Smith & Noble Fusion Hardware User manual

STEP BY STEP INSTALLATION INSTRUCTIONS
Ceiling Mount
Corner Single Rod Set
Fusion
Hardware
© 2019 Smith & Noble Home, Inc. All Rights Reserved SN0519
Warranty Service
The enjoyment of your hardware should be everlasting, which is why our
products come with a limited lifetime warranty. The warranty applies to the
original owner, requires a proof of purchase (hang on to your receipt!) and
covers defects in material or craftsmanship. Hardware must have been properly
installed. We reserve the right to determine if your hardware warrants a repair
or a replacement. Visit smithandnoble.com/guarantee to see full details. In
need of warranty service? Call us at 800.248.8888 and we’ll arrange for a repair
or replacement ASAP.

2
800.248.8888
1smithandnoble.com
A Smooth Set-Up
We want you to love your new hardware and that includes
having a smooth installation experience. We suggest saving
        
please reach out to us for help. It’s why we’re here. Call us at
800.248.8888 for more info on installation.
We recommend you hold on to all packaging until your
hardware is fully installed. Should something go wrong (we
strongly doubt it), we want any potential returns to be a
painless as possible.
Customer Service Hours
Monday — Friday: 6am — 6pm PT
Saturday — Sunday: 7am — 4pm PT
smithandnoble.com
Everything
You Need
Table of Contents
Step 1 - Getting Started ..................................3
Overview - Ceiling Mount Corner Single Rod Set...............4
Step 2 - Mounting the Brackets ........................ 5 - 6
Step 3 - Attaching the Rod Connector......................7
Step 4 - Attaching the Finials and Rings ....................8
Step 5 - Securing Rod to Brackets .........................9
Accessories - Baton/Wand ....................................9
Accessories - Ball Tiebacks...................................10
Accessories - Hold Back .................................11 - 12
Care & Cleaning ...........................................13
Warranty ..........................................Back Cover

34
smithandnoble.com 800.248.8888
STEP 1 - GETTING STARTED OVERVIEW
Before you begin, check the accompanying diagram to make sure you have all the parts you
need. You’ll need to make sure the surface you intend to install your hardware is sturdy enough
to accommodate the brackets. If you’re screwing directly into a surface this means locating
wood studs that are strong enough to securely bond with the included screws. Otherwise,
you’ll need to use a secure fastener (as illustrated) but please note this piece is not included.
Tools & Parts Ceiling Single Corner Rod Set
WALLBOARD OR PLASTER:
Hollow wall applications: Use a secure fastener designed

METAL:
Prepare by pre-drilling holes and then using the included screws.
CONCRETE, STONE, BRICK OR TILE:

be sure it’s designed to support the weight of the product being installed (if you’re not sure,
either give us a call or ask a professional at your local hardware store). Once obtained, follow
the fastener manufacturer’s instructions regarding proper installation.
TOOLS YOU WILL NEED TO INSTALL YOUR HARDWARE:
Pencil, screwdriver, ¼" nut driver, level, and a drill with a 764" drill bit.
Note: It’s important to monitor the amount of pressure you apply when using a drill. If the
screws are too tight this may cause the screw itself to break off in the wall or window frame.
MOLLY
BOLT
SELF DRILLING
ANCHOR
TOGGLE
BOLT
CEILING MOUNT BRACKET
CEILING
BRACKET
ROD QTY BRACKET QTY SINGLE - ELBOWS QTY ROD WIDTH
1 2 1 12"— 48"
1 3 1 4"—72"
1 4 1 4"—96"
2 5 1 4"—144"
2 7 1 4"—192"
3 7 1 4"—216"
3 9 1 4"—288"
411 14"—360"
413 14"—384"
FINIAL ROD
CORNER
ELBOW
BRACKET
RINGS
WALLBOARD OR PLASTER:
Hollow wall applications: Use a secure fastener designed

METAL:
Prepare by pre-drilling holes and then using the included screws.
CONCRETE, STONE, BRICK OR TILE:

be sure it’s designed to support the weight of the product being installed (if you’re not sure,
either give us a call or ask a professional at your local hardware store). Once obtained, follow
the fastener manufacturer’s instructions regarding proper installation.
TOOLS YOU WILL NEED TO INSTALL YOUR HARDWARE:
Pencil, screwdriver, ¼" nut driver, level, and a drill with a 764" drill bit.
Note: It’s important to monitor the amount of pressure you apply when using a drill. If the
screws are too tight this may cause the screw itself to break off in the wall or window frame.
SCREWDRIVER & PENCIL
(NOT INCLUDED) DRILL
(NOT INCLUDED)
LEVEL
(NOT INCLUDED)
SCREWS CORNER BRACKET
ALLEN WRENCHES
SET SCREWS

56
smithandnoble.com 800.248.8888
Mounting the Brackets
Check to make sure the circles are
level & aligned with each other.
Remove mounting plate and center
it inside of the circle outline on wall.
Mark the screw hole locations for all
brackets. See Figure B.
Attach the metal mounting plate to
the ceiling, aligning the holes in the
plate with the marks made in the pre-
vious step, see Figure B. Be sure and
attach the plate to the ceiling with
the appropriate mounting hardware.
(It is always recommended to try and
attach to the ceiling joists found in-
side ceiling. Where this is not possi-
ble please use an anchor suitable to
carry the weight of your hardware
selection as well as your draperies
and any accessories.)
If using plastic expansion anchors,
pre-drill holes using 3/16" drill
bit. If drilling directly into a stud
or wood trim, pre-drill holes with
3/32" drill bit.
Screw on the decorative portion of
the bracket to the mounting base
until it is tight and the open side of
bracket faces horizontally and the
same direction on all. See Figure C.
STEP 2 - MOUNTING BRACKETS STEP 2 - MOUNTING BRACKETS
CENTER ROD
FIGURE B
FIGURE C
Mark all holes needed
showing locations of screw
holes for all brackets.
MOUNTING
PLATE
SET
SCREW
BRACKET
STEM
DECORATIVE
BASE
INSIDE
POST
MOUNTING
PLATE
Mounting the Brackets
Place the panel on the left rod. Hold it up to
the spot you wish to install it making sure
there is enough spacing from wall to where
the back of drapery will hit. Usually about
2” away from wall or window. After you’ve
located the ideal location, use a pencil to
mark the ceiling where the back of the rod
is resting. Repeat on right side.
Remove the panel from the rods and then
center the rods over the window opening
at the desired height. Using the pencil,
mark where the ends of each rod are posi-
tioned; if you’re using a center bracket,note
the middle point between these two spots
as well. If you have more than one center
bracket spread these evenly between the
two end brackets and center point. If you
have a spliced rod, mark where that splice
is as well on the wall since you will need to
add a bracket at that point as well. Meas-
ure 2” inward from the marks you’ve made
on both ends and mark those spots. This is
where the brackets will be installed.
Place ceiling brackets level against ceil-
ing at the marked spots. Using a pencil,
lightly draw a circle around the base of
the brackets onto ceiling, see Figure A.
FIGURE A
X X
X
X

78
smithandnoble.com 800.248.8888
Depending on your order, you may have
received a rod connector.
A rod connector is the short piece of met-
al tubing placed inside each end of the
rods in a multi-segment system to join
them together.
STEP 3 - ATTACHING THE ROD CONNECTOR STEP 4 - ATTACHING THE FINIALS & RINGS
ROD CONNECTOR
STEP 2:
Now slide the second rod segment
over the exposed end of the connector,
making sure there is no gap between the
two segments.
STEP 1:
On the open end of one-rod segment,
slide the connector halfway inside,
leaving the other half exposed.
Insert the rod through the first bracket
and then place the required number
of rings on the rod but leave two rings
out. Then attach the elbow on the oth-
er end. All the rings should now be in
between the brackets and elbow; repeat
on the other side.
For split drapery, add a ring at each
end of the rod and then attach the
finial. This will prevent drapery to be
pulled all the way to one side or the
other when opening and closing it. If
you are opening your drapery only from
one side, leave one ring between the
finial and bracket on the side you won’t be
opening it from. See Below.
ATTACH FINIAL
PLACE ONE RING
BETWEEN FINIAL
AND BRACKET
For treatments using rings and do
not have a center support bracket
Attach the finial to one end of the rod,
and slide it through the first bracket.
Position the drapery panel on the rod,
and then slide it through the elbow.
Repeat on the other side.
For treatments without rings and no
center support bracket
Insert the rod through the end and
center support bracket. Before at-
taching the elbow, place half of the re-
quired number of rings on the rod but
leave two rings out. Then slide the rod
and attach the elbow. Go back to the
opposite side and take the rod out of
the end bracket to allow you to place
the remaining of the rings minus two
of them. All the rings should now be in
between the two end brackets, center
support bracket(s) & elbow. Repeat on
the other side. .
For split drapery, add a ring at one end
of the rod and then attach the finial. This
will prevent drapery to be pulled all the
way to one side or the other when opening
and closing it. If you are opening your
drapery only from one side, leave one
ring between the finial and bracket on
the side you won’t be opening it from.
For treatments using rings and have
a center support bracket
Attach the finial to one end of the rod
and slide it through the first bracket.
Position one of the drapery panels on
the rod, and then slide the rod through
the center support bracket. Position the
other drapery panel on the rod, and then
slide the rod through the elbow. Repeat
on the other side.
For treatments without rings and a
center support bracket
TIGHTEN
SET SCREW
ROD
SEGMENT
ROD
CONNECTOR
ROD
SEGMENT

910
smithandnoble.com 800.248.8888
STEP 5 - SECURING ROD TO BRACKETS
ACCESSORIES
ACCESSORIES
Baton/Wand (optional)
After your hardware is installed, attach
the baton to the eyelet of the first ring
by the clip.
Tiebacks (optional)
BALL TIEBACK
STEP 1
In order to locate where to install your
tiebacks, measure the height of the
window and divide this by two. Using
the previous calculation, mark that
spot on the wall with a pencil.
To ensure you like the way the panel
drapes, gather one side and sweep
it over to the approximate proposed
location. Once you’re sure the tieback
is in the perfect location, use your
pencil to mark the spot to install it.
Measure the distance from the
bottom or top of the window to the
tieback to mark the other side and
ensure they’re even.
Now hold the tieback hardware on
the wall at the desired location and
rest a level above it, adjusting it until
it’s straight.
STEP 2:
Place tieback level against wall in
desired locations and attach to the wall.
BATON/
WAND
CLIP
EYELET
DRAPERY
RING
Push clip through
the eyelet of the
drapery clip
Baton/Wand
Baton/Wand
X
Once the rod has been placed on the
brackets, secure the rod in place by
tightening the bracket set screw with
the allen wrench provided.
SET
SCREW

11 12
smithandnoble.com 800.248.8888
ACCESSORIES ACCESSORIES
Hold Back (optional)
STEP 1
In order to locate where to install your
tiebacks, measure the height of the
window and divide this by two.
Using the previous calculation, mark
that spot on the wall with a pencil.
To ensure you like the way the panel
drapes, gather one side and sweep it
over to the approximate proposed lo-
cation. Once you’re sure the tieback is
in the perfect location, use your pencil
to mark the spot to install it.
Measure the distance from the
bottom or top of the window to the
tieback to mark the other side and
ensure they’re even.
STEP 2:
Hook installation is an option depend-
ing on desired drapery style. When
using the hook option assemble the
" pole,
as shown to the right (A).
STEP 3:
" pole un-
til both holes line up as shown to the
right (B).
STEP 4:
To install the mount screw, place it
through the center of the 1½" pole
& the optional hook, as shown to the
right (C).
STEP 5
Attach the Hold Back to the wall by
holding Hold Back assembly above
the hook hole location. Fingers placed
below this point or on the wall can
become pinched between the wall and
the Hold Back (D).
STEP 6:
Locate the Hold Back screw and mount
hold back, as shown at left (E).
STEP 7:
Assemble the Hold Back by placing
" pole. To secure
the finial to the pole tighten the 4 mm
set screw to the pole (F).
Keep fingers away
from edge and wall
during installation.
Keep fingers away
from edge and wall
during installation.
Hold Here
HOOK
HOLD BACK
MOUNT SCREW
FINIAL
A
D
B
E
C
F

13 14
smithandnoble.com 800.248.8888
CARE & CLEANING
Minimal care and cleaning is needed to maintain the beauty of your Hardware.
To Vacuum: Use brush or dust head attachment.
To Dust: Use soft, clean cloth.
