.1.15 Never touch the knife when the blender is operang.

1.1.16 When installing the blender ground it properly in accordance with local

recommendaons.

1.1.17 Do not use the blender outside.

1.1.18 Do not let the blender operate without supervision.

1.1.19 Your blender does not replace any other kitchen appliance. It is not supposed to

make mashed potatoes, it does not blend egg white or any other cream for covering, it

does not grind raw meat, it does not blend hard pastas and does not extract kernels from

fruit and vegetables.

1.1.20 Remember that this kind of blender works in seconds and not in minutes. Therefore,

never let your blender working for more than one minute. It is beer to switch it oﬀ and

check the mixing consistency aer a few seconds to avoid over blending.

1.1.21 Overload the motor with big or heavy porons, since it will decrease the blender’s

lifespan. If the motor stops, immediately switch it oﬀ, unplug and remove part of the load

before restarng the operaon.

1.1.22 For your safety, the temperature of the processed products shall not exceed 40 °C.

21

___________________________________________________________

20

8. Electric Diagram

Electrical Diagram code: 49957.9

Version: 01

5

IMPORTANT

Make sure the cord is in perfect condions for use. If it is not, change it for a new

one in accordance with the technical speciﬁcaons and safety rules.

The substuon shall be made by a qualiﬁed professional, and shall respect the

local safety norms.

IMPORTANT

This equipment must not be used by children or any persons with reduced

physical or mental aptness, lack of experience or knowledge, unless they are

under supervision or have received from the person responsible for safety, proper

instrucons on how to use the equipment.

IMPORTANT

Children shall be watched in order to avoid them to play with the equipment.

IMPORTANT

In case of emergency take oﬀ the plug from its socket.

IMPORTANT

Never spray water directly on to the equipment.

6

1. 2 Main Components

All components are made with carefully selected materials, in accordance with Siemsen

experience and standard tesng procedures.

Picture 01

02

06

03

04

01

05

07

01 - Cap

02 - Lid

03 - Cup

04 - Housing

05 - On/oﬀ Switch

06 - Feet

07 - General Key

19

6. Norms

The following Norms apply:

ABNT NBR NM 60335-1

IEC 60335-2-64

7. Maintenance

Maintenance must be considered a set of procedures with the purpose to keep the

equipment best operang condions , therefore increasing the equipment life and safety.

* Cleaning – check item 3,3 Cleaning.

* Wiring - Check all wires regarding deteriorate condions as well as all electric contacts

(terminals) regarding ghtening and corrosion.

*Contacts – ON/OFF switch, emergency buon, reset buon , electronic circuits etc,

check the equipment in order to assure that all components are correctly working and the

equipment operaon is normal.

* Installaon – make sure the installaon followed item 2.1 instrucons.

1 – Each month check:

- Check the electrical installaon.

- Measure the voltage at the socket.

- Measure the working current and match it with the nominal current.

- Check the ghtening of all electric terminals to avoid bad contacts.

- Check electric motor shaclearance.

- Check the wiring for overheang, insulaon failures and mechanical damages.

2 – Each three month checks:

- Check electrical components such as ON/OFF switch, emergency buon, reset buon,

electronic and electric circuits, overheang, insulaon failings, or mechanical damages.

- Check bearings clearances.

- Check retainers, O’rings, V’rings and other seals.

18

Table 02

PROBLEM CAUSES SOLUTIONS

- The blender does no switch

ON.

- Electricity shortage.

- Pro b l em with t h e

blender electric circuit.

- Check electricity.

- Call technical assistance.

- Burning smell or smoke. - Problem with the blender

electric Circuits. - Call technical assistance.

- The blender starts, but aer

to place the ingredients inside

the cup , the blender rotaon

is too low.

- Problem with the motor. - Call technical assistance.

- Damaged cord. - Problem during transportaon. - Call technical assistance.

-Unusual noises. - Damaged bearing - Call technical assistance.

-The product does not

process.

- Product pieces too large do not

allow contact with the knife.

- Blunt knife.

- Cut smaller pieces about 3,5

cm.

- Call technical assistance.

- Cup is leaking. - Damaged seal. - Call technical assistance.

7

QUADRO 01

CARACTERÍSITCAS UNIDADE TA-04MB-N

Capacidade máxima do copo l4

Voltage (*) V 110

Frequency Hz 50 / 60

Power Rang W 590

Consumpon kW/h 0,59

Height mm 710

Width mm 270

Depth mm 240

Net Weight kg 4,6

Shipping Weight kg 5,7

1.3 Caracteríscas Técnicas

2. Installaon and Pre Operaon

2.1 Installaon

2.1.1 Placing

The Blender is to be installed onto a leveled surface approximately 850mm high.

2.1.2 Electrical Installaon

This equipment was developed to be used with: 110V. Upon receiving the Blender control

the voltage indicated on the cord label.

The cord has a plug with three pins one of them is grounding. It is mandatory the three

pins to be connected before to start to use the blender.

8

2.2 Pre Operaon

Before using the machine all parts that get in contact with food must be washed with

running water and neutral soap. To clean your Blender read item 3.3 Cleaning.

Make sure the blender is stable on its working place.

2.2.1 Placing the Cup

The Cup # 03 (Pic. 1) has a placing system allowing it to be easy and safely ﬁed

To remove the Cup just liit using the handle .

Always remove or replace the Cup holding it ﬁrmly by its handle.

IMPORTANT

Never remove or place tha Cup with the Blender switched ON.

2.2.2 Placing the Lid

The Cup has a Lid (pic. 02) developed with non toxic material assuring an eﬃcient seal

while processing. Make sure the lid is correctly placed on the cup as you may see picture

02 below.

IMPORTANT

Make sure that the network voltage is the same as the machine voltage.

Picture 02

17

5. Analysis and Problems Solving

5.1 Problem, causes and soluons

The Blenders were designed to operate with the need of minimum maintenance but the

natural wearing caused by longer use of the equipment may occasionally cause some

malfuncons.

If such problem occurs with your Blender refer to Table 02 in which the most common

situaons are listed with recommended soluons.

16

IMPORTANT

Always unplug the machine when emergency cases arise.

4.7 Advice

Electrical or mechanical maintenance must be done by qualiﬁed personal for such

operaon.

Person in charge has to be sure that the machine is under TOTAL SAFETY condions when

working.

4.6 Maintenance

4.6.1 Danger

Any maintenance with the machine in working situaon is dangerous.

TURN IT OFF BY PULLING THE PLUG OFF THE SOCKET DURING MAINTENANCE.

9

2.2.3 Placing the Cap

The Cap (Pic.03) may be used to watch the process and also to add ingredients.

To remove it just turn it clockwise, and when loose li it.

Picture 03

3 . Operaon

3.1 Starng

Plug the device into the outlet;

Turn the main switch;

The Blender is started by pressing the ON/Oﬀ Switch # 05 (Pic.01) to posion “I“.

To switch OFF the blender press the ON/OFF Switch to posion “O “.

3.2 Feeding Procedures

Before to use the blender all the parts in contact with the product shall be washed with

water and neutral soap (read item 3.3 cleaning).

Make sure the equipment is stable on its working place.

10

MPORTANT

Do not use the blender to process heavy dough .

IMPORTANT

The blending me may be diﬀerent for diﬀerent products kinds.

When blending solid ingredients add some liquid, not following such precauon

may create an overheang that will damage the seal.

IMPORTANT

Never switch the machine on without load in it because it will cause irreparable

damages.

Place the Lid and the Cap following instrucon given at item 2.2.2 and 2.2.3.

IMPORTANT

Cut the products in small size pieces of about 3,5 cm. This will help the blending

process me principally with frozen products.

When blending ice add some water.

Remove the Lid with its Cap from the Cup.

With the blender switched OFF put inside the Cup ﬁrst the receipt liquid ingredients and

only aer the ingredients having more consistence.

15

4.3 Roune Inspecon

4.3.1 Advice

When checking the tension of the belts or chains, DO NOT introduce your ﬁngers between

the belts and the pulleys and nor between the chain and the gears.

4.3.2 Precauons

Check if motors and sliding or turning parts of the machine produce abnormal noises.

Check the tension of the belts and chains and replace the set when belt or chain show

signs of being worn out.

When checking tensions of belts or chain DO NOT introduce your ﬁngers between belts

and pulleys, nor between the chains and gears.

Check protecons and safety devices to make sure they are working properly.

4.4 Operaon

4.4.1 Advice

Be sure your hair is not loose in order to avoid geng caught by turning parts which could

lead to a serious accident. Tie your hair well up and/or cover your head with a scarf.

The operaon performed by not trained or skilled personnel shall be forbidden.

- Never touch turning parts with your hands or in any other way.

- NEVER operate machine without all original safety devices under perfect condions.

4.5 Aer Finishing The Work

4.5.1 Precauons

Always TURN THE MACHINE OFF by removing the plug from the socket before cleaning the

machine.

Never clean the machine unless it has come to a COMPLETE STOP.

Put all components back to their funconal posions before turning it ON again.

DO NOT place your ﬁngers in between belts and pulleys nor chains and gears.

Skymsen TA-04MB-N User manual

Popular Blender manuals by other brands
