SolarEdge Dry-Contact switch User manual

Dry-Contact switch Installation Guide
Overview
The SolarEdge Smart Energy Management solutions allow increasing the self-consumption of a site. One
method used for this purpose is controlling the usage (consumption) of loads using Device Control
products.
The SolarEdge Device Control units divert power to an appliance (load) according to pre-configured
schedules, using the following modes:
Refer to Figure 2 for examples of the device modes of operation.
You can re-configure the schedules at any time and manually switch appliances on and off.
You can configure the Device Control products locally through the SolarEdge inverter or remotely, via
the SolarEdge monitoring portal.
The SolarEdge Dry-Contact switch (referred to as "the device") is a ZigBee wireless load management
device. It switches loads (e.g. a heat pump) on and off according to system configuration. It can function
as an AC switch or as a control signal to indicate when the PV system is producing excess energy. It
supports a wide input voltage range of up to 250V and a wide input current range of up to 13A.
Figure 1: SolarEdge System with Dry-Contact switch
Dry-Contact switch Installation Guide
SolarEdge-Dry-Contact switch Installation Guide
1
l Schedule - TThe device turns on and off at times set by the user for the user’s convenience,
regardless of available PV power.w
lSmart Save - The device (typically a boiler or water pump) is controlled automatically to maximize self-
consumption. Grid power is used only if PV power is insufficient to meet the user’s “ready by” time. For
example, to heat water for 2 hours and have hot water by 18:00, set Total Time to 2 hours and Ready by to
18:00. The boiler may work before 16:00 if there is available PV power, but in any case you are guaranteed
to have hot water by 18:00.w

The following figure illustrates a typical example of device operation with Smart Save and Schedule
modes. Note that in Smart Save mode, the consumption is reduced by taking advantage of excess PV
earlier in the day.
Figure 2: Examples of device operation
To enable the Dry-Contact switch functionality, the following supporting devices must be installed:
lDevice Control ZigBee Module, installed inside the inverter. For physical installation refer to
http://www.solaredge.com/sites/default/files/se-device-control-zigbee-module-installation-
guide.pdf.
lSolarEdge Modbus Meter. Refer to http://www.solaredge.com/files/pdfs/solaredge-meter-
installation-guide.pdf
Installation
Figure 3: The Dry-Contact switch
SolarEdge Dry-Contact switch Installation Guide
2
Installation

CAUTION!
lThis product must be operated under the specified operating specifications, as described in
the latest technical specification datasheet.
lConfigure the product so that the load connected is not switched on or off more
frequently than specified by the load manufacturer.
lDo not connect loads that require a continuous current supply (e.g. fridge, freezer).
lDo not use the product if it is damaged or malfunctioning.
lNever connect loads that can cause injuries or fire if they are switched on unintentionally
(e.g. an iron).
lDo not let the product come into contact with water or other liquids.
lThe enclosed documentation is an integral part of this product. Keep the documentation
in a convenient place for future reference and observe all instructions contained therein.
1. Release the two screws of the device front cover and remove the cover.
2. Position the device against the wall and mark the drilling hole locations, at a maximum distance of 50 m
from the inverter. Do not use the device as a drilling template as it may damage the enclosure.e
3. Drill the holes and mount the device using screws and nuts. Fasten the unit to the wall.
4. Release the three internal screws at the bottom of the device, and remove the cable bracket.
Figure 4: Dry-Contact switch connections
Dry-Contact switch Installation Guide
SolarEdge-Dry-Contact switch Installation Guide MAN-01-00278-1.1
3

5. Connect the load wires to the terminal blocks (see Figure 4, Figure 5 and Figure 6 ):w
l230 Vac (connections 1,2 ) - to Line and Neutral. The connections are interchangeable.
lDry-contact 250V / 13A maximum (connections 3, 5) - to a dedicated voltage source from the
appliance (see Figure 3), or an external power supply according to the input control specifications
of the appliance (see Figure 4).
lManaged load (connections 4,6) -to the appliance input control
The two switches have a single control. That is, either both are closed or both are opened.
Figure 5: Connecting to appliance with internal
voltage source (Vout)
Figure 6: Connecting to appliance with external
voltage source
6. Place the cable bracket over the cables and fasten using the screws.
7. Attach the cover to the device and fasten the screws.
Configuration
NOTE
Verify that the inverter is connected to the monitoring portal (refer to the Inverter Installation Guide for
details on setting up communication).
To associate the device with the ZigBee network:
1. Enter the inverter Setup mode as described in the Inverter Installation Guide.
2. Select Communication èZigBee Conf..
SolarEdge Dry-Contact switch Installation Guide
4
Configuration
3. Select:
lDevice TypeèHA (Home Automation)
lProtocol èHAM (Home Automation)
D e v i c e T y p e < H A >
Protocol<HAM>
P A N I D
Scan Channel
L o a d Z B D e f a u l t s

When HA Device Type is selected, a Device Manager menu item will appear in the main configuration
menu:
Country <Italy>
L a n g u a g e < E n g >
Communication
P o w e r C o n t r o l
Display
Maintenance
Information
4. From the main menu select Device Manager. The Device Manager screen is displayed:
A d d D e v i c e s < 0 >
5. Select Add Devices to start the device association with the inverter.
6. Press the association button on the Dry-Contact switch (see Figure 1).
The Device Manager screen should display a new line for each discovered device, including the 3 last
digits of its serial number, operating mode and operating state. Discovery time may take up to 3
minutes. You can press the inverter LCDlight button or the internal ESC button to exit the discovery
process when all devices are discovered.
A d d D e v i c e s < 3 >
R e g x x x < A u t o , O F F >
S E - S W x x x < M a n , O F F >
S E - S - P L G x x x < M a n , O F F >
R e m o v e A l l
Device types:
lREG - Immersion heater controller
lSE-SW - Dry contact switch
lSE-S-PLG - Plug-in socket
lSE-S-SW - AC switch with meter
7. Select the device. The device configuration screen is displayed:
M o d e < M a n u a l >
S t a t e < O F F >
D e v i c e I n f o
R e m o v e D e v i c e
For the following device configuration steps, you can use either the inverter LCDbuttonsor the
monitoring portal. The steps herein show configuration using the inverter LCD.
Dry-Contact switch Installation Guide
SolarEdge-Dry-Contact switch Installation Guide
5

8. Select Mode. The mode configuration screen is displayed:
M a n u a l
A u t o
lManual - turns the device to ONor OFF, as described below
lAuto - allows setting two types of schedules for device control, as described in the next sections:
oSmart Save - set the device operation requirements (ready-by and duration values). This mode
is useful for maximizing self-consumption using excess PVpower: the device operates
autonomously based on configured settings.
oSchedule - set the device start and stop times regardless of available excess PVpower.
To set Manual mode:
1. Select Mode èManual
2. Select ON or OFFto turn the device on or off.
To set Auto mode:
1. Select Auto. The following screen is displayed, showing options for setting the device parameters:
M o d e < A u t o >
A d d S c h e d u l e
D e v i c e P r o p e r t i e s
D e v i c e I n f o
R e m o v e D e v i c e
2. Select Device Properties and set the following properties:
L o a d R a t i n g < x . x K W >
E x p o r t T H < x x x x W >
I m p o r t T H < x x x x W >
M i n O n T i m e < x x x >
lLoad Rating - the appliance rated power (in kW)
lExport TH (threshold) - optional; the minimum power (in W) above which the excess PV power
will be diverted to the appliance. This value can be lower than the load rating. The default value is
5% above the Load Rating.
lImport TH (threshold) - optional; the maximum power (in W) purchased from the grid and
diverted to the appliance. The default value is 5% of the Load Rating.
NOTE
If changing the Export TH and Import TH default values, make sure they sum up to a
value that equals or greater than the appliance Load Rating value. Otherwise, the
device will turn off when there is insufficient power to divert to the appliance.
l Min ONTime - (optional); the minimum duration (in minutes) the appliance should remain
ONonce switched on, even when no excess PVpower is available. The default value is 1
minute.e
SolarEdge Dry-Contact switch Installation Guide
6
Configuration

3. Select Add Schedule. The following screen is displayed, showing schedule setting options. You can
configure up to four different schedules.
S m a r t S a v e
S c h e d u l e
Disable
D e l e t e
Use Disable to deactivate a schedule or Delete to remove it.
4. Select and set one of the scheduling options:
lSmart Save:
S e t < S m a r t >
R e a d y b y < 0 0 : 0 0 >
D u r a t i o n < 0 0 >
M a x D u r a t i o n < 0 0 >
Week Days<1234567>
oReady by - requested energy must be diverted to the load by this time (default: 00:00;
format:hours:minutes).
oDuration - minimum accumulated time the load must remain on (in minutes; default: 00).
oMax Duration - maximum accumulated time the load can be on throughout the day (in
minutes; default: 00).
If the value of Max Duration is longer than the value of Duration, the device will use up only
excess PV energy in the difference time. For example, if Max Duration = T1 and Duration =
T2, during (T1-T2) only excess PV power will be used.
oWeek Days (optional) - days to repeat the settings (default: every day).
lSchedule:
S e t < S c h e d u l e >
S t a r t T i m e < 0 0 : 0 0 >
S t o p T i m e < 0 0 : 0 0 >
Week Days <1234567>
oStart/Stop Time - the time of day by which the Dry-Contact switch must start/complete
its task of delivering energy to the load (default: 00:00; format:hours:minutes). If these
values are not set, only the excess PV power is used.
oWeek Days (optional) - days to repeat the settings (default: every day).
NOTE
In Auto mode , if you configure overlapping time-frames between Schedule and Smart Save
options, Schedule mode takes precedence over the Smart Save mode.
Dry-Contact switch Installation Guide
SolarEdge-Dry-Contact switch Installation Guide
7

You can re-configure the device operation mode and schedules at any time:
To Do this
Manually turn the load on or off Select the device from the Device Manager screen. Select
Mode èManual and set the device to either ON or OFF.
Modify the schedule configuration
Select the device from the Device Manager screen. Select
Mode èAuto and set the parameters of any menu: Smart
Save/Schedule.
Disable or delete a schedule Select Disable or Delete from the Schedule screen.
Disconnect the device(s) from the network Select Remove Device or Remove All from the device
screen.
Verifying the Connection
1. Check the status screens:
lHA devices status, showing the device name and state: ON, OFF, or an asterisk (*), which indicates
no communication with the device:
HA Devices State:
S E - S - P L G 0 1 1 < O N >
lCommunication status, showing the number of communicating HAdevices (under Prot) and the
number of detected devices (under ##):
w w w w w DevProt ##
R S 4 8 5 - 1 < - - - > < - - > < - >
Z i g B e e < H A > < 1 > < 1 >
2. To check the device details, from the device configuration screen, select Device Info. The following
screen is displayed:
MAC: xxxxxxxxxxx
L a s t s e e n : < D D : H H >
MFG: SolarEdge
M o d e l : S E - S - P L G
P o w e r [ W ] : 0
lMAC: the full MACaddress of the device
lLast seen: The date and time when the device communicated with the inverter
lMFG: The device manufacturer
lModel: The device model type
lPower [W]: The energy delivered to the load
SolarEdge Dry-Contact switch Installation Guide
8
Verifying the Connection

LEDIndications
The device has a bi-color LED (red/ green) that provides information about its operation status:
LEDfunction Indication
Solid green (2 seconds), flashing green (2 seconds) Reset
Flashing red No ZigBee association with the inverter
Flashing green ZigBee association in process
Solid green ZigBee association completed and the relay is closed
Solid red ZigBee association completed and the relay is open
Button Functionality
The following table describes the device button functions depending on the network association state:
Network state Pressing duration Result
No ZigBee
association with
the inverter
Any Attempt to associate with the network
ZigBee
associated with
the inverter
Up to 3 seconds (short press)
Manually toggle ON/OFFstate (manual mode). To return to
Auto/Scheduled states, configure the device using the mobile
application or monitoring portal.
More than 10 seconds (long
press)
Disconnect from the network (the LED turns red and the
device resets).
3 - 10 seconds
Start a discovery search for nearby devices. The discovery
may take up to 3 minutes during which the device is not
functional. Not required for normal operation.
Troubleshooting
Symptom / Error Possible cause Troubleshooting
oAn asterisk (*) is displayed
next to the Device type in
the device manager
screen indicating that the
device is not
communicating.
oIn the Communication
status screen, the number
of detected devices does
not match the number of
communicating devices.
oThe device is powered on
but the green LED is OFF
The device
is not associated with the
inverter
Try to solve using these options. If problem is not
solved, proceed with the next option:
oTurn the device OFF and ON. Recheck
communication.
oReset the device by pressing the button for
more than 10 seconds and then repeat the
association process. Reconfiguration is not
required.
oFrom the Device Manager screen select
Remove Device and repeat the discovery
process. Reconfiguration is required in this
case.
oContact SolarEdge support.
The device is powered on and
the green LED is ON
The device is Associated
with the inverter but is not
communicating.
All the devices are not
communicating No ZigBee error is
displayed on the inverter
oTurn OFFthe AC to the inverter.
oCheck that the ZigBee module is inserted
correctly inside the inverter.
Dry-Contact switch Installation Guide
SolarEdge-Dry-Contact switch Installation Guide
9

Symptom / Error Possible cause Troubleshooting
LCD - The inverter has not
detected the installed
ZigBee module. oTurn ON the AC to the inverter.
Network problems
Try to solve using these options. If problem is not
solved, proceed with the next option:
oCheck the ZigBee status screen:Verify that
PAN has been established and Channel is not
0:
PAN:XXXXX
CH:XX/XXXXRSSI:<L>
M I D : X X X X X X
oTurn the inverter OFF and ON (power cycle).
oReset all the devices using the association
button and begin the discovery process again
for all devices.
oFrom the Device Manager screen select
Remove All and repeat the discovery process
for all the devices.
oContact SolarEdge support.
Error message Device limit
reached. Remove devices
from the device list is
displayed in the LCD.
You are attempting to
associate more than 10
devices to the load
managemnt network.
Remove an unused device from the device list
before attempting to add another device.
SolarEdge Dry-Contact switch Installation Guide
10
Troubleshooting

Specifications
ELECTRICAL SERVICE
Operating Voltage Range - Line to Neutral 90 - 250 Vac
AC Frequency 50/60 Hz
Maximum Load Current 13 A
Dry-contact Voltage Range 0-250 V
COMMUNICATION
Supported Communication Protocol ZigBee Home Automation
Nominal Transmit Power 10 dBm
Operating Frequency Range 2.4 - 2.5 GHz
Outdoor (LOS) Range 400 m
Indoor Range150m
STANDARD COMPLIANCE
Radio ETSI EN 300 328 V 1.8.1, ETSI EN 301 489-1, ETSI EN 301
489-17
Safety EN 60335-1, EN 60335-2-30, EN 50371
Immunity EN 55014-2
Emissions EN 55014-1, EN 61000-3-2,
EN 61000-3-3
INSTALLATION SPECIFICATIONS
Operating Temperature Range 0 to +50 °C
Protection Rating IP30
Dimensions (H x W x D) 110 x 70 x 25 mm
Mounting Type Wall mount
1Approximate value. May differ depending on specific installation conditions.
Dry-Contact switch Installation Guide
SolarEdge-Dry-Contact switch Installation Guide
11
