MODEL: TRC800V
INSTALLATION, OPERATION & MAINTENANCE MANUAL
ENERGY RECOVERY VENTILATOR
TRC800
TRC800V
MODEL: TRC800
WWW.SOLERPALAU-USA.COM

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.73702
TRC800/V info ..................... 2-5
Installation......................... 6-12
Start-up............................13-15
Maintenance.....................17-19
TABLE OF CONTENTS
TRC800 & TRC800V INFO
ABOUT S&P
S&P USA operations are based in Jacksonville, Florida. This geographically strategic location allows the
shipment of products throughout the US and Canada. The Jacksonville manufacturing facility has more
than 150,000 square feet of warehouse space for the stocking of a comprehensive range of products.
This permits the overnight delivery of many popular model sizes to anywhere in the US and Canada.
At S&P USA we take pride in the fact that our customers receive only the very highest levels of customer
service and care. Our internal and external technical and customer service teams are on-hand to provide
professional and experienced application advice to enable our customers to apply our products to their
particular ventilation and air movement applications. As the USA sales, marketing and distribution division
of the Soler & Palau Ventilation Group of companies we are committed to providing only the very highest
levels of customer service. Our commitment in providing only the very highest standards of customer
service is key to our company strategy.
Soler & Palau Ventilation Group is the world’s leading fan manufacturer. It celebrated its 50th anniversary
in 2001. Soler & Palau is able to offer a range of ventilation products benefiting from over 50 years of
experience within the industry. The company’s impressive, long-term growth is the result of one simple
philosophy—develop an air-moving product that effectively and efficiently meets the needs of the
customer, supported by unparalleled engineering, distribution and service.
In 1951 Eduard Soler and Josep Palau, both born in Ripoll, Spain, founded the company Soler & Palau
(S&P). From the very start the business proved to be their vocation. Together they combined their
extensive knowledge and flair to ensure the successful start of their business project. There is continual
in-house product development with state-of-the-art technology, and a continued program of in-house
laboratory certifications.
Currently S&P’s R&D, manufacturing and distribution facilities occupy a total of 1.1 million square feet,
with offices and locations around the globe. S&P products can be found in virtually any commercial or
residential application, ranging from innovative, quiet and reliable room ventilators to large diameter, high
capacity exhaust systems designed for critical applications in some of the world’s toughest environments.

ERVTRC800 & TRC800V
31.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM 3
TRC800 & TRC800V INFO
SPECIFICATIONS
NOTE: Specifications may
be subject to change
without notice.
Unless otherwise specified,
dimensions are rounded
to the nearest eighth of
an inch.
AIRFLOW PERFORMANCE
Motor HP
Phase
External Static Pressure (Inches Water Column)
0.0 0.25 0.50 0.75 .9 1.25 1.50
.75
Single Phase
970 CFM
1,490 Watts
925CFM
1,375 Watts
860 CFM
1,270 Watts
795 CFM
1,160 Watts
750 CFM
1,090 Watts
635 CFM
950 Watts
480 CFM
825 Watts
NOTE: Watts is for the entire unit (2 motors).
NOTE: Airflow performance includes effect of clean, standard filter supplied with unit.
ELECTRICAL DATA
HP Volts HZ Phase
FLA
per
motor
Min.
Cir.
Amps
Max.
Overcurrent
Protection
Device
.75 120 60 Single 9.0 20.3 25
.75 230 60 Single 4.5 10.1 15
CORE PERFORMANCE
ThermalPerformanceRatingsG52015.2.xlsx HE1.5X(IOM)
30%
50%
70%
90%
300 600 900 1,200 1,500
Effectiveness (%)
Airflow (CFM)
At AHRI 1060 standard conditions. See all
AHRI certified ratings at www.ahrinet.org.
TRC800 TRC800V
Ventilation Type:
Static plate, heat and humidity transfer
Typical Airflow Range:
250-925 CFM
AHRI 1060 Certified Core:
One L125-G5
Standard Features:
Non-fused disconnect
24 VAC transformer/relay package
Filters:
Total Qty. 2, MERV 8: 20" x 20" x 2"
Unit Dimensions & Weight:
49 1/8" L x 22 1/4" W x 35 7/8" H
210 lbs.
Max. Shipping Dimensions & Weight (on pallet):
63" L x 30" W x 42" H
325 lbs.
Motor(s):
Qty. 2, .75 HP ea., Direct drive blower/standard
motor packages
Ventilation Type:
Static plate, heat and humidity transfer
Typical Airflow Range:
250-925 CFM
AHRI 1060 Certified Core:
One L125-G5
Standard Features:
Non-fused disconnect
24 VAC transformer/relay package
Filters:
Total Qty. 2, MERV 8: 20" x 20" x 2"
Unit Dimensions & Weight:
34 7/8" L x 22 1/4" W x 50 1/8" H
207 lbs.
Max. Shipping Dimensions & Weight (on pallet):
30" L x 42" W x 56" H
325 lbs.
Motor(s):
Qty. 2, .75 HP ea., Direct drive blower/standard
motor packages

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.73704









 

  








   
 
 










 
 

 





  
             



 
  
TRC800 INFO
PRODUCT DIMENSIONS TRC800

ERVTRC800 & TRC800V
51.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM 5













 
 





  
             
   










 












TRC800V INFO
PRODUCT DIMENSIONS TRC800V

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.737066
PLACEMENT OF THE TRC800 & TRC800V
TheTRC800/TRC800V is designed for installation indoors. Select a location that is central to the inside duct
runs,
and close to both the exhaust duct (to the outside) and the fresh air duct (from the outside). The unit
can be installed in any orientation but the contractor is responsible for safe installation of the unit.
PLANNING
YOUR INSTALLATION
INSTALLATION
The fresh air inlet should be at least 10’ away from
chimneys, furnace and water heater exhausts, and
other sources of carbon monoxide, humidity or other
contamination. Do not locate the fresh air inlet where
vehicles may be serviced or left idling. Never locate the
fresh air inlet inside a structure.
WARNING
NOTE: To prevent the entry of rain through the outside air inlet duct, observe the following:
1. Velocity at face of inlet hood should not exceed 500 feet per minute (fpm).
2. Inlet duct must be at least 12” inside diameter.
3. Centerline length along duct from weather hood to unit inlet must be at least 48”.
4. Inlet duct must pitch downward to the outside; centerline of inlet hood must be at least 18” below
the centerline of the unit inlet.
5. Outlet duct must pitch downward to the outside with a slope of at least ¼” to the foot.
Ducts connecting the unit to the outside must be insulated, with sealed vapor barrier on both inside
and outside of the insulation. Insulate both the Outside Air (OA) and Exhaust Air (EA) ducts.
INSIDE DUCTWORK SYSTEM
Ensure Good Ductwork Design
Ductwork should be designed to allow the unit to
provide the required airflow and reduce pressure
drop for efficient, quiet operation. If the inside
ducts run through unconditioned spaces they must
be insulated with a sealed vapor barrier on both
inside and outside of insulation.
Use Non-motorized Dampers to Set and
Balance Air
In most applications, the airflow rate for both the
Fresh Air and the Exhaust Air should be roughly equal
(or “balanced”) for best performance of the TRC Unit.
See unit specification sheet for CFM/ESP curves.
DUCTS TO THE OUTSIDE
The exhaust outlet and fresh air inlet on the
outside of the building should be at least ten feet
apart to avoid cross-contamination. The exhaust
outlet should not dump air into an enclosed space
or any other structure. The inlets and outlets
should be screened against insects and vermin
and shielded from the weather to prevent the
entry of rain or snow.

ERVTRC800 & TRC800V
71.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
ERV
7
PLANNING
YOUR INSTALLATION
INSTALLATION
APPLICATIONS
See figures for examples of some common installation approaches.
(TRC800 shown)
www.renewaire.com (800) 627- 4499 [email protected]
www.renewaire.com (800) 627- 4499 [email protected]
www.renewaire.com (800) 627- 4499 [email protected]

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.73708
1. Beforeservicing or cleaningthe unit,switchpower
off at disconnect switch or service panel and lock-
out/tag-out to prevent power from being switched
on accidentally. More than one disconnect switch
may be required to de-energize the equipment
for servicing.
2. This installation manual shows the suggested
installation method. Additional measures may be
required by local codes and standards.
3. Installation work and electrical wiring must be
done by qualified professional(s) in accordance
with all applicable codes, standards and licens-
ing requirements.
4. Any structural alterations necessary for instal-
lation must comply with all applicable building,
health, and safety code requirements.
5. This unit must be grounded.
6. Sufficient air is needed for proper combus-
tion and exhausting of gases through the flue
(chimney) of fuel burning equipment that might be
installed in the area affected by this equipment.
If this unit is exhausting air from a space in
which chimney-vented fuel burning equipment is
located, take steps to assure that combustion
air supply is not affected. Follow the heating
equipment manufacturer’s requirements and the
combustion air supply requirements of applica-
ble codes and standards.
7. Use the unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
8. This unit is intended for general ventilating only.
Do not use to exhaust hazardous or explosive
materials and vapors. Do not connect this unit to
range hoods, fume hoods or collection systems
for toxics.
9. When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities.
10. If installed indoors this unit must be properly
ducted to the outdoors.
RISK OF FIRE, ELECTRIC SHOCK, OR INJURY. OBSERVE ALL CODES AND THE FOLLOWING:
WARNING
INSTALLATION
PLANNING
YOUR INSTALLATION
Take these simple steps to attenuate noise from the unit.
OUTSIDE THE BUILDING
Exhaust velocity noise is the primary cause of
unit-related noise outside the building. Size the
exhaust duct and grille for less than 1000 FPM
air velocity. When practical, orient the exhaust air
hood to point away from houses or public areas.
DUCTS
Make sure the ductwork at the unit outlets is
stiff enough to resist the flexure and resulting
booming associated with system start-up and
shut-off, as well as the turbulent flow conditions
at the blower outlets.
In general, provide smooth transitions from the
ERV’s outlets to the duct. The ducts connecting
to the outlets should be straight for a sufficient
distance, with gradual transitions to the final
duct size.
These guidelines are consistent with SMACNA
recommended duct layout practices for efficient and
quiet air movement. Follow SMACNA guidelines.
RADIATED NOISE
The TRC800/TRC800V is insulated with high-den-
sity
fiberglass. This provides significant attenuation
of radiated sound.
The outlet ducts can be significant sources of
radiated sound as well. The FA and EA ducts
(outlet ducts) should be insulated for sound
control. This insulation should start at the unit.
At a minimum the first ten feet of duct should be
insulated. All parts of the FA and EA ducts located
in the mechanical space should be insulated for
sound control, both to minimize sound radiation
out of these ducts and also to control sound
radiation into the ducts.
AERODYNAMIC (VELOCITY) NOISE
When sound attenuation is a design concern,
the primary consideration is velocity noise at
the unit’s Fresh Air blower outlet.The average
velocity at the blower outlets is 1235 FPM
when the unit is operating at 970 CFM.
SOUND ATTENUATION
To avoid motor bearing damage
and noisy and/or unbalanced
blowers, keep drywall spray,
construction dust, etc., out of unit.
CAUTION

ERVTRC800 & TRC800V
91.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
INSTALLATIONINSTALLATION
SIngle phase ECM motors are NOT suitable for use
with solid state speed control. They already have
speed control built into the motor electronics.
Moteurs d’une phase de l’ECM ne conviennent pas pour
une utilisation avec regulateur de vitesse electronique.
Ils ont déjà le contrôle de vitesse intégré dans le moteur
électronique.
ELECTRICAL SPECIFICATIONS
Use conduit, strain reliefs, etc. as required by
code to secure the field wiring. Electrical knockouts
are provided for alternate line voltage and voltage
control locations for field wiring to the internal
electrical box. If the alternate sites are desired for
field wiring then carefully remove the knockout
plugs and foam insulating plugs from the alter-
nate sites and install them in the open knockout
locations.
NOTE: If your unit is equipped with EC Motors,
please refer to “EC Motor Manual Supplement” for
more detail.
WARNING
Secure the TRC800 or TRC800V with straps or
clamps so that it cannot fall or tip in the event of
accident, structural failure or earthquake.
WARNING
The TRC800 weighs 210 lbs. and the TRC800V
weighs 207 lbs. It is the installer’s responsibility to
make sure that the screws or bolts used for securing
the units are properly selected for the loads and
substrates involved.
CAUTION
INSTALLATION INSTRUCTIONS

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.737010
CHANGESNAMEREV. DATE
S&P
1
A B C D E
New1 8/3/2018 austine
110189_001
2 3 4 5 6 7 8 9
10 11 12 13
TRC-800
115 VAC
208 VAC
M
Supply Fan Exhaust Fan
Input Power
115 VAC, 1 Phase
208-230 VAC, 1 Phase
Transformer COM 24V
Relay
24 VAC
13 14
8
12
4
Contactor
24 VAC
A1 A2
1L1
3L2
2T1
4T2
YL
RD
YL
BU
OR
RD BU RD
BK
RD
BK
BK BK
TRC800 & TRC800V SINGLE PHASE
INSTALLATION
NOTE: Schematics shown are representative of standard units. See Unit Schematic label for detailed information.

ERVTRC800 & TRC800V
111.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
INSTALLATION
INSTALLATION INSTRUCTIONSLOW VOLTAGE CONTROL SYSTEM
This ERV is provided with a Class II 24VAC power
supply system that operates the unit’s contactor(s)
for TRC800 & TRC800V. The ERV’s 24VAC Power
Supply can also be used to power the external-
ly-installed controls system: up to 8VA of power is
available.
The unit’s power supply system includes isolation
relay(s) so you can use external controls whose
contact ratings are as low as 50mA (1.2VA). Also,
it is possible to operate the isolation relays with
24VAC power from an external source (with proper
wiring connections).
A built-in circuit-breaker prevents damage to the
transformer and other low-voltage components in
the event of a short-circuit or overload. In extreme
cases, the transformer itself is designed to fail safely.
SPECIFICATIONS
•Nominal Output Voltage under load: 24VAC
•Typical Output Voltage at no load: 29-31V
•Minimum contact rating for connected control
device: (50mA (1.2VA)
•Circuit Breaker Trip Point: 3A
1. Connect only to components intended for use with 24VAC power.
2. Do not undersize the low-voltage wires connected to this device. Observe the wire length and gauge
limits indicated in this manual.
3. Do not overload this unit’s 24VAC power supply system. Confirm that the power requirements of devices
you connect to this power supply system do not exceed 8VA in total.
4. If an external source of 24VAC power is used to control the unit, consult the wiring schematics and
connect the external power only to the specified terminals in order to avoid damaging the unit or external
controls. Connect only CLASS II power to the control terminals of this unit.
5. Unit is not equipped to receive analog signals (such as 1-10vdc or 4-20mA).
6. Unit is not equipped to communicate directly with Building Management Systems (such as BACNET,
LONWORKS, etc.). However, the unit can be controlled by powered or non-powered contacts operated by
any kind of control system.
CAUTION
HOW TO RESET THE 24VAC CIRCUIT BREAKER
If the transformer is subjected to an excessive load or a short circuit, the circuit breaker will trip to prevent
the failure of the transformer. When it trips the circuit breaker’s button pops up. Shut off the primary-side
power to the unit, and remove the excessive load or the short. The circuit breaker can be reset about
fifteen seconds after it trips by pressing in the button.
LIMITS OF POWER OUTPUT
If limits on wire gauge and length are observed, you may connect control devices that draw up to 8VA to
the blue and red wires. More than one device can be connected as long as total steady-state load does
not exceed 8VA.
OBSERVE THESE LIMITS TO WIRE LENGTH AND GAUGE
in order to ensure reliable operation of the control system.
Wire Gauge #22 #20 #18 #16 #14 #12
Circuit Length 100’ 150’ 250’ 400’ 700’ 1000’
“Circuit Length” is distance from ERV to Control Device.
If primary-side voltage is 230VAC,
move black primary-side lead from
transformer’s “208V” terminal to
the transformer’s terminal marked
“240V” (“230V” in some units).
Do not move the black primary-
side lead that is connected to the
transformer’s “COM” terminal.
INSTALLATION NOTES

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.737012
INSTALLATION
Connect Blue & First Yellow Leads
Connect Control's N.O. Output to 2nd Yellow Lead
External Control is
powered by 24VAC
available between the Red
and Blue leads.
8VA Maximum Load.
Unit 24VAC
Power Supply
C
UNIT INTERNAL CONTROL WIRING
(SIMPLIFIED)
AN EXTERNAL CONTROL DEVICE USING
UNIT'S 24VAC POWER SUPPLY
Isolation
Relay Coil
MPU
Image 2 from filename Control Connections EV450-HE1XIN_DEC14
KMC 12/11/14
BLUE
YEL
YEL
RED
NOTE: The simplified schematics below show
only the relevant portions of the low-voltage
control circuit in the ERV unit and representational
external control approaches. See the complete
unit schematics elsewhere in this manual.
CONTROL WIRING EXAMPLES BY TYPE OF APPLICATION
A. Single 2-wire Control: Use this schematic if the control requires no power to operate and acts like
a simple on/off switch. The control must not supply any power to the ERV unit. Connect the blue lead
to one yellow lead. Connect the control’s contacts to the red lead and the remaining yellow lead.
Control on separate Power Supply, no power present at Control Output:
Wire as shown for the Single 2-wire control.
C. Control operating on Unit’s 24VAC Power Supply: 24VAC power is available at the blue and red
leads. Connect one of the yellow leads to the blue lead. Connect the switched output of the Control
to the red lead to operate the ERV’s isolation relay.
B. Control Sending 24VAC “On” Signal (from an external power source) to ERV: Make sure the blue
and red leads are separately capped and not connected to any other wires. Now you safely can apply
24VAC to the two yellow leads to operate the ERV’s isolation relay.
Be careful if the external control system provides
24VAC power at its control output: make sure
blue and red leads are separately capped and not
connected to any other wires.
CAUTION
Unit 24VAC
Power Supply
Cap Blue and Red Leads when using
24VAC from external source.
C
UNIT INTERNAL CONTROL WIRING
(SIMPLIFIED)
24VAC FROM AN EXTERNAL SOURCE
Isolation
Relay Coil
Image 3 from filename Control Connections EV450-HE1XIN_DEC14
KMC 12/11/14
RED
YEL
YEL
BLUE
Unit 24VAC
Power Supply
Connect Blue & First Yellow Leads
Connect Switch between Red &
Second Yellow Leads
UNIT INTERNAL CONTROL WIRING
CIsolation
Relay Coil
(SIMPLIFIED)
A SWITCH OR NON-POWERED
CONTROL USING UNIT'S 24VAC POWER
SUPPLY
Image 1 from filename Control Connections EV450-HE1XIN_DEC14
KMC 12/11/14
BLUE
YEL
YEL
RED
AA SWITCH OR NON-POWERED CONTROL
USING UNIT’S 24VAC POWER SUPPLY
B24VAC FROM AN EXTERNAL SOURCE
CAN EXTERNAL CONTROL DEVICE USING
UNITS 24 VAC POWER SUPPLY
CONTROL WIRING SCHEMATICS
Make sure the control provides
no voltage or current at its output
terminals.
CAUTION
Supply only 24VAC (not VDC) from
a Class II Power Source.
CAUTION
External control system should
not draw more than 8VA.
CAUTION

ERVTRC800 & TRC800V
131.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
MEASURING AIR FLOW
START-UP
EQUIPMENT REQUIRED
•A magnehelic gauge or other device capable of
measuring 0 to 1.5 in. water of differential pressure.
•2 pieces of natural rubber latex tubing, 1/8” ID,
1/16” Wall works the best.
NOTE: Be sure to remove cap from pressure port
before inserting tubing. Insure tubing is well seated
in pressure ports.
NOTE: The tubing should extend in the pressure
port approx. 1 inch.
DIFFERENTIAL STATIC ACROSS CORE DSP VS. CFM
TRC800V
DSP 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10
Fresh Air (FA) CFM 280 380 470 570 670 770 860 960 1060 1160
Room Air (RA) CFM 220 320 430 530 630 730 840 940 1040 1140
TRC800
DSP 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10
Fresh Air (FA) CFM 260 360 470 570 670 770 870 970 1070 1180
Room Air (RA) CFM 240 340 440 540 640 740 840 940 1040 1140
RA
OA
EA
FA
Pressure Ports (4)
FA
RA
EA
OA
Pressure Ports (4)
RA
OA
EA
FA
Pressure Ports (4)
FA
RA
EA
OA
Pressure Ports (4)
AIRFLOW DIAGRAM TRC800VAIRFLOW DIAGRAM TRC800
The individual differential static pressures (DSP)
can be measured using the installed pressure ports
located in the front of the units core access doors.
NOTE: These ports have been carefully located on
the unit as to give you the most accurate airflow
measurement. Do not relocate pressure ports.
•To read SCFM of Fresh Air (FA) install the “high”
pressure side (+) of your measuring device to the
Outside Air (OA) port and the “low” pressure side
(-) to the Fresh Air (FA) port.
•To read SCFM of Room Air (RA) install the “high”
pressure side (+) of your measuring device to the
Room Air (RA) port and the “low” pressure side
(-) to the Exhaust Air (EA) port.
•Use the reading displayed on your measurement
device to cross reference the CFM output using
the conversion chart.
NOTE: Be sure to replace cap into pressure port
when air flow measuring is completed.
CROSS CORE STATIC PRESSURE MEASUREMENT INSTRUCTIONS

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.737014
START UP
MEASURING AIR FLOW FILTER SPECIFICATIONS
• (2) 20” x 20” x 2”(nominal) pleated filters. Actual size: 19.5” x 19.5” x 1.75”
• Unit shipped with MERV-8 Filters. Minimum recommended effectiveness: MERV-6
INITIAL PRESSURE DROP OF
MERV 8 FILTERS - SUPPLIED WITH THIS UNIT
Pleated_Filter_PD_APR16 20x20x2 MERV 8 (IOM)
0.0
0.1
0.2
0.3
0.4
250 500 750 1000
Clean-filter Pressure Drop (in.w.g.)
Unit Airflow (CFM)
Initial Pressure Drop of MERV 8 Filters
supplied with this unit
NOTE: clean filter pressure drop is included in unit airflow performance tables.

ERVTRC800 & TRC800V
151.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
NOTES

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.737016
NOTES

ERVTRC800 & TRC800V
171.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
www.renewaire.com (800) 627- 4499 [email protected]
TRC800 Horizontal Unit SERVICE PARTS
MAINTENANCE

ERV TRC800 & TRC800V
WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1.800.961.737018
MAINTENANCE
SERVICE PARTS
www.renewaire.com (800) 627- 4499 [email protected]
TRC800V Vertical Unit

ERVTRC800 & TRC800V
191.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM
Keep your ERV performing at its best by cleaning it as described below:
TO CLEAN THE ENERGY EXCHANGE ELEMENT
Vacuum the face of the energy exchange element yearly. Dust collects only on the entering face of the energy
exchange element, right where the filter sits. The interior of the energy exchange element stays clean even if
the element faces are dust covered.
1. Remove the filters (see below)
2. Vacuum the exposed faces of the energy exchange element with a soft brush attachment
3. Vacuum out dust from the rest of the unit case
4. Install new filters
INSPECT AND CHANGE THE FILTERS REGULARLY.
Inspect and/or replace filters every two or three months when the TRC800/V is in regular use, or as
needed. Filters must be used or the energy exchange core will become blocked by dust and the unit will not do
its job. In extreme cases components may be damaged.
1. To access the filters unlatch the filter access door. The filter access door may be removed.
2. Remove filter keeper.
3. Pull the dirty filters out and replace with new filters.
4. Reinstall the filter keeper.
NOTE: The filters supplied in the unit are usually able to keep the energy exchange core clear for several
months. Finer filters can be used but must be cleaned more often. If using finer filters, their increased
resistance to flow must be allowed for in the system design.
MOTOR MAINTENANCE
The motor needs no lubrication. If necessary vacuum clean the blower wheels at the same time you
clean the face of the energy exchange element (annually).
Don’t allow the filter access door
to drop when unlatched. Injury
to personnel or damage to unit
may occur.
Keep fingers away from
between the filter access door
and the blower access panel
when unlatching and opening
the filter access door. Potential
PINCH POINT.
DO NOT WASH THE ENERGY
EXCHANGE CORE.
Keep it away from water or fire to
avoid damaging it. Always handle
the core carefully.
CAUTION
WARNING
RISK OF INJURY OR DAMAGE.
Motor may have a manual reset thermal protector. Disconnect power before servicing or resetting motor thermal
protector. Use caution, motor may be hot. Allow the motor to cool before resetting the thermal protector.
If the motor thermal protector tripped, correct the issue that caused the motor to overheat (e.g. over motor rated
amperage or locked rotor).
If the motor has a manual reset thermal protector, the red thermal protector reset button is located on the motor body,
on or near the lead end of the motor. If the button does not reset, the motor may still be too hot. Allow the motor to fully
cool to reset the thermal protector, you should feel or hear a click when the thermal protector resets while pushing
the reset button.
Danger of Electrical Shock when servicing an installed unit.
ALWAYS DISCONNECT POWER SOURCE BEFORE SERVICING! More than one disconnect switch may be required.
Proper Wiring Size Selection and Wiring Installation are the Responsibility of the Electrical Contractor.
WARNING REQUIREMENTS
WARNING
MAINTENANCE

ERV
INSTALLATION, OPERATION & MAINTENANCE MANUAL
ENERGY RECOVERY VENTILATOR
132103_003 (10/18)
USA
[phone]
FAX: [phone]
6393 POWERS AVE
JACKSONVILLE, FLORIDA
32217 USA
WWW.SOLERPALAU-USA.COM
CANADA
[phone]
FAX: [phone]
5600 AMBLER DRIVE
MISSISSAUGA, ON L4W 2K9 - CANADA
WWW.SOLERPALAUCANADA.COM
