SMC MAX 700 Front Differential gear box and gear motor maintenance note:
1. Diff. Gear Motor check & Gear tooth align check at 2WD mode.
a. Motor negative pole must be connect to earth.
b. Please check the function of the diff. gear motor (26650-MAX-00) if works nor Check the 2WD gear
align position if correct for the dot with line by following
Switch RH handle switch to 2WD mode. Check the
Diff. Lock motor gear tooth if align with the line
While motor rotate test, must connect
earth in advance.
1. Check display on the meter and motor by switching RH. Handle switch by
2WD-4WD-Diff. Lock if show correctly and motor rotate function.
2. Then switch back to 2WD mode. If display at speedometer still blinking,
change the motor assy. (26650-MAX-00)

2. Shift motor slide gear align check(inside diff. gear box):
a. Shift motor slide gear align
Notice while assembly:
1. The Shift motor slide gear at Diff. gear box must correctly align with motor, otherwise will cause gear
position not correct and not correct engaged.
2. While assembly, please special take care of the o-ring on the motor is correctly seated.
b. Check after assembly:
Move the shift motor
slide gear to the right
end side
Re-assembly the motor to the
diff. gear box at 2WD mode
Switch the RH handle switch for
2WD-4WD-Diff Lock again if normal.
If still not normal, re-check the gear
tooth align between gear motor and
Shift motor slide gear
