SMC Networks VQD1000-V Series User manual

<Example>
VQD1000-V-05-5-B1
Blanking plate assembly
1
Stations
2345
D side U side
Symbol
N.O.
N.C.
Integral
tank
Connection port
(M5 or Rc 1/8 plug)
VQD1151W-:
(For switching)
10-VQ110-:-X46
(For charging release air)
A
(Work piece)
Vacuum pressure
(Suction air) V
Positive pressure
(Release air) P
Integral
tank
Positive pressure
(Release air) P
Vacuum pressure
(Suction air) V
10-VQ110-:-X46
(For charging release air)
VQD1151W-:
(For switching)
Connection port
(M5 or Rc 1/8 plug)
A
(Work piece)
10-VQ110-:-X46
(For charging release air)
VQD1151W-:
(For switching)
Positive
pressure: P
(Release air)
Vacuum
pressure: V
(Suction air)
Work piece: A
(Pad or Nozzle)
How to Order
05
Vacuum /
Release Unit VQD1000 V 5
Note) Calculate and set the volume using the formula for the relationship
between pressure and the release air tank on page 1963.
Nil
L
0.8 cm3
3.2 cm3
Guideline: 1 m or shorter distanced from a work piece
Guideline: 1 m or longer distanced from a work piece
Volume of release air tank
Nil
C
N.O. specifications
N.C. specifications
Valve type
Nil
Q
—
CE-compliant
CE-compliant
01
02
10
1 unit (1 station)
2 units (2 stations)
10 units (10 stations)
Stations
5
6
24 VDC
12 VDC
Voltage
Nil: L plug connector
Standard type
LO: Without L plug connector
M: M plug connector
 The operability of
attaching and
detaching connectors
and manual override
will decrease.
MO: Without M plug connector
Electrical entry
Note) The blanking plates are
mounted in order starting
on the U side of the
vacuum/release unit.
Nil
B1
B2
B9
Without blanking plate
1 set
2 sets
9 sets
Blanking plate
[Option]
Vacuum / Release Unit
Series VQD1000-V
1964

Specifications
Replacement Parts
Valve construction
Fluid
Suction flow rate/Sonic conductance
Manual override
Impact/Vibration resistance
Mounting position
Enclosure
Coil rated voltage
Allowable rated voltage
Coil insulation type
Power
consumption
Electrical entry
Suction (negative pressure)
Release (positive pressure)
Suction (OFF)
Release (ON)
Suction (ON)
Release (OFF)
N.O.
specifications
N.C.
specifications
VQD1151W (for switching)
10-VQ110 (for release supply)
Operating
pressure range
Response
time
Direct operated poppet valve
Air, Inert gas/Low ozone resistant product
0 to –100 kPa
0 to 0.7 MPa
2 o1 msec
4 o1 msec
4 o1 msec
2 o1 msec
16 L/min/0.27 dm3/(s·bar)
Non-locking push type
150/30 m/s2
Unrestricted
Dusttight
24 VDC, 12 VDC
o10% of rated voltage
Class B or equivalent
3.2 W energy saving type (Inrush: 3.2 W, Holding: 2.4 W)
1 W
L/M plug connector (with light/surge voltage suppressor)
:Solenoid valve for switching
VQD1151W 5
5
6
24 VDC
12 VDC
Voltage
L
LO
M
MO
L plug connector
L plug connector (Without connector)
M plug connector
M plug connector (Without connector)
Electrical entry
L
LO
M
MO
L plug connector
L plug connector (Without connector)
M plug connector
M plug connector (Without connector)
L
.Manifold base unit
VVQD1000 1A
;Blanking plate assembly
VVQD1000 10A V
V01
Stations
@Solenoid valve for charging release air
10-VQ110
5
6
24 VDC
12 VDC
Voltage
Electrical entry
X46
Note) Product with specification on pressure charging A port.
If a standard product is used, external leakage may occur.
Note) One set includes a blanking plate assembly for the solenoid valve for
switching and one for the solenoid valve for charging release air.
5L
VP
@ : .
;
VQD1000-V(C)
VQD1000-V(C)L
W = 80n + 31
W = 84n + 49
W: Weight (g)
N: No. of unit (Stations)
Product Weight (Formula)
01
02
10
1 unit (1 station)
2 units (2 stations)
10 units (10 stations)
Nil
L
0.8 cm3
3.2 cm3
Guideline: 1 m or shorter distanced from a work piece
Guideline: 1 m or longer distanced from a work piece
Volume of release air tank
Nil
C
N.O. specifications
N.C. specifications
Valve type
Nil
Q
—
CE-compliant
CE-compliant
Nil
Q
—
CE-compliant
CE-compliant
Valve specifications
Electric
specifications
Vacuum / Release Unit Series VQD1000-V
1965
VV100
VV061
V100
S070
VQD
VQD-V
VKF
VK
VT
VS4
VS3
VQD-V

Dimensions
The dimensions shown in brackets indicate the VQD1000-V(C)L-:: / tank volume 3.2 cm3.
L1
L2
23
17
1
Ln
34
28
2
45
39
3
56
50
4
67
61
5
78
72
6
89
83
7
100
94
8
111
105
9
122
116
10
L: Dimensions (VQD1000-V(C)-::/ Standard type:Tank volume 0.8 cm3)
Formula: L1 = 11n + 12, L2 = 11n + 6 (Max. 10 stations)
L1
L2
25
19
1
Ln
36
30
2
47
41
3
58
52
4
69
63
5
80
74
6
91
85
7
102
96
8
113
107
9
124
118
10
L: Dimensions (VQD1000-V(C)L-::/ Tank volume 3.2 cm3)
Formula: L1 = 11n + 14, L2 = 11n + 8 (Max. 10 stations)
25
21.4
66
77.2 (L type)
P = 11
P = 11
41.1 (46.1)
40.7 (45.7)
58
49
82.7 (M type)
2 x M5
(Release supply port)
2 x M5
(Vacuum supply port)
AA
V
11.5 (13.5)
14.5 (16.5) P = 11
10.5 (15.5)
11.5 (13.5)
8.3 (10.3)
5 (7)
29.5
M plug connector
L plug connector
(Standard type)
33
L1
L2
P
n x M5 (Rc 1/8) plug
(Connection port)
VP
n x M5
(Output port)
4 x ø3.5
(Mounting hole)
25.7 (L type)
24.7 (M type)
22.5 (27.5) 15 (20) 7.5 (12.5)
D side U side
Stations 123 n
Series VQD1000-V
1966

Series VQD1000-V
Specific Product Precautions
Be sure to read before handling.
Refer to front matter 53 for Safety Instructions and pages 3 to 8 for 3/4/5 Port
Solenoid Valve Precautions.
Connected actuator is started by manual operation.
Use the manual override after confirming that there is
no danger.
Warning
Caution
Non-locking push type (Tool required)
VQD1151W-:
(For switching)
10-VQ110-:-X46
(For charging
release air)
Attaching and detaching connectors
# To attach a connector, hold the lever and connector unit between
your fingers and insert straight onto the pins of the solenoid valve
so that the lever’s pawl is pushed into the groove and locks.
#To detach a connector, remove the pawl from the groove by
pushing the lever downward with your thumb, and pull the
connector straight out.
Note) Gently pull the lead wire, otherwise it may cause contact failure or disconnection.
Caution
VQD1151W-:
(For switching)
For the VQD1151W specifications (energy saving type), power
consumption at holding is reduced with the above circuit.
Refer to electrical power waveform as shown below.
<Energy saving type’s electrical power waveform>
(Rated voltage: at 24 VDC)
Caution
When simultaneously energizing 3 stations or more,
make sure to place an energized and non-energized
valve alternatively.
However, if 3 stations or more need to be energized si-
multaneously at the time of installing or adjusting, the
energizing time should be less than 30 minutes to
achieve an energized status not exceeding 50%.
24 V
0 V
3.2 W
2.4 W
0 W 15 to 25 ms
Applied voltage Cover
Groove
Pin
Lever
Connector
Lever
Connector
ø3
push part
Caution
After confirming the gasket is correctly placed under
the valve, securely tighten the bolts with the proper
torque shown in the table below.
s)NORDERTO TURN IT /. PUSH DOWN THE MANUAL
override button in the direction the arrow ( )
indicates until it stops (approx. 0.5 mm), and
RELEASEITTOTURNIT/&&
Manual Override Operation
Valve Mounting
Caution
When piping to a product, check the supply port, etc.
Also, when tightening the piping tube, clamp the base unit to
avoid any undue force from being applied to the valve.
)F A FORCE OF  . OR MORE IS APPLIED TO THE COIL ESPECIALLY THE
connecting pin may be deformed, resulting in malfunction.
When Piping to a Product
How to Use Plug Connector
Wiring Specifications
Proper tightening torque (N·m)
0.18 to 0.25
10-VQ110-:-X46
(For charging release air)
Coil temperature may get high due to ambient tempera-
ture or energizing duration. Do not touch the valve by
hand directly. When there is such a dangerous case to
be touched by hand directly, install a protective cover.
Warning
Continuous Energization
Energy saving type
3/,
3/,
A
C
Black (−)
Red (+)
Lead wire
Energy
saving
)#
Diode
Varistor
A
C
Lead wire
LED
Black (−,+)
Red (+,−)
1967
VV100
VV061
V100
S070
VQD
VQD-V
VKF
VK
VT
VS4
VS3
VQD-V

ZFC050-M5X50
Related Products
Suction Filter
14
ø9.2
A A
M5 x 0.8
IN OUT
(3.5)
ø9.2
14
17.5
3
Section diagram A-A
Width across flats 2
Element
M5 x 0.8
Filtration degree
Fluid
Operating pressure range
Ambient temperature
20 Mm (Nominal)
Air
–100 to 700 kPa
0 to 60nC (No freezing)
Specifications
1. To screw in OUT side port (M5 male thread), tighten by hand
before giving it an additional 1/4 turn with a tightening tool.
2. When replacing the element, remove the IN side body using
the hexagon surface on the IN side, then replace the element.
After replacing the element, tighten the IN side body with the
tightening torque 0.5 to 0.7 N·m.
3. As a rule, replace the element when the pressure drops by 20
kPa.
Caution
Replacement element part no. ··· ZFC-EL050-X50
Width across
flats 7
Example of mounting to the manifold base (A port)
of the vacuum/release unit VQD1000-V series
1968

