SolarEdge EV Series User manual

Installation Guide
EV Charging Single Phase
Inverter
with SetApp Configuration
For North America
Version 1.1

Disclaimers
Important Notice
Copyright © SolarEdge Inc. All rights reserved.
No part of this document may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photographic,
magnetic or otherwise, without the prior written permission of SolarEdge Inc.
The material furnished in this document is believed to be accurate and reliable.
However, SolarEdge assumes no responsibility for the use of this material. SolarEdge
reserves the right to make changes to the material at any time and without notice. You
may refer to the SolarEdge web site (https://www.solaredge.com/us/) for the most
updated version.
All company and brand products and service names are trademarks or registered
trademarks of their respective holders.
Patent marking notice: see https://www.solaredge.com/us/patent
The general terms and conditions of delivery of SolarEdge shall apply.
The content of these documents is continually reviewed and amended, where
necessary. However, discrepancies cannot be excluded. No guarantee is made for the
completeness of these documents.
The images contained in this document are for illustrative purposes only and may vary
depending on product models.
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, you are encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Disclaimers 1
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance may void the user’s authority to operate the equipment.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
2 FCC Compliance

Support and Contact Information
If you have technical problems concerning SolarEdge products, please contact us:
USA and Canada: 1 510 498 3200
Worldwide: [phone]
Fax: [phone]
Email: [e-mail].
Support Center: https://www.solaredge.com/us/service/support

Support and Contact Information 3
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

Before contact, make sure to have the following information at hand:
Model and serial number of the product in question.
The error indicated on the Inverter SetApp mobile application or on the monitoring
platform or by the LEDs, if there is such an indication.
System configuration information, including the type and number of modules
connected and the number and length of strings.
The communication method to the SolarEdge server, if the site is connected.
The inverter software version as appears in the status screen.
Revision History
Version 1.1, May 2019 - editorial changes
Version 1.0 , April 2019 - first release
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
4 Support and Contact Information

Contents
Disclaimers 1
Important Notice 1
FCC Compliance 1
Support and Contact Information 3
HANDLING AND SAFETY INSTRUCTIONS 7
Safety Symbols Information 7
IMPORTANTSAFETYINSTRUCTIONS 8
Chapter 1: Introducing the SolarEdge Power Harvesting System 13
Power Optimizer 14
EV Charging Single Phase Inverter 14
Monitoring Platform 15
Supported ACGrids 15
Installation Procedure 17
Installation Equipment List 17
Inverter Transport and Storage 18
EV Charging Safety Instructions 19
Chapter 2: Installing the Power Optimizers 20
Safety 20
Package Contents 22
Installation Guidelines 22
Step 1: Mounting and Grounding the Power Optimizers 24
Step 3: Connecting Power Optimizers in Strings 27
Step 4: Verifying Proper Power Optimizer Connection 28
Chapter 3: Installing the Inverter 30
Inverter Package Contents 30
Identifying the Inverter 30
Inverter Interfaces 30
Opening Conduit Drill Guides 33
Mounting the Inverter 35
Chapter 3: Connecting the AC and the Strings to the Connection Unit with
Safety Switch 38
Grid Connection Guidelines 38
Connecting the AC Grid to the Connection Unit with Safety Switch 39
Connecting the Strings to the Connection Unit with Safety Switch 39
Chapter 4: Activating, Commissioning and Configuring the System 42
Step 1: Activating the Installation 42
Step 2: Commissioning and Configuring the Installation 43
Support and Contact Information 5
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

Step 3: Verifying Proper Activation and Commissioning 47
Viewing System Status 48
Reporting and Monitoring Installation Data 55
Chapter 5: Setting Up Communication to the Monitoring Platform 58
Communication Options 58
Communication Connectors 60
Removing the Inverter Cover 61
Removing the Connection Unit with Safety Switch Cover 61
Creating an Ethernet (LAN) Connection 63
Creating an RS485 Bus Connection 66
Verifying the Connection 68
Chapter 5: Errors and Troubleshooting 70
Identifying Errors 70
EV Charger-related Troubleshooting 71
Power Optimizer Troubleshooting 74
Mechanical Specifications 76
Appendix A: Replacing and Adding System Components 77
Fuse Replacement 77
Replacing an Inverter 78
Replacing the Connection Unit with Safety Switch 80
Appendix B: Connecting an External Meter to an Inverter 83
Connecting an External Meter to an Inverter 83
Connecting an External Meter to an Inverter with a Built in Revenue Grade Meter
(RGM) 83
Technical Specifications - EV Charging Single Phase Inverter (North America) 84
Inverter Specifications 84
Default Trip Limits and Times According to IEEE1547 86
Recommended OCPD Size per Grid 87
EV Charger and EV Charger Cable Specifications 87
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
6 Support and Contact Information

HANDLING AND SAFETY INSTRUCTIONS
During installation, testing and inspection, adherence to all the handling and safety
instructions is mandatory. Failure to do so may result in injury or loss of life and
damage to the equipment.
Safety Symbols Information
The following safety symbols are used in this document. Familiarize yourself with the
symbols and their meaning before installing or operating the system.
WARNING!
Denotes a hazard. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in injury or loss of life. Do not proceed
beyond a warning note until the indicated conditions are fully understood and
met.
AVERTISSEMENT!
Dénote un risque: il attire l'attention sur une opération qui, si elle n'est pas faite
ou suivi correctement, pourrait causer des blessures ou un danger de mort. Ne
pas dépasser une telle note avant que les conditions requises soient
totallement comprises et accomplies.
CAUTION!
Denotes a hazard. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in damage or destruction of the
product. Do not proceed beyond a caution sign until the indicated conditions
are fully understood and met.
ATTENTION!
Dénote un risque: il attire l'attention sur une opération qui, si elle n'est pas faite
ou suivi correctement, pourrait causer un dommage ou destruction de
l'équipement. Ne pas dépasser une telle note avant que les conditions requises
soient totallement comprises et accomplies.
NOTE
Denotes additional information about the current subject.
IMPORTANTSAFETYFEATURE
Denotes information about safety issues.
HANDLING AND SAFETY INSTRUCTIONS 7
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

IMPORTANTSAFETYINSTRUCTIONS
SAVETHESEINSTRUCTIONS
CONSIGNES DE SÉCURITÉ IMPORTANTES
CONSERVEZ CES INSTRUCTIONS
WARNING!
When using electric products, basic precautions should always be followed,
including the following. This manual contains important instructions that shall
be followed during installation, operation and maintenance of the unit.
a. Read all the instructions before using this product.
b. This device should be supervised when used around children.
c. Do not put fingers into the electric vehicle connector.
d. Do not use this product if the flexible power cord or EV cable is frayed, has
broken insulation, or any other signs of damage.
e. Do not use this product if the enclosure or the EV connector is broken,
cracked, open, or shows any other indication of damage.
1. An insulated grounding conductor that is identical in size, insulation
material, and thickness to the grounded and ungrounded branch-circuit
supply conductors, except that it is green with or without one or more
yellow stripes, shall be installed as part of the branch circuit that supplies the
device or system.
2. The grounding conductor described in item 1 shall be grounded to earth at
the service equipment or, when supplied by a separately derived system, at
the supply transformer.
 AVERTISSEMENT!

Des mesures de précautions de base devraient être utilisées avec tous les
produits électriques, y compris les mesures indiquées ici. Ce manuel contient
d’importantes instructions à suivre au moment de l’installation, de l’utilisation et
de l’entretien de l’appareil.
a. Lire toutes les instructions avant d’utiliser ce produit.
b. Ce dispositif ne devrait pas être laissé sans surveillance s’il est utilisé près
d’enfants.
c. Ne pas mettre les doigts dans la prise du véhicule électrique.
d. Ne pas utiliser ce produit si le cordon souple ou le câble VE est effiloché, si
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
8 IMPORTANTSAFETYINSTRUCTIONS

l’isolant est endommagé, ou s’il présente tout autre signe
d’endommagement.
e. Ne pas utiliser ce produit si le boîtier ou la prise EV est endommagé, fissuré,
ouvert, ou s’il présente tout autre signe d’endommagement.
1. Un conducteur de mise à la terre isolé dont les dimensions, le matériau
d'isolation et l'épaisseur sont identiques aux conducteurs d'alimentation de
circuit de dérivation mis à la terre et non mis à la terre, sauf qu'il est vert avec
ou sans une ou plusieurs bandes jaunes circuit qui alimente l'appareil ou le
système.
2. Le conducteur de mise à la terre décrit à l'article 1 doit être relié à la terre à
l'équipement de service ou, lorsqu'il est alimenté par un système dérivé
séparément, au transformateur d'alimentation.
WARNING!
The inverter cover must be opened only after switching the inverter ON/OFF/P
switch located at the bottom of the inverter to OFF. This disables the DC voltage
inside the inverter. Wait five minutes before opening the cover. Otherwise, there
is a risk of electric shock from energy stored in the capacitors.
 AVERTISSEMENT!

Ne pas ouvrir le couvercle de l'onduleur avant d'avoir coupé l'interrupteur situé
en dessous de l'onduleur. Cela supprime les tensions CC et CA de l'onduleur.
Attendre cinq minutes avant d’ouvrir le couvercle. Sinon, il y a un risque de
choc électrique provenant de l'énergie stockée dans le condensateur.


WARNING!
Before operating the inverter, ensure that the inverter is grounded properly. This
product must be connected to a grounded, metal, permanent wiring system, or
an equipment-grounding conductor must be run with the circuit conductors
and connected to the equipment grounding terminal or lead on the product.
 AVERTISSEMENT!

Avant d'utiliser l'onduleur monophasé, assurez-vous que l'onduleur est
correctement mis à la terre. Ce produit doit être raccordé à un système de
câblage fixe, métallique, l'équipement-le conducteur de mise à la terre doit être
exécuté avec les conducteurs de circuit et raccordé à l'équipement borne de
mise à la terre ou de plomb sur le produit.
IMPORTANTSAFETYINSTRUCTIONS 9
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

WARNING!
Opening the inverter and repairing or testing under power must be performed
only by qualified service personnel familiar with this inverter.
 AVERTISSEMENT!

L’unité ne doit être ouverte que par un technicien qualifié dans le cadre de
l'installation et de la maintenance.
WARNING!
The Safety Switch meets all requirements for a code-compliant installation of
this system. The DC Disconnect Switch disconnects both the positive and
negative conductors.
 AVERTISSEMENT!

Le sectionneur externe (inclus) repond aux exigences de conformité pour
l’installation de ce système . Le coupeur CC ouvre les conducteurs positifs et
négatifs.
WARNING!
The inverter input and output circuits are isolated from the enclosure. This
system does not include an isolation transformer and should be installed with
an ungrounded PV array in accordance with the requirements of NEC Articles
690.35 and 690.43 National Electric Code, ANSI/NFPA 70, 2011 (and Canadian
Electrical Code, Part I, for installations in Canada).
Equipment grounding is the responsibility of the installer and must be
performed in accordance with all applicable Local and National Codes.
 AVERTISSEMENT!

Les circuits d’entrée et de sortie de l’onduleur sont isolés de l’enveloppe. Ce
système n’inclut pas d’isolation galvanique (transformateur) et devra être
installé sans mise à la terre du champ PV et en accord avec les articles 690.35 et
690.43 du National Electric Code (NEC), ANSI/NFPA 70, 2011 (et du Code
Electrique Canadien, Partie 1, pour les installations faites au Canada).
La mise à la terre des équipements est la responsabilité de l’installateur et doit
être faite en accord avec les toutes les règles locales et nationales applicables.
WARNING!
The inverter must be connected to a dedicated AC branch circuit with a
maximum Overcurrent Protection Device (OCPD) of 50A.
The SE10000H-US and SE11400H-US must be connected to a dedicated AC
branch circuit with a maximum Overcurrent Protection Device (OCPD) of 80A.
 AVERTISSEMENT!

Les onduleurs doivent être connectés à un branchement AC dédié avec un
disjoncteur de 50A.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
10 IMPORTANTSAFETYINSTRUCTIONS

Les onduleurs SE10000H-US et SE11400H-US doivent être connectés à un
branchement AC dédié avec un disjoncteur de 80A
WARNING!
SolarEdge products can expose you to chemicals including antimony trioxide,
which is known to the State of California to cause cancer. For more information,
go to www.P65Warnings.ca.gov .
AVERTISSEMENT!
Les produits SolarEdge peut vous exposer à des agents chimiques, y compris
trioxyde d'antimoine, identifiés par l'État de Californie comme pouvant causer le
cancer. Pour de plus amples informations, prière de consulter
www.P65Warnings.ca.gov.
CAUTION!
This unit must be operated according to the technical specification datasheet
provided with the unit.
 ATTENTION!

Cette unité doit être utilisée selon les spécifications de fonctionnement, comme
décrit dans la dernière fiche technique des spécifications.
CAUTION!
HEAVY OBJECT. To avoid muscle strain or back injury, use proper lifting
techniques, and if required - a lifting aid.
ATTENTION!
Objet lourd. Pour éviter la fatigue musculaire ou des blessures au dos, utilisez
des techniques de levage appropriées et, si nécessaire - un auxiliaire de levage
lors du retrait.
NOTE
Use only copper conductors rated for a minimum of 75°C/ 167°F.
NOTE
This inverter is provided with an IMI (Isolation Monitor Interrupter) for ground
fault protection.
NOTE
The symbol appears at grounding points on the SolarEdge equipment. This
symbol is also used in this manual.
IMPORTANTSAFETYINSTRUCTIONS 11
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

NOTE
A SolarEdge inverter may be installed in a site with a generator. SolarEdge
requires installing a physical or electronic interlock, which will signal to the
inverter when the grid has been disconnected. Interlock procurement,
installation, maintenance and support are the responsibility of the installer.
Damage to the inverter due to incorrect interlock installation or use of an
interlock that is incompatible with the SolarEdge system will render the
SolarEdge warranty invalid.
For more information, refer to
https://www.solaredge.com/sites/default/files/se-inverter-
support-of-voltage-sources.pdf.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
12 IMPORTANTSAFETYINSTRUCTIONS

Chapter 1: Introducing the SolarEdge Power
Harvesting System
The SolarEdge power harvesting solution maximizes the power output from any type of
solar Photovoltaic (PV) installation while reducing the average cost per watt. The
following sections describe each of the system’s components.
Figure 1: The SolarEdge power harvesting system components
Chapter 1: Introducing the SolarEdge Power Harvesting System 13
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

Power Optimizer
The power optimizers are DC-DC converters connected to PV modules in order to
maximize power harvesting by performing independent Maximum Power Point
Tracking (MPPT) at the module level.
The power optimizers regulate the string voltage at a constant level, regardless of string
length and environmental conditions.
The power optimizers include a safety voltage function that automatically reduces the
output of each power optimizer to 1 Vdc in the following cases:
During fault conditions
The power optimizers are disconnected from the inverter
The inverter ON/OFF/P switch is turned OFF
The inverter AC breaker is turned OFF
The Rapid Shutdown (PVRSS)is initiated by one of the following methods:
Inverter AC breaker is turned OFF, or AC to the inverter is disconnected by
another method (intentionally or as result of a fault)
Inverter ON/OFF/P switch is turned OFF
The Connection Unit with Safety Switch is turned OFF
Each power optimizer also transmits module performance data over the DC power line
to the inverter.
Two types of power optimizers are available:
Module Add-on power optimizer – connected to one or more modules
Smart modules - the power optimizer is embedded into a module
EV Charging Single Phase Inverter
The EV Charging Single Phase Inverter (referred to as “inverter”throughout) efficiently
converts DC power from the modules into AC power that can be fed into the main
ACservice of the site and from there to the grid. The inverter also receives the
monitoring data from each power optimizer and transmits it to a central server (the
monitoring platform; requires Internet connection).
The EV Charging Single Phase Inverter is designed to provide reliable and economical
charging of an electric vehicle (EV). It provides Level 2 EV charging from both the grid
and the PV system, and is designed to work with all plug-in vehicles with J1772 (Type 1)
socket.
An EV Charger cable (ordered separately)is required for EV charging:
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
14 Power Optimizer

The EV Charger Cable connects the EV plug to the inverter
The wall mounted EV Charger cable holder is used for hanging the EV Charger cable
and plug, protecting the plug from rain when not plugged into the vehicle (V2
holders), and provides strain relief for the inverter when the cable is pulled.
Figure 2: The EV Charger Cables (with holders)
Monitoring Platform
The monitoring platform enables monitoring the technical and financial performance of
one or more SolarEdge sites. It provides past and present information on the system
performance both at the system and module levels.
Supported ACGrids
The following figures illustrate grids that are supported by SolarEdge single phase
inverters. Refer to Setting Country and Language on page 44 ).
15
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

Ground connection is required for all grids, as described in Connecting the AC Grid to
the Connection Unit with Safety Switch on page 39.
Note that in some cases L1 and L2 are not interchangeable. In these places, L1 and L2
locations appear in the drawing.
Figure 3: 240V AC grids supported by SolarEdge single phase inverter
Figure 4: 208V AC grids supported by SolarEdge single phase inverter(1)
(1)208V AC grids are only supported by some inverter models. Refer to the specification supplied with the
inverter.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
16 Supported ACGrids

Installation Procedure
The following is the procedure for installing and setting up a new SolarEdge site. Many
of these also apply to modification of an existing site.
1. Connecting Power Optimizers in Strings, page 27.
2. Recording power optimizer serial numbers (optional), page 56.
3. Mounting the inverter, page 35.
4. Connecting AC and Strings to the Safety Switch page 38.
5. Activating, Commissioning and Configuring the System Using the Inverter SetApp,
page 42
6. Connecting the inverter to the monitoring platform, page 57.
7. Installing and connecting the cable - Refer to the installation guide supplied with
the product. The cable and holder can be installed at the same time as the inverter
or added later.
8. Configuring the EV Charger - Refer to the installation guide supplied with the EV
Charger Cable. Configuration can be done only after the EVCharger Cable is
connected to the inverter and the inverter is connected to the monitoring platform. 
Installation Equipment List
Standard tools can be used during the installation of the SolarEdge system. The
following is a recommendation of the equipment needed for installation:
Allen screwdriver for 3mm screw type for the inverter cover, side screws, and Safety
Switch cover
Standard flat-head screwdrivers set
Non-contact voltage detector
Cordless drill (with a torque clutch)or screwdriver and bits suitable for the surface
on which the inverter and optimizers will be installed and for opening the
Connection Unit with Safety Switch drill guides. Use of an impact driver is not
allowed.
Appropriate mounting hardware (for example: stainless bolts, nuts, and washers)
for attaching:
the inverter mounting bracket to the mounting surface
the power optimizer to the racking (not required for smart modules)
Wire cutters
17
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1

Wire strippers
Voltmeter
Mobile phone with latest SetApp version
For installing the communication options, you may also need the following:
For Ethernet:
CAT5/6 twisted pair Ethernet cable with RJ45 connector
If using a CAT5/6 cable spool: RJ45 plug and RJ45 crimper
For RS485:
Four- or six-wire shielded twisted pair cable
Watchmaker precision screwdriver set
Inverter Transport and Storage
Transport the inverter in its original packaging, facing up and without exposing it to
unnecessary shocks. If the original package is no longer available, use a similar box that
can withstand the weight of the inverter (refer to the inverter weight in the specification
datasheet provided with the unit), has a handle system and can be closed fully.
Store the inverter in a dry place where ambient temperatures are -13°F to 140°F /
-25°C to +60°C.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
18 Inverter Transport and Storage

EV Charging Safety Instructions
WARNING!
Do not charge a vehicle indoors if it requires ventilation. Contact your EV service
representative for information.
 AVERTISSEMENT!

Ne pas recharger un véhicule à l’intérieur si il nécessite une ventilation.
Contactez votre représentant de service pour plus d’informations.
WARNING!
Automatic CCID (charge circuit interrupting device) reset provided.
 AVERTISSEMENT!

Réinitialisation CCID (charge circuit interrupting device) automatique incluse.
WARNING!
Risk of electric shock. Do not remove cover. No user serviceable parts inside.
Refer servicing to qualified service personnel.
 AVERTISSEMENT!

Risque de choc électrique. Ne pas retirer le couvercle. Pas de pièces sujettes à
maintenance. Laissez la maintenance à du personnel qualifié.
CAUTION!
Do not use this product if there is any damage to the unit.
 ATTENTION!

Ne pas utiliser pas ce produit si l'appareil est endommagé.
CAUTION!
Do not use an extension cord between the SolarEdge EV Charger Cable and the
EV Charging Single Phase Inverter. You may use a conversion adapter only if it
has been approved by SolarEdge.
NOTE
This product is intended for use with electric vehicles, however it operates as a
PV inverter also when no charging cable is connected.
19
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
