SMC Networks ZXP7-PFL1-ZP X1 Series User manual

Doc. no. TQ1230001-OM107
PRODUCT NAME
Suction cups with flange
MODEL / Series / Product Number
ZXP7-PFL1-ZP  -X1
The outward appearance showed on this manual is an example of the suction cups with flange which
is indicated by the product number: ZXP7-PFL1-ZPB25JS-X1. Refer to the suction cup catalog for
the detail of other applicable suction cups.

-1-
No. TQ1230001-OM107
Contents
Safety Instructions .................................................................................................................................2
1. Parts included in the package...............................................................................................................4
2. Names of Parts of the Product..............................................................................................................5
3. Specifications .......................................................................................................................................6
3.1. Specifications...............................................................................................................................6
3.2. How to calculate theoretical lifting force....................................................................................6
3.3. How to order.................................................................................................................................7
4. Mounting ..............................................................................................................................................8
4.1. Mounting.......................................................................................................................................8
4.3. Piping............................................................................................................................................9
5. Dimensions.........................................................................................................................................10
5.1. Suction cups with flange...........................................................................................................10
5.2. Center of gravity (ZXP7-PFL1-ZPB25JN-X1) ............................................................................11
5.3. Suction cup with adapter...........................................................................................................12
6. How to change the number of cups ....................................................................................................14
6.1 Change to 1 cup ..........................................................................................................................14
6.2 Change to 2 cups ........................................................................................................................15
7.Maintenance........................................................................................................................................16
7.1. Maintenance for suction cups with flange ...............................................................................16
7.2. Maintenance for suction cup.....................................................................................................16
8.Precautions .........................................................................................................................................17
8.1 Air supply..................................................................................................................................17
8.2 Suction cups with flange precautions ....................................................................................18
8.3 Suction cup precautions..........................................................................................................19
9.Troubleshooting...................................................................................................................................23

-2-
No. TQ1230001-OM107
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition to International Standards
(ISO/IEC)*1) , and other safety regulations.
*1) ISO 4414: Pneumatic fluid power -- General rules relating to systems.
ISO 4413: Hydraulic fluid power -- General rules relating to systems.
IEC 60204-1: Safety of machinery -- Electrical equipment of machines .(Part 1: General requirements)
ISO 10218: Manipulating industrial robots -Safety.
etc.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment
or decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
The expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be performed
by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is
confirmed.
1.The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2.When the product is to be removed, confirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is
to be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, medical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or
other applications unsuitable for the standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by using a
mechanical protective function, and periodical checks to confirm proper operation.

-3-
No. TQ1230001-OM107
Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1.The warranty period of the product is 1 year in service or 1.5 years after the product is
delivered,whichever is first.2)
Also, the product may have specified durability, running distance or replacement parts.
Please consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our
responsibility, a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
2) Suction cups are excluded from this 1 year warranty.
A suction cup is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the suction
cup or failure due to the deterioration of rubber material are not covered by the limited
warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of
mass destruction (WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by
the relevant security laws and regulation of the countries involved in the transaction. Prior
to the shipment of a SMC product to another country, assure that all local rules governing
that export are known and followed.
Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval
tests relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.
! Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval
tests relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.

-4-
No. TQ1230001-OM107
1. Parts included in the package
Cup mounting flange 1 pc.
Suction cup with adapter: 4 pcs.
Plug: 1 pc.
Part No. M-5P
When Rc1/8 port use as vacuum pressure supply port.
(Mount to unused port.)
Parallel pin (6x10): 1 pc.
Hexagon socket head cap
screw (M6x10): 4 pcs.
Plug: 4 pcs.
Part No. M-3P
Used for decreasing the number of
suction cups.

-5-
No. TQ1230001-OM107
2. Names of Parts of the Product
Parallel pin (6x10)
Vacuum pressure
supply (PV) port
M5x0.8
Hexagon socket head cap screw
(M6x10)
Cups with adapter
Cup mounting flange
(With mesh)
(Conforming to “ISO 9409-1-50-4-M6”)
Plug(M-5P)
O-ring (25.6 x 20.8 x 2.4)

-6-
No. TQ1230001-OM107
3. Specifications
3.1. Specifications
■Product specifications
Standards
Conforming to “ISO 9409-1-50-4-M6”
Applicable fluid
Air
Operating temperature range [°C]
5 to 50
Weight [g] (Except cups with adapter)
228
Max. work load [kg] Note2)
7
Air pressure supply (P) port
M5x0.8, Rc1/8
Applicable suction cups
Refer to “3.3. How to order”
Note 1) The weight changes by the selected suction cup. Refer to “3.3 How to order”.
Note 2) May be restricted depending on the cup diameter, mounting orientation, or workpiece. Please use within the max. work
load. Suction and transfer exceeding the max. work load may result in reduced vacuum pressure due to air leakage.
3.2. How to calculate theoretical lifting force
This manual shows how to calculate theoretical lifting force only. Refer to the catalog of suction cups for further
detail of suction cup selection method.
■How to calculate theoretical lifting force
The theoretical lifting force of a cup can be found by calculation or from the theoretical lifting force table.
Calculation
Theoretical lifting force table
The theoretical lifting force (not including the safety factor) can be determined by the cup diameter and vacuum
pressure.
The required lifting force can then be determined by dividing the theoretical lifting force by the safety factor t.
Lifting force = Theoretical lifting force / t
Theoretical lifting force (Theoretical lifting force = P x S x 0.1)
Cup diameter (Φ8 to Φ32) [N]
Cup diameter [mm]
Φ8
Φ10
Φ13
Φ16
Φ20
Φ25
Φ32
S: Cup area [cm2]
0.50
0.79
1.33
2.01
3.14
4.91
8.04
Vacuum
pressure
[kPa]
-85
4.2
6.6
11
17
26
41
68
-80
4.0
6.2
10
16
25
39
64
-75
3.7
5.8
10
15
23
36
60
-70
3.5
5.5
9.3
14
22
34
56
-65
3.2
5.1
8.6
13
20
31
52
-60
3.0
4.7
8.0
12
18
29
48
-55
2.7
4.3
7.3
11
17
27
44
-50
2.5
3.9
6.7
10
15
24
40
-45
2.2
3.5
6.0
9.0
14
22
36
-40
2.0
3.1
5.3
8.0
12
19
32
W: Lifting force [N]
P: Vacuum pressure [kPa]
S: Cup area [cm2]
t: Safety factor Horizontal lifting: 4 or more
Vertical lifting: 8 or more
Cup

-7-
No. TQ1230001-OM107
3.3. How to order
■Suction cups with flange
1
■Suction Cup Part Numbers and Weight
1) Cup series
2) Cup diameter
3) Cup form 4) Cup material 5) Attachment *2
ZXP7-PFL1
－
ＺＰ
20
Ｕ
Attachment
－X1
Symbol
Cup Series
Symbol
Cup
diameter
Ｎ
Symbol
Cup form
Symbol
Material
Symbol
Ｎ
ＮＢＲ
Nil
With (guide) attachment
ZP3P
Bellows type for film
packaging
workpieces
10
Φ10
Ｃ
Flat with rib
ZP
Basic
08
Φ8
Ｕ
Flat
S
Silicone rubber (White) *1
M
With mesh attachment
13
Φ13
B
Bellows
Ｕ
Urethane rubber
16
Φ16
ＵＴ
Ｆ
ＦＫＭ
20
Φ20
Ｊ
Multistage bellows
SF
Silicone rubber (Blue) *1
Thin flat
25
Φ25
ＪT2
2.5-stage bellows
B25
Φ25
ＪT5
5.5-stage bellows
B30
Φ30
32
Φ32
*1 The silicone material
is compliant with the
FDA(U.S. Food and
Drug Administration)
regulation 21CFR
§
177
*2 Only applicable to the cup
form “JT□.“
Note that “M“ applies only
to cup form: JT2.
ZXP7-PFL1 - (1) (2) (3) (4) (5) -X1
Applicable cups Cup part numbers
N
（NBR）
S/SF
(Silicone）
U
(Urethane）
F
(FKM）
ZP 08 UZPT08U-A6 4 4 4 4 ZP08U
ZP 08 BZPT08B-A6 4 4 4 4 ZP08B
ZP 10 UT ZPT10UT-A6 4 4 4 4 ZP10UT
ZP 13 UT ZPT13UT-A6 4 4 4 4 ZP13UT
ZP 16 UT ZPT16UT-A6 4 4 4 4 ZP16UT
ZP 10 U
ZPG10U-7A-X2 7 7 7 7 ZP10U
ZP 13 U
ZPG13U-7A-X2 7 7 7 8 ZP13U
ZP 16 U
ZPG16U-7A-X2 7 7 7 8 ZP16U
ZP 20 U
ZPG20U-7A-X2 9 10 10 10 ZP20U
ZP 25 U
ZPG25U-7A-X2 10 10 10 11 ZP25U
ZP 32 U
ZPG32U-7A-X2 10 11 11 12 ZP32U
ZP 10 C
ZPG10C-7A-X2 7 7 7 7 ZP10C
ZP 13 C
ZPG13C-7A-X2 7 7 7 7 ZP13C
ZP 16 C
ZPG16C-7A-X2 7 7 7 8 ZP16C
ZP 20 C
ZPG20C-7A-X2 9 10 10 11 ZP20C
ZP 25 C
ZPG25C-7A-X2 10 10 10 11 ZP25C
ZP 32 C
ZPG32C-7A-X2 10 11 11 12 ZP32C
ZP 10 B
ZPG10B-7A-X2 7 7 7 8 ZP10B
ZP 13 B
ZPG13B-7A-X2 7 8 8 8 ZP13B
ZP 16 B
ZPG16B-7A-X2 8 8 8 9 ZP16B
ZP 20 B
ZPG20B-7A-X2 11 11 11 13 ZP20B
ZP 25 B
ZPG25B-7A-X2 11 12 12 14 ZP25B
ZP 32 B
ZPG32B-7A-X2 14 15 15 18 ZP32B
ZP 20 UT 
ZPG20UT-7A-X2 4 4 4 4 ZPT1-A6 ZP2-20UT
ZP 16 J
ZPG16J-7A-X2 8 8 8 9 ZPT2-7A-X2 ZP2-16J
ZP B25 J 
ZPGB25J-7A-X2 14 15 15 18 ZP2-B25J
ZP B30 J
ZPGB30J-7A-X2 18 19 19 25 ZP2-B30J
ZP3P 20 JT2 SF ZP3PG20JT2SF-7A-X2 -21 - - ZP3P-20JT2SF-W
ZP3P 20 JT2 SF MZP3PG20JT2SF-M-7A-X2 -21 - - ZP3P-20JT2SF-WM
ZP3P 32 JT2 SF ZP3PG32JT2SF-7A-X2 -48 - - ZP3P-32JT2SF-W
ZP3P 32 JT2 SF MZP3PG32JT2SF-M-7A-X2 -48 - - ZP3P-32JT2SF-WM
ZP3P 20 JT5 SF ZP3PG20JT5SF-7A-X2 -23 - - ZP3P-20JT5SF-WG
ZP3P 25 JT5 SF ZP3PG25JT5SF-7A-X2 -25 - - ZP3P-25JT5SF-WG
ZP3P 32 JT5 SF ZP3PG32JT5SF-7A-X2 -54 - - ZP3PA-T2JT-7A-X2 ZP3P-32JT5SF-WG
Input the material symbol (”N,” “S,” “U,” or “F”) into the * in the part number.
ZP3PA-T1JT-7A-X2
Cup unit
Part number
Weight by cup material (g/cup)
ZPT1-A6
ZPT2-7A-X2
ZPT3-7A-X2
ZP3PA-T1JT-7A-X2
ZPT2-7A-X2
ZPT3-7A-X2
ZPT2-7A-X2
ZPT3-7A-X2
ZPT3-7A-X2
ZP3PA-T2JT-7A-X2
Cup with adapter
(1)
Cup
series
(2)
Cup
diameter
(3)
Cup
form
(4)
Cup
material
Adapter unit
Vacuum inlet:
Male thread M6x1
(5)
Attachment
･See the table below for the suction cup part combination.
･Refer to the catalog of suction cup on the SMC website for the detail of suction cup.
Suction cup part 1 Refer to the table blow for the applicable cups.

-8-
No. TQ1230001-OM107
4. Mounting
4.1. Mounting
■Mounting procedure
1) Confirm the gasket seal on the adapter, then mount 4 cups with adapter to the cup mounting flange.
(Tightening torque: 1N・m or tighten for 45 degrees using a spanner after tightening by hand)
2) Mount parallel pin to the robot tool flange pin hole.
3) Align the parallel pin of the robot tool flange with the robot mounting flange, and assemble them with
bolts included in the accessories. (Tightening torque: 5.2+/-0.5 Nm)
Removal should be performed by following the mounting procedure in reverse.
Gasket seal
Adapter
Oval hole
Pin hole
Parallel pin
Cup mounting flange
Tool flange
Hexagon socket head cap screw
M6x10(4 pcs.)
Suction cups with adapter
2）
1）
3）

-9-
No. TQ1230001-OM107
4.3. Piping
■Tubing
If Rc1/8 port use as vacuum pressure supply port, please mount the plug (part number: M-5P) to M5x0.8
vacuum pressure supply (PV) port.
Please order one-touch fitting and tube separately for mounting to Rc1/8 port.
(Recommended one-touch fitting: KQ2L08-01NS, recommended tube: TU0805)
Connect a tube to the vacuum pressure supply (PV) port.
(Refer to the P.18 “ 2 ) Tube attachment ” )
To remove the tube, push the release button and pull out the tube.
Release button
One-touch fitting
for vacuum pressure supply
(Port size Rc1/8）
Plug(M-5P)

-10-
No. TQ1230001-OM107
5. Dimensions
5.1. Suction cups with flange
*Operating range: 25 to 35 (When a cup is mounted in the center)
As interference between cups may occur depending on the cup
diameter, select the cup diameter according to the pitch to be used.
*Cup distance is changeable.

-11-
No. TQ1230001-OM107
5.2. Center of gravity (ZXP7-PFL1-ZPB25JN-X1)
Center of gravity
X
Y
Z
0.64
0.57
13.96
(Unit: mm)
X
Z
Z
Y
X
Y

-12-
No. TQ1230001-OM107
5.3. Suction cup with adapter
*It is shown here for representative model only. See the suction cup catalog for the other models.
Model：ZPGU-7A-X2
(Suction cup form：Flat type)
Dimensions
Model A B D E F Y
ZPG10U-7A-X2 10 12
ZPG13U-7A-X2 13 15
ZPG16U-7A-X2 16 18 18 22.5 3.5
ZPG20U-7A-X2 20 23
ZPG25U-7A-X2 25 28
ZPG32U-7A-X2 32 35 20 24.5 4.5
13
15
3
4
17.5
19.5
22
24
Model：ZPGC-7A-X2
(Suction cup form：Flat type with ribs)
Dimensions
Model A B D E F Y
ZPG10C-7A-X2 10 12 1.7
ZPG13C-7A-X2 13 15 1.8
ZPG16C-7A-X2 16 18 18 22.5 1.2
ZPG20C-7A-X2 20 23 1.7
ZPG25C-7A-X2 25 28 1.8
ZPG32C-7A-X2 32 35 20 24.5 2.3
13
15
17.5
19.5
22
24
Model：ZPGB-7A-X2
(Suction cup form：Bellows type)
Dimensions
Model A B D E F G H Y
ZPG10B-7A-X2 10 12 5.5 13.5 21.5 26 5.5
ZPG13B-7A-X2 13 15 8.7 19 24 28.5 7.5
ZPG16B-7A-X2 16 18 10 21 25.5 30 8.5
ZPG20B-7A-X2 20 22 12.6 25 29 33.5
ZPG25B-7A-X2 25 27 16 28 29.5 34
ZPG32B-7A-X2 32 34 18.9 37 34.5 39 14
13
15
10.5
Model：ZPG20UT-7A-X2
(Suction cup form：Thin flat type)

-13-
No. TQ1230001-OM107
Note1) “D” and (st) indicate the reference value during gripping at vacuum pressure: -85[kPa].
Model：ZPG16J-7A-X2
(Suction cup form：Multistage bellows type 2.5-Stage)
Model：ZPG(B25,B30)J-7A-X2
(Suction cup form：Multistage bellows type 3.5-Stage)
Dimensions
Model A B D E F G H
ZPGB25J-7A-X2 25 26 27 10.2 32.5 48 52.5
ZPGB30J-7A-X2 30 33 32 13.8 38 54.5 59

-14-
No. TQ1230001-OM107
Plug (M-3P)
(4 pcs)
Tighten by hand and give it an
additional turn approx. 1/4
rotations with a wrench.
Suction cup with adapter
6. How to change the number of cups
6.1 Change to 1 cup
1. Removal of the cup.
(1) Remove the suction cup with adapter from plate B using a spanner.
(2) Loosen the bolt (M4x8), then remove plate B from plate A.
Be careful not to lose the O-ring.
(3) Loosen the bolt for sealing (M6x8), then remove the cup from plate A.
2. Mounting of the plug and suction cup with adapter
(1) Confirm the gasket seal in the accessory plug, then mount the plugs to plate A.
(4 places)
(2) Confirm the gasket seal in the adapter, then mount the suction cup with adapter removed in the
process (1) to plate A.
Reassemble the parts by reversing the disassembling process with specified tightening torque.
Caution
 Tightening torque: 1Nm, (As reference, tighten by 45 degrees using a spanner after tightening by hand.)
If tightened excessively, thread portion may be damaged and gasket may be deformed. This will cause
air leakage. Insufficient tightening may loosen the thread or cause air leakage.
Completion drawing
Plate A
Hexagon socket button bolt (M6x8)
With gasket (M-6G)
(Tightening torque 1±0.1N･m)
Plate B (with O-ring)
Hexagon socket button bolt (M4x8)
(Tightening torque 1.5±0.15N･m)
Suction cup with adapter
(2) Mounting plugs and a suction cup with adapter
(1) Disassemble the suction cups with adapter

-15-
No. TQ1230001-OM107
Plug (M-3P)
(2 pcs.)
Tighten by hand and give it an
additional turn approx. 1/4
rotations with a wrench.
6.2 Change to 2 cups
1. Removal of the cup
(1) Remove the suction cup with adapter from the plate B using a spanner.
(2) Loosen the bolt (M4x8), then remove plate B from plate A.
Be careful not to lose the O-ring.
2. Mounting of the plug
Confirm the gasket seal in the plug, then mount the plugs to plate A.
Reassemble the parts by reversing the disassembling process with specified tightening torque.
Caution
 Tightening torque: 1N・m, (As reference, tighten by 45 degrees using a spanner after tightening by hand))
If tightened excessively, thread portion may be damaged and gasket may be deformed. This will cause air
leakage. Insufficient tightening may loosen the thread or cause air leakage.
Completion drawing
Plate A
Suction cup with adapter
Plate B (with O-ring)
Hexagon socket button bolt
(M4x8)
Tightening torque 1.5±0.15N･m
(1) Disassemble the suction cups with adapter
(2) Plug mounting

-16-
No. TQ1230001-OM107
7.Maintenance
■ Implement the maintenance and check shown below in order to use the vacuum gripper
safely and in an appropriate way for a long period of time.
7.1. Maintenance for suction cups with flange
Caution
1）Check before and after the maintenance work
When the product is to be removed, turn off the power supply, and be sure to cut off the supply pressure and
exhaust the compressed air. Confirm that the air is released to atmosphere.
When mounting the product after the maintenance work, supply compressed air, connect to the power, check
if it functions properly and have a leakage inspection.
2）Maintenance should be performed according to the procedure indicated in the Operation Manual.
Improper handling can cause damage and malfunction of equipment and machinery.
3）Maintenance work
Compressed air can be dangerous when handled incorrectly. Therefore, in addition to observing the product
specifications, replacement of elements and other maintenance activities should be performed by personnel
with sufficient knowledge and experience pertaining to pneumatic equipment.
4）Draining
Remove condensate from air filters and mist separators regularly. If the collected drainage is drained to the
downstream side, it can stick inside of the product, causing operation failure and failure to reach the specified
vacuum pressure.
5）Do not disassemble or modify the product, other than the replacement parts specified in this manual.
7.2. Maintenance for suction cup
Caution
1）Suction cups are disposable. Replace them on a regular basis.
Continued use of suction cups will cause wear and tear on the gripping surface, and the exterior dimensions
will gradually get smaller and smaller. As the cups’ diameter gets smaller, their lifting force will decrease,
though gripping will still remain possible.
It is extremely difficult to provide advice on the frequency of suction cup replacement. This is because there
are numerous factors at work, including surface roughness, operating environment (temperature, humidity,
ozone, solvents, etc.), and operating conditions (vacuum pressure, workpiece weight, pressing force of the
suction cups on the workpieces, presence or absence of a buffer, etc.).
(The weakening of bent parts or the wear or sticking of rubber parts may occur with the bellows type cup.)
Thus, the customer should decide when suction cups should be replaced, based on their condition at the
time of initial use.
The bolts may become loose depending on the operating conditions and environment. Be sure to perform
regular maintenance.
＜How to replace the suction cup＞
・Pull the lock ring upward, and, after lifting it up to the adapter, remove the old cup by pulling it downward.
・While holding the lock ring in the raised position place a new cup onto the adapter.
・Confirm that the cup is securely in place, and then return the lock ring to its original position.
 The cup without lock ring is just inserted to the end of the adapter.
Lock ring
Adapter
Suction cup
Convex
Cup disassembly
Cup assembly

-17-
No. TQ1230001-OM107
2) Mesh
If it is used in such a way that foreign matter is absorbed from the air or the workpiece, the mesh may become
clogged. If the mesh is clogged, it will cause a reduction in the ejector performance. Clean the mesh
periodically as necessary by washing, air blow and so on. If mesh clogging cannot be improved by cleaning,
replace plate B.
･Part number for plate B for replacement : ZXP7-APL1-A-X1
Refer to "6.1 Change to one cup" for the replacement method.
8.Precautions
8.1 Air supply
Warning
■Use clean air.
Supply air containing foreign matter, water, oil, condensate, etc., can cause malfunction of the supply valve and release
valve. So, install air preparation equipment on the upstream side of the product (refer to the piping example below) and
perform maintenance periodically to control the supply air properly.
Refer to "SMC Air Preparation System" for further details on compressed air quality.
Clogged mesh
Unused (No clogging)
Material:
Stainless steel
Plate B
Cups with flange

-18-
No. TQ1230001-OM107
8.2Suction cups with flange precautions
■Designing
Warning
If power or air supply is shutdown, vacuum pressure may decrease and this product may drop a
workpiece during gripping.
Please perform of safety measures by customer systems.
■Mounting
Warning
1) Tighten to the specified tightening torque.
If the tightening torque is exceeded, the body and the mounting screws may break. However, insufficient
torque may cause displacement of the body and loosening of the mounting screws.
2) Hold the product itself when handling.
It can cause the malfunction of the product.
■Piping
Caution
1) Flushing of the inside of the pipes
Before piping is connected, it should be thoroughly blown out with air (flushing) or washed to remove chips,
cutting oil, and other debris from inside the pipe.
2) Tube attachment
・Take a tube having no flaws on its periphery and cut it off at a right angle. When cutting the tube, use tube
cutters TK-1,2,3,5, or 6. Do not use pliers, nippers, scissors, etc. If cutting is done with tools other than tube
cutters, the tube may be cut diagonally or become flattened, etc., making a secure installation impossible,
and causing problems such as the tube pulling out after installation or air leakage. Allow some extra length
in the tube.
・Grasp the tube and push it in slowly, inserting it securely all the way into the fitting.
・After inserting the tube, pull on it lightly to confirm that it will not come out. If it is not installed securely all the
way into the fitting, this can cause problems such as air leakage or the tube pulling out.
3) Tube detachment
・Push in the release button sufficiently, pushing its collar equally around the circumference.
・Pull out the tube while holding down the release button so that it does not come out. If the release button is
not pressed down sufficiently, there will be increased bite on the tube and it will become more difficult to pull
it out.
・When the removed tube is to be used again, cut off the portion which has been chewed before reusing it. If
the chewed portion of the tube is used as is, this can cause trouble such as air leakage or difficulty in removing
the tube.
4) Other Tube Brands
When using other than SMC brand tube, confirm that the following specifications are satisfied with respect to
the tube outside diameter tolerance.
・Nylon tube Within ±0.1mm
・Soft nylon tube Within ±0.1mm
・Polyurethane tube Within+0.15mm, Within -0.2mm
Do not use tube which do not meet these outside diameter tolerances. It may not be possible to connect them,
or they may cause other trouble, such as air leakage or the tube pulling out after connection.
5) Do not apply unnecessary forces, such as twisting, pulling moment loads, vibration, impact, etc., on
fittings or tubing.
6) Tubing, with the exception of coiled tubing, requires stationary installation. Do not use standard tubing
(non-coiled) din applications where tubing is required to travel inside the flexible protection tube.
Tubing that travels may sustain abrasion, extension, or severance due to tensile force. The removal of
tubing from the fitting may also occur. Use caution prior to use in an application.
・Do not lift the product body with the tube after connecting the tube to the product. Otherwise, damage to the
one-touch fittings may occur. For details, refer to the “Handling Precautions for SMC Products” on the SMC
website: https://www.smcworld.com

-19-
No. TQ1230001-OM107
W
Vertical lifting
(This type of application should generally be avoided.)
7) Adjust the length of air tube following by the movement of the robot arm to avoid adding tension the
tube.
When adding the tension of tube repeatedly, it may result in air leakage.
And the tube bending radius in the vicinity of the fitting should be at least the minimum bending radius of the
tubing.
■Workpiece
If water drops or dust are attached on the workpiece surface, they may go into the vacuum ejector and may cause
the low vacuum performance. Also when workpieces are permeable, there is a case that sufficient lifting force
cannot get. In such cases, it is necessary to perform a suction test to check the compatibility to your application
before actual usage.
8.3Suction cup precautions
■Design
Warning
1）In cases where the workpieces are heavy or dangerous objects, etc., take measures to address a
possible loss of gripping force (installation of a drop prevention guide, etc.).
In the case of transportation by vacuum gripping using suction cups, the gripping force is lost when there is a
drop in vacuum pressure. Furthermore, since vacuum pressure can also deteriorate due to the wear and
cracking of cups, vacuum leakage from piping, etc., be certain to perform maintenance on vacuum
equipment.
■Selection
Caution
1）The cup materials which can be used differ depending upon the operating environment.
An appropriate cup material should be selected. Furthermore, since suction cups are manufactured for use
with industrial products, they should not come into direct contact with medicines, food products, etc.
2）Depending upon the weight and shape of the workpieces, the diameter, quantity, and shape of cups
suitable for use will vary.
Refer to “3.2. How to calculate theoretical lifting force” for the theoretical lifting force. Also, the selectable
cups will differ based upon conditions other than the above, such as the condition of the workpiece surface
(presence or absence of oil or water), the workpiece material, and its gas permeability. Confirmation is
necessary by actually performing vacuum gripping on the subject workpieces.
3）Do not apply an impact or large force to a cup when gripping a workpiece.
This will cause the deformation, cracking, and wear of the cup to be accelerated. The stiffening ribs, etc.,
should touch lightly, while staying within the cup skirt’s deformation range. Positioning should be performed
accurately, especially in the case of small-diameter cups.
4）When transporting vertically, factors such as acceleration, wind pressure, and impact force must be
considered in addition to the workpiece weight.
Use caution particularly when lifting items such as glass plates and circuit boards because a large force will
be applied by wind pressure. When a workpiece which is oriented vertically is transported horizontally, large
forces are applied by acceleration when movement is started and stopped. Furthermore, in cases where the
cup and workpiece can slip easily, accelerations and decelerations of horizontal movement should be kept to
a minimum.
5）When transporting flat shaped workpieces that have large surface areas using multiple cups, care
must be taken in arranging the cups, so that the workpieces are evenly gripped.
6）Use caution since the workpiece could rotate during transfer.
Use of more than one cup for each workpiece is recommended.
W
Cup
Horizontal lifting
