Snom 870 User manual

© 2011 snom technology AG
v2.02
Quick Start Guide
IP Phone
ENGLISH
D E UTSCH
FRANÇAI S
ITALIANO
E S PAÑOL
PORTUG U Ê S
Your specialist retailer - Ihr Fachhändler -
Votre distributeur - Su distribuidor - Il tuo rivenditore:
snom technology AG
Charlottenstr. 68-71
10117 Berlin, Deutschland
Tel. [phone]
Fax [phone]
[email protected], s[email protected]
snom technology, Inc.
18 Commerce Way, Suite 6000
Woburn, MA 01801, USA
Tel. [phone]
Fax [phone]
infoU[email protected]
snom UK Ltd
Aspect Court
47 Park Square East
Leeds, LS12NL, UK
Tel. [phone]
Fax [phone]
uks[email protected], [email protected]
snom France SARL
6 Parc des fontenelles
78870 Bailly, France
Tel. [phone]
Fax [phone]
[email protected], s[email protected]
snom technology SRL
Via A. Lusardi 10
20122 Milano, Italia
Tel [phone]
Fax [phone]
[email protected], s[email protected]
snom technology Ltd.
Rm. A2, 3F, No. 37, Ln. 258
Ruiguang Rd., Neihu Dist.
Taipei City 114, Taiwan
Tel [phone]
Fax [phone]
infoAS[email protected]

2
Detaching/attaching the Footstand - Fuß abmontieren/montieren
Detacher/attacher le pied - Smantellare/fi ssare il supporto
Desmontar/montar el soporte
B
2.
1.
a A
1
4
7
2
5
8
3
6
9
0 #
ABC DEF
JKLGHI MNO
PQRS WXYZTUV
Delivery content - Lieferumfang - Contenu de l‘emballage -
Contenuto della confezione - En la caja
A
a A
1
4
7
2
5
8
3
6
9
0 #
ABC DEF
JKLGHI MNO
PQRS WXYZTUV

3
Connecting - Anschließen - Connecter - Collegare - Conectar
C
Optional
Optionel
Opzionale
Opcional
Optional
Optionel
Opzionale
Opcional
Optional
Optionel
Opzionale
Opcional
If no PoE available
Wenn PoE nicht verfügbar
S'il n'y a pas de PoE
Se non disponibile PoE
Si no se dispone de PoE
Press the key:
Drücken Sie auf die Taste:
Appuyez sur la touche:
Premere il tasto:
Pulse la tecla:
Symbols used in this guide - In dieser Anleitung benutzte Symbole
Symboles utilisés dans ce manuel - Symboli utilizzati in questa manuale
Símbolos usados en este manual
D
   
>• Proceeding to next step, next selection, etc. Example: Setting the phone language
• Nächster Schritt, nächste Auswahl etc. Beispiel: Ändern der Telefonsprache
• Passez à l'étape suivante, à la sélection suivante etc. Exemple: Modifi er la langue du
téléphone
• Avanzare allo prossimo passo, alla prossima selezione etc. Esempio: Cambiare la
lingua del telefono
• Avanzar al siguiente paso, al siguiente selección. Ejemplo: Cambiar el idioma del
teléfono
> 1 Preferences > 4 Language > > Deutsch >

4

5
ENGLISH ......................................................................................... 7
DEUTSCH ....................................................................................... 19
FRANÇAIS ...................................................................................... 31
ITALIANO ......................................................................................... 43
ESPAÑOL ........................................................................................55
APPENDIX  ANHANG  ANNEXE  APENDICE  ANEXO
GNU General Public License .......................................................... 67
Table of Contents - Inhaltsverzeichnis
Table des matières - Indice - Índice

6
snom 870 Quick Start Guide
E
N
G
L
I
S
H

7
snom 870 Quick Start Guide
E
N
G
L
I
S
H
This quick start guide describes the installation, setup, and operation of the
snom 870. For further information please refer to the manual on our web
page, http://wiki.snom.com/Snom870.
Copyright, Trademarks, GPL, Legal Disclaimers
© 2011 snom technology Aktiengesellschaft
All Rights Reserved.
snom, the names of snom products, and snom logos are trademarks owned by snom technology
AG. TeamSpirit ® VoiceEngine is Copyright © 1995-2010, SPIRIT. All other product names and
names of enterprises are the property of their respective owners.
snom technology AG reserves the right to revise and change this document at any time, without
being obliged to announce such revisions or changes beforehand or after the fact.
Texts, images, and illustrations and their arrangement in this document are subject to the
protection of copyrights and other legal rights worldwide. Their use, reproduction, and transmittal
to third parties without express written permission may result in legal proceedings in the criminal
courts as well as civil courts.
Although due care has been taken in the compilation and presentation of the information in this
document, the data upon which it is based may have changed in the meantime. snom therefore
disclaims all warranties and liability for the accurateness, completeness, and currentness of the
information published, except in the case of intention or gross negligence on the part of snom or
where liability arises due to binding legal provisions.
Our firmware includes some source code that may be used and modified by anyone and everyone
under the GNU Public License (GPL) (see Appendix on page 67), provided they, in turn, make it
available to everyone else with the same licensing agreement. Please go to http://www.snom.
com/en/support/download/gpl-quellcode/ for the original GPL license and the source code of
components licensed under GPL and used in snom products.
Important Information
Please read the instructions on safety and disposal and on how to set up and use the
device before using it and also give them to other users to read or inform those users
of their contents. Save this manual and do not give the device to third parties without it.
Safety Instructions
Follow the instructions in this manual and other applicable documentation of the device.
• If the phone is not supplied with power via an Ethernet cable, use only the
power adapter included in the package or one expressly recommended by snom
technology. Other power supplies may damage or destroy the phone, affect its
behavior, or induce noise.
• Avoid placing the cables where people may trip over them or where they may be
exposed to mechanical pressure as this may damage them.
• This device is for indoor use only! NOT FOR OUTDOOR USE!
• Do not install the device in rooms with high humidity (for example, in bathrooms,
laundry rooms, damp basements). Do not immerse the device in water and do not

8
snom 870 Quick Start Guide
E
N
G
L
I
S
H
spill or pour liquids of any kind onto or into the device.
• Do not install the device in surroundings at risk for explosions (paint shops, for
example). Do not use the device if you smell gas or other potentially explosive fumes.
• Do not use the device during thunderstorms. Lightning striking the power grid may
cause electric shocks.
• Warning: The handset contains a magnet, and its earpiece may attract small
dangerous objects such as needles or pins. Please ensure before each use that no
such objects are present.
SELV (Safety Extra Low Voltage) Compliance
Safety status of Input/Output connections comply with SELV requirements.
Warning: To avoid electric shock, do not connect safety extra-low voltage (SELV)
circuits to telephone-network voltage (TNV) circuits. LAN ports contain SELV
circuits, and PSTN ports contain TNV circuits. Some LAN and PSTN ports both use
RJ-45 (8P8C) connectors. Use caution when connecting cables.
Standards conformance
This device is CE and FCC-certified and meets European and US health,
safety, and environmental standards.
Unauthorized opening, changing, or modifying the device will cause the
warranty to lapse and may also result in the lapse of the CE and FCC
certifications. In case of malfunction contact authorized service personnel,
your seller, or snom.
• Safety: IEC 60950-1:2001
• Certifications: FCC Class B, CE Mark
• Power consumption: 2.5-7 watts (without USB peripherals)
• 1 x LAN, 1 x PC: RJ45
• Ethernet: 2 x IEEE 802.3/1 Gigabit switch
• Power: Power over Ethernet IEEE 802.3af, Class 2. If PoE not available: Power
adapter 5V DC
Disposal of the device
This device is subject to European Directive 2002/96/EC and may not be
disposed of with general household garbage.
If you do not know where you may dispose of the device at the end of its
lifespan, contact your municipality, your local waste management provider,
or your seller.
Cleaning
To clean the device, use an anti-static cloth. Please avoid cleaning liquids as they might
damage the surface or internal electronics of the device.

9
snom 870 Quick Start Guide
E
N
G
L
I
S
H
Setting up and connecting the phone: See pages 2 - 3.
Initializing and registering the phone
Please note: You will need the registration information received from your Internet service
provider or your network administrator - normally the phone or extension number, the
password, and the registrar.
After you have set up the phone and connected it to the network as shown on pages 2 - 3, the
phone begins to initialize.
Normally the initialization is completely automatic, using DHCP. If your network does not support
DHCP, you must obtain the IP address, netmask, IP gateway, and DNS server from your Internet
service provider or your network administrator and enter them manually when you are asked to do so
on the display.
After initialization, the phone will guide you through the basic settings. Scroll by tapping on /
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
/
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
/
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
After initialization, the phone will guide you through the basic settings. Scroll by tapping on
(see Fig. 4 on page 9). Select and save an option by tapping the button (Fig. 5).
1. Language. The default is English.
2. Time zone. Show all time zones: . Show only those time zones where the selected
language is spoken: .
3. Dial tone.
4. The display will show the "Welcome" screen: Press any key to log on.
5. Enter the account number and tap blue call context area to save.
6. Enter the registrar (see "Entering numerals, letters, and special characters“, below) and save.
7. Enter the password received from your Internet service provider or administrator. Save. After
successful registration you will see the springboard (Fig. 1). Tap
7. Enter the password received from your Internet service provider or administrator. Save. After
to show confi gured
identity (Fig. 2).
Fig. 1: Fig. 2
Entering numerals, letters, and special characters
Press any key or pick up handset.
Fig. 3:
123: Numerals
abc: Small letters
ABC: Capital letters
Change input mode
Call lists
Delete character to left of cursor
Favorites
Contacts, LDAP directory
Internal phone directory
Current input mode:
Tap blue context area to dial the number.
Entering letters, special characters and symbols
In input modes small and capital letters, press the alphanumeric key one or more times
quickly, with a pause after each character.
Special characters and symbols
"0" key": 1x = space ("˽"), 2x = underscore ("_"), 3x = 0

10
snom 870 Quick Start Guide
E
N
G
L
I
S
H
"1" key: . + @ 1 ? ! - _ / \ ( ) ; & % * # <=> $ [ ]. Examples: 1x = "." ; 2x = "+", etc.
Letters with accents and umlauts: Keys "2" to "9". Available letters with accents
and umlauts depend on the phone's language setting. Example: If the phone language
is German, press key "2" four times to type "ä".
At a glance
Pound (hash) key
#
: Rescue
mode for TFTP update
Call LED
• Blinking fast: Incoming call
• Steady light: In call
• Blinking slowly: Missed call.
Press to turn it off.
Star key
a A
• Switching between upper and
lower case when pressed
briefl y while in letter mode
• Press for 3 seconds:
Lock/unlock the keypad
• Confi rming, saving actions/
settings
• Accepting calls on
speakerphone
• From idle screen: Redial
• Canceling actions
• Terminate calls on speaker-
phone + headset
• Turning off call LED after
missed call
From idle screen:
Received calls
Missed calls
Audio keys
Adjust volume
Mute microphone
Speakerphone on/off
Headset on/off
a A
1
4
7
2
5
8
3
6
9
0 #
ABC DEF
JKLGHI MNO
PQRS WX YZTUV
Alphanumeric
keypad
Display -
idle screen
"springboard"
Casing microphone
Casing
loudspeaker
Inactive identity: Red symbol
Active identity: Light-green symbol
Current identity for outgoing calls:
Green symbol with

11
snom 870 Quick Start Guide
E
N
G
L
I
S
H
Using the touch screen
Tap visual display object or area with fi ngertip (Figures 4 - 7).
 Drag-and-drop: Place the fi ngertip on the area or the virtual object on the display,
drag it to the target location, and lift the fi nger off the screen (Figures 8 and 9).
Fig. 4 Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 9a
Idle screen - "springboard" icons
Phone directory Remote directories
(e.g., LDAP) Favorites
Missed calls Received calls Redial (dialed calls)
Confi gured identies.
Select outgoing
identity Settings menu Phone's IP address
and snom's web
address
Time. Tap to show
clockface and date. Virtual function key screen - see pg. 14 Call monitoring screen
Date. Replaced
by info alert when
update available,
reboot necessary, etc.
Tap to see details.
DND: Activate/
deactivate.
Red symbol: DND
active
Forwarding all calls:
Activate/deactivate.
Red symbol: Call
forwarding active
Dedicated, customizable function keys
Turn DND
(do not disturb) on/off
Directory
Settings menu
Transfer call
Hold/unhold call
MWI (LED key)
Must be supported by PBX
• Lit when message is waiting on
mailbox
• Press to listen to message(s)

12
snom 870 Quick Start Guide
E
N
G
L
I
S
H
* The submenus and the settings shaded black and gray are not available when the
phone is running in user mode. The factory setting is administrator mode. The
default administrator password is 0000 (4 x zero).
** System Info: Firmware version, IP address, MAC address, available + total memory
1
Preferences
1
Time Zone
2
Tone Scheme
3
Ringer
4
Language
5
Display
2
Call Features
1
Call Forwarding
1
Forward all
2 Forward
when busy
3
Fwd after timeout
2
Outgoing Calls
1
Auto Dial
2 Number
Guessing
3
Call Completion
4 Hide own
outgoing ID
3
Incoming Calls
1
Reject anonymous
2
Call Waiting
3 Auto Answer
Indication
4
Auto Answer Type
3 *
Identity
1 Outgoing
Identity
2
Reregister
3
Edit
4
Logoff
5
Logoff all
4 *
Network
1
IP Setting
2
Webserver
1
Webserver Type
2
HTTP Admin
3
HTTP Password
3
Reset VLAN
3
VLAN
1
VLAN ID (0-4095)
2 VLAN Priority
(0-7)
3
Switch off WLAN
4
WLAN
1
802.11b/g/n
2
802.11b/g
5 *
Maintenance
1
System Info**
2
User Mode
3
Reboot
4
Reset Values
3 *
Maintenance
1
System Info**
2 Administrator
Mode
3
Reboot
In administrator mode.
Touching button 2 will
switch phone to user
mode!
In user mode.
Administrator
password required to
switch to admin mode!
Maintenance
menu
• Enter menu:
• Tap item or press number key to open
submenus and settings
• Tap to scroll
• Tap list entry to select
• Tap context area or text field to save
• Settings with (On)/(Off) or (Yes)/(No):
Tap item to change and save
• Tap to return to the previous screen
• Tap to return to the idle screen
Settings menu
Time zone:
/
/
/
/
Tap
button to move to
beginning of next/
previous time zone
Show all
time zones
Show only
countries where
phone language is
spoken
Tap time zone to
select.

13
snom 870 Quick Start Guide
E
N
G
L
I
S
H
The phone's web interface
1. Looking up the phone's IP address: Tap the icon. Example: 192.168.10.115.
2. Open a web browser on your PC. Type http:// and the IP address in the address
bar. Example: http://192.168.10.115. Press ENTER to open the phone's web
interface.
3. Click on an item in the menu on the left side of the screen to open that window.
4. If a window contains several pages, click on the tab at the top to open the page.
The font weight of the characters on the tab of the visible page is bold.
5. Any changes you make will not take effect until you click on "Save". Changes will be
lost if you open another page of the web interface without fi rst clicking on "Save".
Clock/time format
Web interface > Preferences > General Information > 24 Hour Clock:
On: 24-hour format, 00:00 to 23:59
Off: 12-hour AM/PM format, 0:00 AM to 11:59 PM
Date format
Web interface > Preferences > General Information > US Date Format (mm/dd).
Example: March 8, 2010
On: 3/8/2010
Off: 8.3.2010
Confi guring & modifying identities
Web interface > Identity 1-12 > Login. See "Initializing and registering the phone"
on page 13 for required and optional information.
Mapping virtual function keys
Key mapping: Web interface of phone > Function keys. Change settings > Click
on "Save". Example: Mapping virtual keys P7 and P8 with the extension function for
extensions 152 (Bill) and 158.

14
snom 870 Quick Start Guide
E
N
G
L
I
S
H
Using the phone
Virtual function keys
Tap to show virtual keys screen.
Mapping the keys: See page 13.
 Ext. [ringing] - green key: Tap to pick
up call ringing on the extension
Ext. [talking] - yellow key: In call
 Ext. [idle]: Tap to call the extension
 Spd.: Speed dial. Tap button to
speed-dial the number
Making calls
 With the handset: Enter the number on the alphanumeric keypad and pick up the
handset or
pick up the handset, enter the number, and press or tap context area.
On speakerphone: , enter the number, and press or tap context area.
Tap anywhere in
context area to dial
Speed Dial
Type the speed dial number or character on the alphanumeric keypad and press or
tap the text fi eld.
Setting the speed dial numbers: Web interface > Speed Dial. Type each phone
number (or other allowable format like SIP URI) with any necessary area code and/or
country code etc. without spaces, hyphens, etc. into one of the textboxes of the table.
Do not add any names or other data that are not part of the number. Example: To enter
[phone], type 9115551234.
Emergency Numbers
These numbers can be called even when the keyboard is locked. The numbers "911",
"112", "110", and "999" are preset.
Change/add numbers: Web interface > Preferences > Lock Keyboard > Emergency
Numbers (space separated). Type each number without spaces, hyphens, etc. between
the digits, separate the individual numbers with one empty space between them.
Example: 911 112 110 999.

15
snom 870 Quick Start Guide
E
N
G
L
I
S
H
Accepting calls
With the handset: Pick up the handset
With a headset: Press or tap context area with ringing phone symbol
With the speakerphone: Press
Putting calls on hold
Press . The call LED starts to blink slowly, and
the held call is shown as a yellow button. Tap the
button to resume the call.
Conference (up to 5 participants, including you)
• Initiating:
1. Call all intended participants and put them on hold.
2. Tap to show "Set up conference" screen.
3. Drag-and-drop participants into the conference area (see "Using the touch
screen" on page 15, Fig. 8).
4. Tap to start the conference (Fig. 7). Conference in progress: Fig. 9 + 9a.
 Dropping one participant from conference: Drag-and-drop onto button on right side
of display (Fig. 9 + 9a).
Stopping the conference and putting all participants on hold: Press or .
 Talking to one of the participants alone: Put all participants on hold and tap on
participant's yellow button.
 Resuming the conference: Drag and drop participants into conference area and tap
.
Call transfer
Attended transfer
Put the call on hold > Call the third party you wish to transfer the call to and
announce the call. If that party wishes to accept the call, tap > Drag-and drop
the yellow button into the text fi eld > To transfer the call, tap the blue context area or
press .
Blind transfer
With call ringing or on the line: Tap > Dial the phone number the call is to be
transferred to > Tap the text fi eld or press to transfer.

16
snom 870 Quick Start Guide
E
N
G
L
I
S
H
Call forwarding
 All incoming calls.
◦Turning on: > Target when forwarding: Enter number > tap text fi eld or
press .
◦Turning off:
• When busy.
◦Turning on: > 2 Call Features > 1 Call Forwarding > 2 Forward when
busy > 2 Target when Forwarding > enter number > tap text fi eld or
press > 1 Enable Forwarding [No]: Press "1" key or tap text fi eld
to change to [Yes] >
> 1 Enable Forwarding [No]: Press "1" key or tap text fi eld
to return to idle screen
◦Turning off:
to change to [Yes] >
> 2 Call Features > 1 Call Forwarding > 2 Forward when
busy > 1 Enable Forwarding [Yes]: Press "1" key or tap text fi eld to
change to [No] >
busy > 1 Enable Forwarding [Yes]: Press "1" key or tap text fi eld to
• When call is not picked up (after timeout).
◦ Turning on: > 2 Call Features > 1 Call Forwarding > 3 Forward after
Timeout > 2 Target when Forwarding > enter number > > 3
Call Forwarding time > enter number of seconds > > 1 Enable
Forwarding [No]: Press "1" key or tap text fi eld to change to [Yes] >
Forwarding [No]: Press "1" key or tap text fi eld to change to [Yes] >
◦Turning off: > 2 Call Features > 1 Call Forwarding > 3 Forward after
Timeout > 1 Enable Forwarding [Yes]: Press "1" key or tap text fi eld
to change to [No] >
Timeout > 1 Enable Forwarding [Yes]: Press "1" key or tap text fi eld
Call lists
 Missed calls: / . A number in the upper right corner of the icon indicates
the number of new missed calls. Tap icon to show details of missed call(s) and
simultaneously turn off fl ashing call LED and clear icon; press to turn off fl ashing
call LED and clear icon without showing details of missed call(s).
Received calls:
call LED and clear icon without showing details of missed call(s).
.
Dialed calls: .
Applicable to all lists:
◦ Scroll through list with / .
◦ Tap entry button to dial.
◦Tap
Tap entry button to dial.
to show call details.
◦Tap to edit entry.
◦Tap
to edit entry.
to edit entry.
to edit entry.
to add to phone directory.
◦Tap
to add to phone directory.
to delete entry.

17
snom 870 Quick Start Guide
E
N
G
L
I
S
H
Phone directory
Tap to open phone directory.
 Shortcut to <New Item> at the end of the list: . Back to top entry: . Scroll:
/ .
Tap name button to dial. Details: Tap . Edit: > tap detail button.
Delete entry:
Tap name button to dial. Details: Tap
Tap name button to dial. Details: Tap
Tap name button to dial. Details: Tap
.
 Entries with several phone numbers (for example, offi ce, home, and cell phone
number) are possible. For more information see the User Manual at
http://wiki.snom.com/Snom870/Documentation.
Trouble shooting
Reboot
> 5 Maintenance > 3 Reboot > "Reboot?" > Tap "OK" or press
Hard reboot
Disconnect power, wait for a few seconds, reconnect.
Never disconnect the power during a fi rmware update!
Reset to factory values
> 5 Maintenance > 4 Reset values > enter administrator password >
All customized settings will be lost!
TFTP Update
When there is no other way to get the phone to work (administrator password lost,
etc.). How it is done: See http://wiki.snom.com/Firmware/Update/TFTP_Update/en.
All customized settings will be lost!

18
snom 870 Quick Start Guide
D
E
U
T
S
C
H

19
snom 870 Quick Start Guide
D
E
U
T
S
C
H
Diese Kurzanleitung beschreibt die Installation, Einrichtung und den Betrieb
des snom 870. Weitere Informationen finden Sie auf unserer Webseite,
http://wiki.snom.com/Snom870.
Copyright, Markenrechte, GNU Lizenz, Haftung
© 2011 snom technology Aktiengesellschaft
Alle Rechte reserviert.
snom sowie die Namen der snom-Produkte und die snom logos sind gesetzlich geschützte Marken
der snom technology AG. TeamSpirit ® VoiceEngine is Copyright © 1995-2010, SPIRIT. Alle
anderen Produkt- und Firmennamen sind Marken der jeweiligen Inhaber.
snom technology AG behält sich jederzeit das Recht auf Überarbeitung und Änderung dieses
Dokumentes vor, ohne verpflichtet zu sein, die vorgenommenen Änderungen anzukündigen oder
mitzuteilen.
Texte, Bilder, Grafiken und deren Anordnung in diesem Dokument unterliegen weltweit dem Schutz
des Urheberrechts und anderen Schutzgesetzen. Ihre Verwendung, Reproduktion oder Weitergabe
ohne ausdrückliche schriftliche Zustimmung der snom technology AG können sowohl straf- als
auch zivilrechtlich verfolgt werden.
Trotz der angewandten Sorgfalt bei der Zusammenstellung und Präsentation der Informationen in
diesem Dokument können sich Daten zwischenzeitlich geändert haben. Daher übernimmt snom
keine Gewähr für die Richtigkeit, Vollständigkeit oder Aktualität der zur Verfügung gestellten
Informationen. Jegliche Haftung für Schäden ist ausgeschlossen, sofern diese nicht auf Vorsatz
oder grober Fahrlässigkeit auf seiten von snom beruhen oder sofern keine Haftung aufgrund
zwingender gesetzlicher Bestimmungen eintritt.
Unsere Firmware enthält teilweise Quellcodes, die unter der GNU Public License (GPL) (ab Seite
S. 67) von jedermann genutzt und modifiziert werden dürfen, solange sie wiederum mit denselben
Lizenzbedingen zur allgemeinen Nutzung veröffentlicht werden. Die Quellcodes der von snom
genutzten und der GPL unterliegenden Komponenten können Sie auf der Supportseite unserer
Webseite auf www.snom.com, den Wortlaut der GPL auf http://www.snom.com/de/support/
download/gpl-quellcode/ herunterladen.
Wichtige Hinweise
Lesen Sie bitte vor Inbetriebnahme die Sicherheitshinweise und die Bedienungsanlei-
tung. Lassen Sie sie auch von den Mitbenutzern des Gerätes lesen oder informieren
Sie sie über deren Inhalt. Bewahren Sie diese Bedienungsanleitung auf und geben Sie
das Telefon nur mit der Bedienungsanleitung an Dritte weiter.
Sicherheit
Befolgen Sie die Anweisungen in dieser Bedienungsanleitung und in der sonstigen
Dokumentation des Geräts.
• Falls die Stromversorgung nicht über ein Ethernetkabel erfolgt, verwenden Sie nur
das mitgelieferte Netzteil. Die Verwendung anderer Netzteile könnte das Telefon
beschädigen oder gar zerstören.
• Verlegen Sie die Netz- und Stromkabel so, dass sie durch mechanischen Druck
nicht beschädigt werden und Personen nicht darüber stolpern könnten.

20
snom 870 Quick Start Guide
D
E
U
T
S
C
H
• Dieses Gerät ist nur für den Gebrauch in Innenräumen bestimmt - NICHT FÜR DEN
AUSSENBEREICH!
• Stellen Sie das Telefon nicht in Räumen mit hoher Luftfeuchtigkeit wie z.B.
Badezimmern, Waschküchen, feuchten Kellerräumen auf. Tauchen Sie das Telefon
nicht in Wasser und gießen Sie keine Flüssigkeiten auf oder in das Gerät.
• Stellen Sie das Telefon nicht in explosionsgefährdeten Umgebungen (z.B.
Lackiereien) auf. Benutzen Sie das Telefon nicht, wenn Sie Gas oder andere
möglicherweise explosionsgefährliche Dämpfe riechen.
• Telefonieren Sie nicht während eines Gewitters (Stromschlaggefahr bei
Blitzeinschlag ins Netz).
• Warnung: Der Hörer enthält einen Magneten und kann kleine gefährliche Objekte
wie Nadeln anziehen. Bevor Sie ihn ans Ohr halten, vergewissern Sie sich, dass
keine Objekte daran haften.
SELV (Safety Extra Low Voltage) Einhaltung
Die Eingangs-/Ausgangsverbindungen halten die SELV-Richtlinien für Kleinspannungs-
geräte ein.
Warnung: Um elektrische Schläge zu vermeiden, verbinden Sie keine SELV-Geräte
mit Geräten, die Fernsprech-Netzspannung (TNV) führen. Nur an LAN-Ports
anschließen! LAN-Ports enthalten SELV-Stromkreise, Festnetz-Anschlüsse dagegen
TNV-Stromkreise. Vorsicht beim Anschließen, da beide Steckverbindungen RJ-45
(8P8C) verwenden könnten.
Normkonformität
Dieses Gerät ist CE- und FCC-geprüft und entspricht den geltenden euro-
päischen und US-amerikanischen Richtlinien.
Die eigenmächtige Öffnung des Geräts sowie Änderungen und Modifizie-
rungen am Gerät führen zum Erlöschen der Gewährleistungspflicht und
können darüberhinaus zum Erlöschen der Zulassungen führen. Wenden Sie
sich bei Betriebsstörungen oder Defekten an authorisiertes Servicepersonal,
an Ihren Verkäufer oder an snom.
• Sicherheit: IEC 60950-1:2001
• Zertifikate: FCC Class B, CE Mark
• Stromspeisung: Über Netzwerk (PoE, IEEE 802.3af, Klasse 2); falls kein PoE
verfügbar, über das mitgelieferte Netzteil 5V DC
• Leistungsaufnahme: 2,5-7 Watt (ohne USB-Peripheriegeräte)
• 1 x LAN, 1 x PC: RJ45
• Ethernet: 2 x IEEE 802.3/1 Gigabit switch
Reinigung
Benutzen Sie ein antistatisches Tuch. Benutzen Sie kein Wasser und keine
Reinigungsflüssigkeiten, da sie die Oberfläche und die Elektronik des Gerätes
beschädigen könnten.
