Smartgen CMM363-2G User manual

CMM363-2G
CLOUD MONITORING COMMUNICATION MODULE
USER MANUAL
SMARTGEN (ZHENGZHOU) TECHNOLOGY CO., LTD.

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 2 of 18
CONTENT
1 OVERVIEW......................................................................................................................................... 4
2 PERFORMANCE AND CHARACTERISTICS.................................................................................... 4
3 SPECIFICATION ................................................................................................................................ 5
4 PANEL AND TERMINAL DESCRIPTION .......................................................................................... 6
4.1 PANEL INDICATION AND BUTTONS ..................................................................................... 6
4.2 GPRS....................................................................................................................................... 7
4.3 GPS.......................................................................................................................................... 7
4.4 SIM INSTALLATION................................................................................................................. 7
4.5 TERMINAL............................................................................................................................... 8
5 PROTECTION..................................................................................................................................... 9
5.1 ALARM..................................................................................................................................... 9
5.2 SHUTDOWNALARM............................................................................................................. 10
6 PROGRAMMABLE PARAMETERS.................................................................................................11
6.1 CONTENTS AND SCOPES OF PARAMETERS....................................................................11
7 COMMISIONING .............................................................................................................................. 16
8 SYSTEM DIAGRAM ......................................................................................................................... 16
9 CASE DIMENSION AND INSTALLATION....................................................................................... 17
10 FAULT FINDING............................................................................................................................... 18

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 3 of 18
Chinese trademark
English trademark
SmartGen —make your generator smart
SmartGen Technology Co., Ltd.
No.28 Jinsuo Road
Zhengzhou
Henan Province
P. R. China
Tel: [phone]
0086-371-67991553/67992951
0086-371-67981000(overseas)
Fax: [phone]
Web: http://www.smartgen.com.cn
http://www.smartgen.cn
Email: [e-mail]
All rights reserved. No part of this publication may be reproduced in any material form (including

CMM363-2G Cloud Monitoring Communication Module U1(m74 c6(m)3Sq107.05 0 53830.8(2G)4( )28(C)BT1 0 0 1 184.82 771.3543m 0 Tc[( )-27C)BT1 0 0 1 184.82 771.3548.98 0 Tc[( )-27CMMMMl Monotit((C)nE()111m)3(m)3(u)11(ni)-5(ca5(ori)9(ngon )26(M)3(od)10)10(3)(u)11dU1(m1 0 0 1 267.65 771.3305.33 51.9(M)3(M)3JEoriJEoriJE21iJE21iJ1 0 0 1 267.65 771.333Tc[9 51.9(M)3(M 0.00864 )-262011 0 0 1 267.65 771.3349003 51.9(M)3(M 0 )-2661 0 0 1 267.65 771.335Tm91 51.9(M)3(M)3BT1 0 0 1 267.65 771.3358c[9 51.9(M)3(M 0.00864 )-2608T1 0 0 1 267.65 771.3370.15 51.9(M)3(M 0 )-26BT1 0 0 1 267.65 771.3373.51 51.9(M)3(M)321JEo1iJEoriJE21iJ1 0 0 1 267.65 771.3406003 51.9(M)3(M[(V)-14(ersio)8()10)11.0)10JEoriJE21iJEoriJ1 0 0 1 267.65 771.3480.22 51.9(M)3(M[(PE(BTBT1 0 0 1 184.82 771.35.2 82 51.9(M)3(M[(4T1 0 0 1 184.82 771.351m051.9(M)3(M)3J1 0 0 1 184.82 771.3516.58051.9(M)3(M)3of)-63J1 0 0 1 184.82 771.3571.34 51.9(M)3(M[-0.111 )-2618T1 0 0 1 267.1 9 221.45 771.3539.98 51.9(M)3(M 0 )-26BT1 0 0 1 q Tc[-0.137 95.44 842.04 reW* n 2.89 T48.13762.64 499006 0.48004 ref*0.5 EMC /P [/TMCID 0/Lao)1(en-US)6.66 20184./F3 137221.45 771.3.224 753.22 )3(M)311 0 0 1 267.65 771.373.944 753.22 )3(M)3J1 0 0 1 184.82 771.37Tm64 753.22 )3(M)3J1 0 0 1 184.82 771.383m64 753.22 MoEE(RVIE(E)7(WT1 0 0 1 184.82 771.3641.34 753.22 )3(M)3J1 0 0 1 EMC /P [/TMCID 1/Lao)1(en-US)6.66 20184./F1 0 0 1 221.45 771.3 cm4 729.34 M363

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 5 of 18
system.All parameters are adjusted via PC through the LINK interface.
11) A variety of temperature, pressure, and oil level sensor curve can be used directly and be
customized.
12) Widely power supply: DC (8~35) V, can adapt to different battery voltage environment.
13) 1 auxiliary relay output ports which can output several of alarm signals.
14) Power and multiple communication status indicators on front panel that working status is clear at a
glance.
15) Lamp test function;
16) Parameter adjust function: users can adjust parameters via USB port;
17) Take standard π-type 35mm guide-rail installation or screw-fixed installation that the module can
be installed in the genset control box;
18) Modular design, self extinguishing ABS plastic shell, light weight, compact structure with easy
installation.
3 SPECIFICATION
Items
Contents
Operating Voltage
DC 8.0V~35.0V, continuous power supply.
AC Generator Voltage Input
Single-phase tri-wire system AC 15V - 360V (ph-N)
AC Generator Frequency
50/60Hz
Analog Input
Resistor Type
Auxiliary Input
Digital Input, connect (B-) is active.
Auxiliary Output
1A DC30V Volts free output
LINK
SmartGen exclusive port
USB Device
B-type USB mother port
GPRS Port
Standard SMA port (female), SMA port (male) for antenna.
GPS Port
Standard SMA port (female), SMA port (male) for antenna, active antenna.
Wireless Network
GPRS 2G
Case Dimensions
73mmx105mmx33mm
Ct Secondery Current
5mA
Working Conditions
Temperature: (-30～+70)°C Humidity: (20～93)%RH
Storage Condition
Temperature: (-40～+80)°C
Weight
0.15kg

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 6 of 18
4 PANEL AND TERMINAL DESCRIPTION
4.1 PANEL INDICATION AND BUTTONS
Icon
Note
POWER
Green LED Light: Cloud transmission communication normal
Red LED Light: Power supply indicator
ALARM(Red)
Normally Extinguish: Alarm free
0.5s Blink: Outage alarm
1s Blink: Warning alarm
GPRS(Red)
Normally Extinguish: No GPRS network
Normally Light: Connect with server successfully
Blink: Real-time data communication normal
GPS(Red)
Normally Extinguish: GPS disabled
Normally Light: GPS not gained satellite signal
Blink: GPS gained satellite signal
LINK(Red)
Normally Extinguish: Disabled
Normally Light: Communicate with PC normal
Voltage(Red)
Normally Extinguish: No power or abnormal power
Normally Light: Power normal
FREQ(Red)
Extinguish: No power or abnormal power frequency
Normally Light: Frequency normal
Lamp test/Reset:
Press this button for 1s, all the LEDs are illuminated; press for 10s, reset the module to default and all
the LEDs blink for 3 times.
NOTE: After reset the module, set up the parameters via PC software is recommended. Please
operate cautiously.
NOTE: Without insert SIM card, GPRS indicator and GPS indicator blink at the same time.

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 7 of 18
4.2 GPRS
Connect GPRS antenna to GRPR/3G port.
Antenna: 50Ω/SMA female.
4.3 GPS
GPS enabled, connect GPS antenna to CMM363-2G.
Note: GPS antenna needs to be placed to open outdoors, otherwise location information may not
accurate or cannot be gained.
Antenna: 50Ω/SMA female, active antenna.
Note: GPRS antenna and GPS antenna cannot be connected reversely.
CMM363-2G Antenna Connection
4.4 SIM INSTALLATION
Insert SIM card, CMM363-2G will connect to servers via GPRS network.
Note: Only mobile and Unicom network are supported. Use standard SIM card (25mmX15mm); If
GPS indicator and GPRS indicator blink in the same time, which means SIM card hasn’t been inserted or
bad contacts.
After detached head cover, the installation steps are as below:

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 8 of 18
4.5 TERMINAL
No.
Function
Cable Size
Note
1
B-
1.0mm2
Connected with negative of starter battery.
2
B+
1.0mm2
Connected with positive of starter battery. 3Afuse is
recommended.
3
Aux. Input 1
1.0mm2
Connect analog sensors
4
Aux. Input 2
1.0mm2
Connect analog sensors
5
Aux. Output
Normally
Open
1.0mm2
Normally open outputs, rated 1A DC30V
6
Common
1.0mm2
7
Normally
Close
1.0mm2
8
Gen A-phase Voltage
Monitoring Input
1.0 mm2
Connect genset output A phase(Recommend 2A
fuse)
9
Empty
10
Genset N Line Input
1.0mm2
Connect genset output N line
11
Empty
12
Current Transformer
A-phase Monitoring Input
0.5 mm2
External current transformer secondary coil(rated 5mA)
13
Current Transformer
Common Terminal
0.5 mm2
Check the installation instructions for more details

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 9 of 18
5 PROTECTION
5.1 ALARM
When warning signals been detected, the controller only warning not closing down.
Controller warning parameters as below:
No.
Type
Description
1
Over-frequency
Controller issued warning signal when detected genset frequency over the
pre-set alarm threshold.
2
Under-frequency
Controller issued warning signal when detected genset frequency under
the pre-set alarm threshold and over the under-frequency protection input
threshold.
3
Over-voltage
Controller issued warning signal when detected genset voltage over the
pre-set alarm threshold.
4
Under-voltage
Controller issued warning signal when detected genset voltage under the
pre-set alarm threshold and over the protection input threshold.
5
Over-current
Controller issued warning signal when detected genset current over the
pre-set alarm threshold, if the action select alarm.
6
Over-power
Controller issued warning signal when detected genset power over the
pre-set alarm threshold, if the action select alarm.
7
Battery
Over-voltage
Controller issued warning signal when detected genset battery voltage
over the pre-set alarm threshold.
8
Battery
Under-voltage
Controller issued warning signal when detected genset battery voltage
under the pre-set alarm threshold.
9
Flexible Sensor1
Open Circuit
Controller issued warning signal when detected open circuit, if the action
select alarm.
10
Flexible Sensor1
High
Controller issued warning signal when detected sensors numerical value is
greater than the pre-set upper limit warning and the power frequency over
the protection input threshold.
11
Flexible Sensor1
Low
Controller issued warning signal when detected sensors numerical value is
lower than the pre-set floor limit warning and the power frequency over the
protection input threshold.
12
Flexible Sensor2
Open Circuit
Controller issued warning signal when detected open circuit, if the action
select alarm.
13
Flexible Sensor2
High
Controller issued warning signal when detected sensors numerical value is
greater than the pre-set upper limit warning and the power frequency over
the protection input threshold.
14
Flexible Sensor2
Low
Controller issued warning signal when detected sensors numerical value is
lower than the pre-set floor limit warning and the power frequency over the
protection input threshold.
15
Digital Input
Controller issued relevant digital input port warning signal when flexible
sensor set to switch input port and the alarm is active.

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 10 of 18
5.2 SHUTDOWN ALARM
Shutdown alarm immediate output when the controller detects shutdown alarm signal.
Shutdown alarms as bellow:
No.
Type
Description
1
Over-frequency
When the controller detects that the genset frequency has exceeded
the pre-set value, it will initiate a shutdown alarm.
2
Under-frequency
When the controller detects that the genset frequency has fallen below
the pre-set value and over the protection input threshold, it will initiate
a shutdown alarm.
3
Gen Over-voltage
When the controller detects that the generator voltage has exceeded
the pre-set value, the controller will initiate a shutdown alarm.
4
Gen
Under-voltage
When the controller detects that the genset voltage has fallen below
the pre-set value and over the protection input threshold, it will initiate
a shutdown alarm.
5
Gen Over-current
When the controller detects that the genset current has exceeded the
pre-set value and the action select ―Shutdown‖, it will initiate a
shutdown alarm.
6
Over Power
If over power detection is enabled, when the controller detects that the
over power value (power is positive) has exceeded the pre-set value
and the action select ―Shutdown‖, it will initiate a shutdown alarm.
7
Flexible Sensor 1
Open Circuit
When the controller detects that the flexible sensor 1 is open circuit
and the action select ―Shutdown‖, it will initiate a shutdown alarm.
8
Flexible Sensor 1
High
When the controller detects that the sensor 1 value has exceeded the
pre-set value and the power frequency exceed protection input
threshold, it will initiate a shutdown alarm.
9
Flexible Sensor 1
Low
When the controller detects that the sensor 1 value has fallen below
the pre-set value and the power frequency exceed protection input
threshold, it will initiate a shutdown alarm.
10
Flexible Sensor 2
Open Circuit
When the controller detects that the flexible sensor 2 is open circuit
and the action select ―Shutdown‖, it will initiate a shutdown alarm.
11
Flexible Sensor 2
High
When the controller detects that the sensor 2 value has exceeded the
pre-set value and the power frequency exceed protection input
threshold, it will initiate a shutdown alarm.
12
Flexible Sensor 2
Low
When the controller detects that the sensor 2 value has fallen below
the pre-set value and the power frequency exceed protection input
threshold, it will initiate a shutdown alarm.
13
Digital Input
When digit input port is set as shutdown and the alarm is active, it will
initiate a shutdown alarm.
Note: When controller detects the frequency is 0, all the shutdown alarms except for switching
value shutdown alarm will automatic remove shutdown alarm after delay 5s.

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 11 of 18
6 PROGRAMMABLE PARAMETERS
6.1 CONTENTS AND SCOPES OF PARAMETERS
No.
Items
Parameters
Default
Description
Module Setting
1
Time Zone
(-12-12)
8
Setting time zone.
2
Address
(1-254)
1
Address of controller when remote
control.
3
History Data
Interval
(0-3600)s
0
History data upload interval.
Note：0s do not upload data.
4
Real-time Data
Upload Interval
(1-20)s
5
Real-time data upload interval.
5
Timing Upload
Enabled Set
(0-1)
0
0：Disable；1：Enable
6
Timing Data
Upload Interval
(0-600000)min
600
Timing upload enabled，the pre-set
time internal will trigger cloud data
transmission for 2 minutes.
Gateway Setting
1
Website
(0-65535)
20 Chinese characters, letters or
numbers
2
URL
(0-65535)
monitor.smartgen.com.cn
40 characters
3
Server Port
(0-65535)
50158
4
Password
(0-65535)
123456
16 characters
GPS Setting
1
GPS Enabled
(0-1)
1
0: Manual input 1: Using GPRS for
location.
2
Longitude
(-180-180)°
0.000000
GPS location, altitude
3
Latitude
(-90-90)°
0.000000
4
Altitude
(-9999.9-9999.9)
100.0
GSM Setting
1
GSM Enabled
(0-1)
1
0:Disabled; 1:Enabled
2
GPRS Password
Reserved
3
SMSNO
Reserved
Generator Setting
1
AC Supply
System
(0-3)
3
0: Three-phase four-wire 3P4W；
1：Three-phase three-wire 3P3W；
2：Two-phase three-wire 2P3W；
3: Single phase 1P2W
2
Nominal Voltage
(30-30000)V
230
Provide standard for over-voltage and
under–voltage. If use voltage
transformer, it is the transformer
primary voltage.
3
Nominal
Frequency
(10.0-75.0)Hz
50.0
Provide standard for over-voltage and
under–voltage.
4
Voltage
(0-1)
0
0: Disabled; 1: Enabled

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 12 of 18
Transformer
5
Over-voltage
Shutdown
(0-200)%
120
Protection on input threshold value is
percentage of gen rated voltage. Delay
also can be set.
6
Under-voltage
Shutdown
(0-200)%
80
7
Over-frequency
Shutdown
(0-200)%
114
Protection input threshold value is
percentage of gen rated frequency.
Delay value also can be set
8
Under-frequency
Shutdown
(0-200)%
80
9
Over-voltage
Alarm
(0-1000)%
110
Protection input threshold value is
percentage of gen rated voltage. Delay
and returned value also can be set.
10
Under-voltage
Alarm
(0-1000)%
84
11
Over-frequency
Alarm
(0-1000)%
110
Setting value, protection input
threshold value is percentage of gen
rated frequency. Delay and returned
value also can be set.
12
Under-frequency
Alarm
(0-1000)%
84
13
Battery Nominal
Voltage
(0-60.0)V
12.0
Provide standard for battery
over-voltage and under-voltage.
14
Battery Over-voltage
Alarm
(0-200)%
120
Setting value is percentage of battery
rated voltage. Delay and returned
value also can be set.
15
Battery
Under-voltage Alarm
(0-200)%
85
Load Setting
1
Current
Transformer
Changing-ratio
(5-6000)/5mA
30
An external variable ratio of current
transformer.
2
Rated Full-load
Current
(5-6000)A
30
Gen rated current is the standard of
the load current.
3
Rated Power
(0-6000)Kw
5
Gen rated power is the standard of
the load current.
4
Over-current
(0-200)%
120
Setting value is percentage of rated
full-load current. Delay value can be
set to fixed time-lag or inverse time
lag.
5
Over-power
(0-1)
0
0：Disabled；1：Enabled.
Analog Input Setting
Flexible Sensor 1 Setting
1
Sensor Option
(0-4)
1
Factory default：temperature sensor
2
Curve Type
(0-15)
7 SGX
0: Close active；1: Break active
See: Form 3
3
Open Circuit
(0-1)
0

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 13 of 18
5
High Downtime
(0-1000) ºC
98
When external sensor’s temperature
exceeds 98, high downtime alarm
will be initiated. Only when protection
input is valid, will it start to judge.
Delay value can be set.
6
Low Downtime
(0-1000) ºC
10
When external sensor’s temperature
fall below 10, low downtime alarm will
be initiated. Only when protection
input is valid, will it start to judge.
Delay value can be set.
7
High Alarm
(0-1000) ºC
95
When external sensor’s temperature
exceeds 95, high temperature
warning alarm will be initiated. Only
when protection input is valid, will it
start to judge. Delay value can be set.
8
Low Alarm
(0-1000) ºC
70
When external sensor’s temperature
fall below 70, low temperature
warning alarm will be initiated. Only
when protection input is valid, will it
start to judge. Delay value can be set.
Flexible Sensor2 Setting
1
Sensor Option
(0-4)
4
Factory default：Switching value
2
Protection Input
Frequency
threshold
(0-200)%
0
If gen frequency fall bellow protection
input frequency threshold, input port is
ineffective.
3
Input Content
(0-9)
4
Factory default ：Cloud transport
trigger input.
See: Form 1
4
Input Effect Type
(0-1)
0
0: Closed active；1: Open active.
5
Input Valid Delay
(0-20.0)
2.0
Input action delay.
6
Cloud
Transmission
Duration
(1-1000)min
1
After cloud transmission triggered
input actively, data transmit duration.
Switching Value Output Setting
1
Output
(0-34)
1
Factory default ：

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 14 of 18
Form1
No.
Item
Description
0
Not Used
Not used.
1
Lamp Test
All the indicators are illuminated when input is active.
2
WarningAlarm Input
Only warning without stopping when input is active.
3
Stop Alarm Input
Stop alarm output when input is active.
4
Cloud Transport Trigger
Input
Transmit real time data to the server when input is active.
5
Temperature High Input
Stop
Controller send out temperature high stop alarm when input is
active.
6
Oil Pressure Low Input
Stop
Controller send out oil pressure low stop alarm when input is
active.
7
Reserved
8
Reserved
9
Reserved
Form 2
No.

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 15 of 18
24
Sensor 2 Open Circuit
Sensor 2 open circuit alarm action.
25
Sensor 2 Low Alarm
Sensor 2 low warning alarm action.
26
Sensor 2 Low Stop Alarm
Sensor 2 low stop alarm action.
27
Sensor 2 HighAlarm
Sensor 2 high warning alarm action.
28
Sensor 2 High Stop Alarm
Sensor 2 low stop alarm action.
29
Reserved
30
Reserved
31
Reserved
32
Reserved
33
Reserved
34
Reserved
Form3
No.
Item
Content
Note
1
Temperature Sensor
0 Nonuse
1 Customized resistor type
2 Customized 4-20mA
3 VDO
4 CURTIS
5 VOLVO-EC
6 DATCON
7 SGX
8 SGD
9 SGH
10-15 Reserved
Customized resistor
type input scope:
0Ω-6000Ω
Factory default: SGX
sensor
2
Pressure Sensor
0 Nonuse
1 Customized resistor type
2 Customized 4-20mA
3 VDO 10Bar
4 CURTIS
5 VOLVO-EC
6 DATCON 10Bar
7 SGX
8 SGD
9 SGH
10-15 Reserved
Customized resistor
type input scope:
0Ω-6000Ω
Factory default: SGX
sensor

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 16 of 18
7 COMMISIONING
Before the formal operation, suggest do checks as bellow:
1) Confirm all wiring correct and the wire diameter suitable.
2) Confirm module DC working power installed fuse and positive and negative electrode which
connected to starter battery connect correctly.
3) Confirm GPS antenna placed open outdoor, otherwise, location information will not be found or
inaccuracy.
4) Confirm insert SIM card.
5) Confirm POWER indicator turns to green, which means cloud monitoring module connected to the
cloud platform successfully.
6) Confirm module’s ID be added to the register account through cloud sever platform. Ten real time
data can be checked.
7) Any other problems please contact with SmartGen service.
8 SYSTEM DIAGRAM
CMM363-2G System Application
CMM363-2G Typical Application

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 17 of 18
9 CASE DIMENSION AND INSTALLATION
CMM363-2G Case Dimension
CMM363-2G Guide Rail Installation
Screw Installation

CMM363-2G Cloud Monitoring Communication Module User Manual
CMM363-2G Cloud Monitoring Communication Module 2016-08-21 Version 1.0 Page 18 of 18
1) AC Input
Controller current input must connect with CT and CT secondary current must be 5mA. Meanwhile,
phase of CT and phase of voltage must be correct. Otherwise, the sample current and the active
power may be incorrect.
Note: ICOM perminal must be connected with controller negtive electrode.
Warning: Transformer secondary side is forbidden to open circuit when with load current.
2) High Voltage Test
Caution: If controller has been installed into control panel, when do High voltage tests, amphenol
connectors of controller must be disconnect to avoid high voltage damage the controller.
10 FAULT FINDING
Symptoms
Possible Solutions
Controller no response with
power.
Check power voltage;
Check controller connection wirings.
GPRS Indicator Not Light
Check SIM card is inserted or not;
Check GPRS antenna is connected or not.
GPS Not Gained Location
Check GPS parameters are enabled or not;
Check GPS antenna is connected or not and placed outdoor or not.
LINK Communication
Abnormal
Check connections;
Check COM port is correct or not;
Check PC communication port is damaged or not.
