Snorkel S39770RT Owner's manual

REPAIR PARTS
MANUAL
Part Number 15124-2 
March8(Rev A)
Serial Numbers:
S2770RT-07-161200500,
S3370RT-07-180300500,
S3970RT-07-180300500 and after
Diesel
Bi-Energy 24V DC
Version 7

GENERAL INFORMATION
General Information 1-1
REPAIR PARTS
Chassis Assembly 2-1
Steer Assembly 2-2
Swing Arms Assembly 2-3
Swing Arm Assembly After Serial Numbers S2770RT-07-200300598, S3370RT-07-200300602, S3970RT-
07-200500562 2-4
Wheel Mounting Assembly 2-5
Engine Cabinet Assembly 2-6
Engine Cabinet Assembly After Serial Numbers S2770RT-07-200900621, S3370RT-07-200900626,
S3970RT-07-200900582 2-7
Exhaust Extension 2-8
Radiator Guard Assembly 2-9
Hydraulic Cabinet Assembly 2-10
Hydraulic Cabinet After Serial Numbers: S2770RT-07-200900621, S3370RT-07-200900626 S3970RT-07-
200900582 2-11
Cabinets Assembly 2-12
V7 Stabiliser Assembly 2-13
Base, Stack, Platform Assembly 2-14
Base, Stack, Platform Assembly After Serial Numbers S3970RT-07-181100510, S3370RT-07-181100524,
S2770RT-07-181100530 2-15
Platform Assembly 2-16
Platform Assembly After Serial Numbers S2270RT-07-181100530, S3370RT-07-181100524, S3970RT-07-
181100510 2-17
Platform Rear Handrail Assembly 2-18
Emergency Bleed Down 3970, 3370 2-19
Emergency Bleed Down 2770 2-20
Scissor Stack Tees 2-21
Scissor Stack Assembly 3970 2-22
Scissor Stack Assembly 3370 2-23
Scissor Stack Assembly 2770 2-24
Angle Transducers Before Serial Numbers: S2770RT-07-200900617 S3370RT-07-200900626 S3970RT-07-
200900577 2-25
Angle Transducer After Serial Numbers S2770RT-07-200900617 S3370RT-07-200900626 S3970RT-07-
200900577 2-26
Kubota D902 T4 Diesel Engine Assembly 2-27
Plastic Fuel Tank Assembly 2-28
Steel Fuel Tank Assembly 2-29
Plastic Hydraulic Oil Tank Assembly 2-30
Steel Hydraulic Oil Tank, No Heater Assembly 2-31
Steel Hydraulic Oil Tank, With Heater Assembly 2-32
Placards And Decals 2-33
Placards and Decals Bi-Energy Machines 2-34
HYDRAULICS

Hose Tags And Colour Codes 3-1
Main Manifold, No Fittings 3-2
Main Manifold, With Fittings 3-3
4WD Manifold, No Fittings 3-4
4WD Manifold, With Fittings 3-5
Auto Stabiliser Manifold, No Fittings 3-6
Auto Stabiliser Manifold, With Fittings 3-7
AXLE CYLINDER 3-8
Axle Cylinder Assembly After Serial Numbers S2770RT-07-200300598, S3370RT-07-200300602,
S3970RT-07-200500562 3-9
STEER CYLINDER 3-10
Upper Lift Cylinder Assembly 3-11
Lower Lift Cylinder 3-12
Stabiliser Leg Cylinder Assembly 3-13
ELECTRICAL
Loom List 4-1
GP400/IO Menus 4-2
GP400/IO Allocations 4-3
14023-04 Overload Diesel ANSI/NZS/AS/CE Upper Control Box 4-4
14023-05 Overload Petrol/LPG ANSI/NZS/AS/CE Upper Control Box 4-5
14023-08 Overload Diesel, Reverse Lift ANSI/NZS/AS/CE Upper Control Box 4-6
14023-09 Overload Petrol/LPG, Reverse Lift ANSI/NZS/AS/CE Upper Control Box 4-7
13811-01 Diesel AS/NZS/CE Lower Control Box 4-8
13811-02 ANSI Diesel Lower Control Box 4-9
13811-03 Petrol/LPG ANSI Lower Control Box 4-10
13811-04 Overload Petrol/LPG ANSI/AS/NZS/CE Lower Control Box 4-11
13811-05 Bi-Energy Diesel/24V DC AS/NZS/CE Lower Control Box 4-12
24V DC Option 4-13
24VDC Cabinet Assembly 4-14
24V DC Battery Box Mounting 4-15
OPTIONS
AC110V Platform Assembly 5-1
240VAC Assembly 5-2
AC240V at Platform 5-3
LPG Cabinets Assembly 5-4
LPG Engine Cabinet Assembly 5-5
LPG Engine Cabinet Assembly After Serial Numbers S2770RT-07-181100530, S3370RT-07-190100529,
S3970RT-190100519 5-6
LPG Engine Cabinet Radiator Guard Assembly 5-7
LPG Kubota WG752 Engine Assembly 5-8
LPG Engine Assembly, Kubota WG752 After Serial Numbers S2770RT-07-181100530, S3370RT-07-
190100529, S3970RT-07-190100519 5-9
BLOCK HEATER UPGRADE 5-10
MAINTENANCE

Maintenance 6-1
SCHEMATICS
Wiring Schematics 7-1
Hydraulic Schematic 7-2
A A
B B

The aerial platform is not electrically insulated. Death or serious injury will result from contact
with, or inadequate clearance from, an energized conductor.
Do not go closer than the Minimum Safe Approach Distance as defined by ANSI standards.
Regard all conductors as energized.
Allow for electrical wire sag and aerial platform sway.
If the platform, stack, or any part of the aerial platform contacts a high-voltage electrical conductor,
the entire machine can become electrically charged.
If that happens, remain on the machine and do not contact any other structure or object. This in-
cludes the ground, adjacent buildings, poles, and any other objects that are not part of the aerial
platform.
Such contact could make your body a conductor to the other object, creating an electrical shock
hazard resulting in death or serious injury.
Ifanaerialplatformisincontactwithanenergizedconductortheplatformoperatormustwarnground
personnelinthevicinitytostayaway.Theirbodiescanconductelectricitycreatinganelectricalshock
hazard resulting in death or serious injury.
Do not approach or leave the aerial platform until the electricity has been turned off.
Do not attempt to operate the lower controls when the platform, stack, or any part of the aerial
platform is in contact with a high-voltage electrical conductor or if there is an immediate danger of
such contact.
Personnel on or near an aerial platform must be continuously aware of electrical hazards, recogniz-
ing that death or serious injury can result from contact with an energized conductor.
© Snorkel – all rights reserved
California
Proposition 65 Warning
Battery posts, terminals and related accessories contain lead
andleadcomponents, chemicals knowntotheState of California
to cause cancer and birth defects or other reproductive harm.
Wash hands after handling.
