SMART-AVI FDX-3000 User manual

Installation
Manual
FDX-3000
DVI-D Video, Stereo Audio, USB
Keyboard/Mouse and RS-232
Extender over Fiber Optic Cable

2
Introduction
The FDX-3000 consists of a transmitter and receiver that extend
KVM, DVI-D, audio and RS-232 signals. It is a professional quality KVM
capable of extending signals up to 1,400 feet over a single multimode
fiber optic cable.
Features
•Top Signal Quality at Maximum Extension Over Multimode Fiber
(1,400 ft.)
•Superior Image Quality at all Resolutions
•Video Resolutions up to 1920 x 1200 at 60Hz (1280 x 1024 at 75Hz)
•Customizable/Programmable DDC Table
•Supports USB Keyboard/Mouse
•Supports Stereo Audio
•Supports DVI-D
•Supports RS-232 Control from 300bps to 115,000bps
•Supports all USB Keyboards Fully Transparent
•Fiber Plug Type LC
•Compatible With all Operating Systems
•Compatible With all Major KVM Switches
•Compact Metal Casing

3
Applications
•Corporate or Educational Presentations
•Financial (Remote Servers/User Control)
•Call Centers
•Industrial (Long-Range Workstation Isolation)
•Information Terminals/Kiosks
•Airport Installations (Air Trac Control/Passenger Information)
•KVM Extension where Exceptional Quality of Signal is Crucial
•Medical (Remote Operation Away from Sensitive/Magnetic
Equipment)
•Recording (for Large Studios where Editing/Mixing Stations are
Compact and/or Require Complete Silence)
Why Fiber Optic?
SmartAVI has created a full line of ber optic extender products,
understanding that this technology is superior to traditional
cabling.
Fiber optic cables are:
•capable of transmitting over very long distances with no
signal loss.
•immune to electromagnetic interference. In situations where
there is considerable interference, ber optic cabling is the
only solution.
•much more secure because they cannot be easily tapped. For
this reason, military and law enforcement agencies use ber
optic cables for the transmission of sensitive data.
•relatively inexpensive and small enough to be routed through
small spaces.

4
FDX-3000 Receiver Front
FDX-3000 Receiver Rear

5
What’s in the Box?
PART NO. QTY DESCRIPTION
FDX-TX3000 1 FDX-3000 Transmitter Unit - DVI-D, Stereo Audio, USB Keyboard/Mouse and RS-232 Extender over
Fiber Optic Cable
FDX-RX3000 1 FDX-3000 Receiver Unit - DVI-D, Stereo Audio, USB Keyboard/Mouse and RS-232 Extender over Fiber
Optic Cable
Power Supply 2 PS5VDC4A
Technical Specications
VIDEO
Format DVI-D Single Line
Maximum Pixel Clock 165 MHz
Input Interface (2) DVI-D 29-pin female
Output Interface (1) DVI-D 29-pin female
Resolution Up to 1920 x 1200 @60Hz
DDC Internal
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
AUDIO
Frequency Response 20 Hz to 20 KHz
Impedance 600 ohm
Nominal Level 0-1.0 V
Common Mode Rejection at 60dB
Input Interface (1) 3.5 mm Stereo Audio
Output Interface (1) 3.5 mm Stereo Audio
USB
Signaling USB Keyboard and Mouse ONLY
Input Interface (1) USB Type B
Output Interface (2) USB Type A
OTHER
Power External 100-240 VAC/5VDC4A @20W
Dimensions 4.5”W x 5.375”H x 1.75”D
Weight 1 lb.
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-131°F (0-55 °C)
Storage Temp. -4-185 °F (-20-85 °C)
Humidity Up to 95%
RS-232 Data up to 115,000 bps

6
Installation
1. Turn o the computer, display, and speakers.
2. Connect the DVI extension cable, USB cable, and audio cable
(not included) to the computer and to the ports on the FDX-
3000-TX.
3. Connect the display to the DVI connector on the FDX-3000-RX.
4. Connect USB mouse and keyboard ONLY to the USB connectors
on the FDX-3000-RX.
5. Connect speakers to the audio connector on the FDX-3000-RX.
6. Connect the FDX-3000-TX to the FDX-3000-RX with a multimode
ber-optic cable (see opposite page).
7. Connect the power cord and power on the FDX-3000TX and the
FDX-3000-RX.
8. Power on the computer, display and speakers.
Transmitter
Product - Installation Diagram
Fiber Optic Cable up to 1,400 ft.

7
Fiber-Optic Cable Specications
Receiver
OPTICAL
Fiber Type Single, multi mode
Connector Type LC Type
Wavelength 1310 nm/1550 nm (Dual wavelength)
Data Rate 5 Gbps (2.5 Gbps per single wavelength)
Transmission Power -5 dB Min.
Receiver Sensitivity -21 dB Max
Distance 500 m Max.
