SMC Networks ZXPE5 011P Series User manual

Doc. no. DOC1069701
PRODUCT NAME
Electric Vacuum Gripper
MODEL / Series / Product Number
ZXPE5  011P-  - 
The outward appearance showed on this manual is an example of the vacuum gripper with suction
cups which is indicated by the product number: ZXPE5A011P-25JS-. Refer to the suction cup
catalog for the detail of other applicable suction cups.

-1-
No. DOC1069701
Contents
Safety instructions…………………………………………………………………………………………………..2
1. Parts included in the package...............................................................................................................6
2. How to order.........................................................................................................................................8
3. Names and descriptions of parts ........................................................................................................10
3.1. Names of parts of the product ..................................................................................................10
3.2. Descriptions of parts .................................................................................................................11
4. Mounting ............................................................................................................................................16
4.1. Mounting.....................................................................................................................................16
4.2. Wiring..........................................................................................................................................18
4.3. Power on.....................................................................................................................................19
5. Operation ...........................................................................................................................................20
5.1. Initial setup and diagnostic function ........................................................................................20
5.2. Using URCap..............................................................................................................................23
5.3. When URCap is not used...........................................................................................................35
6. Specifications .....................................................................................................................................42
6.1. Specifications.............................................................................................................................42
6.2. List of setting items ...................................................................................................................43
7. Dimensions.........................................................................................................................................44
7.1. Electric Vacuum Gripper............................................................................................................44
7.3. Suction cup with adapter...........................................................................................................46
8. Technical information..........................................................................................................................48
8.1. How to calculate theoretical lifting force..................................................................................48
8.2. How to change the number of cups..........................................................................................49
8.3. Suction with a vacuum saving valve ........................................................................................52
9. Maintenance.......................................................................................................................................54
9.1. Maintenance for electric vacuum gripper................................................................................54
9.2. Maintenance for suction cup.....................................................................................................55
9.3. Spare parts .................................................................................................................................56
10. Precautions ......................................................................................................................................57
10.1. Electric vacuum gripper precautions .....................................................................................57
10.2. Suction cup precautions .........................................................................................................58
11.Troubleshooting .................................................................................................................................60

-2-
No. DOC1069701
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage. These
instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are
all important notes for safety and must be followed in addition to International Standards (ISO/IEC)*1), and other
safety regulations.
1) ISO 4414: Pneumatic fluid power - General rules and safety requirements for systems and their components
ISO 4413: Hydraulic fluid power - General rules and safety requirements for systems and their components
IEC 60204-1: Safety of machinery - Electrical equipment of machines - Part 1: General requirements
ISO 10218-1: Robots and robotic devices - Safety requirements for industrial robots - Part 1:Robots
etc.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the
equipment or decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results. The expected performance and safety assurance of the equipment will
be the responsibility of the person who has determined its compatibility with the product. This person should
also continuously review all specifications of the product referring to its latest catalog information, with a view
to giving due consideration to any possibility of equipment failure when configuring the equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly. The assembly, operation and
maintenance of machines or equipment including our products must be performed by an operator who is
appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is
confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2. When the product is to be removed, confirm that the safety measures as mentioned above are
implemented and the power from any appropriate source is cut, and read and understand the specific
product precautions of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Our products cannot be used beyond their specifications. Our products are not developed,
designed, and manufactured to be used under the following conditions or environments.
Use under such conditions or environments is not covered.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Use for nuclear power, railways, aviation, space equipment, ships, vehicles, military application, equipment
affecting human life, body, and property, fuel equipment, entertainment equipment, emergency shut-off
circuits, press clutches, brake circuits, safety equipment, etc., and use for applications that do not conform
to standard specifications such as catalogs and operation manuals.
3. Use for interlock circuits, except for use with double interlock such as installing a mechanical protection
function in case of failure. Please periodically inspect the product to confirm that the product is operating
properly.

-3-
No. DOC1069701
Safety Instructions
Caution
We develop, design, and manufacture our products to be used for automatic control equipment, and
provide them for peaceful use in manufacturing industries.
Use in non-manufacturing industries is not covered.
Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the
Measurement Act.
The new Measurement Act prohibits use of any unit other than SI units in Japan.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after the product is delivered, whichever is
first.∗2)
Also, the product may have specified durability, running distance or replacement parts. Please consult your
nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility, a
replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage incurred due to
the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers noted in the
specified catalog for the particular products.
*2) Suction cups are excluded from this 1 year warranty.
A suction cup is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the suction cup or failure due to
the deterioration of rubber material are not covered by the limited warranty
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass destruction
(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by the relevant
security laws and regulations of the countries involved in the transaction. Prior to the shipment of a SMC
product to another country, assure that all local rules governing that export are known and followed.

-4-
No. DOC1069701
■Explanation of Symbols
Symbol
Definition
Things you must not do.
Instructions are provided as a drawing or sentence next to the symbol.
Things you must do
Instructions are provided as a drawing or sentence next to the symbol.
■Operator
1. This Operation Manual is intended for those who have knowledge of machinery using pneumatic equipment, and
have sufficient knowledge of assembly, operation and maintenance of such equipment.
Only those persons are allowed to perform assembly, operation and maintenance.
2. Read and understand this Operation Manual carefully before assembling, operating or providing maintenance to
the product.
■Safety Instructions
Warning
Disassembly
prohibited
Do not disassemble, modify (including the replacement of board) or repair other than
instructed in this manual.
Otherwise, an injury or failure can result.
Do not
Do not operate the product outside of the specifications.
Do not use for flammable or harmful fluids.
Fire, malfunction, or damage to the product can result.
Please check the specifications before use.
Do not
Do not use in an atmosphere containing flammable or explosive gases.
Fire or an explosion can result.
The product is not designed to be explosion proof.
Do not
Do not use the product in a place where static electricity is a problem.
Otherwise failure or malfunction of the system can result.
Do not
Do not cut off the power and compressed air supplied to this product while it is operating.
Otherwise it can cause injury due to dropping of workpieces or damage to the system.
Instruction
If using the product in an interlocking circuit
- Provide a double interlocking system, for example a mechanical system.
- Check the product for proper operation.
Otherwise malfunction can result, causing an accident.
Instruction
The following instructions must be followed during maintenance
- Turn off the power supply
- Stop the air supply, exhaust the residual pressure in piping and verify that the air is
released before performing maintenance work.
It may cause an injury.

-5-
No. DOC1069701
Caution
Do not touch
Do not touch the terminals and connectors while the power is on.
Otherwise electric shock, malfunction or damage to the switch can result.
Instruction
Perform sufficient trial run.
Otherwise, injury or damage to the system can result due to suction failure depending on
the conditions of the suction of the workpiece.
Perform sufficient verification before using this product.
Instruction
After maintenance is complete, perform appropriate functional inspections and leak test.
Stop operation if the equipment does not function properly or there is leakage of fluid.
If there is leakage from parts other than the piping, the product might be broken.
Cut off the power supply and stop the fluid supply.
Do not supply fluid if there is leakage.
Safety cannot be assured in the case of an unexpected malfunction.
■Precautions for Handling
Follow the instructions given below for selecting and handling of the electric vacuum gripper.
Product specifications
- Ensure to provide enough space for maintenance.
Design the system allowing the required space for maintenance.
- Use the specified voltage. Otherwise, failure or malfunction can result.
-Do not exceed the specified maximum allowable load. Otherwise, it can cause damage or shorten the life of the product.
- Design the product to prevent reverse current when the circuit is opened, or the product is forced to operate for
operational check. Reverse current can cause malfunction or damage the product.
- Data duration of input data to the pressure monitor is 20 years.
Operating environment
-Do not use the product in environments where the following atmospheres exist:
1. Corrosive gases, chemicals, sea water, water, water stream, or where there is contact with any of these
2. Flammable gases or explosive gases
3. Oil or chemicals
4. Thermal cycles other than normal temperature changes
5. Direct sunlight (ultraviolet rays) or outdoor
6. Ambient temperature exceeds the operating temperature range (refer to the specification table)
7. A source of heat, causing radiant heat
-Do not use the product in an area where surges are generated.
When there are machines or equipment that generate a large surge near the product (magnetic type lifter, high frequency
inductive furnace, motor, etc.), this can result in deterioration and damage of the internal elements. Take measures
against the surge sources and prevent the lines from coming into close contact.
-Do not use the product in an area where a strong magnetic field or strong electric field is generated; this can result in
damage to internal parts and product malfunction.
-Do not allow oil, moisture, particles, dust, cutting chips, spatter, or other foreign objects to enter inside the product; this
can result in deterioration in product performance or malfunction. Provide appropriate protection when using the product
in an environment where contamination may occur.
-Do not apply vibration or impact to the product. Handle the product with care as vibration and impact may cause
deterioration in product performance or malfunction.

-6-
No. DOC1069701
1. Parts included in the package
C
To use a URCap, download the relevant URCap software from the SMC website and copy it to a USB
memory.
Electric Vacuum Gripper: 1 pc.
Main plate assembly
Part No. RMTM2-4M1
Parallel pin (6x10) × 1, Parallel pin (6x15) × 1,
Hexagon thin socket head bolt (M6 x 10) × 4, Hexagon
thin socket head bolt (M6 x 8) × 4, Hexagon thin
socket head bolt (M5x25) x 2
(When “With main plate assembly” is selected.)
Connector cable: 1 pc.
Part No. RMH-A00-11-A
(When “With connector cable” is
selected.)
Plug: 4 pcs.
Part No. M-3P
(When “With flange assembly” is selected)
(Used for decreasing the number of suction
cups)
Suction cup with adapter: 4 pcs.
(When “Cup diameter” is selected.)

-7-
No. DOC1069701

-8-
No. DOC1069701
2. How to order
Suction cup part 1
Refer to “■Suction Cup Part Numbers and Weights” for the applicable cups.
･See “■Suction Cup Part Numbers and Weights” for the suction cup part combination.
･Refer to the catalog of suction cup on the SMC website for the detail of suction cup.
3. Output type
5. Cup form
6. Cup material
7. Cup attachment *3
9. Unit specifications
10. Manual changer
Φ32
32
Φ30
30
With main
plate assembly
Without main
plate assembly
The main plate assembly is required to mount the gripper to
the robot. In addition, when the main plate assembly is
mounted to the robot, several different tool models can be
used with the robot.
Customers who already have a main plate assembly can select
option "F" (Without main plate assembly).
4
Multistage bellows
Nil
U
SF
UT
25
Φ25
16
Φ16
13
FKM
Urethane rubber
Silicone rubber
(White)*2
NBR
10
9
8
7
08
Φ8
4. Cup diameter
5
ZXPE
5
A
－
20
U
N
E
M
N
Without cup
Silicone rubber
(Blue)*2
011
P
－
2
1
A
10
Φ10
Robot
manufacturer
6
Flat with rib
S
Nil
M
F
JT5
5.5-stage bellows
F
UNIVERSAL
ROBOTS
N
Flat type for film
packaging
workpieces
C
JT2
Φ13
J
2.5-stage bellows
Thin flat
U
Flat
P
PNP
SI units only *5
With unit selection
function *4
E
F
PT
Without
connector cable
With connector cable
Electric Vacuum Gripper
N
Without
cup
Nil
C
M
B
Bellows
Nil
Without cup
20
Φ20
3
With flat
attachment
With mesh
attachment
With (guide)
attachment
Nil
N
8. Robot connector cable
With flange assembly
(42mmx42mm)
Without flange assembly
1. Cup mounting flange assembly
2. Robot manufacturer
Identification
symbol
011
Supported
model
UR16e
UR10(e)
UR5(e)
UR3(e)
*2The silicone material is
compliant with the FDA
(U.S. Food and Drug
Administaration)
regulation 21CFR
§
177.
*3 Only applicable to the
cup form “JT*.”Note that
“M”applies only to cup
form: JT2.
*4Under the New
Measurement Act, switches
with the unit selection function
are not permitted for use in
Japan.
*5 Fixed unit: kPa, MPa
With flange assembly
(42)
Without flange
assembly

-9-
No. DOC1069701
*1
■Suction Cup Part Numbers and Weights
ZXPE5(A,N)011P - 4 5 6 7 -*
Applicable cups Cup part numbers
N S/SF U F
（NBR） (Silicone rubber) (Urethane rubber) (FKM)
08 U * ZPT08U*-A6 4 4 4 4 ZP08U*
08 B * ZPT08B*-A6 4 4 4 4 ZP08B*
10 UT * ZPT10UT*-A6 4 4 4 4 ZP10UT*
13 UT * ZPT13UT*-A6 4 4 4 4 ZP13UT*
16 UT * ZPT16UT*-A6 4 4 4 4 ZP16UT*
10 U * ZPT10U*-AS6 7 7 7 7 ZP10U*
13 U * ZPT13U*-AS6 7 7 7 8 ZP13U*
16 U * ZPT16U*-AS6 7 7 7 8 ZP16U*
20 U * ZPT20U*-AS6 9 10 10 10 ZP20U*
25 U * ZPT25U*-AS6 10 10 10 11 ZP25U*
32 U * ZPT32U*-AS6 10 11 11 12 ZP32U*
10 C * ZPT10C*-AS6 7 7 7 7 ZP10C*
13 C * ZPT13C*-AS6 7 7 7 7 ZP13C*
16 C * ZPT16C*-AS6 7 7 7 8 ZP16C*
20 C * ZPT20C*-AS6 9 10 10 11 ZP20C*
25 C * ZPT25C*-AS6 10 10 10 11 ZP25C*
32 C * ZPT32C*-AS6 10 11 11 12 ZP32C*
10 B * ZPT10B*-AS6 7 7 7 8 ZP10B*
13 B * ZPT13B*-AS6 7 8 8 8 ZP13B*
16 B * ZPT16B*-AS6 8 8 8 9 ZP16B*
20 B * ZPT20B*-AS6 11 11 11 13 ZP20B*
25 B * ZPT25B*-AS6 11 12 12 14 ZP25B*
32 B * ZPT32B*-AS6 14 15 15 18 ZP32B*
20 UT * ZP2-T20UT*-A6 4 4 4 4 ZPT1-A6 ZP2-20UT*
16 J * ZP2-T16J*-AS6 8 8 8 9 ZPT2-AS6 ZP2-16J*
25 J * ZP2-TB25J*-AS6 14 15 15 18 ZP2-B25J*
30 J * ZP2-TB30J*-AS6 18 19 19 25 ZP2-B30J*
20 JT2 SF ZP3P-T20JT2SF-W-AS6 - 21 - - ZP3P-20JT2SF-W
20 JT2 SF MZP3P-T20JT2SF-WM-AS6 - 21 - - ZP3P-20JT2SF-WM
20 JT2 SF FZP3P-T20JT2SF-WF-AS6 - 21 - - ZP3P-20JT2SF-WF
25 JT2 SF ZP3P-T25JT2SF-W-AS6 - 21 - - ZP3P-25JT2SF-W
25 JT2 SF MZP3P-T25JT2SF-WM-AS6 - 21 - - ZP3P-25JT2SF-WM
25 JT2 SF FZP3P-T25JT2SF-WF-AS6 - 21 - - ZP3P-25JT2SF-WF
32 JT2 SF ZP3P-T32JT2SF-W-AS6 - 37 - - ZP3P-32JT2SF-W
32 JT2 SF MZP3P-T32JT2SF-WM-AS6 - 37 - - ZP3P-32JT2SF-WM
32 JT2 SF FZP3P-T32JT2SF-WF-AS6 - 37 - - ZP3P-32JT2SF-WF
20 JT5 SF ZP3P-T20JT5SF-AS6 - 23 - - ZP3P-20JT5SF-WG
25 JT5 SF ZP3P-T25JT5SF-AS6 - 25 - - ZP3P-25JT5SF-WG
32 JT5 SF ZP3P-T32JT5SF-AS6 - 43 - - ZP3PA-T2JT-AS6 ZP3P-32JT5SF-WG
20 PT SF ZP3P-T20PTSF-AS6 - 20 - - ZP3P-20PTSF
25 PT SF ZP3P-T25PTSF-AS6 - 20 - - ZP3P-25PTSF
Cup with adapter
Adapter unit
Vacuum inlet：
Male thread M6×1
Cup unit
Part No.
Weight by cup material（g/cup）
7
Cup
attach-
ment
6
Cup
material
5
Cup
form
4
Cup
diameter
ZP3PA-T1-AS6
ZPT1-A6
ZPT2-AS6
ZPT3-AS6
ZPT2-AS6
ZPT3-AS6
ZPT2-AS6
ZPT3-AS6
ZPT3-AS6
ZP3PA-T1JT-AS6
ZP3PA-T2JT-AS6
ZP3PA-T1JT-AS6

-10-
No. DOC1069701
3. Names and descriptions of parts
3.1. Names of parts of the product
Main plate assembly
Cup mounting flange assembly
Parallel pin
DIP switch
Switch cover
When the
cover is
removed
LED
Lamp cover
Pressure monitor
Vacuum pump
SET/TEST button
Atmospheric release valve
Vacuum port
O-ring
Cup mounting flange
Plate B
Suction cup adapter
Cups with adapter
Main plate

-11-
No. DOC1069701
3.2. Descriptions of parts
Main plate assembly: Connects the gripper with the robot.
LED: Indicates the gripper status.
DIP switch: Changes the gripper operation mode.
Pressure monitor: Displays real-time vacuum pressure, the gripper operation mode and sets
parameter threshold values.
Vacuum pump: Generates vacuum.
Atmospheric release valve: Releases air to atmosphere upon the release command.
SET/TEST button: Moves to initial setup and diagnostic function or between parameters.
Cup mounting flange assembly: Connects a cup with the gripper body.
Cups with adapter: Grips workpieces. Select a cup suitable for the workpiece.
(Refer to “8.1. How to calculate theoretical lifting force” and the suction cup
catalog for how to select a suction cup.)
3.2.1. LED
Table 1. LED light and status of the gripper
LED
Gripper status
LED
Gripper status
No supply voltage
Initial setup and diagnostic
Idle state
At the start of initial setup and diagnostic
Set value fixed
Alarm
Grip success
Execute "Factory reset",
Setting values invalid
Grip/release failure,
Work drop detection,
Setpoint error
No light
Flashing green
Flashing green x 2
Flashing orange ×2
Green light
Red light
Flashing orange
Flashing red
Flashing red ×2

-12-
No. DOC1069701
3.2.2. DIP switch (for changing the gripper operation mode)
To change the gripper operation mode, use the 2-pole DIP switch on the top of the product. Change the
operation mode before mounting the electric vacuum gripper on the robot, while the power is off.
How to change
1. Remove the switch cover above the Lamp cover and switch ON or OFF the DIP switch as shown in the
table below.
2. Return the switch cover and connect the electric vacuum gripper to the robot. (Refer to “4.1. Mounting”.)
Table 2. Gripper operation modes
* In “Automatic mode and auto-diagnostic” mode, the vacuum pressure without workpiece is
automatically diagnosed when the gripper is turned on. (For details on operation, see “5.1. Initial setup
and diagnostic function”).
Caution
Gripper
operation mode
Automatic mode
(Factory default)
Manual mode Continuous mode
Automatic mode
and auto-diagnostic
Output
1pole：OFF 2pole：OFF 1pole：ON 2pole：OFF 1pole：OFF 2pole：ON 1pole：ON 2pole：ON
Image of DIP switch
Pressure monitor
sub screen display
(left)
(After power on)
ON
1
2
ON
1
2
ON
1
2
ON
1
2
When URCap plugin software is used, the operation mode can be changed with the software. In this case,
the operating mode set by the software is effective, overriding the mode set by the DIP switch. However, if
you use “Automatic mode and auto-diagnostic” mode, the DIP switch must be changed.
*

-13-
No. DOC1069701
3.2.3. Gripper operation modes
3.2.3.1. Automatic mode
In automatic mode, the electric vacuum gripper operates in an energy-saving manner, automatically setting
a threshold value based on the vacuum pressure at gripping, the maximum vacuum pressure of the product,
and the pre-determined vacuum pressure without workpiece (*).
Below is the description of the energy-saving operation.
Upon the grip command, the pump engages and starts suctioning. According to the vacuum pressure after
suction has started, the gripper performs one of the following five actions:
1. When the vacuum pressure reaches P1, the pump stops. After that, when the vacuum pressure drops
by H1, the pump starts again and maintains the vacuum. If the vacuum pressure reaches P1 again, the
pump stops, and thereafter it repeats the on and off cycle.
If the on and off cycle is repeated a predetermined number of times, the pump will operate continuously.
2. When the vacuum pressure reaches P1, the pump stops. When the vacuum pressure drops by H1, the
pump starts again. However, if the vacuum pressure does not reach P1, the pump runs continuously.
3. If the vacuum pressure does not increase sufficiently after the start of suction, the pump does not stop
and runs continuously.
4. If the vacuum pressure does not reach P2, it indicates that gripping has failed, and the pump stops.
5. If the vacuum pressure drops to P2+H2 during suction, it indicates that a dropped workpiece event has
been detected, and the pump stops.
*Vacuum pressure without workpiece means the pressure when the grip command is given without
workpiece.
H1
H2
P1: Threshold of pressure for energy-saving operation
H1: Energy-saving operation range
P2: Pressure for gripping success detection
H2: Hysteresis of pressure for gripping success detection
(P2+H2: Pressure for workpiece drop detection)
P1
Time
Vacuum pressure
P2
Atmospheric pressure

-14-
No. DOC1069701
3.2.3.2. Manual mode
In manual mode, threshold values are manually set, and the vacuum gripper operates in an energy-saving
manner (which controls the pump’s actions) similarly to automatic mode. The following four threshold
values can be set as described in “5.2.2.3. Pump settings” or with the buttons on the pressure monitor as
described in “5.3.4. Viewing and setting thresholds”. Refer to “6.2. List of setting items” for default values
and adjustable ranges.
P1: Threshold of pressure for energy-saving operation
H1: Energy-saving operation range
P2: Pressure for gripping success detection
H2: Hysteresis of pressure for gripping success detection
(P2+H2: Pressure for workpiece drop detection)
Caution
3.2.3.3. Continuous mode
In continuous mode, the pump operates continuously while the grip command is valid. The pressure for
gripping success detection P2 and the hysteresis of pressure for gripping success detection H2 are
automatically determined based on the gripper maximum vacuum pressure and the pre-determined
vacuum pressure without workpiece.
H2
Time
Vacuum pressure
P2
Atmospheric pressure
In manual mode, each threshold value can be set arbitrarily within adjustable range, but depending on the
set value, malfunctions may occur.
For example, if the vacuum pressure without workpiece Pe at initial setup is higher than the manually set
the pressure for workpiece drop detection P2+H2, the workpiece drop detection cannot be judged correctly.
In that case, set the value appropriately or use automatic mode or continuous mode.

-15-
No. DOC1069701
3.2.4. Pressure monitor display
Main display: Displays pressure measurement values. (in red)
Sub display (left): Displays the current gripper operation mode or parameter (in orange)
Sub display (right): Displays the set value, peak value or bottom value (in orange)
The buttons on the pressure monitor are used only in manual mode or to change the measurement unit.
button: Increases a set value and changes the parameter to display.
button: Decreases a set value and changes the parameter to display.
button: Changes a set value.
*Indicator lights indicate as follows:
IO-Link status indicator: Always turns on while the gripper is energized as IO-Link communication is used
inside the product.
Gripper’s vacuum status indicator: (OUT1/OUT2): Turns on or off according to the threshold values of each
parameter. But it is not relevant to the product’s specification.
Operation light (OUT2)
IO-Link status indicator light
Operation light (OUT1)
Indicator light ( )
Main dis play
Sub display (left)
button
button
button
Sub display (right)
*

-16-
No. DOC1069701
4. Mounting
4.1. Mounting
■Mounting the gripper on the robot
1) Insert the parallel pin into the robot tool flange pin hole.
2) Aligning the parallel pin with the oval hole of the main plate, mount the main plate on the robot with 4
hexagon thin socket head bolts provided, with a tightening torque of 5.2±0.5 N·m.
3) Aligning the grooves of the main plate and the lamp cover, insert the clamper into the grooves and
mount the gripper by tightening the hexagon thin socket head bolts (M5 X 25) with a tightening torque
of 1.5±0.1 N·m.
4) With the gasket seal in place on the adapter, mount 4 cups with adapter on the electric vacuum
gripper with a tightening torque of 1 N·m or tighten by 1/4 turn using a spanner after tightening by
hand.
To remove the gripper, follow the mounting procedure in reverse.
Hexagon thin socket head bolt (M6x10)
Clamper
Hexagon thin socket head
bolt (M5x25)
Parallel pin (6x10)
Tool flange
Cups with adapter
Main plate
Oval hole
Main plate
Electric vacuum gripper
Lamp cover
Groove
*Refer to “8.3. Suction with a vacuum
saving valve”, when using the ZP2V
vacuum saving valve.
M8 connector pin (Plug)
Gasket seal
Adapter
Cup with adapter

-17-
No. DOC1069701
Caution
<Example of mounting>
Mount the electric vacuum gripper on the robot in an orientation that minimizes slack in the M8 connector
cable. If the cable slack is large, the cable may cause an unexpected accident by pulling on the surrounding
equipment, workpieces, or people while the robot is in operation.
M8 tool I/O connector
entry direction
Front of the electric vacuum
gripper (pressure monitor)

-18-
No. DOC1069701
4.2. Wiring
■Mounting the M8 connector cable
Connect the electric vacuum gripper’s M8 connector pin and the tool flange’s tool I/O connector together
with the M8 connector cable.
Do not energize while securing the connector.
Check that the connector is not loose.
■M8 Connector pin
M8 connector plug angle
Table 3. M8 connector pin assign
Pin no.
Function
1
RS485+
2
RS485-
3
Digital output 1
4
Digital output 0
5
Power supply voltage (24V)
6
Digital input 1 *
7
Digital input 0 *
8
Power supply voltage (GND)
* Set the digital output 0/1 in the robot tool I/O to sourcing (PNP).
M8 connector cable
Tool I/O connector
Tool flange

-19-
No. DOC1069701
4.3. Power on
When supply voltage is applied to the M8 connector cable, the pressure monitor is turned on and performs
zero-clear (*). The LED flashes green, indicating that the electric vacuum gripper is idling.
Caution
*Zero-clear: Function to adjust the displayed pressure to zero.
Power on the electric vacuum gripper with the vacuum port released to atmosphere. This product clears
the display value to zero upon power on. If it is powered on with pressure applied (performs zero-clear),
the displayed pressure value may deviate. If this happens, power it on again after powering off and
removing the pressure from the vacuum port to release to atmosphere.
