SOLTEK SL-75ERV User manual

R
The Soul Of Computer Technology
Mainboard
SL-75ERV User Manual V1.1

Product Model : SL-75ERV
Manual Revision : V1.1
Release Date : Januar 2002
• AMD Athlon ThunderbirdTM, DuronTM, and AthlonTM XP processors are trademarks of AMD
Corporation.
• V A, KT-266A, VT8366A and VT8233A are trademarks of V A Corporation.
T
his Users Guide & Technical Reference is to help system
manufacturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer nc. is not responsible for printing or
clerical errors. nformation in this document is subject to change
without notice and does not represent a commitment on the part of
Soltek Computer nc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer nc.
Companies and products mentioned in this manual are for identification
purpose only. Product names appearing in this manual may or may
not be registered trademarks or copyrights of their respective
companies.
Soltek Computer nc. provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. n no event shall Soltek Computer nc. be liable
for any loss or profits, loss of business, loss of use or data, interruption
of business, or for indirect, special, incidental, or consequential
damages of any kind, even if Soltek Computer nc. has been
advised of the possibility of such damages arising from any defect
or error in this manual or product.
Copyright © 2002 Soltek Computer Inc. All Rights Reserved.
NOTIC

SOLTEK AROUND THE WORLD
SOLT K COMPUT R INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL T CHNOLOGY UROP B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-
erlands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soultech-europe.com
SOLT K KOR A INC.
Address : 1002, Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]

75ERV
4
CONTENT
Chaper 1 Introduction ............................................................. 8
1-1 Mainboard Specification ............................................................ 9
1-1.1 Processor .......................................................................................... 9
1-1.2 Chipset .............................................................................................. 9
1-1.3 AWARD B OS V6.0 Supporting ......................................................... 9
1-1.4 Sound Controller ............................................................................... 9
1-1.5 Power Management .......................................................................... 9
1-1.6 Full Featured Accelerated Graphics Ports (AGP) Controller ........... 10
1-1.7 Multi- /O Function ............................................................................ 10
1-1.8 Expansion Slots .............................................................................. 10
1-1.9 Advanced High Performance SDR/DDR DRAM Controller ............. 10
1-1.10 Form Factor ................................................................................... 11
1-1.11 Hareware Monitoring ..................................................................... 11
1-2 Mainboard Layout .................................................................... 12
1-3 Chipset Diagram ...................................................................... 13
Chaper 2 Hardware Setup .................................................... 15
2-1 CPU nstallation ....................................................................... 16
2-2 Memory nstallation.................................................................. 17
2-3 HDD/FDD nstallation .............................................................. 19
2-4 Switch Setting For CPU Frequency And Voltage ..................... 21
2-4.1 nformation On AMD Socket 462 Processor (Model 4, 5 Products) ........ 21
2-4.2 nformation On AMD Socket 462 Processor (Model 6, 7 Products) ........ 22
2-4.3 Processor Core Voltage Select (By SW1 D P1-D P6) ..................... 23
2-4.4 CPU External Frequency Setting (By SW2) .................................... 24
2-5 Jumper Settings ....................................................................... 25
2-5.1 JP1 Power Lost Resume ................................................................. 26

5
Content
2-5.2 JBAT1 For Clear CMOS Data ......................................................... 26
2-6 Connectors Configurations ...................................................... 27
2-6.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) .................. 27
2-6.2 WOL1 Wake On LAN ...................................................................... 28
2-6.3 CD-ROM Audio Connector (JCD_ N1) ............................................ 28
2-6.4 Complex Header CON1 .................................................................. 29
2-6.5 ATX Power Supply Connector ......................................................... 30
2-6.6 Chassis Panel Connector ................................................................ 31
2-6.7 Communication And Networking Riser Slot (CNR) ......................... 32
2-6.8 USB Ports and USB Headers (Header USB 3) ............................... 33
2-6.9 PS/2 Mouse And PS/2 Keyboard .................................................... 33
Chaper 3 Software Setup...................................................... 35
3-1 Open up the Suport CD and choose Drivers and Utilities........ 36
3-2 Proceed to V A 4- n-1 Drivers nstallation ............................... 37
3-3 Proceed to AC’97 Audio Driver nstallation .............................. 39
3-4 Proceed to Hardware Monitor nstallation................................ 40
Chaper 4 BIOS Setup ............................................................ 43
4-1 What s B OS Setup ................................................................. 44
4-2 How To Run B OS Setup ......................................................... 44
4-3 What s CMOS ......................................................................... 44
4-4 What s POST .......................................................................... 44
4-5 B OS Upgrade ......................................................................... 45
4-5.1 Before Upgrading B OS .................................................................. 45
4-5.2 Upgrade Process ............................................................................ 45
4-6 B OS Setup --- CMOS Setup Utility ......................................... 49
4-6.1 CMOS Setup Utility ......................................................................... 49
4-6.2 Standard CMOS Setup ................................................................... 50
4-6.3 Advanced B OS Features ................................................................ 53

75ERV
6
4-6.4 Advanced Chipset Features ............................................................ 57
4-6.5 ntegrated Peripherals ..................................................................... 62
4-6.6 Power Management Setup .............................................................. 68
4-6.7 PNP / PC Configuration ................................................................. 74
4-6.8 SmartDOC Anti-Burn Shield ............................................................ 77
4-6.9 Frequency/Voltage Control .............................................................. 79
4-6.10 Load Optimized Defaults ............................................................... 81
4-6.11 Set Supervisor / User Password ................................................... 81
4-6.12 Save & Exit Setup ......................................................................... 82
4-6.13 Exit Without Saving ....................................................................... 82
Appendices ............................................................................ 84
Appendix-1 dentify B OS Version & B OS Part Number .............. 85
Appendix-2 dentifying Mainboard model Number ........................ 86
Appendix-3 Technical Terms .......................................................... 87

7
Content
Mainboard
====Support CD
====User’s Manual
====Bundled Bonus Pack CD
====Bundled Bonus Pack Manual
====Temperature Sensor Cable (Optional)
====ATA66/100/133 DE Cable
====RS232 Cable
FDD Cable
IT M LIST CH CKUP

75ERV
8
This chapter contains the following topics :
1-1 Mainboard Specification
1-2 Mainboard Layout
1-3 Chipset Diagram
• This chapter briefly introduces the characteristics of the mainboards. t includes
the information regarding the chipset, CPU types, built-in functions and layout.
Users will have more ideas about mainboards after reading this chapter.
Chaper 1 Introduction

Chapter 1 Introduction
9
1-1 Mainboard Specification
1-1.1 Processor
• Supporting AMD Athlon™ Thunderbird processor up to 1.5GHz or above.
• Supporting AMD Duron™ processor up to 1.2GHz or above.
• Supporting 200MHz & 266MHz FSB bus.
• Supporting Processor V D(voltage D) and F D(Frequency D) auto
detection.
• Supporting Atholon™ XP Processors.
1-1.2 Chipset
• V A VT8366A DDR V-Link Host North Bridge.
• V A VT8233A V-Link Client South Bridge.
• TE 8705 LPC /O.
1-1.3 AWARD BIOS V6.0 Supporting
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• B OS writing protection.
• SmartDOC Anti-Burn shield.
1-1.4 Sound Controller
• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio
Controller with Codec onboard.
1-1.5 Power Management
• ACP 1.0 compliant (Advanced Configuration and Power nterface).
• APM V1.2 compliant (legacy power management).
• Supporting ACP suspend STR mode (Suspend To RAM) and POS mode
(Power On Suspend).
• System event monitoring with two event classes.
• Supporting PS/2 Keyboard & Mouse power on.
• Supporting Wake On LAN (WOL) & Wake On Ring.
• Supporting Real Time Clock (RTC) with date alarm, month alarm, and
century field.
• USB boot-up Function.

75ERV
10
1-1.6 Full Featured Accelerated Graphics Ports (AGP)
Controller
• AGP v2.0 compliant.
• Supports Side Band Addressing(SBA) mode (non-multiplexed address /
data).
• Supporting 66MHz 1x, 2x, and 4x modes for AD and SBA signaling.
1-1.7 Multi-I/O Function
• Two UltraDMA-33/66/100/133 Master Mode PC E DE ports.
• Two UARTs for complete Serial Ports.
• One dedicated R connector:
--At third serial port dedicated to R function either through the two complete serial
ports or the third dedicated port nfrared- rDA (HPS R) and ASK( Amplitude Shift
Keyed) R.
• Multi-mode parallel connector supporting:
--Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
--One FDD with drive swap function.
• Universal Serial Bus connector supporting:
-- USB v1.1 and ntel Universal HC v1.1 compatible.
-- 2 built-in USB connectors, in addition to one internal USB header which requires
a USB cable to support 2 more optional USB ports.
• PS/2 keyboard connector.
• PS/2 Mouse connector.
1-1.8 xpansion Slots
• Six PC bus Master slots.
• One CNR slot.
• One AGP 4x mode slot.
• Three 184-pin D MM slots.
1-1.9 Advanced High Performance SDR/DDR DRAM Controller
• Supporting memory size up to 3GB.
• Supporting 184-pin DDR SDRAM type only.
• Supporting PC1600 and PC2100 DDR SDRAM.

Chapter 1 Introduction
11
1-1.10 Form Factor
• ATX form factor, 4- layer PCB.
• Mainboard size 22.0cm x 30.5cm.
1-1.11 Hareware Monitoring
• Programmable control, status to provide, monitoring and alarm for flexible
desktop management (software include).
• 5 positive voltage statuses monitoring.
• 2 temperatures statuses monitoring.
• 2 Fan-speeds statuses monitoring.

75ERV
12
1-2 Mainboard Layout
Using non-compliant memory with higher bus clock (over clocking) may
severely compromise the integrity of system.
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233A
SW2 SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1
ON DIP
1 2 3 4 5 6

Chapter 1 Introduction
13
1-3 Chipset Diagram
• The VT8366A and VT8233A chipset is a high performance, cost-effective
and energy efficient system controller for the implementation of AGP /
PC / SA desktop personal computer system based on 64-bit Socket-A
(AMD Athlon) processors.
Diagram of Apollo Pro266A System Block Using the VT8233A V-Link
South Bridge
DDR Vlink
Host North
552 BGA
VT8233A
Vlink
Client South
352 BGA
3D
Graphics
Controller
Athlon
Host CPU
SDR/VCM
& DDR
SDRAM
Clock
Buffer
Clock
Generator
SDR/DDR Memory Bus
AGP Bus
SYSCLK, SYSCLK#
INTR, NMI, SM#, STPCLK#,
IGNNE#, FERR#, A20M#,
PWROK, INIT#, RESET#
GCLK
PCLK
PCKRUN#
ATA33/66/100/133
MII/LAN
6x USB
LPC
SMBus
Power Plan & Peripheral Control
GPIO and ACPI Events
PCI Bus
CKE#
MCLK
HCLK
PCLK
CPUSTP#
PCISTP#
SUSCLK,
SUSST1#
GCKRUN#
Address
Out
CFWDRST
CONNECT
PROCRDY
In
Data
VT8366A

14
75ERV
MEMO
MEM
O

15
Chapter 2 Hardware Setup
2-1 CPU Installation
2-2 Memory Installation
2-3 HDD/FDD Installation
2-4 Switch Setting For CPU Frequency And Voltage
2-5 Jumper Settings
2-6 Connectors Configuration
This chapter contains the following topics :
ATT NTION !!!
1. Please refer to your processor installation or other
documentation attached to your CPU for detailed in-
stalling instruction.
2. Installing a heat sink and cooling fan is necessary
for proper heat dissipation from your CPU. Incorrect
installation may result in overheating and damage
of your CPU.
3. Before changing the setting of CPU Vcore from BIOS
program, user SHOULD make sure of correct speci-
fication both of CPU CLOCK and RATIO. Incorrect
setting may cause damage to your CPU.
Chaper 2 Hardware Setup

16
75ERV
WARNING !!!
• Make sure that +5V DCV and +3.3 DCV capabilities of your power supply
are suitable for the processor.
• Any attempt to operate the AMD Athlon or Duron processor without a
suitable coolin Fan will dama e processor and other component.
2-1 CPU Installation
SOCKT 462
SOCKT 462
AMD
Take notice of the red circles
as shown below. While inserting
the CPU into the socket, you
can find out there is a definite
pin orientation for CPU and
socket.
2
Pull out the lever from the
socket, and then raise the
lever up to a 90-degree angle.
1
AMD
SOCKT 462
Make sure that the CPU is
placed into the socket tightly.
Then lower down the level to
complete the CPU installation.
3

17
Chapter 2 Hardware Setup
Installing DIMM
• Make sure you have the correct memory module type for your mainboard.
• Insert the module(s) as shown below, DIMMs have 1 4-pins and one
notch that will be matched by the onboard DIMM socket. Memory modules
are installed by inserting them straight into the slot until they “click” in the
right place. They only fit in one direction, so do not force them in by a
wrong direction.
184-Pin DIMM Notch Key Definitions(2.5V)
DR M Key Position Voltage Key Position
2.5V
2-2 Memory Installation
Removing DIMM
• Press down the holding clips on both sides of a DIMM socket and the
module will be released from it.
WARNING!!!
• Make sure to unplug your power supply before adding or removing memory
modules or other system omponents. Failure to do so may ause severe
damage to both your mainboard and expansion ards.
• Be areful when inserting or removing DIMM. For ing a DIMM in or out
of a so ket improperly may damage the memory module or the so ket.
Some DIMMs whi h ontain EDO or FTP DRAM are in ompliant with
the mainboard. The M/B supports 2.5V DDR SDRAM DIMMs only.

18
75ERV
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233A
SW2 SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1
ON DIP
1 2 3 4 5 6
NOTICE: When LED “ZD1”
is on, meanin that 2.5V is
operatin and flowin into
DIMM slots, please do not
add or remove memory
modules .

19
Chapter 2 Hardware Setup
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233A
SW2 SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1
ON DIP
1 2 3 4 5 6
• To install HDD (Hard Disk Drive), you may connect the cable’s blue con-
nector to the mainboard’s primary ( DE1) or secondary ( DE2) connector,
and then connect the gray connector to your slave device and the black
connector to your master device. f you install two hard disks, you must
configure the second drive to Slave mode by setting its jumper accordingly.
Please refer to your hard disk documentation for the jumper settings.
Hard Disk Drive Connector:
Orient the red line on the DE
ribbon cable to Pin1.
2-3 HDD/FDD Installation
Gray connector
Blue connector
ID Cable
Black connector
red line

20
75ERV
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233A
SW2 SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1
ON DIP
1 2 3 4 5 6
• To install FDD (Floppy Disk Drive), you may connect the single end to the
board , and connect two plugs on the other end to the floppy drives.
Floppy Disk Drive Connector:
Orient the red line on the
floppy ribbon cable to Pin1.
FDD Cable
To 1st Floppy Drive
To mainboard
To 2nd Floppy Drive
red line
