Smithco 300G600 Quick start guide

Spray Star 3180
Model 30-000-E
SN: 300G600
January 2021
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]
Parts & Service

Introduction Service Diagrams Parts Accessories Reference
CONTENTS
Introduction............................................1-3
Introduction........................................................................ 1
General Safe Practices...................................................... 2
Specications ................................................................... 3
Optional Spray Equipment................................................. 3
Service..................................................4-11
Maintenance...................................................................4-6
Wheel Creep...................................................................... 6
Adjustments....................................................................7-8
Service Chart................................................................9-10
Storage............................................................................ 11
Diagrams ............................................12-15
Wiring Diagram...........................................................12-13
Hydraulic Diagram......................................................14-15
Parts....................................................16-57
Body & Frame ............................................................16-17
Nose Cone .................................................................18-19
Seat/Control Panel .....................................................20-21
Steering Orbital Drawing ................................................. 22
Fuel Tank ........................................................................ 23
Foot Pedal Linkage.....................................................24-25
Spray Boss Linkage....................................................26-27
Front Axle .................................................................28-29
Oil Tank.......................................................................30-31
Seat Panel..................................................................32-33
Engine ........................................................................34-35
Hydrostatic Pump .......................................................36-37
Cooler and Exhaust....................................................38-39
Rear Wheel Drive ............................................................ 40
Spray Pump..................................................................... 41
Spray Tank..................................................................42-43
Turbo Quad Agitator ........................................................ 44
16-998 Hypro®Pump ...................................................... 45
15-301 Orbital.............................................................46-47
76-197 Eaton Gear Pump................................................ 48
30-101 Eaton Motor......................................................... 49
30-102 Hydrostatic Pump...........................................50-53
30-099 Auburn Power Wheel®...................................54-55
30-100 Disc Brake......................................................56-57
Accessories .....................................58-119
3182 System Plumbing ...............................................58-59
3184 System Plumbing...............................................60-61
TeeJet® Radion Wiring ..................................................... 62
TeeJet® 744A Wiring ........................................................ 63
Plumbing Star Command I&II System........................64-65
Star Command I Rear Module Mount.............................. 66
Star Command I Wiring ................................................... 67
Star Command II Rear Module Mount............................. 68
Star Command II Wiring .................................................. 69
Control Mounts ...........................................................70-71
20-817 Regulator Valve ................................................... 72
20-785 Regulator Valve ................................................... 73
15-743 Manifold Ball valve .............................................. 74
15-737/14-628 Flanged Strainer...................................... 75
14-801 Agitation Strainer................................................. 76
17-580 20’ HD Boom ..................................................78-81
17-580 20’ HD Boom 744 and Radion Plumbing............. 82
17-580 20’ HD Boom Star Command I Plumbing............ 83
17-580 20’ HD Boom Star Command II Plumbing........... 84
17-585 18’ HD Boom Star Command II Plumbing........... 85
17-585 18’ HD Boom ..................................................86-89
17-585 18’ HD 744 and Radion Plumbing ....................... 90
17-585 18’ HD Boom Star Command I Plumbing............ 91
Star Command I Nozzle Assembly.............................92-93
Standard Nozzle Assembly.............................................. 94
Star Command II Nozzle Assembly................................. 95
30-010 Electric Hose Reel .........................................96-98
30-009 Hose Reel ........................................................... 99
Hose Reel Installation.............................................100-101
Hose Reel Adjustments ................................................. 101
30-375 Foam Marker Installation............................102-107
14-291 Foam Marker Parts List..............................108-109
Foamer Regulator Valve................................................ 110
14-515 Water Meter Kit (Gallons)...................................111
15-618 Water Meter Kit (Liters) ......................................111
30-006 Fresh Water Tank - Rear Mount ........................ 112
20-758 Fresh Water Tank - Front Mount........................ 113
15-835 Tank Rinsing System........................................ 114
30-350 26GAL Rinse Tank............................................ 115
30-007 Chemical Clean-load System..................... 116-117
15-620 Chemical Clean-load®Eductor ................... 118-119
Reference .......................................121-122
Decal List....................................................................... 121
Quick Reference Replacement Parts ............................ 122

1
Introduction
WARNING
Failure to follow cautious operating practices can re-
sult in serious injury to the operator or other persons.
The owner must understand these instructions, and
must allow only trained persons who understand these
instructions to operate this vehicle.
INTRODUCTION
Thank you for purchasing a Smithco product.
Read this manual and all other manuals pertaining to the Spray Star 3180 carefully as they contain safety, op-
erating, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment
damage.
Keep manuals in a safe place after operator and maintenance personnel have read them. Right and left sides
are from the operator’s seat, facing forward.
All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering
parts. The machine serial number is located on the main frame behind the left front wheel. Refer to engine
manual for placement of engine serial number.
For product and accessory information, help nding a dealer, or to register your product please contact us at
www.Smithco.com.
Information needed when ordering replacement parts:
1. Model Number of machine
2. Serial Number of machine
3. Name and Part Number of part
4. Quantity of parts
For easy access record your Serial and Model numbers here.

 
WARNING:
Engine exhaust and some of its constituents are
known to the State of California to cause cancer,
birth defects, and other reproductive harm.
For more information visit
www.P65Warnings.ca.gov

2
Introduction
SAFE PRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine.
2. Never allow anyone to operate or service the machine or its optional equipment without proper training
and instructions. Never allow minors to operate any equipment.
3. Learn the proper use of the machine, the location and purpose of all the controls and gages before you
operate the equipment. Working with unfamiliar equipment can lead to accidents.
4. Wear all the necessary protective clothing and personal safety devises to protect your head, eyes, ears,
hands and feet. Operate the machine only in daylight or in good articial light.
5. Inspect the area where the equipment will be used. Pick up all debris you can nd before operating.
Beware of overhead obstructions and underground obstacles. Stay alert for hidden hazards.
6. Never operate equipment that is not in perfect working order or without decals, guards, shields, or other
protective devices in place.
7. Never disconnect or bypass any switch.
8. Carbon monoxide in the exhaust fumes can be fatal when inhaled, never operate a machine without
proper ventilation.
9. Fuel is highly ammable, handle with care.
10. Keep engine clean. Allow the engine to cool before storing and always remove the ignition key.
11. Disengage all drives and set park brake before starting the engine.
12. Never use your hands to search for oil leaks. Hydraulic uid under pressure can penetrate the skin and
cause serious injury.
13. This machine demands your attention. To prevent loss of control or tipping of the vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
D. Stay alert for holes in the terrain and other hidden hazards.
14. Before leaving operator’s position:
A. Disengage all drives.
B. Shut engine o󰀨 and remove the ignition key.
C. If engine has to run to perform any maintenance keep hands, feet, clothing and all other parts of
body away from moving parts.
15. Keep hands, feet and clothing away from moving parts. Wait for all movement to stop before you clean,
adjust or service the machine.
16. Keep the area of operation clear of all bystanders.
17. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase.
18. Use parts and materials supplied by Smithco only. Do not modify any function or part.
19. Use caution when booms are down as they extend out beyond the center line of the machine.
20. The tank is a conned space, take precaution.
These machines are intended for professional maintenance on golf courses, sports turf, and any other
area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any task is
expressed or implied.

3
Introduction

WEIGHTS AND DIMENSIONS
Length 128" (3.3m)
Width 72" (1.8m)
Width w/ Booms Open 20' - 260" (6.6m) 18' - 240" (6.1m)
Height w/ Roll Bar 84" (2.1m)
Height w/ Booms Folded 20' - 136" (3.5m) 18' - 110"(2.8m)
Wheel Base 68" (1.7m)
Weight Empty 2340 lbs (1061 kg)
Weight Full 4950 lbs (2245 kg)
SOUND LEVEL   
At ear level 88 dBA
At 30 ft. (9.14 m) 77 dBA
ENGINE
Make Kubota
Model# WG1605
Code / Spec# G-E3-KEA-3
Rated Horsepower 57 hp (42.5 kW) @3600RPM
Fuel (EMISSIONS) Unleaded 87 Octane Gasoline Minimum
Cooling System Liquid Cooled
Lubrication System Full Pressure
Alternator 40 Amp
WHEELS & TIRE Front: Two 20 x 11.00 x 10 Turf; 20 psi (1.4 bar)
Rear: Two 29 x 14.00 x 15 Multi-Trac; 30 psi (2.0 bar)
SPEED
Innitely Variable 0-10 m.p.h. (0-18 kph)
 Automotive type 24F - 12 volt
BCI Group Size 24
Cold Cranking Amps 900 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
Maximum Height 10" (25 cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 20 gallon (75.7 liters)
Hydraulic Fluid 10 gallon (37.8 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil
OPTIONAL EQUIPMENT
15-618 Water Meter Kit (liters) 30-009 Manual Hose Reel
14-515 Water Meter Kit (Gal) 30-010 Electric Hose Reel
17-585 18' HD Super Boom 30-350 26 Gallon Wash Tank
17-580 20' HD Super Boom 30-375 Foam Marker
30-006 Rear Fresh Water Tank 20-758 Front Fresh Water Tank
30-007 Chemical Cleanload Safe Fill 15-850 Sunshade Canopy
17-622 Drift Reduction Boom Shield 15-835 Tank Rinse System

4
Service
F
MAINTENANCE
Before servicing or making adjustments to machine, stop engine and remove
key from ignition.
Use all procedures and parts prescribed by the manufacturer's. Read the en-
gine manual before operation.

Use No. 2 General purpose lithium base grease and lubricate every 100 hours. The Spray Star 3180 has 8
grease ttings.
A. One on the rod end of hydraulic cylinder.
B. One on each the right and left spindles.
C. One on the center front pivot.
D. One on the idler arm.
E. One on each of the pedal relays.
F, One on the linkage relay.
G. One on each end of tie rod.
ELECTRICAL CONNECTIONS
Use dielectric grease on all electrical connections.
AIR CLEANER ON ENGINE
Since the air cleaner on this engine is a dry type, never apply oil to it.
1. Open evacuator valve (see engine manual) once a week to remove large particles of dust and dirt.
2. Wipe the inside of the air cleaner with a cloth if it gets wet or dirty.
3. Avoid touching the element except when cleaning.
4. When dust adheres to the element, gently tap element on at surface.
5. When carbon or oil adheres to the element clean according to engine manual.
6. Replace the element every year or every 6 months.
7. IMPORTANT - Make sure wing bolt for the element is tight enough. If it is loose, dust and dirt may be
sucked in, wearing down the cylinder liner and piston ring, resulting in poor power output.
Do not use petroleum solvents, e.g.., kerosene, which will cause cartridge to
deteriorate. Do not use pressurized air to clean cartridge. Pressurized air can
damage cartridge.

5
Service
MAINTENANCE
ENGINE OIL
Change and add oil according to chart below based on air temperature at the time of operation. Do not over-
ll. Use a high quality detergent oil classied "For Service use API classication SJ or higher" oil. Use no spe-
cial additives with recommended oils. Do not mix oil with gasoline.
Starting Temperature Range Anticipated Before Next Oil Change
HYDRAULIC OIL
1. Use SAE 10W-40 API Service SJ or higher motor oil.
2. For proper warranty, change oil the rst 50 hours and then every 200 hours or annually, which ever is
rst.
3. Oil level should be 2-2½" (5-6.4cm) from top of the tank when uid is cold. Do not overll.
4. After changing oil, run the machine for a few minutes. Check oil level and for leaks.
5. Always use extreme caution when lling hydraulic oil tank or checking level to keep system free of con-
taminants. Check and service more frequently when operating in extremely cold, hot or dusty conditions.
6. If the natural color of the uid has become black or smells burnt, it is possible that an overheating prob-
lem exists.
7. If uid becomes milky, water contamination may be a problem.
8. If either of the above conditions happen, change oil immediately after uid is cool and nd the cause.
Take uid level readings when the system is cold.
9. In extreme temperatures you can use straight weight oil. We recommend SAE 30W API Service SG
when hot (above 90°F (33°C)) and SAE 10W API Service SJ or higher when cold (below 32°F (0°C)
ambient temperature. Use either motor oil or hydraulic oil, but do not mix.
10. Oil being added to the system must be the same as what is already in the tank. Mark the tank ll area
as to which type you put in.
TIRE PRESSURE
Caution must be used when inating a low tire to recommended pressure. Over inating can cause tires to
explode. Front tires should be 20 psi (1.4bar) and rear tires should be 30 psi (2.0bar). Improper ination will
reduce tire life considerably.






6
Service
MAINTENANCE

Batteries normally produce explosive gases which can cause personal injury. Do not allow ames, sparks or any ignited
object to come near the battery. When charging or working near battery, always shield your eyes and always provide
proper ventilation.
Battery cable should be disconnected before using “Fast Charge.”
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended charging rate. If
electrolyte starts boiling over, decrease charging.
Always remove grounded (-) battery clamp rst and replace it last. Avoid hazards by:
1. Filling batteries in well-ventilated areas.
2. Wear eye protection and rubber gloves.
3. Avoid breathing fumes when electrolyte is added.
4. Avoid spilling or dripping electrolyte.
Battery Electrolyte is an acidic solution and should be handled with care. If electrolyte
is splashed on any part of your body, ush all contact areas immediately with liberal
amounts of water. Get medical attention immediately.
Use of booster battery and jumper cables. Particular care should be used when con-
necting a booster battery. Use proper polarity in order to prevent sparks.

1. Shield eyes.
2. Connect ends of one cable to positive (+) terminals
of each battery, rst (A) then (B).
3. Connect one end of other cable to negative (-) termi-
nal of "good" battery (C).
4. Connect other end of cable (D) to engine block on
unit being started (NOT to negative (-) terminal of
battery)
To prevent damage to other electrical components on unit
being started, make certain that engine is at idle speed
before disconnecting jumper cables.
WHEEL CREEP
WHEEL CREEP
"Creep" is when the engine is running and hydrostatic transmission is in neutral, but due
to inadequate alignment, wheels still move. Do the following procedure to stop this mo-
tion.
1. Lift up and support machine so rear wheels are o󰀨 the ground and can turn freely.
2. In the engine compartment, the hydrostatic pump is on the right side. The shift arm
(D) is on top of the pump The idler arm (B) has a bearing that rides in the V of the
shift arm. Loosen bolt (A).
3. With engine running, move bearing (B) so it centers on the shift arm (D) and
'wheel creep' stops.
4. Tighten all fasteners and test by using foot pedal linkage to see that 'creep' is
removed.
5. Turn engine o󰀨 and lower machine.

7
Service
ADJUSTMENTS

Located to the right of the engine. The belt should have approximately 1/2" (13mm) of deection in the center
of the top strand.
SAFETY INTERLOCK SWITCH
To adjust the interlock switch on the back hydrostatic pump loosen the set screw on the front half of the
switch, with the ignition switch OFF. With a continuity tester connected across the switch, it should light with
the shift arm centered. Move the shift arm to the right or left and the light should go o󰀨. By turning the back
half of the switch clockwise it will reduce the amount of travel on the shift arm that is required for the light to
remain on. The light must be on ONLY with the shift arm centered.

The master boom switch(B), located on the left oorboard,
is used to override the master switch (A) on the computer
console of the spray systems. By pushing down on the oor
master boom switch (B) it will turn on/o󰀨 the booms. For the
TeeJet System the master switch(A) on the computer must
be on for the master boom control switch(B) on the oor to
work.

The ground speed control(C) is located on the left oorboard
and is used to lock forward speed. The ground speed control
does not work the same as an automotive type cruise.
TO ENGAGE:
1. Flip rocker switch(D)‘On’ (green light).
2. Obtain desired speed with forward foot pedal.
3. Step on foot switch(C) to lock speed.
4. Push foot switch(C) again to disengage.

8
Service
ADJUSTMENTS

Engages and disengages speed boss. Forward is
engage and all the way back is disengage. When
the lever is engaged it sets a stop for the accelera-
tor. The accelerator pedal must be used to maintain
this speed. To adjust speed use the knob on the end
of the lever, counter clockwise increases speed and
clockwise decreases speed. Disengage the lever
and you will have full accelerator pedal range.
TANK AGITATION
The valve to turn on and o󰀨 the tank agitation is
located on the front of the seat panel, drivers right
hand side. Rotate valve handle down to shut o󰀨 and
rotate back up to turn on.

Run machine at half-throttle minimum, prior to
operating traction pedal. This will ensure proper
brake release.
TOWING
Brake must be disengaged for towing. The brake disengage
cover is located at the center of the Auburn wheel drive on
the rear wheels. To disengage the brake, remove the disen-
gage cover and assemble the disengage cover with the dim-
ple center protruding inward. This will release the brake shaft.
Road speeds must not exceed 20 MPH. Re-assemble the
disengage cover back to its original way when done towing.
Machine is in free wheel mode when towing.
Machine has no braking capabilities when being towed.

9
Service
SERVICE CHART
Before servicing or making adjustments to the machine, stop engine, block
wheels and remove key from ignition.
Follow all procedures and ONLY use parts prescribed by the manufacturer.
Read the engine manual before maintenance.
The suggested maintenance checklist is not o󰀨ered as a replacement for the manufacturer’s engine manual
but as a supplement. You must adhere to the guidelines established by the manufacturer for warranty cover-
age. In adverse conditions such as dirt, mud or extreme temperatures, maintenance should be more frequent.
Duplicate this page for routine use
Maintenance Check Item For the week of:
Mon Tues. Wed. Thurs. Fri. Sat. Sun.
Check the Safety Seat Switch
Check Steering Operation
Check the fuel level
Check the engine oil level.
Check the condition of the air lter
Clean the engine cooling ns.
Check for unusual engine noises
Check the hydraulic oil level
Check hydraulic hoses and ttings for damage
Check for uid leaks.
Check the tire pressure (20-30 psi)
Check the Instrumentation
Inspect electrical system for frayed wires
Check neutral start
Change oil lter.
Change oil.
Lubricate Machine and Booms
Ensure all warning decals are intact.
Areas of Concern
Inspection Performed by:
Item Date Information

10
Service
SERVICE CHART
Item Maintenance Procedure
After the rst 8 operating hours Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change the engine oil lter.
Before each use daily
Check the engine oil level.
Clean area around mu󰀪er and controls.
Check the hydraulic uid level.
Check the tire pressure.
Check condition of hydraulic hoses and ttings.
Check for oil or water leaks.
Proper function of glow lamp timer.
After the rst 50 hours Change Hydraulic Oil Filter.
Change Engine oil and lter.
Every 100 hours
Clean or change air lter.1&2
Clean fuel lter element. 1
Lubricate machine.
Check the battery uid level and cable connections..
Check fan belt tension and damage.
Every 200 hours
Check radiator hoses and clamp bands.
Change engine oil.1
Check idle speed.
Replace oil lter cartridge.1
Change hydraulic oil lter.1
Check air intake line.1
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Every 500 hours or yearly Clean Water Jacket and radiator interior.
Replace fan belt.
Every 800 hours Check valve clearance.
Every 1500 hours Check injection nozzle pressure.
Every 3000 hours
Check turbo charger.
Check injection pump.
Check injection timing.
Every 2 years
Change radiator coolant (L.L.C.)
Replace radiator hoses and clamp bands.
Replace fuel hoses and clamps.
Replace intake air lines.
1In dusty conditions or when airborne debris is present, clean more often.
2Replace after every 6 times of cleaning

11
Service
STORAGE
To prevent damage from freezing, pour window washer uid into spray sys-
tems tank and operate pump to circulate mix through gun and hose back to
tank. Open boom control to circulate through rest of spray system.
1. Clean the exterior surfaces of the engine.
2. Change the oil and lter while the engine is still warm from operation.
3. Drain coolant from the radiator. Open cock at the bottom of the radiator, and remove the pressure cap
to drain water completely. Leave the cock open. Hang a not written "No Water" on the pressure cap.
Since water freezes when temperature drops below 0°C (32° F) it is important that no water is left in the
machine.
4. Remove battery from the engine, adjust the electrolyte level, and recharge it. Store battery in a dry dark
place.
5. Store machine in a clean, dry place.
EXTENDED STORAGE
1. Check for any damaged parts or missing decals. Replace as needed.
2. Drain crankcase completely and rell with recommended engine oil or equivalent.
3. Lubricate all grease points.
4. Check coolant protection and level.
5. Clean exterior surface of engine.
6. Seal all openings in engine and accessories with non-hygroscopic material. Mask o󰀨 all areas to be
used for electrical contact.
7. Tape all openings and make sure all surfaces are dry. Then spray all taped openings, all engine acces-
sories including ignition wiring, and all exterior surfaces of engine with Insulation Compound.
8. Disconnect, remove and clean battery. Check electrolyte level. Charge the battery and store in a cool
dry place (NOT directly on cement).
9. Put blocks or stands under the machine to take weight o󰀨 tires.
AFTER STORAGE
1. Check for any damaged parts or missing decals. Replace as needed.
2. Lubricate all grease points.
3. Clean exterior surface of engine.
4. Remove all tape and obstructions from exterior engine surfaces.
5. Charge and replace battery.
6. Check tire pressure.
7. Remove blocks or supports from under the machine.
8. Check engine oil level and coolant level and lubricate all grease points.
9. Fill fuel tank.
10. Check belt tension.
11. Run engine approximately 5 minutes before putting the engine under load.

12
Diagrams
WIRING DIAGRAM
Color Code Chart
Bl Blue
Br Brown
Y Yellow
G Green
O Orange
R Red
B Black
P Purple
W White
Use dielectric grease on all electrical connections.

13
Diagrams
WIRING DIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 20-730-01 GPS Antenna (part of speedometer) 1
2 30-356 GPS Speedometer 1
3 33-084 Magnetic Coil 1
4 32-637 LED Lights 2
5 33-509 Cruise Foot Switch 1
6 15-725 Mount Panel End 1
15-727 Rocker, No Light 1
15-782 Non-Lighted Switch 1
7 15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-732 Rocker, Green 1
8 15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-731 Rocker, Amber 1
9 15-729 Mount Panel Middle 1
15-727 Rocker, No Light 1
15-728 Centering Switch, Momentary, On-O󰀨-On 1
10 15-725 Mount Panel End 1
15-727 Rocker, No Light 1
15-728 Centering Switch, Momentary, On-O󰀨-On 1
11 30-042-06 Relay 1
12 33-480 Pressure Switch 1
13 16-998 Hypro Pump 1
14 77-207 Buzzer 1
15 18-372 Manifold 3-way Ball Valve 1
16 12-804 Hour Meter 1
17 14-292 Seat Switch 1
18 32-576 USB Power Charger 1
19 20-693 Circuit Breaker, 50AMP 1
8977 Circuit Breaker Boot 1
20 32-573 Fuse Block 1
21 33-216 Battery 1
22 48-147 Ground Battery Cable 1
23 75-518 Battery Cable 1
24 17-068 Ignition Switch 1
25 32-649 LED Fuel Gage w/ Terminals 1
26 9016 Weather Pack 1
9017 Weather Pack Terminal 2
9018 Seal 2
27 30-194 Brake Manifold with Relief Valve 1
28 12-003 Park Brake Toggle Switch 1
30-143 Toggle Switch Guard 1
33-273 Auto Blade Fuse, 30AMP 1
30-364 Main Wire Harness 1
30-344 Engine Wire Harness 1
30-345 Fuel Pressure Manifold Harness 1

14
Diagrams
HYDRAULIC DIAGRAM
Letter Code Chart
C Center
I Inside
O Outside
T Top
B Bottom

15
Diagrams
HYDRAULIC DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 30-156 Hydraulic Hose 1
2 30-091 Hydraulic Hose 1
3 15-301 Orbital 1
4 30-094 Hydraulic Hose 2
5 15-839 Steering Hydraulic Cylinder 1
14-531 Seal Kit 1
18-171 3/8Seal Loc Adapter 2
6 30-025 Oil Tank 1
13-747 Filler Breather 1
13-586-03 Neck 1
7 8833-9 1" Suction Hose 1
18-222 Hose Clamp 2
8 8833-17 1" Suction Hose 1
18-222 Hose Clamp 2
9 30-093 Hydraulic Hose 1
10 76-197 Gear Pump 1
11 30-102 Eaton Closed Loop Pump 1
12 18-405 Run Tee 1
13 30-086 Hydraulic Hose 1
14 30-085 Hydraulic Hose 1
15 30-090 Hydraulic Hose 2
16 30-087 Hydraulic Hose 2
17 30-099 Wheel Drive 2
18 30-100 Hydraulic Release Brakes 2
19 30-101 Eaton Wheel Motors 2
20 30-089 Hydraulic Hose 4
21 30-103 Hot Oil Shuttle Manifold 1
22 18-395 Union Tee 1
23 30-088 Hydraulic Hose 1
24 72-146 Oil Filter Assembly 1
60-334 Replacement Element 1
25 8833-41 1" Suction Hose 1
18-222 Hose Clamp 2
26 30-105 Oil to Air Heat Exchanger 1
27 18-308 Swivel Tee 1
28 30-194 Brake Manifold w/ Relief 1
30-104-01 Cartridge Valve 1
30-104-02 Coil 1
29 8917-17 5/8" Suction Hose 1
18-040 Hose Clamp 2
30 8833-28 1" Suction Hose 1
18-222 Hose Clamp 2

16
Parts


Parts
17

REF# PART# DESCRIPTION QUANTITY
1 30-110 Accessory Mount Bracket 1
HB-516-18-175 Hex Bolt, 5/16 - 18 x 13/44
HW-516 Flat Washer, 5/16 4
HNFL-516-18 Flange Whiz-loc Nut, 5/16 - 18 4
2 17-615 Boom Carrier 2
HB-12-13-150 Hex Bolt, 1/2- 13 x 11/24
HNFL-12-13 Flange Whiz-loc Nut, 1/2- 13 4
3 16-557 Square Cap 2
4 30-095 318 Gallon Tank (Fiberglass) 1
25-372 Decal, Smithco 4" Star 1
30-016 Decal, Spray Star 3180 2
5 16-953 16" Hinged Lid Well 1
16-953-01 Gasket for Lid 1
16-169 Strainer Basket 1
6 14-365 Air Gap Filler 1
7 30-362 Roll Bar 1
8 30-308 Engine Cover (Fiberglass) 1
9 27-055 Flush Hinge 2
HSM 10-32-100 Machine Screw, #10-32-100 12
HNFL-10-32 Flange Whiz-loc Nut, #10 - 32 12
10 14-294 Seat Kit (includes * items) 2
*14-292 Seat Switch 2
*14-800 Seat Rail Set 2
*HSP-1260-340-250 Seat Spacer 8
11 10-706 Arm Rest Set 1
12 13-718 15" Steering Wheel 1
13-726 Center Cap 1
27-077 Decal, Smithco Round 1
13 30-352 Nose Cone (Fiberglass) 1
14 30-360 Main Frame 1
15 43-124 Turf Tread Tire and Wheel 2
43-123-01 Tire 2
43-058-01 Wheel 2
HNL-12-20 Lug Nut, 1/2- 20 14
16 20-658 Front Mud Flap 2
17 30-358 Seat Assembly(Fiberglass) 1
18 32-531 20 Gallon Fuel Tank 1
19 30-351 Fuel Cap 1
20 30-048 Tire and Wheel(assembled) 2
30-048-01 Tire 2
30-048-02 Wheel 2
HNL-12-20 Lug Nut, 1/2- 20 14
21 20-657 Rear Mud Flap 2

18
Parts
NOSE CONE DRAWING
